B072JT89JC
Aluminum Medium Duty Press Board Double Post Shelf
Estante De Poste Doble De Aluminio De Resistencia Media De Madera Comprimida
Étagères Moyennes En Aluminium Dotées De Montants Doubles Et De Panneaux Comprimés
B072JT89JC-AmazonBasics-IM-V01 (US).indb 1 8/28/17 5:46 PM

English ..................................... 3
Español.................................. 14
Français ................................. 25
B072JT89JC-AmazonBasics-IM-V01 (US).indb 2 8/28/17 5:46 PM

3
Welcome Guide •English
Aluminum Medium Duty Press
Board Double Post Shelf
Contents:
Before getting started, ensure the package contains the following components:
Part Qty
Beam 10
Brace 10
Bottom post 4
Top post 4
Press board 5
Bottom protective cover 4
Top protective cover 4
B072JT89JC-AmazonBasics-IM-V01 (US).indb 3 8/28/17 5:46 PM

4
Assembly
Step 1:
Setting Up the Product
• Insert all 4 bottom protective covers to bottom posts , insert all 4 top protective covers
to top posts .
• Note: Do not omit this step, which could protect your floor from scratches.
B072JT89JC-AmazonBasics-IM-V01 (US).indb 4 8/28/17 5:46 PM

5
Assembly
Step 2:
Setting Up the Product
• Slide the rivets of brace into bottom posts of your desired location with the key slot
pointing down and shelf ledge of brace facing up. Tap lightly to seat rivets.
• Note: Make sure all the rivets are fully seated into the post slots. You may want to use a rubber
mallet (not included) to help push the rivets into the post slots. This applies to all the rivets used
in this unit.
B072JT89JC-AmazonBasics-IM-V01 (US).indb 5 8/28/17 5:46 PM

6
Assembly
Step 3:
Setting Up the Product
• Repeat the previous step 2 to attach beams and brace to bottom posts until the first
level is assembled.
• Note: Each of the beams and braces on the same level should be at the same height.
B072JT89JC-AmazonBasics-IM-V01 (US).indb 6 8/28/17 5:46 PM

7
Assembly
Step 4:
Setting Up the Product
• Repeat the previous two steps to attach beams and braces to posts until the first two
levels are assembled.
B072JT89JC-AmazonBasics-IM-V01 (US).indb 7 8/28/17 5:46 PM

8
Assembly
Step 5:
Setting Up the Product
• Top posts , bottom posts , beams , braces should be connected as illustrated.
B072JT89JC-AmazonBasics-IM-V01 (US).indb 8 8/28/17 5:46 PM

9
Assembly
Step 6:
Setting Up the Product
• Repeat step 2 & 3 to form the fourth to fifth levels.
B072JT89JC-AmazonBasics-IM-V01 (US).indb 9 8/28/17 5:46 PM

10
Assembly
Step 7:
Setting Up the Product
• Hold the press board at an angle to make it easier to fit them onto each previously
assembled level on the frame.
B072JT89JC-AmazonBasics-IM-V01 (US).indb 10 8/28/17 5:46 PM

11
Safety and Compliance
Please read and understand this entire manual before using the product.
CAUTION
• Do not exceed 800 lbs per shelf, total max load weight do not exceed 3500 lbs. Be aware
of dynamic loading! Sudden load movement may briefly create excess load causing product
failure.
• Evenly distribute the weight on each shelf, and keep the heaviest loads on the bottom shelf.
• Use only on flat, level and hard surface capable of supporting the shelving and any items placed
on it. Remember to only use the shelf on level ground with evenly distributed weight.
• Do not store flammable liquids in the unit unless they are secured in an approved container.
• Keep bystanders out of the area during assembly.
• This product is not a toy. Do not allow children to play with, on or near the unit.
WARNING
• Do not stand on, step on, or alter this unit for anything outside the designed function of storage.
• Use care when handling and assembling metal parts.
• The metal may have sharp edges or corners. The use of protective gloves is recommended.
• Always remember to use proper lifting techniques when moving the boxed or assembled unit.
Preparation
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list. If any part is missing or damaged, do not attempt to assemble the product.
It is recommended that this product be assembled on a clean, soft surface, such as a piece of
cardboard. The assembling task can be performed by one person but availability of a second
person will make the task simpler.
Tools Required for Assembly (not included): Rubber mallet.
B072JT89JC-AmazonBasics-IM-V01 (US).indb 11 8/28/17 5:46 PM

12
Troubleshooting
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Shelf is not level.
• Beam(s) or brace(s) used for the same
level are not at the same height or they
are assembled upside down.
• Re-assemble beam(s) or
brace(s).
• Rivets on the beam(s) or brace(s) are
not fully seated into the post slots.
• Fully seat the rivets.
• The ground is uneven or too soft. • Move the shelf to a flat,
level and hard surface.
Specications
Measurements (W x D x H) US Standard Metric
Shelving unit 48 x 18 x 72 in. approx. 122 x 45.7 x 182.8 cm
Warranty Information
To obtain a copy of the warranty for this product:
Visit amazon.com/AmazonBasics/Warranty
— or —
Contact Customer Service at 1-866-216-1072
B072JT89JC-AmazonBasics-IM-V01 (US).indb 12 8/28/17 5:46 PM

13
Feedback
Love it? Hate it?
Let us know with a customer review.
AmazonBasics is committed to delivering customer-driven products that live up to your high
standards. We encourage you to write a review sharing your experiences with the product.
Please visit: amazon.com/review/review-your-purchases#
For further services:
Visit amazon.com/gp/help/customer/contact-us
— or —
Contact Customer Service at 1-866-216-1072
B072JT89JC-AmazonBasics-IM-V01 (US).indb 13 8/28/17 5:46 PM

14
Guía De Bienvenida •Español
Estante De Poste Doble De Aluminio
De Resistencia Media De Madera
Comprimida
Contenido:
Antes de comenzar, asegúrese de que la caja contenga los siguientes componentes
Pieza Cantidad
Barra 10
Abrazadera 10
Poste inferior 4
Poste superior 4
Madera comprimida 5
Cubierta protectora inferior 4
Cubierta protectora
superior 4
B072JT89JC-AmazonBasics-IM-V01 (US).indb 14 8/28/17 5:46 PM

15
Armado
Paso 1:
Montaje Del Producto
• Inserte las 4 cubiertas protectoras inferiores en los postes inferiores , inserte las 4
cubiertas protectoras superiores en los postes superiores .
• Nota: No omita este paso, la cual podría proteger su piso contra rayas.
B072JT89JC-AmazonBasics-IM-V01 (US).indb 15 8/28/17 5:46 PM

16
Armado
Paso 2:
Montaje Del Producto
• Deslice los remaches de la abrazadera dentro de los postes inferiores de su ubicación
deseada con la ranura de llave apuntando hacia abajo y la saliente de la abrazadera del
estante mirando hacia arriba. Golpee ligeramente para asentar los remaches.
• Nota: Asegúrese de que todos los remaches estén totalmente asentados dentro de las ranuras
de los postes. Puede recurrir a un mazo de goma (no incluido) para lograr este objetivo. Esto
es válido para todos los remaches usados en esta unidad.
B072JT89JC-AmazonBasics-IM-V01 (US).indb 16 8/28/17 5:46 PM

17
Armado
Paso 3:
Montaje Del Producto
• Repita el paso 2 anterior para sujetar las barras y la abrazadera a los postes inferiores
hasta que el primer nivel esté armado.
• Nota: Cada una de las barras y abrazaderas en el mismo nivel deberán estar a la misma
altura.
B072JT89JC-AmazonBasics-IM-V01 (US).indb 17 8/28/17 5:46 PM

18
Armado
Paso 4:
Montaje Del Producto
• Repita los dos pasos anteriores para sujetar las barras y abrazaderas a los postes
hasta que los primeros dos niveles estén armados.
B072JT89JC-AmazonBasics-IM-V01 (US).indb 18 8/28/17 5:46 PM

19
Armado
Paso 5:
Montaje Del Producto
• Los postes superiores , postes inferiores , las barras , las abrazaderas deberán estar
conectados como se ilustra.
B072JT89JC-AmazonBasics-IM-V01 (US).indb 19 8/28/17 5:46 PM

20
Armado
Paso 6:
Montaje Del Producto
• Repita los pasos 2 y 3 para formar el cuarto y quinto nivel.
