Ambia ACH-120 User manual

IMPORTANT SAFEGUARDS
READ AND SAVE THESE SAFETY INSTRUCTIONS
BEFORE USING THIS HEATER.
ACH-120 OWNER’S MANUAL
Home Comfort Products

3
TABLE OF CONTENTS
1. Important Instructions.........................................................4
2. Operating Instructions.........................................................6
3. Controling Your Heater .......................................................7
4. Troubleshooting ...................................................................8
5. Warranty...............................................................................9
6. Cleaning and Maintenance ...............................................10

4 5
9.This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of shock, this plug is intended to fit only one way in a po-
larized outlet. If the plug does not fit fully in the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician. DO NOT attempt to
defeat this safety feature.
10. This heater draws 12.5 amps during operation. To prevent overloading
a circuit, do not plug the heater into a circuit that already has other
appliances working.
11. It is normal for the plug to feel warm to the touch; however, a loose fit
between the AC outlet (receptacle) and plug may cause overheating and
distortion of the plug. Contact a qualified electrician to replace loose or
worn outlet.
12. To disconnect the heater, first set controls to the OFF position, then grip
the plug and pull it from the wall outlet. Never pull by the cord.
13. Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the heater.
14. To prevent a possible fire, do not block air intakes or exhaust in any
manner. Do not use on soft surfaces, like a bed, where openings may
become blocked.
15. A heater has hot and arcing or sparking parts inside. Do not use it in the
areas where gasoline, paint, or flammable liquids are used or stored.
16. Use this heater only as described in this manual. Any other use not rec-
ommended by the manufacturer may cause fire, electric shock, or injury
to persons.
17. Avoid the use of an extension cord because the extension cord may
overheat and cause a risk of fire. However, if you have to use an
extension cord, the cord shall be No. 14 AWG minimum size and
rated not less than 1875 watts.
18. The output of this heater may vary and its temperature may become
intense enough to burn exposed skin. Use of this heater is not recom-
mended for persons with reduced sensitivity to heat or an inability to
react to avoid burns.
SAVE THESE INSTRUCTIONS.
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should always be
followed to reduce the risk of fire, electric shock, and injury to persons,
including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch
hot surface. If provided, use handles when moving this heater. Keep
combustible materials, such as furniture, pillows, bedding, papers,
clothes, and curtains at least 3 feet (0.9 m) from the front of the heater
and keep them away from the sides and rear.
3. Extreme caution is necessary when any heater is used by or near children
or invalids and whenever the heater is left operating and unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord or plug or after the
heater malfunctions, has been dropped or damaged in any manner.
Return heater to authorized service facility for examination, electrical or
mechanical adjustment, or repair.
6. Do not use outdoors.
7. This heater is not intended for use in bathroom, laundry areas and
similar moist indoor locations. Never locate heater where it may fall
into a bathtub or other water container.
8. Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or the like. Arrange cord away from traffic areas where it will
not be tripped over.

6 7
CONTROLING YOUR HEATER
Use the power knob to turn
the heater on, and select
which modules you wish to
provide heat.
• Position 1 powers both
units.
• Position 2 powers only the
right module, and
• Position 3 powers only the
left module,
OFF
OPERATING INSTRUCTIONS
SITUATING YOUR TWO ZONE HEATER
Your heater has been designed with a variety of use situations in mind. The
two basic uses are:
1. Combined: both heat modules attached to base, used as a single heat
source
2. Separated: each heater module in a different position, connected by the
interconnect tether
COMBINED
Place the heater where desired, taking careful note of the safety guidelines
listed in Section 3 of this manual. Please see the Controlling Your Heater
section for further instructions.
SEPARATED
A unique aspect of your Two Zone Heater is the ability to locate the two
heater modules in separate locations.
To separate the modules:
Lift module, pull away from base.
To make routing the
interconnect cord easier,
it can be disconnected
from the base unit, and
reconnected after you’ve
located the module
where you want it.
NOTE: When re-attaching the
module to the base, you may
choose from 3 angles.

8 9
WARRANTY
3 YEAR LIMITED WARRANTY
The Fulham Group Inc. (“Fulham”) warrants that for a period of three years
from the date of purchase, this product will be free from defects in material
and workmanship. Fulham, at its option, will repair or replace this product
or any component of the product found to be defective during the warranty
period. Replacement will be made with a new or remanufactured product or
component. If the product is no longer available, replacement may be made
with a similar product of equal or greater value.
This is your exclusive warranty. Do NOT attempt to repair or adjust any
electrical or mechanical functions on this product. Doing so will void this
warranty. This warranty is valid for the original retail purchaser from the date
of initial retail purchase and is not transferable. Keep the original sales receipt.
Proof of purchase is required to obtain warranty performance. Fulham dealers,
service centers, or retail stores selling Fulham products do not have the right
to alter, modify or any way change the terms and conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from
any of the following: negligent use or misuse of the product, use on improper
voltage or current, use contrary to the operating instructions, disassembly,
repair or alteration by anyone other than Fulham or an authorized Fulham
service center. Further, the warranty does not cover: Acts of God, such as fire,
flood, hurricanes and tornadoes.
Liability Limits:
Fulham shall not be liable for any incidental or consequential damages caused
by the breach of any express, implied or statutory warranty or condition.
Except to the extent prohibited by applicable law, any implied warranty or
condition of merchantability or fitness for a particular purpose is limited in
duration to the duration of the above warranty. Fulham disclaims all other
warranties, conditions or representations, express, implied, statutory or
otherwise. Fulham shall not be liable for any damages of any kind resulting
from the purchase, use or misuse of, or inability to use the product including
incidental, special, consequential or similar damages or loss of profits, or for
any breach of contract, fundamental or otherwise, or for any claim brought
against purchaser by any other party. Some provinces, states or jurisdictions
The thermostat will allow the
heater to maintain a desired
temperature.
• Power on the heater and turn
the thermostat knob fully
clockwise.
• When the desired temperature
is reached, slowly turn the knob
counterclockwise until a click is
heard.
The heater will then cycle on and
off to maintain that temperature.
TROUBLESHOOTING
If your heater shuts off unexpectedly, safety features may have been activated
to prevent overheating. If this happens:
• Be sure the power cord is plugged into a working electrical outlet.
• Check your thermostat setting. The unit may simply be off because you
have reached your desired heat setting.
• Check for any obstructions. If you nd one, turn the heater OFF and unplug
it. Wait at least 10 minutes to allow the heater to cool completely before
removing any obstruction. When done, plug-in the heater and follow the
OPERATION INSTRUCTIONS.
For more troubleshooting tips, visit our website at:
www.ambiaproducts.com
NOTE: IF YOU CONTINUE TO EXPERIENCE A PROBLEM, PLEASE RETURN THE
HEATER TO THE PLACE OF ORIGINAL PURCHASE OR SEE YOUR WARRANTY.
DO NOT ATTEMPT TO OPEN THE HEATER YOURSELF. DOING SO MAY VOID
YOUR WARRANTY AND CAUSE DAMAGE TO THE HEATER OR PERSONAL
INJURY. IF YOU HAVE ANY QUESTIONS REGARDING THIS HEATER, PLEASE
CALL OR WRITE:
Home Comfort Products
130 Rumford Avenue, Suite 105
Auburndale, MA 02466
1-866-994-6390

10 11
do not allow the exclusion or limitation of incidental or consequential damages
or limitations on how long an implied warranty lasts, so the above limitations or
exclusion may not apply to you. This warranty gives you specific legal rights,
and you may also have other rights that vary from province to province, state
to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
If you have any question regarding this warranty or would like to obtain
warranty service, please call 1-866-994-6390.
CLEANING AND MAINTENANCE
We recommend that the heater be cleaned at least once a month and before
off-season storage.
• Turn the heater OFF and unplug it. Allow it to cool completely.
• Use only a dry cloth to clean the external surfaces of the heater.
DO NOT USE WATER, WAX, POLISH, OR ANY CHEMICAL
SOLUTION.
• Clean your heater using the above-mentioned steps, then pack the
heater in its original container and store it in a cool, dry place.

Home Comfort Products
130 Rumford Avenue, Suite 105
Auburndale, MA 02466
1-866-994-6390
