Ambient Weather F007PF User manual

Version 1.5 ©Copyright 2017, Ambient LLC. All Rights Reserved. Page 1
Ambient Weather F007PF 8-Channel Wireless
Floating Pool and Spa Thermometer User Manual
Table of Contents
1Introduction.....................................................................................................................................2
2Warnings .........................................................................................................................................2
3Getting Started ................................................................................................................................2
2.1 Parts List .......................................................................................................................................2
2.2 Floating Pool and Spa Thermometer Sensor Set Up.....................................................................2
2.3 Sensor Placement..........................................................................................................................9
4Maintenance....................................................................................................................................9
5Glossary of Terms.........................................................................................................................10
6Specifications................................................................................................................................10
4.1 Wireless Specifications...............................................................................................................10
4.2 Measurement Specifications.......................................................................................................10
4.3 Power Consumption....................................................................................................................10
7Troubleshooting Guide..................................................................................................................10
8Accessories ...................................................................................................................................11
9Liability Disclaimer ......................................................................................................................12
10 FCC Statement..........................................................................................................................12
11 Warranty Information ...............................................................................................................13

Version 1.5 ©Copyright 2017, Ambient LLC. All Rights Reserved. Page 2
1Introduction
Thank you for your purchase of the Ambient Weather F007PF 8-Channel Wireless Floating Pool and
Spa Thermometer. The following user guide provides step by step instructions for installation,
operation and troubleshooting. To download the latest manual and additional troubleshooting tips,
please visit the FAQ website:
http://ambientweather.wikispaces.com/f007pf
The P007PF transmits wirelessly to any compatible Ambient Weather receiver, including the WS-07,
WS-08 and WS-09, WS-10, WS-14, WS-15, WS-16, and WS-21 wireless weather station display
consoles. Other console models may be added later, and will be listed on the FAQ website.
2Warnings
Desiccant Pack Warning
Do not remove the enclosed desiccant pack(s). We recommend replacing the pack(s) once per year.
3Getting Started
Note: The power up sequence must be performed in the order shown in this section (insert
batteries in the remote transmitter(s) first, Display Console second).
2.1 Parts List
QTY
Item
1
Thermometer transmitter (F007PF) for pool/SPA
Dimensions (LxHxW): 8.5” x 4.2” x 3.7”(216x106x95mm)
LCD Dimensions (LxW): 1.1 x 0.62”(27x16mm)
Remote sensor depth: 7.1’’ (180mm)
2
User Manual
2.2 Floating Pool and Spa Thermometer Sensor Set Up
Note: We recommend fresh alkaline batteries for temperature ranges between -4 °F and 140 °F
and fresh lithium batteries for temperature ranges between -40 °F and 140 °F. The solar panel does not
charge the batteries, so rechargeable batteries are not needed or recommended.

Version 1.5 ©Copyright 2017, Ambient LLC. All Rights Reserved. Page 3
Figure 1
1. To insert the batteries,, (1) Twist the KEY lid to unlock, (2) remove the key, and (3) twist the
main body of the sensor by removing the lid, as shown in Figure 2 .
IMPORTANT NOTE: Turn the lid counter clockwise to open, like the lid of a jar.
Turning the lid clockwise may overtighten the lid.
Figure 2
IMPORTANT NOTE: Turn the lid counter clockwise to open, like the lid of a jar (Figure 3).
Turning the lid clockwise may overtighten the lid.

Version 1.5 ©Copyright 2017, Ambient LLC. All Rights Reserved. Page 4
Figure 3
2. The floating thermometer includes dip switches for assigning channel numbers. BEFORE
inserting the batteries, locate the dip switches on the inside cover of the lid of the transmitter.
Figure 5 displays all four switches in the OFF position (factory default setting).
NOTE: The second generation pool float includes a reset button.
If the display does not power up after inserting the batteries, press the reset button shown in
Figure 4.
If your pool float does not include a reset button, cover the solar panel with one hand, remove the
batteries, wait 60 seconds, reinsert the batteries, and uncover the solar panel.
Figure 4

Version 1.5 ©Copyright 2017, Ambient LLC. All Rights Reserved. Page 5
Figure 5
Channel Number: The F007PF supports up to eight transmitters. To set each channel number (the
default is Channel 1), change Dip Switches 1, 2 and 3, as referenced in Table 1.
Temperature Units of Measure: To change the transmitter display units of measure (°F vs. °C),
change Dip Switch 4, as referenced in Table 1.
DIPSWITCH
FUNCTION
1
2
3
4
DOWN
DOWN
DOWN
---
Channel 1 (pool)
DOWN
DOWN
UP
---
Channel 2 (SPA)
DOWN
UP
DOWN
---
Channel 3 (optional)
DOWN
UP
UP
---
Channel 4 (optional)
UP
DOWN
DOWN
---
Channel 5 (optional)
UP
DOWN
UP
---
Channel 6 (optional)
UP
UP
DOWN
---
Channel 7 (optional)
UP
UP
UP
---
Channel 8 (optional)
---
---
---
DOWN
°F
---
---
---
UP
°C
Table 1

Version 1.5 ©Copyright 2017, Ambient LLC. All Rights Reserved. Page 6
3. Reference Figure 6. Install 4 x AAA batteries.
Figure 6
(1) Open the battery compartment and (2) insert 4 x AAA batteries into the battery compartment,
observing the correct battery polarity.
4. After inserting the batteries, the remote sensor LED indicator will light for 4 seconds, and
then flash once per 60 seconds thereafter. Each time it flashes, the sensor is transmitting data.
5. Verify the correct channel number (CH) and temperature units of measure (°F vs. °C) are on
the display, as shown in Figure 7.
Figure 7
(1) temperature

Version 1.5 ©Copyright 2017, Ambient LLC. All Rights Reserved. Page 7
(2) temperature units (°F vs. °C)
(3) channel number
6. Close the battery door. Make sure both red colored gaskets are properly seated in their traces
prior to closing the battery door, as shown in Figure 8. Failure to properly seal the floating
thermometer will result in water leakage and damage.
Figure 8
7. To close the lid, (1) Twist the lid until it is firmly locked and the key is aligned. (2) Insert the
key and turn 90 degrees to lock the lid, as shown in Figure 9.
Figure 9
A tether can be added into the key as shown in Figure 10.

Version 1.5 ©Copyright 2017, Ambient LLC. All Rights Reserved. Page 8
Figure 10
Place the sensor in the water and make sure that it is within the effective transmission range from the
display console.

Version 1.5 ©Copyright 2017, Ambient LLC. All Rights Reserved. Page 9
2.3 Sensor Placement
1. Place the sensor in the pool or spa within 100 feet of the display console (Figure 11,
reference A). Avoid transmitting through solid earth or ground (Figure 11, reference B).
Use a tether (string) to fix the sensor in the pool or spa.
2. Place the console at least three feet away from computers, TVs and wireless phones.
3. Avoid transmitting through solid metal barriers.
Figure 11
NOTE: The F007PF is designed to float. If the F007PF is used under a cover and the sensor is
constantly submerged, the additional pressure will lead to premature gasket failure. Moisture will
enter the sensor compartment and cause sensor failure.
4Maintenance
During each battery change (1-2 years), we recommend applying waterproof silicon grease to the

Version 1.5 ©Copyright 2017, Ambient LLC. All Rights Reserved. Page 10
seals:
http://en.wikipedia.org/wiki/Silicone_grease
Silicone grease is available at most hardware and pool stores.
5Glossary of Terms
Term
Definition
Accuracy
Accuracy is defined as the ability of a measurement to match the actual
value of the quantity being measured.
Range
Range is defined as the amount or extent a value can be measured.
6Specifications
4.1 Wireless Specifications
Line of sight wireless transmission (in open air): 150 feet, 100 feet under most conditions.
Frequency: 433 MHz
Update Rate: 60 seconds
4.2 Measurement Specifications
The following table provides specifications for the measured parameters.
Measurement
Range
Accuracy
Resolution
Channel 1-8
Temperature
-40 to 140 °F
± 1 °F
0.1 °F
4.3 Power Consumption
Remote sensor : 4 xAAA 1.5VAlkaline or Lithium batteries (not included)
Battery life:
Minimum 24 months for floating thermometer sensor (use lithium batteries for temperatures
less than -4 °F)
7Troubleshooting Guide
If your question is not answered here, you can contact us as follows:
1. Email Support: [e-mail]
2. Live Chat Support: www.ambientweather.com/chat.html (M-F 8am to 4pmArizona Time)
3. Technical Support: 480-346-3380 (M-F 8am to 4pm Arizona Time)
Problem
Solution
Wireless remote (floating thermometer)
not reporting in to console.
There are dashes (--.-) on the display
console.
The maximum line of sight communication range is 150’
and 100’ under most conditions. Move the sensor closer
to the display console.
If the sensor assembly is too close (less than 5’), move
the sensor assembly away from the display console.
