AMC AMC-1228 User manual

1228
Multidrop Version
INSTRUCTIONS
Installation and Operation of the
AMC-1228 Electrochemical Sensor Module
For Use With Multidrop AMC Monitors
IMPORTANT:
Please read these installation and operating instructions completely
and carefully before starting.
Filename: 3075405B Revised, Apr. 17 2007 Copyright ©, September 1996
The Armstrong Monitoring Corporation
215 Colonnade Road South, Ottawa, Ontario, Canada K2E 7K3
Tel: [phone] • Fax: [phone] • U.S. & CANADA Toll Free: [phone]
E-mail: [email protected] • Internet: www.armstrongmonitoring.com/gas/

AMC-1228 Multidrop
1
TABLE OF CONTENTS
Section Title Page
1WARRANTY..........................................................................................................................3
1.1 LIABILITY.......................................................................................................................3
1.2 MODIFICATIONS AND SUBSTITUTIONS.....................................................................3
1.3 PRODUCT RETURN......................................................................................................3
2PRODUCT INFORMATION...................................................................................................4
2.1 SENSOR MODULE........................................................................................................4
2.2 FACTORY CALIBRATION .............................................................................................4
3PRODUCT DESCRIPTION ...................................................................................................5
3.1 GENERAL DESCRIPTION.............................................................................................5
3.1.1 INTERNAL FEATURES ..........................................................................................5
4INSTALLATION ....................................................................................................................7
4.1 LOCATION AND MOUNTING........................................................................................7
4.2 CABLE SELECTION AND WIRING ...............................................................................7
4.2.1 MULTI-UNIT INTERCONNECTION........................................................................7
4.2.2 TERMINATION........................................................................................................7
5OPERATION AND CALIBRATION.....................................................................................10
5.1 OPERATION ................................................................................................................10
5.1.1 ALARM CONDITIONS ..........................................................................................10
5.1.2 FAULT SUPERVISION .........................................................................................10
5.2 CALIBRATION..............................................................................................................10
5.2.1 Span Adjustment...................................................................................................10
5.2.2 Alarm Adjustment..................................................................................................11
6MAINTENANCE ..................................................................................................................12
6.1 GENERAL ....................................................................................................................12
6.2 VERIFICATION OF OPERATION ................................................................................12
6.3 SENSOR REPLACEMENT ..........................................................................................12
7ADDENDUM........................................................................................................................13
7.1 AMC MULTIDROP WITH HIGH ALARM LATCHING OPTION....................................13
7.1.1 OVERVIEW...........................................................................................................13
7.1.2 OPERATION.........................................................................................................13
7.1.3 LATCHING MODULE SPECIFICATIONS.............................................................13

AMC-1228 Multidrop
2

AMC-1228 Multidrop
3
1WARRANTY
The AMC-1228 Module is warranted against defects in material and workmanship for a period of
two years from date of shipment (For sensor warranty see section 2.1). During the warranty
period, The Armstrong Monitoring Corporation will repair or replace components that prove to
be defective in the opinion of AMC. We are not liable for auxiliary interfaced equipment, or
consequential damage. This warranty shall not apply to any product, which has been modified
in any way, which has been repaired by any other party other than a qualified technician or
authorized AMC representative, or when such failure is due to misuse or conditions of use.
1.1 LIABILITY
All AMC products must be installed and maintained according to instructions. Only qualified
technicians should install and maintain the equipment. AMC shall have no liability arising from
auxiliary interfaced equipment, for consequential damage, or the installation and operation of
this equipment. AMC shall have no liability for labour or freight costs, or any other costs or
charges in excess of the amount of the invoice for the products.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,
AND SPECIFICALLY THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. THERE ARE NO WARRANTIES THAT EXTEND BEYOND THE
DESCRIPTION ON THE FACE THEREOF.
1.2 MODIFICATIONS AND SUBSTITUTIONS
Due to an ongoing development program, AMC reserves the right to substitute components and
change specifications at any time without incurring any obligations.
1.3 PRODUCT RETURN
All products returned for warranty service will be by prepaid freight and they will only be
accepted with a repair number issued by AMC. All products returned to the client will be freight
collect.
WARNING
USING ELECTRICALLY OPERATED EQUIPMENT NEAR GASOLINE, OR GASOLINE
VAPOURS MAY RESULT IN FIRE OR EXPLOSION, CAUSING PERSONAL INJURY AND
PROPERTY DAMAGE. CHECK TO ASSURE THE WORKING AREA IS FREE FROM SUCH
HAZARDS DURING INSTALLATION OR WHEN PERFORMING MAINTENANCE, AND USE
PROPER PRECAUTIONS.

AMC-1228 Multidrop
4
2PRODUCT INFORMATION
2.1 SENSOR MODULE
Sensor Module Part Number ………………………….
Sensor Module Serial Number ………………………..
Sensor Element Part Number …………………………
Sensor Element Serial Number ……………………….
Sensor Warranty Period ………………………………. ______ years
Wire Gauge …………………………………………….. 18 AWG @150 ft max between units
Power Supply Requirement …………………………... 6 to 18 VDC
Operating Temperature ……………………………….. 0° to 40° C
Operating Pressure ……………………………………. Ambient atmospheric pressure
Relative Humidity ………………………………………. 0 to 99% RH, non-condensing
Sensor Warranty ………………………………………..
2.2 FACTORY CALIBRATION
Gas Type ………………………………….…………….
Low Alarm Setting ……………………………….……..
High Alarm Setting …………………………………..…
Calibration Adapter Part Number……………………...
Note:
All Armstrong Monitoring systems must be installed and maintained according to
instructions, to ensure proper operation. Only qualified technicians should install and
maintain the equipment.

AMC-1228 Multidrop
5
3PRODUCT DESCRIPTION
In this section a general product description is given followed by a detailed list of the AMC-1228
unit's internal features.
3.1 GENERAL DESCRIPTION
The AMC-1228 sensor unit provides continuous, reliable surveillance of surrounding air for
traces of hazardous gases (listed in section 2.2 FACTORY CALIBRATION, page 4). This unit is
designed to allow interconnection in series as in a "daisy chain" configuration (refer to Figure 2)
to a single or multi-channel AMC 1AD Series monitor or so equipped inputs of other AMC
monitors. A maximum of eight (8) sensor modules can be connected to each zone. The units
can also be branched out from the central line allowing maximum flexibility. Each unit produces
Low alarm, High alarm and sensor Fail signals, which are transferred from one sensor to the
next up the line back to the monitor.
3.1.1 INTERNAL FEATURES
Each sensor module features alarm indicators, adjustment trimmers and connection terminal
blocks, as listed and described below.
1) SENSOR: Electrochemical cell, factory calibrated.
2) HIGH ALARM INDICATOR: High conditions of gas are indicated by a red LED.
3) LOW ALARM INDICATOR: Low conditions of gas are indicated by a yellow LED.
4) POWER/FAIL INDICATOR: Power is indicated by an illuminated green LED. A sensor
failure causes the green LED to turn OFF.
5) HIGH ALARM ADJUSTMENT: Sets the high alarm trip point.
6) LOW ALARM ADJUSTMENT: Sets the low alarm trip point.
7) SIGNAL ADJUSTMENT: Sets the sensitivity of the sensor.
8) TERMINATING JUMPERS: Jumper clips are supplied installed on the circuit card.
When connecting additional sensor modules, the jumper clip
corresponding to the terminal block must be removed.
Refer to section 4.2.2 TERMINATION, for more details.
9) OUTPUT TERMINAL BLOCK: The output terminals (labeled –,s,+), connect to the (–,s,+)
terminals in the monitor, or to the input (–,s,+) terminals of
another sensor module.
10) INPUT TERMINAL BLOCKS: The input terminals (–,s,+), are used to connect additional
sensor modules. Each unused input terminal block must be
locked-out using a terminal jumper (see item 8).

AMC-1228 Multidrop
6
FIGURE 1: Internal Features of the AMC-1228 sensor module.

AMC-1228 Multidrop
7
4INSTALLATION
This section relates to the proper installation of the AMC-1228 unit. The topics of proper
location, sensor wiring selection, and multi-unit interconnection are all discussed in detail.
4.1 LOCATION AND MOUNTING
Mount the sensor unit on a solid, non-vibrating surface or structure, easily accessible for status
checking and calibration. The unit must be mounted in an area where the local concentration of
gas is unaffected by the presence of ventilation systems.
NOTE:
Mounting arrangement of the housing depends on the location and mounting surface.
Mounting hardware is NOT supplied.
4.2 CABLE SELECTION AND WIRING
To gain access to the terminal blocks, remove the four (4) screws and front panel from the
housing. This will expose the field wiring terminals. The sensor module output (-,s,+) terminal
block, connects to the input terminal block of the previous unit, or to the sensor/transmitter
terminal block in the monitor, as shown in Figure 2.
NOTE:
Turn off the power supply before removing or replacing the sensor.
Connection should be made using 3-conductor, shielded cable (shield must be grounded at the
monitor). Run cable through steel conduit for best signal transmission and maximum noise
rejection. A maximum length of 150 feet of 18 AWG size cable is allowed between each unit as
well as between the monitor and first unit(s). For other distances or cable sizes, consult with
The Armstrong Monitoring Corporation.
4.2.1 MULTI-UNIT INTERCONNECTION
Each sensor module is designed to interconnect to other units in series and/or branching
configurations. Various typical configurations are shown in Figure 3, illustrating the versatility of
this type of system. Because each unit is pre-calibrated, additional units can be added to a
system without altering the monitor settings. When multiple units are interconnected, either one
or both jumpers need to be removed (refer to section 4.2.2 TERMINATION and Figure 2).
4.2.2 TERMINATION
For each unused input terminal block, the corresponding jumper MUST be left installed (as
shown in Figure 2). Failure to do so may cause the system to malfunction.

AMC-1228 Multidrop
8
FIGURE 2: Detail wiring of sensor modules.

AMC-1228 Multidrop
9
FIGURE 3: Typical system configuration layouts.

AMC-1228 Multidrop
10
5OPERATION AND CALIBRATION
This section covers instructions for the proper operation and calibration of the AMC-1228 unit.
The operation principles are described in further detail, followed by different types of periodic
adjustments that might be required throughout the lifetime of the equipment.
5.1 OPERATION
In general, after the stabilization period and in a clean air environment, the sensor module
should be displaying a GREEN Power ON LED. This green indicator, as well as the yellow and
red alarm indicators, are all visible through windows on the front panel.
5.1.1 ALARM CONDITIONS
If any gas exceeds the LOW alarm trip point setting, the yellow LED will turn ON and the unit will
transmit a signal and also turn ON the yellow LED at the monitor. Likewise, if any gas exceeds
the HIGH alarm trip point setting, the red LED's will turn ON.
5.1.2 FAULT SUPERVISION
The AMC-1228 is equipped with fault detection circuitry. This condition is indicated by turning
OFF the green Power LED viewed through the front panel. The condition will exist until the fault
is corrected.
5.2 CALIBRATION
The AMC-1228 sensor module is factory calibrated at levels based on set standards.
Calibration of the unit should last for the life of the sensor, with few periodic adjustments, unless
the alarm trip point settings need to be changed. All on-site adjustments are made at each
sensor module. Recalibration is necessary when replacing the sensor or changing the alarm
trip point settings. Factory or on-site calibration services, customer training, and/or calibration
adapter can be provided, refer to section 2.2 FACTORY CALIBRATION, page 4. Specify each
sensor module’s model number and gas when requesting any of the above.
Equipment Required:
•Digital Multimeter,
•Miniature slot screw driver,
•Calibration adapter
•Calibration gas and regulator (Contact factory for information)
5.2.1 Span Adjustment
1. Signal is measured from TB3 (-) to 20K resistor (see Figure 4 for location).
2. Apply calibration gas to sensor.

AMC-1228 Multidrop
11
3. Using Span Adjust Trimmer adjust signal voltage to proportional calibration gas
concentration.
I.E. Full Scale = 10ppm NO2 =3VDC/Full Scale X Calibration Gas
Calibration Gas = 5ppm NO2 =3VDC/10ppm X 5ppm
= 1.5VDC
5.2.2 Alarm Adjustment
Alarm Adjustment can be made with the corresponding High or Low Trimmer.
Adjust the corresponding Alarm Voltage to the appropriate fraction of full-scale gas
concentration. Alarm Voltage can be measured from TB3(-) to Low test point and high test point.
(see Figure 4 for location).
I.E. Full Scale 10ppm =3VDC/Full Scale X alarm Trip Point
Alarm Trip Point 1ppm =3VDC/10ppm X 1ppm
=.3VDC
FIGURE 4: Span and alarm adjustment.
CAUTION:
Only qualified personnel should perform the actual calibration. Users are advised to
consult The Armstrong Monitoring Corporation as to the recommended calibration gas
concentration for the application, and any other questions.

AMC-1228 Multidrop
12
6MAINTENANCE
This section covers topics related to the maintenance of the AMC-1228 unit. A general
description of maintenance to be carried out is followed by a verification of operation and then
details about the sensor replacement.
6.1 GENERAL
The sensor unit should be brushed or wiped clean once a year or more, of any dust or dirt which
settles on it, depending on the accumulation. The unit SHOULD NOT be submerged or placed
under conditions where water or other liquids would be able to enter the transmitter.
6.2 VERIFICATION OF OPERATION
Verification of operation and calibration should be done at least once every 6 months for safety
reasons and for highly demanding applications, monthly verification is recommended.
6.3 SENSOR REPLACEMENT
The sensor should be replaced when the green LED turns OFF while the unit is powered, or
when the sensor no longer adequately responds to test gas.
CAUTION:
Turn off the power supply before attempting the following.
When the sensor needs replacing, reorder the Part Number listed in section 2.1 SENSOR
MODULE (page 4). To replace the sensor element, remove the four screws and cover plate
from the housing. Unplug the used sensor element from its socket and discard then plug in the
replacement sensor element. Reinstall the cover plate and screws.
NOTE:
Allow 24 hours for the new sensor element to stabilize (burn-in) before recalibration
then follow instructions in the Calibration section of this manual.

AMC-1228 Multidrop
13
7ADDENDUM
7.1 AMC MULTIDROP WITH HIGH ALARM LATCHING OPTION
7.1.1 OVERVIEW
For the AMC Multidrop there is a latching alarm option available. This may be used where one
would like to know if there has been a high alarm level of gas overnight, or other period when
unattended. The latching option includes the AMC Multidrop, latching module, the latching LED
and the reset switch, plus the installation and connections.
For this option there is a latching red LED with a short time delay and reset switch on the front
panel. The latching module itself is located inside the Multidrop under the main circuit board.
7.1.2 OPERATION
The unit will operate as per a standard Multidrop with the additional feature. When there is a
high alarm the latching high alarm red LED will turn ON and stay on. To turn this LED OFF, the
reset button has to be pushed.
NOTE: When first powered up, the latching high alarm LED may have to be reset.
7.1.3 LATCHING MODULE SPECIFICATIONS
Power – Non alarm: 5 VDC @ 2 uA
Power – Alarm: 5 VDC @ 7 mA
Operating temperature: -10 to +40 °C
Wiring to Multidrop PCB: Red (+), yellow (signal), green (ground)
Wiring to reset switch: Brown, brown
Wiring to latching LED: Black, orange
