AMD RADEON PRO W7000 Series User manual

AMD RADEON™PRO W7000 SERIES
WORKSTATION GRAPHIC S CARD QUICK SETUP GUIDE

CONTENTS
AMD R ADE O N ™ PRO W7000 SERIES G R APH I C S CARDQ UICK SETUP GUID EPAGE 2
Getting Started
Important Safety Instructions
Hardware Installation
Software Installation
Display Configurations
Helpful Information
Disclaimer
Compliance Information
3
4
5
6
7
8
9

AMD R ADE O N ™ PRO W7000 SERIES G R APH I C S CARDQ UICK SETUP GUID EPAGE 3
Before You Begin...
System Requirements
Recording the Serial and Part Numbers
GETTING STARTED
Before you begin installing your new graphics card, visually inspect the card and any components that may have shipped with it, and contact your AMD
reseller in the event of missing or damaged parts. Also make sure that you have the proper system requirements and have reviewed the preinstallation
information outlined below.
The following are the minimum requirements for installation of AMD Radeon™ PRO W7000 series graphics cards. For additional
processing power and graphics performance, multiple AMD Radeon™ PRO W7000 series graphics cards can be installed in the same
system provided there are enough PCI-Express® slots available, and the system power supply has sucient capacity.
Write down the serial number and part number before installing your product.
The serial number and part number on the product are required for registration
and technical support. They are located on a sticker on the back of your AMD
Radeon™ PRO W7000 Series graphics card [Fig. 01].
These apply to both single-card and multi-card installations:
PC with at least one PCI-Express® x16 graphics slot available on the motherboard.


Minimum of 16 GB of system memory, 32 GB is recommended

Supported operating systems include Linux®, Windows® 10, and
Windows® 11, 64-bit operating system is required.

At least one display that is compatible with a DisplayPort™
connection is recommended

If unsure on the power supply requirements for multiple GPU configurations, please consult
with AMD Customer Care. See Page 11 for details.
AMD RadeonTM PRO W7900 - Minimum 650W system power supply
AMD RadeonTM PRO W7800 - Minimum 650W system power supply
Fig. 01
Serial Number &
Part Number
PRO TIP:
For multi-card installations, it is
recommended that there be enough
room on the motherboard to provide at
least one empty slot between graphics
cards.

AMD R ADE O N ™ PRO W7000 SERIES G R APH I C S CARDQ UICK SETUP GUID EPAGE 4
IMPORTANT SAFETY INSTRUCTIONS
Installation and servicing of computer components and creating customized computer mods can be hazardous. Only trained, qualified personnel should
install, repair or service computer components or create customized mods. Please ensure that before working on computer components, the computer is
unplugged and all components have been fully discharged. Be sure to ground yourself before touching sensitive components, which can be damaged by
static discharge.
Failure to exercise appropriate caution can result in serious personal injury and/or damage to computer components.
CAUTION: This product is for use only with compatible UL-listed personal computers with
installation instructions detailing user installation of this product. Read all
instructions before beginning installation. All safety and installation instructions
should be read before the product is installed or operated. Retain all instructions.
Safety, installation, and operating instructions should be retained
for future reference. Heed all warnings. All warnings regarding the product and
its operating instructions should be obeyed. Use appropriate grounding.
CAUTION: [Where applicable] For continued protection against electric shock and fire risk,
install this accessory only in products equipped with a three-wire grounding plug,
a plug with a third (grounding) pin. This is a safety feature. Do not remove the
grounding pin of a three-pin plug.
Attach product securely. All product-securing screws or fasteners should be
completely tightened to provide continuous bonding between the product and
the PC chassis, as appropriate.

Overview
Once you have determined that your system meets the
recommended minimum requirements, perform the following tasks
to install your new graphics card. Detailed installation instructions
are provided in the following sections.
If replacing an existing graphics card, uninstall the old graphics
driver and software before installing the new AMD Radeon™ PRO
W7000 Series graphics card.
NOTE: If you are using a motherboard containing an on-board graphics
solution and do not intend to use it as part of a multiple monitor configuration,
disable it.
1.
2. If needed, remove any existing graphics card(s).
3. Install the new graphics card.
4. Reassemble and connect your computer system and display(s).
5. Start the computer system, install the AMD drivers and
configuration software.
6. Restart the computer system.
HARDWARE INSTALLATIONStep-by-Step: Installing your
AMD Radeon™ PRO Graphics Card
1.
2. Unplug the computer’s power cord, and then disconnect all cables
from the back ofthe computer.
3. Remove the cover to the computer’s case.
4. Unscrew or unfasten and remove any existing graphics card from
the computer.
5. Locate the appropriate bus slot and, if necessary, remove the
corresponding metal backplate cover(s). Make sure all internal
cablesare clear ofthe slot.
6. Align the graphicscard withthe slot and press it in firmly until
the card is fully seated.
7. If your card requires supplementary power and must be
connected directly to the power supply, locate the appropriate
power connector cable(s) from the power supply and connect
it (or them) to the graphics card’s supplementary power
connector(s).
8. Fasten the graphics card securely to the back panel.
9. Make sure no internal cablesare interfering with components
inside the computer (for example, a cooling fan) and then replace
the computer cover.
10. Reconnect any cablesyou have disconnected during installation,
and then plug in the computer’s power cord. Turn onthe monitor,
and then the computer. Ifyou have properly installed the graphics
card, the computer should start normally. Proceed to install
the software and drivers for yourAMD Radeon™ PRO W7000 Series
graphics card.
CAUTION:
Wait approximately 20 seconds
after unplugging the power
cord before disconnecting a
peripheral cable or removing a
component from the
motherboard to avoid possible
damage to the motherboard.
AMD R ADE O N ™ PRO W7000 SERIES G R APH I C S CARDQ UICK SETUP GUID EPAGE 5

AMD Radeon™ PRO W7000 Series Drivers and Software
.
SOFTWARE INSTALLATION
DisplayPort®2.1
DisplayPort®2.1
DISPLAY CONNECTOR TYPES:
DISPLAY CONFIGURATIONS
Connecting Displays
NOTE: Only up to three (3) passive adapter cables may be used. Active adapter cables are required for
additional displays. The following table lists options for attaching displays to your graphics card.
For best graphics performance and quality, always use native (or active) connections
when possible.
Display Configuration Connection Options
CRT (VGA) display DisplayPort connection with DisplayPort-to-VGA adapter
DFP (digital flat-panel)display DisplayPort connection with DisplayPort cable
DisplayPort connection with DisplayPort-to-DVI adapter
HDMI®HDMI Connection with HDMI Cable
DisplayPort connection with DisplayPort-to-HDMI adapter
Drivers are small but important programs that enable an operating system to communicate with a piece of hardware, such as a graphics card. When you
install a new graphics card, you must also install the appropriate AMD Radeon™ PRO W7000 graphics driver and configuration software for your card to
take full advantage of the capabilities of your card. You should also reinstall Radeon Software drivers each time you reinstall or upgrade your operating
system. AMD Software: PRO Edition features and the latest drivers are available at AMD.com/support.
Continous Performance
Accelerate your workflows with the continuous performance
optimizations in every enterprise driver release
https://www.amd.com/en/technologies/software-pro
AMD Radeon™ PRO W7000 Series graphics cards provide support for up to 8K Ultra
HD resolution via its DisplayPort® connections.
Mini Enhanced
AMD R ADE O N ™ PRO W7000 SERIES G R APH I C S CARDQ UICK SETUP GUID EPAGE 6

AMD Customer Care
Contact Support by Phone 24/7
For additionalproduct support, please visit amd.com/support for technical troubleshooting guides and AMD Customer Care contact information.
• AMD is not responsible for any expense incurred accessing Customer Care. It is expected that customers will review the expense associated with the available support options
and will choose the method that best meets their needs and budget.
• AMD Customer Care reserves the right to limit support options for products that are not registered or are reaching end-of-life.• AMD Customer Care reserves the right to limit support options for products that are not registered or are reaching end-of-life.
HELPFUL INFORMATION
You can also use this online form to submit a service request, please visit amd.com/en/support/contact-email-form
Canada
China
France
Germany
India
Japan
United Kingdom
United States
Tel: [phone] (Toll Free – English only)
Tel: [phone] (Chinese Mon-Fri 9:30–17:00 BJT. English on o-hours.)
Tel: [phone] | Intl Tel: [phone] (French Mon-Fri 11:00 – 18:00 CET. English on o-hours.)
Tel: [phone] | Intl Tel: [phone] (German Mon-Fri 11:00 – 18 CET. English on o-hours)
Tel: [phone] (English 24/7)
Tel: [phone] (Japanese Mon-Fri 9:30 – 18:00 JST. English on o-hours.)
Tel: [phone] | Int Tel: [phone] (English 24/7)
Tel: [phone] (Toll Free – English only)
AMD R ADE O N ™ PRO W7000 SERIES G R APH I C S CARDQ UICK SETUP GUID EPAGE 7
AMD Customer Care for Graphics Products will work to resolve your issue and help you to get your product up and running. If your issue is not
resolved, our technicians will determine whether the diculty you are experiencing is the result of the product, whether your product contains a
defect, and whether your product is under warranty.

Disclaimer
The information contained herein is for informational purposes only, and is subject to change without notice. While every precaution has been taken in
the preparation of this document, it may contain technical inaccuracies, omissions and typographical errors, and AMD is under no obligation to update
or otherwise correct this information.
Advanced Micro Devices, Inc. makes no representations or warranties with respect to the accuracy or completeness of the contents of this document,
and assumes no liability of any kind, including the implied warranties of noninfringement, merchantability or fitness for particular purposes, with
respect to the operation or use of AMD hardware, software or other products described herein.
No license, including implied or arising by estoppel, to any intellectual property rights is granted by this document. Terms and limitations applicable to
the purchase or use of AMD’s products are as set forth in a signed agreement between the parties or in AMD’s Standard Terms and Conditions of Sale.
Important Safety Instructions:
Note: This product is for use only with compatible UL-listed personal computers that have installation instructions detailing user installation of this
class of product. Read all instructions before beginning installation. All safety and installation instructions should be read before the product is
installed or operated. Retain all instructions. Safety, installation, and operating instructions should be retained for future reference. Heed all warnings.
All warnings regarding the product and its operating instructions should be obeyed. Use appropriate grounding.
Caution:
[Where applicable] For continued protection against the risk of electric shock and fire, install this accessory only in products equipped with a
three-wire grounding plug, a plug having a third (grounding) pin. This is a safety feature. Do not remove the grounding pin of a three-pin plug.
Attach product securely. All product-securing screws or fasteners should be completely tightened in order to provide continuous bonding between
the product and the PC chassis, as appropriate.
AMD R ADE O N ™ PRO W7000 SERIES G R APH I C S CARDQ UICK SETUP GUID EPAGE 8

FCC Compliance Information
(USA)
Class B
This product complies with FCC Rules Part 15.
Operation is subject to the following conditions:
• This device may not cause harmful
interference.
• This device must accept any interference
received, including interference that may
cause undesired operation.
This equipment has been tested and found
to comply with the limits designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used
in accordance with manufacturer’s instructions,
may cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment to an outlet on
receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
FCC Part 15, Subpart B, Class B
For further compliance information:
Advanced Micro Devices, Inc.
ATTN: General Counsel
P.O. Box 3453
Sunnyvale, CA 94088-3453
USA Tel: [phone]
ISED Compliance Information
(Canada)
Class B
This Class B digital apparatus complies with
Canadian ICES-003:
CAN ICES-3(B)/NMB-3(B).
Cet appareil numérique de la Classe A est
conforme à la norme
CAN ICES-3(B)/NMB-3(B) du Canada.
UKCA Compliance
Information
(European Union)
Class B
This device complies with the following Directives:
• S.I. 2016/1091: Electromagnetic Compatibility
Regulations 2016
• S.I. 2016/1101: Electrical Equipment (Safety)
Regulations 2016
• S.I. 2012/3032: The Restrictionofthe Use of
Certain Hazardous Substances in Electrical and
Electronic Equipment Regulations 2012
Single Point of Contact:
Attention: Sales, Advanced Micro Devices (U.K.),
Ltd.
Regus – Midsummer Court, 314 Midsummer
Boulevard
Milton Keynes, MK9 2UB, U.K.
CE Compliance Information
(European Union)
Class B
This device complies with the following Directives:
• EMC Directive 2014/30/EU
• LVD Directive 2014/35/EU
• RoHS Directive 2011/65/EU
Single Point of Contact:
Attention: Sales, AMD GmbH,
Einsteinring 24, 85609
Aschheim-Dornach, Germany.
Electrical Safety
• Underwriters Laboratories (UL):
UL 62368-1
• Canada: CSA C22.2 No. 62368-1-14
• European Union (EU): EN 62368-1
• International: IEC 62368-1
A copy of the Declaration of Conformity (DoC) to
essential equirements may be obtained from:
Attention: Sales, AMD GmbH, Einsteinring 24,
85609 Aschheim-Dornach – Germany
VCCI ITE Compliance
Information (Japan)
Class B
KC Compliance Information
(Korea)
Class B
BSMI Compliance
Information (Taiwan)
Class B
Morocco Compliance
Information
Moroccan Regulatory Framework (CMIM)
RCM Compliance
Information
(Australia and New Zealand)
This device complies with the requirements of
the relevant Australian Communications and
Media Authority (ACMA) Standards made under
the Radiocommunications Act 1992 and the
Telecommunications Act 1997.
Product Environmental
Compliance
This product may carry a marking similar
to those below that indicates its level of
compliance with China RoHS standards.
For information on China RoHS, EU RoHS, or
EU REACH compliance, please refer to Product
Environmental Compliance on the AMD Web site.
Waste Electrical and
Electronic Equipment
(WEEE) Directive
Compliance (European Union)
This product was manufactured by Advanced
Micro Devices, Inc.
CAUTION: Changes or modifications not
expressly approved by the
party responsible for compliance could void the
user’s authority to operate the equipment.
COMPLIANCE INFORMATION
AMD RADEON™ RX 7900 XT GRAPHICS CARD QUICK SETUP GUIDE
PAGE 6
FCC Compliance Information
(USA)
Class B
This product complies with FCC Rules Part 15.
Operation is subject to the following conditions:
• This device may not cause harmful
interference.
• This device must accept any interference
received, including interference that may
cause undesired operation.
This equipment has been tested and found
to comply with the limits designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used
in accordance with manufacturer’s instructions,
may cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment o
and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment to an outlet on
a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
FCC Part 15, Subpart B, Class B
For further compliance information:
Advanced Micro Devices, Inc.
ATTN: General Counsel
P.O. Box 3453
Sunnyvale, CA 94088-3453
USA Tel: [phone]
ISED Compliance Information
(Canada)
Class B
This Class B digital apparatus complies with
Canadian ICES-003:
CAN ICES-3(B)/NMB-3(B).
Cet appareil numérique de la Classe A est
conforme à la norme
CAN ICES-3(B)/NMB-3(B) du Canada.
UKCA Compliance
Information
(European Union)
Class B
This device complies with the following Directives:
• S.I. 2016/1091: Electromagnetic Compatibility
Regulations 2016
• S.I. 2016/1101: Electrical Equipment (Safety)
Regulations 2016
• S.I. 2012/3032: The Restriction of the Use of
Certain Hazardous Substances in Electrical and
Electronic Equipment Regulations 2012
Single Point of Contact:
Attention: Sales, Advanced Micro Devices (U.K.),
Ltd.
Regus – Midsummer Court, 314 Midsummer
Boulevard
Milton Keynes, MK9 2UB, U.K.
CE Compliance Information
(European Union)
Class B
This device complies with the following Directives:
• EMC Directive 2014/30/EU
• LVD Directive 2014/35/EU
• RoHS Directive 2011/65/EU
Single Point of Contact:
Attention: Sales, AMD GmbH,
Einsteinring 24, 85609
Aschheim-Dornach, Germany.
Electrical Safety
• Underwriters Laboratories (UL):
UL 62368-1
• Canada: CSA C22.2 No. 62368-1-14
• European Union (EU): EN 62368-1
• International: IEC 62368-1
A copy of the Declaration of Conformity (DoC) to
essential equirements may be obtained from:
Attention: Sales, AMD GmbH, Einsteinring 24,
85609 Aschheim-Dornach – Germany
VCCI ITE Compliance
Information (Japan)
Class B
섮셉ٝ셊뺮셽솷솇$Ʈ،셂섴뺯섮셉ٝ
셊뺮ʐ௮րؗ셂ů섴셦섮셃셭ϝĀ셃섲셁섟
셙섴섧뺮섮셉ٝ섧솷솆셸셟솔솺송솆솵쇁ɩ
ƱƮ셆˦ˈ섲셁ů섰셧셦셃뺮ɩƱචҴ셭ڇ
섨ő섮섴섮셃섧석셥셙섴뺯ȿ䔃炗džΌ셆䉡섾
셁Ȣ섲섟ȿ셥䔃섟셭섲셁Ī섰섟뺯8%%+$
KC Compliance Information
(Korea)
Class B
BSMI Compliance
Information (Taiwan)
Class B
Morocco Compliance
Information
Moroccan Regulatory Framework (CMIM)
RCM Compliance
Information
(Australia and New Zealand)
This device complies with the requirements of
the relevant Australian Communications and
Media Authority (ACMA) Standards made under
the Radiocommunications Act 1992 and the
Telecommunications Act 1997.
Product Environmental
Compliance
This product may carry a marking similar
to those below that indicates its level of
compliance with China RoHS standards.
For information on China RoHS, EU RoHS, or
EU REACH compliance, please refer to Product
Environmental Compliance on the AMD Web site.
Waste Electrical and
Electronic Equipment
(WEEE) Directive
Compliance (European Union)
This product was manufactured by Advanced
Micro Devices, Inc.
CAUTION: Changes or modifications not
expressly approved by the
party responsible for compliance could void the
user’s authority to operate the equipment.
COMPLIANCE INFORMATION
AMD R ADE O N ™ PRO W7000 SERIES G R APH I C S CARDQ UICK SETUP GUID EPAGE 9

© 2023 Advanced Micro Devices, Inc. All rights reserved. AMD, the AMD Arrow logo, Radeon, FreeSync, and combinations thereof are trademarks of Advanced Micro Devices, Inc. Direct®X and Microsoft are registered
trademarks of Microsoft Corporation in the USand otherjurisdictions. PCI Express and PCIeare registered trademarks of PCI-SIG Corporation. Vulkan and the Vulkan logo are trademarks of the Khronos Group Inc. HDMI,
theHDMI logo and High-Definition Multimedia Interface are trademarks orregistered trademarks of HDMI Licensing, LLC in the United States and other countries. Other names are for informational purposes only and may
be trademarks of their respective owners. PID# 232090657
AMD.COM
Create. Visualize. Inspire.
The Next Generation of Professional Graphics.
102 P/N (102-D70701, 102-D70711, 102-D74911, and 102-D74901)
