American DJ Jelly Fish User manual

12/09
User Instructions
American DJ® - www.americandj.com - Jellysh Instruction Manual Page 2
Unpacking: Thank you for purchasing the Jellysh by American DJ®.
Every Jellysh has been thoroughly tested and has been shipped in
perfect operating condition. Carefully check the shipping carton for
damage that may have occurred during shipping. If the carton appears
to be damaged, carefully inspect your xture for any damage and be
sure all equipment necessary to operate the unit has arrived intact. In
the event damage has been found or parts are missing, please contact
our toll free customer support number for further instructions. Please
do not return this unit to your dealer without contacting customer sup-
port rst.
Introduction: The Jellyfish is a DMX intelligent, LED fixture. The fix-
ture has three different operating modes; sound-active mode, show
mode, or it can be controlled by a DMX controller. In DMX mode it has
2 different channel mode; a 3 channel mode, and 28 channel mode. It
can operate as a stand alone fixture or in a Master/Slave configuration.
For best results use fog or special effects smoke to enhance the beams
projections.
Customer Support: American DJ® provides a toll free customer
support line, to provide help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to
5:00 p.m. Pacic Standard Time.
Voice: [phone]
Fax: [phone]
E-mail: [email protected]
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Warning! This may cause severe eye damage. Avoid looking directly
into the light source at all times!
Jellyfish General Information

For Your Own Personal Safety, Please Read and Understand This
Manual Completely Before You Attempt To Install Or Operate
This Unit!
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Be sure that the local power outlet match that of the required volt-
age for your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken.
• Do not attempt to remove or break off the ground prong from
the electrical cord. This prong is used to reduce the risk of electrical
shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience recep-
tacles, and the point where they exit from the appliance.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 16 for cleaning details.
• Heat -This fixture should be situated away from heat sources such
as radiators, heat registers, stoves, or other appliances (including
amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. Objects have fallen, or liquid has been spilled into the appliance.
B. The appliance has been exposed to rain or water.
C. The appliance does not appear to operate normally or exhibits a
marked change in performance.
Jellyfish Safety Precautions
American DJ® - www.americandj.com - Jellysh Instruction Manual Page 4American DJ® - www.americandj.com - Jellysh Instruction Manual Page 3
• DMX-512 Protocol Compatible
• 2 DMX Channel Modes: 3 Channel & 28 Channel
• 3 Operating Modes - Sound Active, Show, DMX Control
• Stand Alone or Master/Slave Configuration
• Internal Microphone
• UC3 Controller (Not Included)
• Power Cord Daisy Chaining
Jellyfish Features
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ®.
American DJ®will not accept any liability for any resulting damages
caused by the non-observance of this manual or any unauthorized
modication to this unit.
Jellyfish Handling Precautions
Jellyfish Warranty Registration
The Jellyfish carries a 3 year (1095 days) limited warranty. Please fill
out the enclosed warranty card to validate your purchase and war-
ranty. You may also register your product online at www. americandj.
com. All returned service items whether under warranty or not, must
be freight pre-paid and accompany a return authorization (R.A.) num-
ber. If the unit is under warranty you must provide a copy of your
proof of purchase invoice. Please contact American DJ® customer
support for a R.A. number.
To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the basic
operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please
keep this manual with the unit, for future reference.
Jellyfish General Instructions

American DJ® - www.americandj.com - Jellysh Instruction Manual Page 6American DJ® - www.americandj.com - Jellysh Instruction Manual Page 5
Jellyfish Set Up Jellyfish Set Up
Power Supply: Before plugging your unit in, be sure the source
voltage in your area matches the required voltage for your American
DJ® Jellysh™. The American DJ® Jellysh is available in a 120v and
220v version. Because line voltage may vary from venue to venue,
you should be sure your unit voltage matches the wall outlet voltage
before attempting to operate you xture. Also be sure to only use the
included I.E.C. power cable supplied with the unit, this cable matches
the voltage and current requirements of the unit.
DMX-512: DMX is short for Digital Multiplex. This is a universal pro-
tocol used by most lighting and controller manufactures as a form of
communication between intelligent fixtures and controllers. A DMX
controller sends DMX data instructions from the controller to the fix-
ture. DMX data is sent as serial data that travels from fixture to fixture
via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX
fixtures (most controllers only have a DATA “OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models
of different manufactures to be linked together and operate from a
single controller, as long as all xtures and the controller are DMX
compliant. To ensure proper DMX data transmission, when using
several DMX fixtures try to use the shortest cable path possible. The
order in which fixtures are connected in a DMX line does not influence
the DMX addressing. For example; a fixture assigned a DMX address
of 1 may be placed anywhere in a DMX line, at the beginning, at the
end, or anywhere in the middle. Therefore, the first fixture controlled
by the controller could be the last fixture in the chain. When a fixture
is assigned a DMX address of 1, the DMX controller knows to send
DATA assigned to address 1 to that unit, no matter where it is located
in the DMX chain.
Data Cable (DMX Cable) Requirements (For DMX
and Master/Slave Operation): The Jellysh can be
controlled via DMX-512 protocol. The Jellysh has
two DMX Channel modes. It has a three channel
mode and 28 channel mode. The DMX address
is set electronically using the controls on the rear
panel of the unit. Your unit and your DMX controller
require a approved DMX-512 110 Ohm Data cable
for data input and data output (Figure 1). We recommend Accu-Cable
Figure 1
DMX cables. If you are making your own cables, be sure to use stan-
dard 110-120 Ohm shielded cable (This cable may be purchased at
almost all professional sound and lighting stores). Your cables should
be made with a male and female XLR connector on either end of the
cable. Also remember that DMX cable must be daisy chained and
cannot be split.
Notice: Be sure to follow gures two and three when making your own
cables. Do not use the ground lug on the XLR connector. Do not con-
nect the cable’s shield conductor to the ground lug or allow the shield
conductor to come in contact with the XLR’s outer casing. Grounding
the shield could cause a short circuit and erratic behavior.
DMX512 IN
3-PIN XLR
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OUT
3-PIN XLR
Figure 2
Figure 3
1 Ground 1 Ground
XLR Male Socket XLR Pin Conguration
3 Hot
2 Cold 2 Cold
3 Hot
XLR Female Socket
Pin 3 = Data True (positive)
Pin 2 = Data Compliment (negative)
Pin 1 = Ground
Special Note: Line Termination. When longer runs of cable are
used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is con-
nected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last
unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.
DMX512 IN
3-PIN XLR
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OUT
3-PIN XLR
Figure 4

American DJ® - www.americandj.com - Jellysh Instruction Manual Page 7 American DJ® - www.americandj.com - Jellysh Instruction Manual Page 8
5-Pin XLR DMX Connectors. Some manufactures use 5-pin XLR
connectors for DATA transmission in place of 3-pin. 5-pin XLR xtures
may be implemented in a 3-pin XLR DMX line. When inserting stan-
dard 5-pin XLR connectors in to a 3-pin line a cable adaptor must be
used, these adaptors are readily available at most electric stores. The
chart below details a proper cable conversion.
Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)
Pin 1
Pin 5 - Do Not Use
Pin 4 - Do Not Use
Pin 3
Pin 2
Pin 1
Pin 3
Pin 2
Not Used
Not Used
Data True (+ signal)
Data Compliment (- signal)
Ground/Shield
3-Pin XLR to 5-Pin XLR Conversion
Jellyfish Set Up Jellyfish System Menu

American DJ® - www.americandj.com - Jellysh Instruction Manual Page 10American DJ® - www.americandj.com - Jellysh Instruction Manual Page 9
Jellyfish System Menu Jellyfish System Menu
System Menu: When making adjustments you can press
ENTER to conrm your setup or you can wait 8 seconds for
automatic setup. To exit without making any adjustments
press the MENU button.
ADDR - DMX Address Setting.
1. Tap the either the MENU, UP, or DOWN buttons until “ADDR”
is displayed, press ENTER.
2. “1” will now be displayed and ashing. Press the UP or
DOWN buttons to nd your desired address. Press ENTER to
set your desired DMX address.
CHND - This will let you the DMX Mode you want to run.
You can choose between 3 channel mode and 28 channel
mode.
1. Tap the MENU button until “CHND” is displayed, press
ENTER. Either “3CH” or “28CH ” will be displayed.
2. Tap the UP or DOWN buttons until your desired DMX chan-
nel mode is displayed, press ENTER to conm. See page 7 for
DMX Channel modes and traits.
SLND - This will let you set unit as a slave in a master/
slave conguration.
1. Tap the MENU button until “SLND” is displayed, press
ENTER. Either “MAST”, “SL 1”, “SL 2”, “SL 3”, or “SL 4” will be
displayed.
2. Tap the UP or DOWN buttons until your desired mode setting
is displayed, press ENTER to conm.
Note: Each slave mode is a different light show.
NOTE: In a Master/Slave conguration you can set one xture
to Master and then set the next xture to “SL 2”, the xtures will
now have contrast movement to each other.
Sh 0-Sh 11 - Show modes 0 - 11 (Factory programs).
1. Tap the MENU button until “ShNd” is displayed, press
ENTER.
2. “Sh X” will now be displayed, “X” representing a number
between 1-11. Programs 1-11 are factory programs, while “Sh
0” is random mode. Press the UP or DOWN buttons to nd your
desired show and press ENTER to conrm.
SOUN - Sound Active mode.
1. Tap the MENU button until “SOUN” is displayed, press
ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or
DOWN buttons to select “ON” to activate sound active mode, or
“OFF” to deactivate sound active mode.
3. Press ENTER to conrm.
BLND - Blackout or Stand by mode.
1. Tap the either the MENU button until “BLND” is displayed,
press ENTER. Either Yes or No will be displayed.
2. To activate Blackout tap the UP or DOWN buttons until Yes is
displayed, press ENTER to conm and exit. The xture will now
be in Blackout mode. To deactivate Blackout mode, select No
and press Enter.
LED - With this function you can have the LED display
turn off after 10 seconds.
1. Tap the MENU button until “LED” is displayed, press ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or
DOWN buttons to select “ON” to keep the LED display on at

American DJ® - www.americandj.com - Jellysh Instruction Manual Page 11 American DJ® - www.americandj.com - Jellysh Instruction Manual Page 12
Operating Modes: The Jellyfish can operate in three different
modes.
• Sound Active mode -
The unit will react to sound, chasing through the built-in programs.
• Show mode -
Select one of 11 preprogrammed shows.
• DMX control mode -
This function will allow you to control each individual fixtures traits
with a standard Elation®DMX-512 controller.
Universal DMX Control: This function allows you to use a univer-
sal DMX-512 controller to control the colors, chases. chase speed,
and strobe. A DMX controller allows you to create unique programs
tailored to your individual needs. The Jellyfish has two DMX channel
modes; a 3 channel mode and 28 channel mode.
1. To control your fixture in DMX mode, follow the set-up procedures
on pages 5-7 as well as the set-up specifications that are includ-
ed with your DMX controller.
2. Use the controller’s faders to control the various DMX fixture traits.
3. Follow the instructions on page 9 to set the DMX address and
choose your desired DMX Channel mode.
4. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
5. For help operating in DMX mode consult the manual included
with your DMX controller.
6. The optional UC3 Controller (not included) may be used to control
different functions including blackout.
Sound Active Mode:This mode allows either single unit or sev-
eral units linked together, to run to the beat of the music.
1. Tap the MENU button until “SOUN” is displayed, and press
ENTER. Tap the UP or DOWN buttons so that “ON” is dis-
played and press ENTER.
2. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Show Mode:
1. Tap the MENU button until “SHND” is displayed, and press ENTER.
Jellyfish OperationJellyfish System Menu
all times, or “OFF” to switch to have the LED display switch off
after 10 seconds.
3. Press ENTER to conrm.
IDSP - This function will reverse the display 180º.
1. Tap the MENU button until “IDSP” is displayed, press ENTER.
2. Press ENTER to “ip” the display. Press ENTER to “ip” it
again. Press ENTER when you have made your desired setup.
FHRS - With this function you can display the running time
of the xture.
1. Tap the MENU button until “FHRS” is displayed, press
ENTER.
2. The running time of the xture will now be displayed. Press
MENU to exit.
VER - With this function you can display the version soft-
ware of the xture.
1. Tap the MENU button until “VER” is displayed, press ENTER.
2. The software version will now be displayed. Press MENU to
exit.
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 46 xtures maximum. After 46 xtures you will need
to use a new power outlet. They must be the same xtures. DO
NOT mix xtures.
Jellyfish Power Cord Daisy Chaining

American DJ® - www.americandj.com - Jellysh Instruction Manual Page 13 American DJ® - www.americandj.com - Jellysh Instruction Manual Page 14
Jellyfish Operation
2. Using the either the UP or DOWN buttons, nd your desired show.
See page 10 for more details.
3. Press ENTER to conrm.
4. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Master-Slave Operation (Sound Active): This function will allow
you to link up to 16 units together and operate without a controller. The
units will be sound activated. In Master-Slave operation one unit will
act as the controlling unit and the others will react to the controlling
units programs. Any unit can act as a Master or as a Slave.
1. Using standard XLR microphone cables, daisy chain your units
together via the XLR connector on the rear of the units. Remem-
ber the Male XLR connector is the input and the Female XLR
connector is the output. The rst unit in the chain (master) will use
the female XLR connector only - The last unit in the chain will use
the male XLR connector only. For longer cable runs we suggest a
terminator at the last fixture.
2. On the Master unit tap the MENU button until “SLND” is dis-
played, and press ENTER. Press the UP or DOWN button until
“MAST” is displayed, and press ENTER to conrm. Now, select
your desired operating mode and set that show by pressing the
ENTER button.
3. On the slave units tap the MENU button until “SLND” is dis-
played, select your desired Slave mode and Press ENTER.
4. The slave units will now follow the Master unit.
5. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Jellyfish 3 Channel DMX Traits
Channel Value Function
1 COLOR/CHASE/SOUND ACTIVE
0 - 119 COLOR
120 - 239 CHASE
240 - 255 SOUND ACTIVE
2 COLOR (CH. 1 VALUES 1 - 119)
0 - 15 OFF
16 - 31 COLOR 1
32 - 47 COLOR 2
48 - 63 COLOR 3
64 - 79 COLOR 4
80 - 95 COLOR 5
96 - 111 COLOR 6
112 - 127 COLOR 7
128 - 143 COLOR 8
144 - 159 COLOR 9
160 - 175 COLOR 10
176 - 191 COLOR 11
192 - 207 COLOR 12
208 - 223 COLOR 13
224 - 239 COLOR 14
240 - 255 COLOR 15
CHASE (CH. 1 VALUES 120 - 239)
0 - 9 OFF
10 - 19 CHASE 1
20 - 29 CHASE 2
30 - 39 CHASE 3
40 - 49 CHASE 4
50 - 59 CHASE 5
60 - 69 CHASE 6
70 - 79 CHASE 7
80 - 89 CHASE 8
90 - 99 CHASE 9
100 - 109 CHASE 10
110 - 119 CHASE 11
Jellyfish UC3 Control
Stand by Blackout the unit
Function
1. Strobe
2. Sound Synchronous Strobe
3. Sound Asynchronous Strobe
Show
12
Mode Strobe (LED OFF) Latch (LED ON)

American DJ® - www.americandj.com - Jellysh Instruction Manual Page 15 American DJ® - www.americandj.com - Jellysh Instruction Manual Page 16
Jellyfish 28 Channel DMX Traits
Channel Value Function
1 RED
1 - 255 0% - 100%
2 GREEN
1 - 255 0% - 100%
3 BLUE
1 - 255 0% - 100%
Jellyfish 3 Channel DMX Traits
Channel Value Function
2 CHASE Cont. (CH. 1 VALUES 120 - 239)
120 - 129 CHASE 12
130 - 139 CHASE 13
140 - 149 CHASE 14
150 - 159 CHASE 15
160 - 169 CHASE 16
170 - 179 CHASE 17
180 - 189 CHASE 18
190 - 199 CHASE 19
200 - 209 CHASE 20
210 - 219 CHASE 21
220 - 229 CHASE 22
230 - 239 CHASE 23
240 - 249 CHASE 24
250 - 255 CHASE 25
3 STROBE (CH. 1 VALUES 0 - 119)
0 - 9 OPEN
10 - 255 STROBING SLOW - FAST
CHASE SPEED
(CH. 1 VALUES 120 - 239)
0 - 9 OPEN
10 - 255 CHASE SPEED SLOW - FAST
3 CHANNEL MODE: The setting of Channel 1 is used with
Channel 2 and Channel 3.
Jellyfish 28 Channel DMX Traits
Channel Value Function
4 WHITE
1 - 255 0% - 100%
5 RED
1 - 255 0% - 100%
6 GREEN
1 - 255 0% - 100%
7 BLUE
1 - 255 0% - 100%
8 WHITE
1 - 255 0% - 100%
9 RED
1 - 255 0% - 100%
10 GREEN
1 - 255 0% - 100%
11 BLUE
1 - 255 0% - 100%
12 WHITE
1 - 255 0% - 100%
13 RED
1 - 255 0% - 100%
14 GREEN
1 - 255 0% - 100%
15 BLUE
1 - 255 0% - 100%
16 WHITE
1 - 255 0% - 100%
17 RED
1 - 255 0% - 100%
18 GREEN
1 - 255 0% - 100%
19 BLUE
1 - 255 0% - 100%
20 WHITE
1 - 255 0% - 100%

Jellyfish Cleaning
Jellyfish Trouble Shooting
Trouble Shooting: Listed below are a few common problems that
you may encounter, with solutions.
No light output from the unit;
1. Be sure you have connected your unit into a standard 120v wall
outlet.
2. Be sure the external fuse has not blown. The fuse is located on
the bottom panel of the unit.
3. Be sure the fuse holder is completely and properly seated.
Unit does not respond to sound;
1. Low frequencies (bass) should cause the unit to react to sound.
Tapping on the microphone, quiet or high pitched sounds may
not activate the unit.
Fixture Cleaning: Due to fog residue, smoke, and dust cleaning the
internal and external optical lenses and mirror should be carried out
periodically to optimize light output. Cleaning frequency depends on
the environment in which the fixture operates (I.e. smoke, fog residue,
dust, dew). In heavy club use we recommend cleaning on a monthly
basis. Periodic cleaning will ensure longevity, and crisp output.
1. Use normal glass cleaner and a soft cloth to wipe down the out-
side casing.
2. Use a brush to wipe down the cooling vents and fan grill.
3. Clean the external optics and mirror with glass cleaner and a soft
cloth every 20 days.
4. Clean the internal optics with glass cleaner and a soft cloth every
30-60 days.
5. Always be sure to dry all parts completely before plugging the unit
back in.
American DJ® - www.americandj.com - Jellysh Instruction Manual Page 17 American DJ® - www.americandj.com - Jellysh Instruction Manual Page 18
Jellyfish Fuse Replacement
First unplug the power. The fuse holder is located next to the power
cord. Using a flat-head screw driver to unscrew the fuse holder.
Remove the bad fuse and replace with a new one.
Jellyfish 28 Channel DMX Traits
Channel Value Function
21 RED
1 - 255 0% - 100%
22 GREEN
1 - 255 0% - 100%
23 BLUE
1 - 255 0% - 100%
24 WHITE
1 - 255 0% - 100%
25 RED
1 - 255 0% - 100%
26 GREEN
1 - 255 0% - 100%
27 BLUE
1 - 255 0% - 100%
28 WHITE
1 - 255 0% - 100%
28 CHANNEL MODE: Each channel is 3 LEDs per Lens. i.e.
Channel 1 is 3 Red LEDs behind the rst lens, Channel 4 is 3
LEDs behind the second lens, .........

American DJ® - www.americandj.com - Jellysh Instruction Manual Page 19
Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Jellyfish Specifications
American DJ®
American DJ World Headquarters:
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: [phone] / Fax: [phone]
Web: www.americandj.com / E-mail: [email protected]
Model: Jellyfish
Voltage: 120v ~ 230v / 50Hz ~ 60Hz
LED: 84 x 5mm LEDs (21 Red, 21 Green, 21
Blue, & 21 White)
Power Draw: 9W (120v) / 13W (230v)
Fuse: 7A (120v & 230v)
Power Cord Daisy Chain: 46 Fixtures Max.
Beam Angle: 116 Degrees
Dimensions: 8”(L) x 12.5”(W) x 7.25”(H)
250mm x 317mm x 182mm
Weight: 4.4 Lbs. / 2.0kgs.
Colors: RGB & W
Duty Cycle: None
DMX: 2 DMX Channel Modes; 3 Channel
Mode & 28 Channel Mode
Sound Active: Yes
Working Position: Any Safe, Secure Position
Warranty: 3 Year (1095 days)
Jellyfish Warranty
MANUFACTURER’S LIMITED WARRANTY
A. American DJ, Inc. hereby warrants, to the original purchaser, American DJ and American
Audio products to be free of manufacturing defects in material and workmanship for a prescribed
period from the date of purchase (see specic warranty period on reverse). This warranty shall be
valid only if the product is purchased within the United States of America, including possessions
and territories. It is the owner’s responsibility to establish the date and place of purchase by ac-
ceptable evidence, at the time service is sought.
B. For warranty service you must obtain a Return Authorization number (RA#) before
sending back the product. Contact American DJ, Inc. Service Department at 800-322-6337. Send
the product only to the American DJ, Inc. factory. All shipping charges must be pre-paid. If the
requested repairs or service (including parts replacement) are within the terms of this warranty,
American DJ, Inc. will pay return shipping charges only to a designated point within the United
States. If the entire instrument is sent, it must be shipped in it’s original package. No accessories
should be shipped with the product. If any accessories are shipped with the product, American DJ,
Inc. shall have no liability whatsoever for loss of or damage to any such accessories, nor for the
safe return thereof.
C. This warranty is void if the serial number has been altered or removed; if the product is
modied in any manner which American DJ, Inc. concludes, after inspection, affects the reliability
of the product; if the product has been repaired or serviced by anyone other than the American DJ,
Inc. factory unless prior written authorization was issued to purchaser by American DJ, Inc.; if the
product is damaged because not properly maintained as set forth in the instruction manual.
D. This is not a service contract, and this warranty does not include maintenance, cleaning
or periodic check-up. During the period specied above, American DJ, Inc. will replace defec-
tive parts at its expense with new or refurbished parts, and will absorb all expenses for warranty
service and repair labor by reason of defects in material or workmanship. The sole responsibility
of American DJ, Inc. under this warranty shall be limited to the repair of the product, or replace-
ment thereof, including parts, at the sole discretion of American DJ. All products covered by this
warranty were manufactured after January 1, 1990, and bear identifying marks to that effect.
E. American DJ, Inc. reserves the right to make changes in design and/or improvements
upon its products without any obligation to include these changes in any products theretofore
manufactured. No warranty, whether expressed or implied, is given or made with respect to any
accessory supplied with products described above. Except to the extent prohibited by applicable
law, all implied warranties made by American DJ, Inc. in connection with this product, including
warranties of merchantability or tness, are limited in duration to the warranty period set forth
above. And no warranties, whether expressed or implied, including warranties of merchantability
or tness, shall apply to this product after said period has expired. The consumer’s and/or Dealer’s
sole remedy shall be such repair or replacement as is expressly provided above; and under no
circumstances shall American DJ, Inc. be liable for any loss or damage, direct or consequential,
arising out of the use of, or inability to use, this product.
This warranty is the only written warranty applicable to American DJ and American Audio
Products and supersedes all prior warranties and written descriptions of warranty terms and
conditions heretofore published.
MANUFACTURER’S LIMITED WARRANTY PERIODS:
• All American Audio Products = 1-year (365 day) Limited Warranty (except V-Plus Series Ampli-
ers)
• All American Audio V-Plus Series Ampliers = 3-year (1095 day) Limited Warranty
• American DJ Lighting and American DJ Branded Products = 1-year (365 day) Limited Warranty
(Such as: Special Effect Lighting, Intelligent Lighting, UV lighting, Strobes, Fog Machines, Bubble
Machines, Mirror Balls, Par Cans, Trussing, Lighting Stands etc. excluding Laser Products, lamps,
and Star Tec Series)
• American DJ Laser Products and Star Tec Products = 90-Day Limited Warranty
• American DJ L.E.D. Products = 3-year (1095 day) Limited Warranty (excluding motors which
have a 1-year (365 day Limited Warranty)
Auto Sensing Voltage: This xture contains a electronic bal-
last, which will auto sense the voltage when it is plugged into the
power source.
