CADET ELITE™CORNER
WHIRLPOOLS BY AMERICAN STANDARD
HIGH GLOSS ACRYLIC
CADET ELITE™CORNER WHIRLPOOL
Comfortable two person design with dual back
support positions, molded-in armrests and
generous faucet deck area.
❏2775E (specify White 020, Bone 021, or
Linen 222)
•Acrylic with fiberglass reinforcement
•2.0 HP self-draining pump/motor
with dry run seal
•Eight multi-directional and flow adjustable
jets including:
Two high performance Ideal-flow™Jets
Six interchangeable Flex-jets™
•Two silent air volume controls
•Deck-mounted On/Off control
•Complete factory installed and tested
whirlpool system
❏2775EC (specify White 020, Bone 021, or
Linen 222)
•Same as above with the StayClean™
whirlpool system featuring Antimicrobial
AlphaSan®
Nominal Dimensions: 60”x 60”x 19-3/4"
(1524 x 1524 x 502mm)
Installed Size: 85”x 60”x 19-3/4"
(2159 x 1524 x 502mm)
© 2003 American Standard Inc. HD-003
SPS 2775E
Revised 6/03
Components Needed:
❏Bath Filler*: (specify finish)
❏Bath Drain: BATH-DRAIN
(specify Chrome 002, Polished Brass 099,
or Satin 295)
Custom Accessories Available:
❏Pulse Jet Kit: PULSE-JET (two per kit,
specify White 020, Bone 021, or Linen 222)
❏Soft Jet Kit: SOFT-JET (two per kit, specify
White 020, Bone 021, or Linen 222)
❏E-Z-Install™Whirlpool Heater - EZHEAT-100
❏Tile Bead Kit: TILE-BEAD
NOTE: Roughing-in dimensions and product specifica-
tions shown on reverse side of page.
Compliance Certifications -
Meets or Exceeds the Following Specifications:
•Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
•ASME A112.19.7M for Whirlpool Appliances
•ANSI Z124.1 for Plastic Bathtubs
•ASTM E162 for Flammability
•NFPA 258 for Smoke Density
* See American Standard Faucet Selector
NOTE: E-Z-Install™Whirlpool Heater is designed to
maintain water temperature during operation. It will not
heat cold water to desired bathing temperature.

CADET ELITE™CORNER
WHIRLPOOLS BY AMERICAN STANDARD
HIGH GLOSS ACRYLIC
© 2003 American Standard Inc.
NOTES:
BATH CAN BE INSTALLED EITHER ABOVE OR BELOW FLOOR LINE AS PIER, ISLAND, OR PENINSULA TYPE
INSTALLATION. SUPPORT OF BATH BY SUMP BEDDING. SUPPORT AND ENCLOSING MATERIAL BY OTHERS.
REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.
OPTIONAL 2 WALL TILING BEAD KIT No. TILE-BEAD AVAILABLE AND MUST BE ORDERED SEPARATELY.
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.
IMPORTANT:
Dimensions of fixtures are nominal and may vary within the range of tolerances established by ANSI Standard
Z124.1/A112.19.7M.
These measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or
voided leaflet.
■
1524mm
(60)
70mm REF.
(2-3/4)
165mm
(6-1/2)
279mm
(11)
RECOMMENDED
FITTING LOCATION
64 X 330mm (2-1/2 X 13)
229 X 305mm
(9 X 12)
CUTOUT IN
FLOOR FOR
DRAIN
ON/OFF
SWITCH
PROVIDE ACCESS
TO PUMP FOR
SERVICING ON ALL
INSTALLATIONS
OUTLINE OF
CUTOUT
2159mm
(85)
1080 mm
(42-1/2)
C/L
1524mm
(60)
1076mm
(42-3/8)
1080mm
(42-1/2)
PUMP
C/L OF
DRAIN OUTLET
1-1/2 O.D. TAILPIECE
LEVELING STRINGER
NOT FOR SUPPORT
70mm
(2-3/4)
117mm
(4-5/8)
1-1/2 N.P.T.M.
THREADS
38 mm REF.
(1-1/2)
C/L OF
OVERFLOW 76mm
(3)
464mm
(18-1/4)
502mm
(19-3/4)
ROUGH
FLOOR
INTEGRAL
SUPPORT
FEET
IN-LINE
HEATER
REMOVABLE
BLANK
85 X 60 X 19-3/4In.
(2159mm X 1524 mm X 502mm)
130 Lbs. (59 Kg.)
756 Lbs. (343 Kg.)
75 Gal. (284 L.)
60 Gal. (227 L.)
32 X 32 In. (813 mm X 813 mm)
46 X 46 In. (1168 X 1168mm)
14 In. (356 mm)
34 Lbs./Sq. Ft. (115 Kgs/Sq. m.)
41.7
70.4
GENERAL SPECIFICATIONS FOR 2775E WHIRLPOOL
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
MIN. OPERATING GAL.
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT
3
)
WHIRLPOOL ELECTRICAL SPECIFICATIONS
2.1 HP, 14.4 AMPS, 120V.PUMP
