American Standard Cadet 2772.002 User manual

CADET™5’X 42”
WHIRLPOOL & BATHING POOL
HIGH GLOSS ACRYLIC
CADET™5’X 42”WHIRLPOOL & BATHING
POOL
❏2772.018W Whirlpool featuring System I
•Acrylic with fiberglass reinforcement
•Pre-leveled tub bottom
•Form-fitted backrest position
•Dual, molded in arm rests
•1.5 HP single speed, self-draining pump/motor
•Factory installed power cord with plug
•Eight multi-directional and flow-adjustable
jets including:
- Two Ideal-flow jets
- Four body massage jets
- Two recessed back-rest jets
•Deck-mounted air switch On/Off
•Two silent air volume controls
•Quick Connect Safe-T-Heater connection
system
•Factory installed and tested whirlpool system
❏2772.018WC Stay Clean™Whirlpool Massage
Featuring System I:
•Same as 2772.018W except with the
StayClean™whirlpool system featuring
Antimicrobial AlphaSan®
❏2772.002 Bathing Pool only
Nominal Dimensions: 1524 x 1067 x 502mm
(60”x 42”x 19-3/4")
© 2003 American Standard Inc. BV-24
NOTE: Roughing-in dimensions and product
specifications shown on reverse side of page.
Rev. 3/03
Compliance Certifications -
Meets or Exceeds the Following Specifications:
•Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
•ASME A112.19.7M for Whirlpool Appliances
•ANSI Z124.1 for Plastic Bathtubs
•ASTM E162 for Flammability
•NFPA 258 for Smoke Density
To Be Specified - Required:
❏Color:
❏Bath Filler: (specify finish)
❏Bath Drain: 1583.470 (specify finish)
To Be Specified - Optional:
❏Safe-T-Heater*: 9075.120
❏5 Foot Acrylic Apron: 9360.018(specify color)
❏5 Foot Apron: 9260.018 (specify color)
❏Jet Trim Ring Kit: 9860.200-two per kit
(Specify finish)
❏Universal Tile Bead Kit: 751755-100
❏Grab Bar Kit: 9822.200-two per kit (specify finish)
For color/finish availability and other faucet choices,
please see the Product Selector and Pricing Guide.
* NOTE: the Safe-T-Heater is designed to maintain water
temperature during operation. It will not heat cold water to
desired bathing temperature.

CADET™5’X 42”
WHIRLPOOL & BATHING POOL
HIGH GLOSS ACRYLIC
© 2003 American Standard Inc.
OUTLINE OF CUTOUT
1486mm x 1029mm
(58-1/2 X 40-1/2)
RECOMMENDED FITTING LOCATION
76 X 330mm (3 x 13")
FOR PIER OR ISLAND
INSTALLATIONS ONLY
ALT. FITTING LOCATION
464 mm
(18-1/4)
38 mm
(1-1/2)
502 mm
(19-3/4)
1-1/2 O.D.TAILPIECE
■ LEVELING
STRINGER
NOT FOR
SUPPORT
ROUGH
FLOOR
1524mm
(60)
1067mm
(42) 533mm
(21)
235 mm
(9-1/4)
305 mm
(12)
57 mm
(2-1/4) (8) JETS
76mm
(3)
CUTOUT IN FLOOR
FOR DRAIN PUMP
FINISHED
WALL
305mm
(12)
OPTIONAL TO
FINISHED FLOOR
USUALLY BETWEEN
1651 & 1981mm
(65 & 78) C/L OF
OVERFLOW
102 mm
(4)
C/L OF
SPOUT
C/L OF
VALVES
C/L OF
SHOWER ARM
70 mm
(2-3/4) 117 mm
(4-5/8)
1-1/2 N.P.T.M.
THREADS
19 mm
(3/4)
229 mm
(9)
C/L OF
SUPPLIES
C/L OF DRAIN
SEE FITTING
SPECS FOR
DIMENSIONS
(2) AIR VALVES
ON/OFF
SWITCH
PROVIDE ACCESS TO PUMP FOR
SERVICING ON ALL INSTALLATIONS
INTEGRAL
SUPPORT
FEET
SAFE-T-HEATER
REMOVABLE
BLANK
OUTLINE OF CUTOUT
1473 mm x 1016mm
(58 X 40)
RECOMMENDED FITTING LOCATION
76 X 330mm (3 x 13")
FOR PIER OR ISLAND
INSTALLATIONS ONLY
ALT. FITTING LOCATION
464 mm
(18-1/4)
38 mm
(1-1/2)
502 mm
(19-3/4)
1-1/2 O.D.TAILPIECE
INTEGRAL
SUPPORT
FEET
■ LEVELING STRINGER
NOT FOR SUPPORT
ROUGH
FLOOR
1524 mm
(60)
1067 mm
(42) 527 mm
(20-3/4)
250 mm
(9-3/4)
305 mm
(12)
57 mm
(2-1/4)
89 mm
(3-1/2)
CUTOUT IN FLOOR
FOR DRAIN
FINISHED
WALL
305 mm
(12)
OPTIONAL TO
FINISHED FLOOR
USUALLY BETWEEN
1651 & 1981mm
(65 & 78) C/L OF
OVERFLOW
102 mm
(4)
C/L OF
SPOUT
C/L OF
VALVES
C/L OF
SHOWER ARM
70 mm
(2-3/4) 117 mm
(4-5/8)
1-1/2 N.P.T.M.
THREADS
19 mm
(3/4)
229 mm
(9)
C/L OF
SUPPLIES
C/L OF DRAIN
SEE FITTING
SPECS FOR
DIMENSIONS
60 x 42 x 19-3/4 In.(1524 x 1067 x 502mm)
117 Lbs. (53 Kg.)
642 Lbs. (289 Kg.)
63 Gal. 239 L.)
54 Gal. (204 L.)
40 x 26 In. (1016 x 660 mm)
52 x 32-1/2 In. 1321 x 826 mm)
13-1/4 In. (337 mm)
37 Lbs./Sq. Ft. (182 Kgs/Sq. m.)
27.8
45.4
GENERAL SPECIFICATIONS FOR 2772 WHIRLPOOL
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
MIN. OPERATING GAL.
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
WHIRLPOOL ELECTRICAL SPECIFICATIONS
1.6 HP, 9.7 AMPS, 120V.SYSTEM I PUMP
60 x 42 x 19-3/4 In.
(1524mm x 1067mm x 502mm)
92 Lbs. (41 Kg.)
617 Lbs. (278 Kg.)
63 Gal. (239 L.)
40 x 26 In. (1016 x 660 mm)
52 x 32-1/2 In. 1321 x 826 mm)
13-1/4 In. (337 mm)
36 Lbs./Sq. Ft. (175 Kgs/Sq. m.)
27.8
45.4
GENERAL SPECIFICATIONS FOR 2772 BATHING POOL
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
NOTES:
BATH CAN BE INSTALLED EITHER ABOVE OR BELOW FLOOR LINE AS PIER, ISLAND, OR PENINSULA
TYPE INSTALLATION. SUMP OF BATH IS SUPPORTED BY INTEGRAL FEET. NO ADDITIONAL SUPPORT
REQUIRED. ENCLOSING MATERIAL BY OTHERS.
REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL
INFORMATION.
OPTIONAL 3 WALL TILING BEAD. KIT AND APRON No. 9260.018 or 9360.018 AVAILABLE AND MUST BE
ORDERED SEPARATELY.
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.
IMPORTANT:
Dimensions of fixtures are nominal and may vary within the range of tolerances established by ANSI
Standard Z124.1
These measurements are subject to change or cancellation. No responsibility is assumed for use of
superseded or voided leaflet.
■
