American Standard Cadet 3099.016 Operating and safety instructions

M46
© 2008 AS America Inc. Revised 2/08
To Be Specied:
❏ Color: ❏ White ❏ Bone ❏ Linen
❏ Silver ❏ Fawn Beige ❏ Black
❏ Seat: American Standard #5324.019 “Rise and
Shine" (with easy to clean lift-off hinge system)
solid plastic closed front seat with cover.
❏ Seat: American Standard #5311.012 “Laurel"
molded closed front seat with cover.
❏ Alternate Seat:
❏ Supply with Stop:
* Flushmate III tank system by Flushmate® Div. of Sloan Valve Co
CADET™ ELONGATED
PRESSURE-ASSISTED TOILET
VITREOUS CHINA
CADET™ ELONGATED
PRESSURE-ASSISTED TOILET
❏ 2333.100
• Vitreous china
• Low-consumption (6.0 Lpf/1.6 gpf)
• Elongated bowl
• Pressure-assisted siphon jet ush action
• Fully-glazed 2" ballpass trapway
• 10" x 12" water surface area
• Side-mounted chrome trip lever
• Close-coupled ushometer tank*
• Speed Connect® tank/bowl coupling system
• 2 bolt caps
• 100% factory ush tested
❏ 3099.016 Bowl with two bolt caps
❏ 4098.100 Tank complete with
coupling components
Nominal Dimensions:
787 x 495 x 737mm
(31" x 19-1/2" x 29")
Fixture only, seat and supply by others
Recommended working pressure range
20 psi - 80 psi
Alternate Congurations Available:
❏ 3099.203 Elongated bowl only with slotted
rim for bedpan holding
❏ 4098.700 Tank and tank cover only with tank
cover locking device
❏ 4098.800 Tank and tank cover only with right
hand trip lever
❏ 4098.900 Tank complete with right hand trip
lever and tank cover locking device
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.2 for Vitreous China Fixtures
NOTES:
THIS COMBINATION IS DESIGNED TO ROUGH-IN AT A MINIMUM DI-
MENSION OF 305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
FOR ADDITIONAL INFORMATION REFER TO INSTALLATION
INSTRUCTIONS SUPPLIED.
IMPORTANT: Dimensions of xtures are nominal and may vary within
the range of tolerances established by ANSI Standard A112.19.2. These
measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided pages.
12
(305mm)
31
(787mm)
C/L OF OUTLET
3-1/4
(83mm)
FINISHED WALL
225mm
(8-7/8)
3/4 ±1/4
(19mm ±6mm)
14
(356mm)
18-1/2
(470mm)
C/L OF SEAT POST HOLES
5-1/2 (140mm CENTERS)
13
(330mm)
5-3/4
(146mm)
5/8
(16mm) FINISHED
FLOOR
29
(737mm)
9-3/4
(248mm)
6
(152mm)
19-1/2
(495mm)
8
(203mm)
SUPPLY
AS
REQ'D
15
(381mm)
*
*
