American Standard Enfield Console Table 7460.100 Instruction manual

752877-100 REV. A
Product names listed herein are trademarks of American Standard Inc.
© American Standard Inc. 2002
ASSEMBLY & INSTALLATION
INSTRUCTIONS
Enfield Console Table
7460.100 With Raised Wood Panels
7460.200 With Cast Grilles
- 1 -
Recommended Tools & Materials Roughing-in Dimensions
Thank you for selecting our products...products which have been the benchmarks of fine quality for over 100 years.
To help insure that the installation process will proceed smoothly, please read these instructions carefully before you
begin. Also, review the recommended tools and materials list; carefully unpack and examine your new plumbing fixture.
Adjustable Wrench
Channel Locks
Phillips Screwdriver
Putty Knife
Regular Screwdriver
Drill
Saber Saw
Level
Basin Wrench
Plumbers' Putty or
Caulking
Tubing Cutter
10'
Tape
Measure
Hacksaw
Pipe Wrench
™
To maintain the beauty of the finish, avoid placing the furniture in direct sunlight, as sunlight causes fading. Also avoid
extreme changes in temperature by arranging furniture away from radiators, heat and air vents, and air conditioning units.
Avoid placing furniture directly under windows.
7460.100
7460.200
6860.725 Bakersfield White or
6860.722 Autumn Spray 0740 Enfield
CONSOLE TABLE VANITY TOP-GRANITE RECOMMENDED SINK
25-1/4
(641mm)
8" *
(203mm) 4" *
(102mm)
14-1/8
(359mm)
16-1/4
(413mm)
29
(737mm)
LEG ANCHORING
SCREW HOLES
5/16 (8mm) DIA.
(TYP. 4 PLACES)
22 REF.
(559mm)
34
(864mm)
1-1/4
(32mm)
6-1/4
(159mm)
*12-3/4
(324mm)
12-1/4
(811mm)
11-1/4
(286mm)
7
(178mm)
FINISHED
FLOOR
8
(203mm)
25-3/4 REF.
(654mm)
1-1/4 O.D.
WASTE
1-1/4 O.D.
TAILPIECE
SUPPLIES
AS REQ'D
SEALING
COMPOUND
1-1/8" (30mm) THK.
GRANITE SURFACE
SATIN SWALLTAIL
LAPPER
CAST METAL
DESIGN INSERT
PANELED INSERT
L of Faucet **
C

752877-100 REV. A
- 2 -
C/L of 2 x 6
Reinforcement
Finished
Floor
30"
762mm
Identify desired location of the console table.
Provide suitable reinforcement required for anchoring the vanity to the wall. Centerline of reinforcement should be 30" up
from the floor (see Figure 1).
Rough in supply lines and waste per rough in dimensions.
Drill at least two 3/8" O.D. anchoring holes through the rear stringer of the console table at 2-1/2" down from the top of
the table (see Figure 2).
Move the vanity into place and level with the adjustable glides on the bottom of the feet. The glides can be adjusted
outward up to 3/8". Anchor it to the wall through the 2 anchoring holes in the rear of the vanity (see Figure 2). Do not
overtighten to prevent cracking the rear stringer.
VANITY TOP, SINK, AND FAUCET INSTALLATION
Install the faucet onto the granite top per the manufacturer's instructions.
Two people recommended for this installation
CONSOLE TABLE INSTALLATION
FIGURE 1
FIGURE 2
MOLDING
ADJUSTABLE
GLIDES
(LOCATED
UNDER
EACH FOOT) 3/8" ANCHORING
HOLES IN
REAR STRINGER
2-1/2"
64mm
19-1/4"
489mm
GRANITE TOP
SEALANT
Apply a continuous 1/8" bead of silicone
sealant 1" from the inside edge of the
console. Carefully set the stone top on the
console table. Be sure that the top is
centered on the table.
Use mineral spirits to remove excess silicone from the console and stone top.

752877-100 REV. A
- 3 -
AB
POST INSTALLATION CLEAN-UP
Care and Cleaning of the Console Table
Clean the product by using soft, slightly damp cloth. Buff the product by using a soft dry cloth. Avoid using silicone
cleaners and waxes.
Clean up excess water and spills immediately. Use a blotting rather than a wiping action. Water left over a long
period of time will cause white spots in the finish.
NOTE: Please note that some chemicals may damage the finish. Take care to avoid the following: iodine, hair dye,
after shave lotion, shaving cream, alcohol, perfume, Lestoil®, Lysol Tub and Tile Cleaner®, Lysol Spray Disinfectant®,
Dow Disinfectant®, acetone, paint remover, Formula 409®, Tile-X®, and Nair®.
Care and Cleaning of the Granite Vanity Top
A solution of 1/4 part vinegar and 3/4 parts water is excellent for general cleaning of your stone table top. Do not use
abrasive or thick cream cleaning solutions. Common stains such as red wine or mustard should not remain on the
stone top for an extended length of time. For additional protection, commercial sealers for marble are available.
Remove all construction debris from the sink and console top. Do not use wire brushes or any other metal implement on
sink and console top surfaces. Post installation clean-up generally can be completed using warm water and liquid
dishwashing detergent. Stubborn dirt or stains may be removed using franular Spic and Span®mixed with water. Painter's
naphtha can be used to remove excess adhesives and/or wet oil-base paint.
Install the sink on the granite top using sealant. Add
or remove excess compound around the base of sink
rim. Form fillet the sealant with wet finger or sponge.
Mount the drain assembly to the sink. Be certain to apply
a bead of sealing putty on the underside of the drain (area
"A") in order to ensure a watertight seal between the sink
and drain. Remove excess putty.
A
SEALANT
After installing the sink, connect the trap to the drain assembly and
hand tighten to check alignment. It may be necessary to cut off part
of the tailpiece (area "A") or part of the horizontal leg of the trap (area
"B").
Connect hot and cold supply lines to the shut off valves. Tighten trap
joints for watertight assembly.

752877-100 REV. A
- 4 -
In the United States:
American Standard Inc.
P.O. Box 6820
Piscataway, New Jersey 08855
Attention: Director of Consumer Affairs
For residents of the United States, warranty information
may also be obtained by calling the following
toll free number: [phone]
In Canada:
American Standard
2480 Stanfield Rd.
Mississauga, Ontario
Canada L4Y 1S2
Toll Free: [phone]
In Mexico:
Customer Service Manager
Ideal Standard, S.A. de C.V.
Via Morelos #330
Col. Santa Clara
Ecatepec 55540 Edo. Mexico
AMERICAN-STANDARD GRANITE/MARBLE TABLE TOP WARRANTY
If inspection of this American-Standard plumbing product, within one year after its initial purchase, confirms that it is defective in materials or workmanship,
American-Standard will repair or, at its option, exchange the product for a similar model. Variations in shading, veining, and texture which may result from
natural characteristics of stone and as such are not defects and are not covered by this warranty.
This warranty applies only to the original purchaser and installation of these products.
This limited warranty does not apply to local building code compliance. Since local building codes vary considerably, the purchaser of this product should
check with a local building or plumbing contractor to insure local code compliance before installation.
This warranty shall be void if the product has been moved from its initial place of installation; if it has been subjected to faulty maintenance, abuse, misuse,
accident or other damages; if it was not installed in accordance with American-Standard’s instructions; or if it has been modified in a manner inconsistent
with the product as shipped by American-Standard.
American-Standard’s option to repair or exchange the product under this warranty does not cover any labor or other costs of removal or installation, nor
shall American-Standard be responsible for any other incidental or consequential damages attributable to a product defect or to the repair or exchange of a
defective product, all of which are expressly excluded from this warranty. (Some states or provinces do not allow the exclusion or limitation of implied
warranties, so this exclusion may not apply to you).
This warranty gives you specific legal rights. You may have other statutory rights that vary from state to state or province to province, in which case this
warranty does not affect such statutory rights.
AMERICAN-STANDARD WOOD FURNITURE WARRANTY
If inspection of this American-Standard plumbing product, within one year after its initial purchase, confirms that it is defective in materials or workmanship,
American-Standard will repair or, at its option, exchange the product for a similar model. Variations in actual wood color and finishes which may result from
natural characteristics of the wood, such as grain patterns, mineral streaks and the like, are not defects and are not covered by this warranty.
This warranty applies only to the original purchaser and installation of these products.
This limited warranty does not apply to local building code compliance. Since local building codes vary considerably, the purchaser of this product should
check with a local building or plumbing contractor to insure local code compliance before installation.
This warranty shall be void if the product has been moved from its initial place of installation; if it has been subjected to faulty maintenance, abuse, misuse,
accident or other damages; if it was not installed in accordance with American-Standard’s instructions; or if it has been modified in a manner inconsistent
with the product as shipped by American-Standard.
American-Standard’s option to repair or exchange the product under this warranty does not cover any labor or other costs of removal or installation, nor
shall American-Standard be responsible for any other incidental or consequential damages attributable to a product defect or to the repair or exchange of a
defective product, all of which are expressly excluded from this warranty. (Some states or provinces do not allow the exclusion or limitation of implied
warranties, so this exclusion may not apply to you).
This warranty gives you specific legal rights. You may have other statutory rights that vary from state to state or province to province, in which case this
warranty does not affect such statutory rights.
REPAIR PARTS
730679-0070A
752686-3300A
752686-3340A
752679-0070A
Adjustable Threaded Foot Glide (4 per pack)
Cherry Wood Panel Kit (2 side and 1 front panel and screws)
Maplewood Panel Kit (2 side and 1 front panel and screws)
Cast Grille Kit (2 side and 1 front grille and screws)
