CHAMPION® SELECT
ROUND FRONT TOILET
VITREOUS CHINA
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
*DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
IMPORTANT: Dimensions of xtures are nominal and may vary within the
range of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided pages.
FINISHED WALL
19mm ± 6mm
(1 ± 1/4)
387mm
(15-1/4)
FINISHED
FLOOR
305mm
(12)
721mm
(28-3/8)
C/L OF OUTLET
83mm
(3-1/4)
216mm
(8-1/2)
419mm
(16-1/2)
C/L OF SEAT POST HOLES
140mm (5-1/2 CENTERS)
362mm
(14-1/4)
264mm
(10-3/8)
16mm
(5/8)
841mm
(33-1/8)
489mm
(19-1/4)
SUPPLY
AS
REQ'D
254mm
(10)
152mm
(6)
254mm
(10)
356mm
(14)
*
To Be Specied:
❏Color:
❏White ❏Bone ❏Silver ❏Linen ❏Black
❏Seat: (please specify color)
❏Champion®Slow Close Round Front #5330.010
❏Rise & Shine Round Front #5322.011
❏Laurel Round Front #5308.014
❏Supply with stop:
Revised 5/06
CHAMPION®SELECT ROUND FRONT TOILET
❑2035.212
• Vitreous china
• EverClean™ anti-microbial glaze
(available Summer 2006)
• Low-consumption (6.0 Lpf/1.6 gpf)
• Features Champion® Flushing System
performance platform
• 3" non-adjustable, apper-free ush valve
• Round Front siphon action jetted bowl
• 2-3/8" fully-glazed trapway
• Speed Connect™ tank/bowl coupling system
• Chrome-plated trip lever
• Sweeping pier on bowl
• 100% factory ush tested
• 2 bolt caps
• 10 year warranty
❑3110.016 Round Front Bowl
❑4272.216 Tank
Nominal Dimensions:
721 x 489 x 841mm
(28-3/8" x 19-1/4" x 33-1/8")
Fixture only, seat and supply by others
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.2M for Vitreous China Fixtures -
includes Flush Performance, Ball Pass Diameter,
Trap Seal Depth and all Dimensions
• Los Angeles Department of Water and Power
Supplementary Purchase Specication for
Non-Adjustability - July, 2003 revision
