American Standard Colony Set Two-Handle Centerset Bar Sink Faucet... User manual

A59
© 2008 AS America Inc.
COLONY SOFT
TWO-HANDLE CENTERSET BAR SINK FAUCET
WITH BRASS GOOSENECK SPOUT
GENERAL DESCRIPTION:
Durable brass construction. 1/4 turn washerless ceramic
disc valve cartridges. One-half inch male inlet shanks
with brass coupling nuts. Brass gooseneck swivel spout.
2.2gpm/8.3L/min. maximum flow rate.
PRODUCT FEATURES:
Ceramic Disc Valve Cartridges: Assures a lifetime of
drip-free performance.
Solid Brass Construction: Durable. Ideal for prolonged
contact with water.
Low Lead: Meets NSF Standard 61/Section 9 & Prop 65
lead requirements.
Choice of Finishes: Available in Polished Chrome or Satin
Nickel (PVD).
MODEL NUMBER:
2475.500 Centerset Bar Sink Faucet
Lever handles.
SUGGESTED SPECIFICATION:
Centerset bar sink faucet shall feature brass construction with brass inlet shanks and brass coupling nuts. Shall also feature
1/4 turn washerless ceramic disc valve cartridges. Fitting shall be American Standard Model # 2475.500.___.
2475.500
Product
Number Description
Bar Sink faucet. Lever handles.
Finish Options
PVD
Satin
Nickel
295
Polished
Chrome
002
Meets the American Disabilities Act Guidelines
and ANSI A117.1 Requirements for the
physically challenged.
127mm
(5)
181mm
(7-1/8)
332mm
(13-1/16)
74mm
(2-7/8)
FLOW RATE*
GALLONS PER MINUTE
INLET PRESSURE (PSI)
*Flow rates shown are for mixed hot and cold.
0.0
0.5
1.0
1.5
2.0
2.5
3.0
10080604020
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ANSI A117.1
ASME A112.18.1
CSA B 125
NSF 61/Section 9
30mm
(1-1/4)
35mm - 38mm
(1-3/8" to 1-1/2")
DIA. MOUNTING
HOLES (2)
25.4mm
(1-1/16)
1/2
NPSM

A60
© 2008 AS America Inc.
COLONY SOFT
TWO-HANDLE CENTERSET BAR SINK FAUCET
WITH BRASS GOOSENECK SPOUT
GENERAL DESCRIPTION:
Durable brass construction. 1/4 turn washerless ceramic
disc valve cartridges. One-half inch male inlet shanks
with brass coupling nuts. Brass gooseneck swivel spout.
2.2gpm/8.3L/min. maximum flow rate.
PRODUCT FEATURES:
Ceramic Disc Valve Cartridges: Assures a lifetime of
drip-free performance.
Solid Brass Construction: Durable. Ideal for prolonged
contact with water.
Low Lead: Meets NSF Standard 61/Section 9 & Prop 65
lead requirements.
Choice of Finishes: Available in Polished Chrome or Satin
Nickel (PVD).
MODEL NUMBER:
2475.500 Centerset Bar Sink Faucet
Lever handles.
SUGGESTED SPECIFICATION:
Centerset bar sink faucet shall feature brass construction with brass inlet shanks and brass coupling nuts. Shall also feature
1/4 turn washerless ceramic disc valve cartridges. Fitting shall be American Standard Model # 2475.500.___.
2475.500
Product
Number Description
Bar Sink faucet. Lever handles.
Finish Options
PVD
Satin
Nickel
295
Polished
Chrome
002
Meets the American Disabilities Act Guidelines
and ANSI A117.1 Requirements for the
physically challenged.
127mm
(5)
181mm
(7-1/8)
332mm
(13-1/16)
74mm
(2-7/8)
FLOW RATE*
GALLONS PER MINUTE
INLET PRESSURE (PSI)
*Flow rates shown are for mixed hot and cold.
0.0
0.5
1.0
1.5
2.0
2.5
3.0
10080604020
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ANSI A117.1
ASME A112.18.1
CSA B 125
NSF 61/Section 9
30mm
(1-1/4)
35mm - 38mm
(1-3/8" to 1-1/2")
DIA. MOUNTING
HOLES (2)
25.4mm
(1-1/16)
1/2
NPSM
