American Standard Cadet 0236.004 User manual

J16
© 2008 AS America Inc.
CADET™
PEDESTAL SINK
VITREOUS CHINA
NOTES:
* DIMENSIONS SHOWN FOR LOCATION OF SUPPLIES AND “P" TRAPS
ARE SUGGESTED.
▼ PEDESTAL ANCHORING SCREWS NOT INCLUDED.
■ SUITABLE FOR REINFORCEMENT ONLY. ACTUAL DIMENSIONS MUST
BE TAKEN FROM FIXTURE.
FITTING NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL WALL SUPPORTS.
INSTALLATION INSTRUCTIONS SUPPLIED WITH LAVATORY.
IMPORTANT: Dimensions of xtures are nominal and may vary within the
range of tolerance established by ANSI Standard A112.19.2
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided pages.
102 mm
(4)
86mm
(3-3/8)
508mm
(20) FINISHED
WALL
191mm
(7-1/2)
508mm
(20)
622mm
(24-1/2)
PEDESTAL
ANCHORING
SCREW HOLES
8 mm (5/16) DIA.
305mm REF.
(12)
6mm
(1/4)
889mm
(35)
635mm
(25)
533mm
(21-1/2)
FINISHED
FLOOR
SUPPLIES AS
REQUIRED
8mm (5/16)
DIA. SCREW
ANCHOR HOLES
203mm
(8)
1-1/4 O.D.
WASTE
1-1/4 O.D.
TAILPIECE
203mm
(8)
203mm
(8)
178mm
(7)
*
*
PEDESTAL
SIDE SECTION
DRAIN
CHASE
OPEN
TO
FLOOR
To Be Specied:
❏ Color: ❏ White ❏ Bone ❏ Linen
❏ Silver ❏ Fawn Beige ❏ Black
❏ Faucet:
❏ Faucet Finish:
❏ Supplies:
❏ 1-1/4" Trap:
CADET™ PEDESTAL SINK
• Classic vitreous china lavatory and pedestal
• Rear overow
• Faucet ledge with generous shelf area
• Supplied with mounting kit
❏ 0236.411 Faucet holes on 4" (102mm) centers
(Illustrated)
❏ 0236.811 Faucet holes on 8" (203mm) centers
❏ 0236.111 Center hole only
Nominal Dimensions:
622 x 508 x 889mm
(24-1/2" x 20" x 35")
Separate Components:
❏ 0236.004 Pedestal top - 4" (102mm) centers
❏ 0236.008 Pedestal top - 8" (203mm) centers
❏ 0236.001 Pedestal top - Center hole only
❏ 731100-400 Pedestal base only
Bowl Sizes:
508mm (20") wide
305mm (12") front to back
152mm (6") deep
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.2M for Vitreous China Fixtures
