American Standard EVERCLEAN / EVOLUTION 422L418C Operating instructions

1
MODEL 2422L418C / 2422V418C 5' x 32"
MODEL 2771L418C / 2771V418C 5' x 36"
MODEL 2645L418C / 2645V418C OVAL
MODEL 7236L418C / 7236V418C 6' x 36"
MODEL 2425L618C / 2425V618C 5' x 32" IA-LHO
MODEL 2425L518C / 2425V518C 5' x 32" IA-RHO
EVERCLEAN®/ EVOLUTION®
COMBINATION TUBS
Installation and
Operation Guide
ATTENTION INSTALLER:
Please deliver this manual to homeowner.
THANK YOU...
for selecting an American Standard bath. Your new bath is shipped to you after careful inspection. The whirlpool
version is completely assembled with pump, motor, and system piping. All you need to finish the whirlpool
installation are your selected fittings and electrical connections.
To ensure maximum performance and pleasure from this product, please follow the instructions and cautions.
FOR AFTER-SALES SERVICE CALL 1 [phone] WEEKDAYS.
© AS America, Inc. 2014
Product names listed herein are trademarks of AS America, Inc.
All information in this manual is based on the latest product information available at the time of publication.
American Standard Inc. reserves the right to make changes in product characteristics, packaging, or
availability at any time without notice.
754679-100 Rev. A

2
754679-100 Rev. A
TABLE OF CONTENTS:
Safety Instructions...............................................................................Page 3
General Information.............................................................................Page 4
Optional Components..........................................................................Page 4
Specifications......................................................................................Page 5
Roughing-in Reference...................................................................Pages 6-7
Framing and Support Instructions.......................................................Page 8
Mounting Instructions..........................................................................Page 9
Electrical Connections.......................................................................Page 10
Remote Blower Location...................................................................Page 11
Operation...................................................................................Pages 12-14
Drain Connection and System Test...................................................Page 15
Care and Cleaning.............................................................................Page 15
Warranty............................................................................................Page 16

3
!
!
!
!
!
!
!
SAVE THESE INSTRUCTIONS
WARNING: Risk of personal injury. Do not permit children to use this unit without adult supervision.
WARNING: Risk of personal injury. Do not operate this unit without the guard over the suction fitting.
WARNING: Risk of electric shock. Do not permit electrical appliances (hair dryer, telephone, radio, etc.) within
60 inches (1524mm) of this unit.
WARNING: Risk of hyperthermia and possible drowning. People using medications and/or having adverse
medical history should consult a physician before using this product.
WARNING: Risk of personal injury. Do not overfill unit before entering. Entering tub when filled more than 2/3
can cause overflow and slippery conditions. Exercise caution when entering and exiting.
WARNING: No Food or Alcoholic Beverages. Use of your bathtub immediately after meals is not
recommended. Avoid alcohol consumption before or during bathing. Alcoholic beverages can cause drowsiness or
hyperthermia resulting in loss of consciousness or even drowning.
WARNING: Pregnancy. If you are or think you may be pregnant, consult your physician before using the bathtub.
Never drop or insert any object into any opening.
Use this unit only for its intended use as described in this manual. Do not use any attachments not recommended by
American Standard.
The unit must be connected only to a supply circuit that is properly protected by a ground-fault circuit-interrupter
(GFCI). Such a GFCI should be provided by the installer and should be tested on a routine basis. To test the GFCI,
push the test button. The GFCI should interrupt power. Push the reset button. Power should be restored. If the GFCI
fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to the bathtub without the test button
being pushed, a ground current is flowing, indicating the possibility of an electric shock. Do not use this hydromassage
bathtub. Disconnect the hydromassage bathtub and have the problem corrected by a licensed electrician before using.
A pressure wire connector is provided on the exterior of the motor unit to permit connection of a no. 8 AWG solid
copper bonding conductor between this unit and all other electrical equipment and exposed metal in the vicinity, as
needed to comply with local requirements. To reduce the risk of an electric shock, connect this connector the
grounding terminal of your electric service or supply panel with a conductor equivalent in size to the circuit conductors
supplying this unit.
IMPORTANT SAFETY INSTRUCTIONS
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, ELECTRIC SHOCK
OR INJURY TO PERSONS
READ AND FOLLOW ALL INSTRUCTIONS!
754679-100 Rev. A

4
754679-100 Rev. A
Everclean
®
/Evolution
®
5' x 32"
Everclean
®
/Evolution
®
5' x 36"
Everclean
®
/Evolution
®
6' x 36"
Everclean
®
/Evolution
®
5' x 32" IA
Everclean
®
/Evolution
®
Oval
2422
2771
7236
2425
2645
√
√
√
√
√
9261.019
9261.019
9271.019
INTEGRAL
9266.018
√
√
√
N/A
√
1599.500.020*
1599.500.020*
1599.500.020*
1599.500.020*
1599.500.020
Optional Components
(Not Included)
Required Components
(Not Included)
E-Z
Install
Heater
Apron
Kit
Tile
Bead
Kit
1599.205.XXX*
1599.205.XXX*
1599.205.XXX*
1599.205.XXX*
1583.470.XXX
Drain •
(Specify
Finish)
Drain •
(White)
List of Required Tools and Supplies:
Tools
• Level
• Tape Measure
• Pipe Wrench
• Slip Joint Pliers
• Screw Driver
• Standard Woodworking Tools
• Personal Safety Equipment
• Caulking Gun
Supplies
• Nails
• Putty
• Caulking (waterproof)
• 1 x 4 Stringers
• Drop Cloth
• Cement, Plaster, Grout
General Installation Information
Carefully uncrate and inspect your new bath for any shipping damage. If such damage is found, report it to your
vendor immediately. After inspection and during installation, protect the bath from construction damage. Before
installation, and before enclosing with wallboard, tile, etc., the bath must be filled with water and operated to
check for leaks that may have resulted from shipping damage or mishandling ! Do not make modifications to
the whirlpool system or remove pump from factory mounting. This could adversely affect the safety and performance
of the whirlpool and void the warranty. Do not handle or move the whirlpool by the pump, motor, or piping system.
Fittings (bath filler, shower arm, etc.) are not provided with the bath and must be ordered separately. Framing and
enclosing materials are provided by others.
For electrical requirements, refer to section titled “Whirlpool Electrical Installation Instructions”.
Check for availability of optional American Standard wall tiling bead (required for recess installation).
Protect all finished surfaces of the whirlpool during construction and installation using a drop cloth.
Description Model
Number
LIST OF OPTIONAL COMPONENTS (NOT INCLUDED):
• For these components please see your Vendor.
*These models require American Standard Lifetime
®
Drain 1599.205 or 1599.500
!WARNING: Do not lift whirlpool by the piping harness at any time.

754679-100 Rev. A
5
SPECIFICATIONS:
GENERAL SPECIFICATIONS FOR LIFETIME / EVOLUTION WHIRLPOOLS AND BATH TUBS
TABLE 1
SIDE VIEW DRAIN / OVERFLOW END VIEW
L
H
W
CA
B
J
2422L / V
5' x 32"
2771L / V
5' x 36"
7236L / V
6' x 36"
2425L / V
5' x 32”
LHO /
RHO
2645L / V
Oval
A 20-1/8"
(511mm)
B 11"
(279mm)
A 20-1/8"
(511mm)
B 11"
(279mm)
A 20-1/8"
(511mm)
B 11"
(279mm)
A 19-1/8"
(485mm)
B 10-1/2"
(266mm)
A 15-1/4"
(387mm)
B 8-1/4"
(209mm)
3-1/4"
(83mm)
3-1/4"
(83mm)
3-1/4"
(83mm)
2-7/8"
(73mm)
1-3/4"
(44mm)
C 20"
(508mm)
C 20"
(508mm)
C 20"
(508mm)
C 20-1/4"
(515mm)
C 18-1/4"
(464mm)
58-1/2"
(1485mm)
x 30-1/2"
(774mm)
58-1/2"
(1485mm)
x 34-1/2"
(876mm)
70-1/2"
(1790mm)
x 34-1/2"
(876mm)
N/A
64"
(1625mm)
x 34"
(863mm)
60-3/16"
(1528mm)
x 30-1/2"
(774mm)
60-3/16"
(1528mm)
x 34-1/2"
(876mm)
72-3/16"
(1833mm)
x 34-1/2"
(876mm)
60-3/16"
(1528mm)
x 30-1/2"
(774mm)
66-3/16"
(1681mm)
x 34-1/2"
(876mm)
L 1524mm (60")
W 813mm (32")
H 546mm (21-1/2")
L 1524mm (60")
W 914mm (36")
H 546mm (21-1/2")
L 1829mm (72")
W 914mm (36")
H 546mm (21-1/2")
L 1524mm (60")
W 813mm (32")
H 521mm (20-1/2")
L 1676mm (66")
W 914mm (36")
H 502mm (19-3/4")
74 lb.
(34 kg.)
75 lb.
(34 kg.)
106 lb.
(48 kg.)
92 lb.
(42 kg.)
96 lb.
(44 kg.)
690 lb. (313 kg)/
53 lb./sq.ft.
(260 kg/sq.m)
800 lb. (363 kg)/
53 lb./sq.ft.
(260 kg/sq.m)
1031 lb. (467 kg)/
57 lb./sq.ft.
(280 kg/sq.m)
675 lb. (306 kg)/
54 lb./sq.ft.
(262 kg/sq.m)
580 lb. (263 kg)/
36 lb./pies
cuadrados
(175 kg/sq.m)
Optional
Optional
Optional
Included
Optional
Optional
Optional
Optional
Optional
Optional
74 gal.
(280 l.)
87 gal.
(329 l.)
111 gal.
(420 l.)
70 gal.
(265 l.)
58 gal.
(219 l.)
33 gal.
(125 l.)
50 gal.
(189 l.)
53 gal.
(201 l.)
39 gal.
(148 l.)
42 gal.
(159 l.)
Description
Drain /
Overflow
Cut Out
Pier
G x F
Rough-In
Recess
E x D
Tub Edge to
Centerline
Overflow: J
Weight with
Water / Floor
Loading
Product
Weight
Apron /
Mounting
Heater Ready
for Field
Installation
Gallon to
Overflow
Whirlpool
Operating
Volume
Height to
Underside
of Deck: C
Dimensions
L-W-H

6
754679-100 Rev. A
DIMENSIONS OF FIXTURES ARE NOMINAL AND MAY VARY WITHIN THE RANGE
OF TOLERANCES ESTABLISHED BY ANSI STANDARDS Z124.1 AND A112.19.7.
ROUGHING-IN REFERENCES
5' x 32" (MODEL 2422L / V)
60"
(1524mm)
36"
(914mm)
3"
(76mm)
7-1/2"
(191mm)
11"
(279mm)
13-3/4"
(349mm)
CUT OUT IN FLOOR
FOR DRAIN
5' x 36" (MODEL 2771L / V)
72"
(1829mm)
36"
(914mm)
7-3/4"
(197mm)
11"
(279mm) 3-1/4"
(83mm)
3"
(76mm)
6"
(152mm)
13-3/4"
(349mm)
CUT OUT IN FLOOR
FOR DRAIN
6' x 36" (MODEL 7236L / V)
60"
(1524mm)
32"
(813mm)
11"
(279mm)
7-3/4"
(197mm)
13-3/4"
(349mm)
6"
(152mm)
3"
(76mm)
3-1/4"
(83mm)
CUT OUT IN FLOOR
FOR DRAIN
3-1/4"
(83mm)
6"
(152mm)
PROVIDE
ACCESS TO
PUMP FOR
SERVICING
ON ALL
INSTALLAT IONS
PROVIDE
ACCESS TO
PUMP FOR
SERVICING
ON ALL
INSTALLATIONS
PROVIDE
ACCESS TO
PUMP FOR
SERVICING
ON ALL
INSTALLATIONS

754679-100 Rev. A
7
DIMENSIONS OF FIXTURES ARE NOMINAL AND MAY VARY WITHIN THE RANGE
OF TOLERANCES ESTABLISHED BY ANSI STANDARDS Z124.1 AND A112.19.7.
ROUGHING-IN REFERENCES
CUT OUT IN FLOOR
FOR DRAIN
60"
(1524mm)
32"
(813mm)
7-1/2"
(191mm)
10-1/2"
(267mm)
3"
(76mm) 2-7/8" (73mm)
13-1/2"
(343mm)
16"
(406mm)
5' x 32" IA-RHO (MODEL 2425L/V-RHO) - shown
5' x 32" IA-LHO (MODEL 2425L/V-LHO)
66"
(1676mm)
5-3/8"
(137mm)
36"
(914mm)
8-1/4"
(210mm)
3"
(76mm)
11-1/4"
(286mm) 1-3/4"
(44mm)
18"
(457mm)
CUT OUT IN FLOOR
FOR DRAIN
OVAL (MODEL 2645L / V)
6"
(152mm)
6"
(152mm)
PROVIDE ACCESS
TO PUMP FOR
SERVICING ON ALL
INSTALLATIONS
PROVIDE
ACCESS TO
PUMP FOR
SERVICING
ON ALL
INSTALLAT IONS

8
754679-100 Rev. A
INSTALLATION AND FRAMING INSTRUCTIONS
The variety of installations possible for this whirlpool may require framing procedures other than those shown. Locate studs as needed. Ensure
roughing-in dimensions are proper, plumb and square. Provisions must be made in all installations for an access opening for servicing the pump
and controls. It is strongly recommended that an additional opening be provided for access to the drain components. The apron should not be used
as the primary access opening.
TYPICAL PIER TYPE INSTALLATION
AS DESIRED
F
CUTOUT
AS DESIRED
G
CUTOUT
C
24
(610 mm)
12
(305 mm)
MOUNTING
SURFACE
WATERPROOF
SEALANT
BATH
TYPICAL RECESS INSTALLATION
24
(610 mm)
12
(305 mm)
C
E
D
W
LEVELING
STRINGERS
TILE
TILE
BEAD
STRIP
LEVELING STRINGER
1 x 4 (not for support)
BATH
ADHESIVE
SEALANT
WALLBOARD
NOTE: Tile bead kit not included and
must be purchased separately.
C
TYPICAL INSTALLATION
FIGURE 1
This bath must be supported along its entire bottom. Use mortar as bedding
material (do not use sand or foam). Apply enough mortar to support the complete
bottom of the bath. After the mortar has been poured, and before it sets, position
whirlpool or bath within recess until the rim is leveled against the leveling stringers (see
"Typical Recess Installation") shown below.
The rim of the bath must not support weight. Allow the mortar material to completely
harden before applying weight to the rim or bottom of the bath. Any finish material such
as tile or wall board must be self-supporting if it contacts the deck of the bath.
Replace whirlpool and re-shim the integral support feet, shimming the entire length of
the support feet. Secure the shims using construction adhesive, silicone, mortar or
equivalent materials. While not a necessity, the use of a foundation base consisting of
cement, mortar, or grout will help provide a solid and secure installation.
3. Install drain components to the whirlpool following the drain installation instructions. Before
replacing your whirlpool for final installation, be certain that an opening has been provided in
the sub-floor for the drain. See the roughing-in drawing and Ta ble 1 for suggested opening
size (shadowed) and location dimensions. The drain/overflow of the bath extends below the
bottom of the bath. Note that this requires a cutout in the floor.
The floor structure beneath the bath must be able to support a total weight of bath, water, and
bather. Refer to Ta ble 1 under total weight for your model.
For Models: 2425L/V-LHO and 2425L/V-RHO;
For Models: 2645L/V, 2771L/V, 2422L/V and 7236L/V;
2. Remove the whirlpool and attach a 1 x 4 stringer to the studs, with the top of the stringer touching the traced line.
The rim of the bath must not support weight.
1. Position the whirlpool into the installation opening and level the deck in both directions, shimming the integral support feet IF necessary.
Mark the final position of the underside of the deck by tracing a line on to the studs (see Figure 1).
!
!
!
!
ACCESS PANEL MUST BE LOCATED
ON THE SAME SIDE AS THE MOTOR.
ALLOW OPEN FRAMING ON PUMP/MOTOR
END FOR SERVICE.
ACCESS PANEL MUST BE LOCATED
ON THE SAME SIDE AS THE MOTOR.
ALLOW OPEN FRAMING ON
PUMP/MOTOR END FOR SERVICE.
FOR E & D DIMENSIONS SEE TABLE 1 ON PAGE 5. FOR G & F DIMENSIONS SEE TABLE 1 ON PAGE 5.
NOTE:
FRONT EDGE
OF BATH MUST
BE SUPPORTED
BY STUD WALL OR
AMERICAN STA NDARD
APRON KIT
The rim of the bath must not support weight. If foundation base is used, allow the
bedding material to completely harden before applying weight to the rim or bottom of
the bath. Any finish material such as tile or wall board must be self-supporting if it
contacts the deck of the bath.
UNLESS AN ACCESS OPENING OF AT LEAST 12" X 24" (305 X 610mm)
IS PROVIDED, WARRANTY SERVICE WILL NOT BE PERFORMED.
UNLESS AN ACCESS OPENING OF AT LEAST 12" X 24" (305 X 610mm)
IS PROVIDED, WARRANTY SERVICE WILL NOT BE PERFORMED.
(EXCEPT 2425 WHERE APRON IS PRIMARY ACCESS OPENING)
ACCESS PANELS NOT REQUIRED
FOR BATH TUBS. ACCESS PANELS NOT REQUIRED
FOR BATH TUBS.

754679-100 Rev. A
9
SUGGESTED WHIRLPOOL / BATH INSTALLATION METHOD
SECURE THE BATH TO THE STUDS AS SHOWN FOR
WOOD OR STEEL STUD CONSTRUCTION.
TYPICAL FLANGE MOUNTING DETAIL
Please note that care must be taken to protect the surface of the tub during all aspects of the installation.
Do not drill or cut the bath deck with the tub directly beneath it as damage to the tub may result.
1. Install the tub per the installation instructions provided with the unit.
2. Prepare the bath deck support structure per the local codes. Note - the bath deck must be self supporting.
3. Cut bath deck to your specifications.
4. Place the bath deck in position and trace the opening on the tub with a soft pencil. Do not drill or cut the bath
deck with the tub directly beneath it as damage to the tub may result.
5. Remove the bath deck and apply a generous bead of waterproof sealant on the outer edge of the traced line.
6. Replace the bath deck and secure it into place.
7. Apply additional sealant along the tub and bath deck interface as necessary to ensure a watertight seal.
8. Remove excess sealant per the manufacturer's instructions.
Finished bath deck surface material must be
self-supporting and secured per local codes
Tub support structure per installation
instructions provided with the tub
Bath deck support material
Bathtub
Waterproof
Sealant
UNDER DECK MOUNTING INSTRUCTIONS
STUD
WATERPROOF DRYWALL
OR CEMENT BOARD
WATERPROOF DRYWALL
OR CEMENT BOARD
TILE
SEALANT
TUB
ROOFING NAIL
1 x 3 (25 x 76mm) WOOD
STRINGER FULL LENGTH
1 x 3 (25 x 76mm) WOOD
STRINGER FULL LENGTH
STEEL
STUD
WASHER
TILE
SEALANT
TUB
4" (102mm)
DRYWALL
SCREW
WOOD
STUDS
STEEL
STUDS

10
754679-100 Rev. A
All wiring must be performed by a licensed electrician in accordance with the national electrical code and all other applicable codes.
WARNING: When using electrical products, basic precautions should always be observed, including the following:
1. DANGER: RISK OF ELECTRIC SHOCK! Connect only to a circuit protected by a ground-fault circuit interrupter.
2. Grounding is required. The unit should be installed by a licensed electrician and grounded.
3. Permit access for servicing motor as noted.
4. All building materials and wiring should be routed away from the pump body and heater (if equipped).
ELECTRICAL INSTALLATION INSTRUCTIONS
!
120V, 60HZ
15A GFCI
ELECTRICAL
FEED
AIR SWITCH ACTIVATED WHIRLPOOL PUMP
GFCI
Refer to the schematics below for the combination tub electrical installation. Note that two separate 15A circuits with
GFCI (Ground Fault Circuit Interrupter) protection are required.
At initial start-up with the power ON, push the GFCI test button. The reset button should pop out. Push this button in to
reset. If the GFCI fails to operate in this manner, there is a ground fault or malfunction, indicating the possibility of
electrical shock. Turn of the power and do not use until the source of the problem has been identifed and corrected.
ELECTRONIC ACTIVATED AIR BATH (4 BUTTON PANEL)
120V, 60HZ
15A GFCI
ELECTRICAL
FEED
GFCI
