HD-87
© 2008 AS America, Inc.
CADET
SINGLE CONTROL KITCHEN FAUCET
MODEL NUMBER:
8411 Kitchen Faucet
Metal Lever Handle. Separate Handspray.
Polished Chrome finish.
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ANSI A117.1
ASME A112.18.1
CSA B125
NSF 61/Section 9
GENERAL DESCRIPTION:
Cast Brass 8-1/2" (218mm) long swivel spout. Metal lever
handle. Washerless 40mm ceramic disc valve cartridge. Cast
brass waterway with 1/2" male inlet shanks. Metal escutcheon
plate (escutcheon size 10-5/16"L x 2-3/8"W). 2.2gpm/8.3L/min.
maximum flow rate.
SUGGESTED SPECIFICATION:
Single control kitchen faucet shall feature cast brass waterway. Shall also feature washerless 40mm ceramic disc valve
cartridge. Cast brass swivel spout. Fitting shall be American Standard Model # 8411.
PRODUCT FEATURES:
Ceramic Disc Valve Cartridge: Assures a lifetime of
smooth handle operation and drip-free performance.
Cast Brass Waterways with "City Shanks": Strong and
durable. Integral tabs on casting provide a wobble-free
installation.
Low Lead: Meets NSF Standard 61/Section 9 & Prop 65
lead requirements.
Memory Position Valving: Allows user to turn valve on
and off at preferred temperature setting without readjusting
handle position each time.
Large "Comfort Zone": Allows easy fine tuning of
temperature.
Simple Installation: Fast and easy one person installation.
Faucet drops in from top. Quick spin nuts secure faucet in place.
Lifetime Warranty: On Function and Finish.
FLOW RATE*
GALLONS PER MINUTE
INLET PRESSURE (PSI)
*Flow rates shown are for mixed hot and cold.
0.0
0.5
1.0
1.5
2.0
2.5
3.0
10080604020
173mm
(6-13/16)
203mm
(8) 262mm
(10-5/16)
121mm
(4-3/4)
129mm
(5-1/8)
155mm
(6-1/8)
218mm
(8-1/2)
113mm
(4-1/2)
35mm to 38mm
(1-3/8 to 1-1/2)
DIA. MOUNTING
HOLE (4 PLACES)
21mm
(13/16)
22mm
(7/8)
51mm
(2)
28.6mm
(1-1/8)MAX. 28.6mm
(1-1/8)MAX.
Product
Number Description
8411 Kitchen faucet. Separate White Handspray. Polished Chrome Finish.
Meets the American Disabilities Act Guidelines
and ANSI A117.1 Requirements for the
physically challenged.
