American Standard Cadet Round Countertop Sink with Scotchgard... Operating and safety instructions

J40
BARRIER FREE
© 2008 AS America Inc.
31"
(787mm)
SUGGESTED
33-1/4"
(845mm)
7-1/2"
(191mm)
19"
(448mm)
19"
(483mm)
FINISHED WALL
OR SPLASHBACK
8"
(203mm)
1-1/4" O.D. TAILPIECE
1-1/4" O.D. WASTE
FINISHED FLOOR
*10-3/4"
(273mm)
*12-7/8"
(327mm)
COUNTERTOP
(BY OTHERS)
SEALING
COMPOUND 3/4"
(19mm)
8"
(203mm)
OPTIONAL
SUPPLIES
AS REQ'D
3-1/8"
(79mm)
4"
(102mm)
33-1/4
(845mm)
BARRIER FREE
CLEARANCE
4
(102mm)
24
(610mm)
6
(152mm)
MAX.
27
(686mm)
MIN.
8
(203mm)
MIN.
9
(229mm)
MIN.
DRAWING FOR
DIMENSIONAL
PURPOSES ONLY.
IT IS NOT AN EXACT
REPRESENTATION.
MEETS THE AMERICANS WITH DISABILITIES ACT GUIDELINES
AND ANSI A117.1 ACCESSIBLE AND USABLE
BUILDINGS AND FACILITIES - CHECK LOCAL CODES.
Install lavatory 864mm (34") from finished floor.
Lavatory installed 51mm (2") minimum from front edge
of countertop provides 686mm (27") knee clearance area.
NOTES:
* DIMENSIONS SHOWN FOR LOCATION OF SUPPLIES AND “P" TRAP ARE
SUGGESTED.
FOR COUNTERTOP CUTOUT AND INSTALLATION INSTRUCTIONS USE
TEMPLATE SUPPLIED WITH SINK.
FITTINGS NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
SEALING COMPOUND SUPPLIED BY OTHERS.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range
of tolerances established by ANSI Standard A112.19.2. These measurements
are subject to change or cancellation. No responsibility is assumed for use of
superseded or voided pages.
CADET™ ROUND
COUNTERTOP SINK
VITREOUS CHINA
CADET™ ROUND COUNTERTOP SINK
• European-styled interior bowl
• Available with Scotchgard® nish for
easier cleaning
• Made from vitreous china
• Self-rimming with cutout template supplied
• Front overow
❏ 0427.444 Faucet holes on 4" (102mm) centers
(illustrated)
❏ 0427.888 Faucet holes on 8" (203mm) centers
❏ 0427.111 Center hole only
❏ 0427.444SG Faucet holes on 4" (102mm) centers
(with Scotchgard® nish)
❏ 0427.888SG Faucet holes on 8" (203mm) centers
(with Scotchgard® nish)
Nominal Dimensions:
19" dia. (483mm) Round
Bowl sizes:
15-1/4" (387mm) wide
12-1/4" (311mm) front to back
6" (152mm) deep
Compliance Certications -
Meets or Exceeds the
Following Specications:
• ASME A112.19.2M for
Vitreous China Fixtures
• CAN/CSA B45 series
Revised 2/08
To Be Specied:
❏ Color: ❏ White ❏ Bone
❏ Linen ❏ Silver
❏ Fawn Beige ❏ Black
❏ Faucet*:
❏ Faucet Finish:
❏ Supplies:
❏ 1-1/4" Trap:
* See faucet section for additional models available
Available with
