Installation & Operation Instruction
Installation & Operation Instruction
8
7
WF-6521.609.50
In-wall B&S Mixing Valve
WF-6521.609.50 WF-6522.709.50
WF-6522.709.50
In-wall Shower Mixing Valve
1
2
3
4
5
6
7
8
9
10
11
12
13a
1
1
1
1
1
1
2
1
2
1
1
1
0
1
WF-6521.609.50
In-wall B&S Mixing Valve
WF-6522.709.50
In-wall Shower Mixing Valve
1
2
3
4
5
6
7
8
9
10
Seva
Seva
Seva
Seva
13b
WF-6521 / WF-6522
A/1
To ensure that your installation proceeds smoothly,
please read this instructions carefully before you begin.
PARTS LIST
No. Part Name Q'ty
Attention Installer:
Leave this information to the customer after
installation is completed.
Trouble Shooting
Trouble Checkpoint Contents Action
Leakage
Temperature
problem
Valve
Pipe connection Check the pipe's connection
Check valve position Lock valve
If pip connection incorrect please reinstall
All Connection Check washer installation Replace Washer
Maintenance
* AERATOR may accumulate dirt causing distorted and reduced water flow. If you need change or clean it, please
shut off water suplly first, then follow below steps:
14
14 In-Hex Wrench 1
1

4
5
6
3
1
2
Hot
Cold
ON
WF-6521.609.50
42
G1/2"
G1/2"
120
128
106.5
45
20
7
30~35
1
2
3
4
5
6
7
WF-6521.609.50
In-wall B&S Mixing Valve
WF-6522.709.50
In-wall Shower Mixing Valve
Seva
Seva
Connect to the Shower
Connect to the Spout
Warning：
W“ F-6522”Has no Connector
5mm
WF-6522.709.50
G1/2"
Finished Wall
42
G1/2"
120
128
106.5
45
20
7
30~35
G1/2"
Finished Wall
Clip
Clip
Connector
Pipe Line
Conditions for use
Note
* Recommended water pressure condition: 0.1~0.5Mpa
* Environment Temperature:1~55℃
* Steam is not allowed to use .
* The cold and hot water pipes must not be changed.
Remove all impurities in pipes before beginning.
Make sure the cold water hose is connected to the right side and the hot water hose to the left.
Dimension
Install Body
Cold
Hot
* Finish wall should be between the minimum
and the maximum
Body Cover
Wall(Min)
Wall(Max)
Connector
Pipe Line
Usage
Test
* Move handle down to turn off the valve. Turn on supply angle valve to check all connections if leak or not.
* Operate handle up and down, left and right to flush water lines thoroughly.
Fulfill the Wall
Install Escutcheon & Handle
