American Standard Ovalyn Universal Access 9482.000 User manual

J55
BARRIER FREE
© 2008 AS America Inc.
FINISHED WALL
267mm
(10-1/2)
140mm
(5-1/2)
51mm
(2) MIN.
COUNTER
TOP
CUTOUT
UNDER
COUNTER
BASIN RIM
C/L
489mm
(19-1/4)
37mm(1-7/16) DIA.
HOLE TYP.
SEALING
COMPOUND COUNTERTOP
(BY OTHERS)
140mm
(5-1/2)
203mm
(8)
92mm
(3-5/8)
1-1/4 O.D. TAILPIECE
1-1/4
O.D. WASTE
SUPPLIES
AS REQ'D
45°
MOUNTING
CLIP
(SEE DETAIL)
337mm
(13-1/4) 400mm
(15-3/4)
16mm
(5/8) -2mm(1/16)
+3mm(1/8)
*311mm
(12-1/4)
*262mm
(10-1/2)
425mm
(16-3/4)
70mm
(2-3/4)
DETAIL OF MOUNTING CLIP
(KIT No.047194-0070A)
LAVA
BRASS
INSERT
19mm
(3/4) MIN.
REFER TO INSTRUCTIONS
PROVIDED WITH KIT FOR
ADDITIONAL INFORMATION
CLIP
MACH.
SCREW
864mm
(34)
51mm
(2)
610mm
(24)
152mm
(6)
MAX.
BARRIER FREE
CLEARANCE
686mm
(27)
MIN.
203mm
(8)
MIN.
229mm
(9)
MIN.
DRAWING FOR
DIMENSIONAL
PURPOSES ONLY.
IT IS NOT AN EXACT
REPRESENTATION.
OVALYN UNIVERSAL ACCESS™
UNDERCOUNTER SINK
VITREOUS CHINA
Revised 2/08
OVALYN UNIVERSAL ACCESS™ SINK
• Made from vitreous china
• Unglazed rim for under counter mount
• Rear overow
• Supplied with mounting kit (047194-0070A)
and template
❏ 9482.000
Nominal Dimensions:
489 x 400mm
(19-1/4" x 15-3/4")
Bowl sizes:
425mm (16-3/4") wide
337mm (13-1/4") front to back
140mm (5-1/2") deep
102mm (4") bowl depth
Compliance Certications -
Meets or Exceeds the
Following Specications:
• ASME A112.19.2M for
Vitreous China Fixtures
• CAN/CSA B45 series
• 1995 National Building Code, section 3.7
and CAN/CSA-B651-M90 and OBC 3.7.
MEETS THE AMERICANS WITH DISABILITIES ACT
GUIDELINES AND ANSI A117.1 ACCESSIBLE AND
USABLE BUILDINGS AND FACILITIES -
CHECK LOCAL CODES.
Countertop 864mm (34") from finished floor. Lavatory
installed 51mm (2") MIN. from front edge of countertop.
Countertop thickness to be 25mm (1") maximum.
NOTES:
* DIMENSIONS SHOWN FOR LOCATION OF SUPPLIED AND “P" TRAP ARE
SUGGESTED.
▼ UNDERCOUNTER MOUNTING KIT SUPPLIED WITH BASIN.
FITTINGS NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
USE ENCLOSED TEMPLATE FOR COUNTERTOP CUTOUT
SEALING COMPOUND SUPPLIED BY OTHERS.
IMPORTANT: Dimensions of xtures are nominal and may vary within the
range of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided pages.
For Universal Design Options, top of counter may be
mounted at 813mm (32") minimum from nished oor
to meet ADA and ANSI A117.1 requirements. A 838mm
(33") minimum mounting height is required for Ontario.
Check local codes for heights and faucet handles
requirements.
To Be Specied:
❏ Color: ❏ White ❏ Bone
❏ Linen ❏ Silver
❏ Fawn Beige ❏ Black
❏ Faucet*:
❏ Faucet Finish:
❏ Supplies:
❏ 1-1/4" Trap:
* See faucet section for additional models available
