CADET® 3 RIGHT HEIGHT™ ELONGATED
COMPLETE with the FLUSH RIGHT™ SYSTEM
VITREOUS CHINA
5/06
CADET® 3 RIGHT HEIGHT™
ELONGATED COMPLETE TOILET with the
FLUSH RIGHT™ SYSTEM
❏ 3305.000
• Vitreous china
• Low-consumption (6.0 Lpf/1.6 gpf)
• EverClean™ anti-microbial ceramic glaze
• Featuring the Flush Right™ System
• 16-1/2" rim height for accessible application
• Elongated siphon action jetted bowl
• Fully-glazed 2-1/8" trapway with 2" ball pass
• Generous 9" x 8" water surface area
• Close-coupled tank with at tank cover for
superior storage
• Oversized 3" ush valve with chemical
resistant apper
• Chrome trip lever
• New Speed Connect™ tank-to-bowl
coupling system
• New sanitary dam on bowl with four point
tank stabilization
• Color matched solid plastic seat with cover
• 2 color-matched bolt caps
• Wax ring gasket with closet bolts
• 100% factory ush tested
Nominal Dimensions:
30-1/4" x 17-1/4" x 30-1/4"
(768 x 438 x 768mm)
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.2M for Vitreous China Fixtures -
includes Flush Performance, Ball Pass Diameter,
Trap Seal Depth and all Dimensions
• Los Angeles Department of Water and
Power Supplementary Purchase Specication
for Non-Adjustability
To Be Specied:
❏ Color: ❏ White ❏ Bone
❏ Supply with stop:
FINISHED WALL
FINISHED
FLOOR
C/L OF OUTLET
SUPPLY
AS
REQ'D.
216mm
(8-1/2)
768mm
(30-1/4)
25mm ± 6mm
(1 ± 1/4)
102mm
(4)
464mm
(18-1/4)
438mm
(17-1/4)
768mm
(30-1/4)
419mm
(16-1/2)
*203mm
(8)
305mm
(12)
356mm
(14)
213mm
(8-3/8)
C/L OF SEAT POST HOLES
140mm (5-1/2 CENTERS)
*352mm
(13-7/8)
*152mm
(6)
238mm
(9-3/8)
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range
of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided page
MEETS THE AMERICANS WITH DISABILITIES ACT GUIDELINES
AND ANSI A117.1 REQUIREMENTS FOR ACCESSIBLE AND
USEABLE BUILDING FACILITIES-CHECK LOCAL CODES.
INSTALL WITH SEAT AT HEAD END.
