American Time SiteSync IQ Instruction Manual

American Series Digital Clocks
1. Take the clock to the area where it will be used.
2. To activate the clock, connect to AC power.
3. Display will ash “U40” or 1:00 o’clock until it
receives a signal.
4. Verify synchronization takes place within 2-5
minutes
Your SiteSync IQ system is now set up for proper operation.
For information on other features, see the Installation and
Operation Manual that was included with your system. If you
have any questions, please contact Technical Support at
American Time: 800-328-8996.
6
Activate and hang your clocks
Don't activate the battery or apply power to the clocks until the Remote Transmitter is installed and
transmitting and the clock is in the intended location.
SiteSync IQ®Remote Transmitter
with Magnetic Mount TX Antenna
INST-SSQRTM-N-E Rev 3
Please read this rst!
After determining the proper wattage for your facility, we guarantee the coverage of your Remote
Transmitter when you follow a few simple steps. If this is your rst installation or you have questions at
any time during this process, please call American Time toll free at 800-328-8996.
We're here to help!
This Quick Start Guide will help you avoid three common installation mistakes:
1. Improper location of transmitting (TX) antenna. A temporary install of the Remote Transmitter
is recommended.
Don't drill holes for permanent installation and mounting until the system is working correctly.
2. Improper Remote Transmitter start-up. A successful transmission is indicated by the PTT and
DATA LED's ashing on the front of the unit.
Don't locate the magnetic mount TX antenna within 4' of the Remote Transmitter.
3. Improper clock start-up. Activate clocks in their intended location.
Don't activate the clocks in one room and move them to another location as signal reception
will not be veried. Make sure the Remote Transmitter is transmitting and is not in Quiet Mode.
Important Note: Clocks should be installed within 24 hours of installing the Remote Transmitter.
After 24 hours, the Remote Transmitter will enter Quiet Mode. To disable Quiet Mode, reference
the Remote Transmitter Installation and Operation Manual section Remote Transmitter Connect
Configuration tab step 5 and Appendix F.
AC
DC
To
wiring
box
Reset
Button
LED
Electric
Electric (AC) Analog Clocks
1. Take the clock to the area where it will be used.
2. To activate the clock, connect to AC power.
The LED on the back of the clock (see below)
will ash red within 30 seconds of power-up to
indicate receiver is looking for the wireless
signal.
When the signal is received, the LED will ash
green. Be patient. The clock hands will rapid
advance to the correct time. This may take
up to 7 minutes.
3. Hang the clock once signal reception is
veried and clock is operating correctly.
Note: If the LED does not ash within 30 seconds,
disconnect the barrel plug on the clock receiver, wait
10 seconds and reconnect. The LED will begin ashing
within 30 seconds.
Activation Note: Clocks should be installed within 24 hours of
installing the Remote Transmitter. After 24 hours, the Remote
Transmitter will enter Quiet Mode. To disable Quiet Mode
reference the Remote Transmitter installation and Operation
Manual section Remote Transmitter Connect Configuration tab
step 5 and Appendix F.
phone: [phone] fax: [phone] online: american-time.com
mail: 140 3rd St. So.; PO Box 707, Dassel, MN 55325-0707
AC
DC
To
wiring
box
LED
Battery
Barrel
Jack
Input
Battery Analog Clocks
1. Take the clock to the area where it will be
used.
2. To activate the clock, connect barrel jack plug
of battery pack to wireless receiver. The
LED on the back of the clock will ash red
within 30 seconds of power-up to indicate
receiver is looking for the wireless signal.
When the signal is received, the LED will ash
green. Be patient. The clock hands will rapid
advance to the correct time. This may take up
to 7 minutes.
3. Hang the clock after hands are rapid
advancing.
Note: If the LED does not ash within 30 seconds,
remove the barrel jack plug of the battery pack from
the wireless receiver for 5 seconds and reconnect it.
This resets the receiver. The LED will begin ashing
within 30 seconds.

QUICK START INSTALLATION GUIDE SITESYNC IQ®REMOTE TRANSMITTER
abcdefghijklmn
1 4
Unpack the box
1. Remove the components and Remote Transmitter from the
box. Save the packing materials in case you need them later.
Check the components
Your system kit comes with:
• Remote Transmitter
• Power cord (B)
• Magnetic mount TX antenna with 12' cable (C)
• Installation and Operation Manual
Choose your location
• Locate the Remote Transmitter in an area with a network drop,
or run an Ethernet data cable to the unit from a network
switch or hub.
• Choose a location for your magnetic mount TX antenna either
outside or inside at the highest central location in your facility.
The TX antenna must be located at least 4' away from
the Remote Transmitter and must always point up or down,
never horizontal! The cable length cannot be extended.
2
3
4 ft
minimum
TX Ant signal
out to clocks
Remote Transmitter
located high & central
with Ethernet drop for
time reference
Back-UPS ES 550
SurgeProtection
PowerOn
ReplaceBattery
BatteryBackup+
SurgeProtection
C
A
B
To local
power
(120vac)
Connect cables to the Remote Transmitter
A. Connect a CAT 5 or higher Ethernet patch cable (not included)
to the ETHERNET RJ45 port.
B. Connect the power cord to the Remote Transmitter.
C. Connect mag mount antenna to the Antenna port. *Lightning
arrestor must be grounded per local electrical code.
Plug 110v cord into power source. Turn the POWER SWITCH on
the back of the Remote Transmitter to the on position.
Setup the Remote Transmitter
1. Record the last 6 digits of the Serial Number in the empty spaces
below. The Serial Number is located on the product label on the
bottom of the Remote Transmitter.
Host Name: s q r t
The Host Name is used to identify the Remote Transmitter on the network.
5
Example Product Label
continued
2. The default Ethernet setting has DHCP enabled to automatically
obtain its TCP/IP network setting from a DHCP server. Launch your
web browser, and enter the above recorded host name
http://sqrtxxxxxx/ into the URL field of the web browser. Press the
Enter key. This will connect to the Remote Transmitter’s
configuration utility Remote Transmitter Connect.
Note: If the Remote Transmitter is on a network without a DHCP
server the default address of the Remote Transmitter
will be 192.168.10.10.
Note: If a static IP is required for your network, reference the Remote
Transmitter Installation and Operation Manual.
3. Once you are connected to the Remote Transmitter a User Login
window will appear. Enter sclock in lowercase letters in the User
Name field and sclock in the Password field. This is the default
service login which will allow access to all menus. Then, click the
Login button.
Note: Passwords may be changed in the Configuration Tab.
4. Click on the Set tab menu and verify the appropriate local time zone
from the drop down menu.
5. Daylight Saving Time default is set to AUTO. If your location doesn’t
observe DST select drop down menu to OFF.
6. To confirm proper setup, enable the On Demand Sync Ethernet
button and press Sync Now. If successful a green check-mark will
appear next to the Sync Now button.
7. Verify the unit is transmitting. The PTT and Data LED’s on the front
of the Remote Transmitter should flash every 30 seconds unless in
Quiet Mode.
5
