Ametek Thermox 2000 ATEX Series User manual

Thermox®Series 2000 ATEX
WDG-HPII and WDG-HPIIC
User Manual
Thermox
150 Freeport Road
Pittsburgh, PA 15238
PN 90571VE, Rev B

ii | Thermox Series 2000 WDG-HPII / HPIIC -ATEX
©2000AMETEK
This manual is a guide for the use of the Thermox Series 2000 ATEX WDG-HPII and WDG-HPIIC. Data herein has been verified and validated
and is believed adequate for the intended use of this instrument. If the instrument or procedures are used for purposes over and above the
capabilities specified herein, confirmation of their validity and suitability should be obtained; otherwise, AMETEK does not guarantee results
and assumes no obligation or liability. This publication is not a license to operate under, or a recommendation to infringe upon, any process
OFFICES
USA - Pittsburgh
150 Freeport Road
Pittsburgh, PA 15238
Ph. 412-828-9040
Fax [phone]
USA - Delaware
455 Corporate Blvd.
Newark, DE 19702
Ph. 302-456-4400
Fax [phone]
USA - Texas
9750 Whithorn Drive
Houston, TX 77095
Ph. 281-463-2820
Fax [phone]
CANADA
2876 Sunridge Way N.E.
Calgary, AB T1Y 7H9
Ph. 403-235-8400
Fax [phone]
CHINA
AMETEK Shanghai (SPL)
Room 408, Metro Tower
#30 Tian Yao Qiao Road
Shanghai 200030
Ph. 86 21 6426 8111
Fax [phone]
AMETEK Beijing
CITIC Building, Room 2305
19, Jianguomenwai Dajie
Beijing 100004
Ph. 86 10 8526 2111
Fax [phone]
FRANCE
AMETEK Precision Instruments France
Rond Point de l’épine des champs
Buroplus Bat D
78990 Elanbourt
Ph. 33 1 30 68 89 20
Fax [phone]
GERMANY
AMETEK GmbH
Rudolf-Diesel-Strasse 16
D-40670 Meerbusch
Ph. 49 21 59 91 36 0
Fax [phone]
MIDDLE EAST – Dubai
AMETEK
PO Box 17067
Jebel Ali Free Zone
Dubai, UAE
Ph. 971-4-881 2052
Fax [phone]
SINGAPORE
AMETEK Singapore Pte. Ltd.
10 Ang Mo Kio Street 65
#05-12 Techpoint
569059 Singapore
Ph. 65-6484-2388
Fax [phone]

Contents | iii
Table of Contents
Safety Notes .......................................................................................................... vi
Electrical Safety.................................................................................................... vi
Grounding ............................................................................................................ vi
Important Notice to Users ................................................................................ vii
Explosion Hazards: ............................................................................................ vii
Environmental Information (WEEE).............................................................viii
General Safety Summary ................................................................................... ix
1 OVERVIEW
Basic Elements of the Sensor........................................................................... 1-2
Start Up Checklist ............................................................................................. 1-6
Technical Support ............................................................................................. 1-7
Return of Equipment........................................................................................ 1-7
2 SPECIFICATIONS
3 INSTALLATION
Inspect Shipping Contents.............................................................................. 3-1
Mechanical Installation .................................................................................... 3-2
Probe and Probe Filter Connection to Sensor ...................................... 3-2
Mounting the Sensor ................................................................................. 3-4
Mounting the Sensor to the Process ..................................................... 3-11
Calibration ........................................................................................................ 3-12
Required Calibration Gases and Tubing ............................................... 3-12
Connections ..................................................................................................... 3-12
Purging Operation .......................................................................................... 3-13
Manual Calibration Connections ................................................................. 3-16
Remote Calibration Unit Mechanical Installation ................................... 3-16
O2-Only RCU Connections ................................................................... 3-17
O2 and Combustibles RCU Connections ............................................ 3-17
Control Unit Mounting ................................................................................. 3-20
Weatherproof - Panel Mount.................................................................. 3-20
Weatherproof - Wall/Pole Mount ........................................................... 3-21
Wiring ................................................................................................................ 3-22
Sensor connections ......................................................................................... 3-28
Sensor AC mains supply connections ......................................................... 3-28
Standard sensor connections ........................................................................ 3-29
RS-485 Communications Connections........................................................ 3-38
Option Card Installation ................................................................................ 3-42

iv | Thermox Series 2000 WDG-HPII / HPIIC -ATEX
4 CONTROLLER / USER INTERFACE
Areas of the Control Unit ................................................................................ 4-1
Setup Key ............................................................................................................ 4-5
Analog Range Key ........................................................................................... 4-18
Alarm Key.......................................................................................................... 4-25
5 CALIBRATION
Definitions .......................................................................................................... 5-2
Span and Zero Calibration Gas Definitions ................................................. 5-2
Types of Calibrations ........................................................................................ 5-3
Overview ............................................................................................................. 5-4
Aborting a Calibration ...................................................................................... 5-6
Password ............................................................................................................. 5-6
Initiate Cal and Initiate Verify......................................................................... 5-7
Auto Calibrate/Auto Verify ............................................................................... 5-8
Remote Calibrate/Remote Verify .................................................................. 5-10
Manual Calibrate/Manual Verify .................................................................. 5-12
Cal/Verify Data ................................................................................................. 5-15
Cal Gas Value ................................................................................................... 5-17
Inject Cal Gas ................................................................................................... 5-18
Set Cal Timers .................................................................................................. 5-21
6 MAINTENANCE & TROUBLESHOOTING
System Messages ............................................................................................... 6-2
Error Messages ................................................................................................... 6-4
Diagnostics Checks ........................................................................................... 6-8
General Troubleshooting ................................................................................ 6-15
7 SERVICE & PARTS
Cell Replacement/Cleaning ............................................................................. 7-4
Thermocouple Replacement ........................................................................... 7-6
Furnace Replacement ....................................................................................... 7-8
Combustibles Detector Replacement .......................................................... 7-10
Replacement Parts List ................................................................................... 7-14
APPENDIXA SERIAL COMMUNICATIONS
APPENDIX B MENU OPTION CHARTS
APPENDIX C CURRENT OUTPUTS: OTHER APPLICATIONS
APPENDIX D DRAWINGS AND CUSTOM INSTRUCTIONS

Contents | v
Safety Notes
WARNINGS, CAUTIONS, and NOTES contained in this manual emphasize critical instruc-
tions as follows:
An operating procedure which, if not strictly observed, may result in personal injury or
environmental contamination.
An operating procedure which, if not strictly observed, may result in damage to the
equipment.
Important information that should not be overlooked.
Electrical Safety
Up to 5 kV may be present in the analyzer housings. Always shut down power source(s)
before performing maintenance or troubleshooting. Only a qualified electrician should make
electrical connections and ground checks.
Any use of the equipment in a manner not specified by the manufacturer may impair the
safety protection originally provided by the equipment.
Grounding
Instrument grounding is mandatory. Performance specifications and safety protection are
void if instrument is operated from an improperly grounded power source.
Verify ground continuity of all equipment before applying power.
!
CAUTION

NOTE
!
WARNING
!
WARNING

vi | Thermox Series 2000 WDG-HPII / HPIIC -ATEX
Important Notice to Users
No operator serviceable components inside any components of the WDG system. Do not re-
move the cover from any WDG component. Refer servicing to qualified personnel.
The following applies to the Series 2000 Control unit and the WDG-HPII series Models:
Power, input, and output (I/O) wiring must be in accordance with Class I, Zone 2 wiring
methods and in accordance with the authority having jurisdiction.
Use only OEM replacement parts to ensure proper ATEX certification for your ana-
lyzer.
Explosion Hazards:
Substitution of components may impair suitability for Class I, Zone 2.
When in hazardous locations, turn off power before replacing or wiring IQ Link
modules.
Do not disconnect equipment unless power has been switched off or the area is known
to be nonhazardous.
This equipment is suitable for use in Class I, Zone 2, Groups IIC or non-hazardous
locations only.
The maximum ambient temperature for the Series 2000 control unit is 50 °C (122 °F)
The Series 2000 Control Unit with WDG-HP sensor is a complex piece of equipment that
should only be serviced by a qualified service technician with expertise in instrument tech-
nology and electrical systems. AMETEK recommends that all equipment requiring service be
sent back to the factory. You should only attempt to repair or service this equipment after
receiving training from an AMETEK/P&AI Division training representative. If you decide to
service this equipment be aware that high voltages, high temperatures, and other potentially
hazardous conditions may arise.
!
WARNING

NOTE

NOTE

Contents | vii
Environmental Information (WEEE)
This AMETEK product contains materials that can be reclaimed and recycled. In some
cases the product may contain materials known to be hazardous to the environment or
human health. In order to prevent the release of harmful substances into the environment
and to conserve our natural resources, AMETEK recommends that you arrange to recycle
this product when it reached its “end of life”.
Waste Electrical and Electronic Equipment (WEEE) should never be disposed of in a mu-
nicipal waste system (residential trash). The Wheelie Bin marking on this product is a
reminder to dispose of the product properly after it has completed its useful life and been
removed from service. Metals, plastics, and other components are recyclable and you can
do your part by doing one of the following steps:
• When the equipment is ready to be disposed of, take it to your local or
regional waste collection administration for recycling.
• In some cases, your “end of life” product may be traded in for credit to-
wards the pur-chase of new AMETEK instruments. Contact your dealer to
see if this program is avail-able in your area.
• If you need further assistance in recycling your AMETEK product, contact
our office listed in the front of the instruction manual.

viii | Thermox Series 2000 WDG-HPII / HPIIC -ATEX
General Safety Summary
Review the following safety precautions to avoid injury and prevent damage to this product
or any products connected to it.
Use Proper Wiring
To avoid fire hazards, use only the wiring specified in the Installation Chapter of this user’s
manual.
Avoid Electrical Overload
To avoid electrical shock or fire hazard, do not apply a voltage to a terminal that is outside the
range specified for that terminal.
Ground the Product
Follow the grounding instructions provided in the Installation Chapter of this user’s manual.
Before making connections to the input or output terminals of this product, ensure that the
product is properly grounded.
Do Not Operate without Covers
To avoid electric shock or fire hazard, do not operate this product with covers or panels re-
moved.
Use Proper Fuse
To avoid fire hazard, use only the fuse type and rating specified for this product.
Do Not Operate in Explosive Atmosphere
To avoid injury or fire hazard, do not operate this product in an explosive atmosphere unless
you have purchased options that are specifically designed for these environments.
Product Damage Precautions
Use Proper Power Source
Do not operate this product from a power source that applies more than the voltage specified.
Do Not Operate with Suspected Failures
If you suspect there is damage to this product, have it inspected by qualified service personnel.

Contents | ix
Declaration of Conformity
Manufacturer’s Name: AMETEK Process Instruments
Manufacturer’s Address: 150 Freeport Road
Pittsburgh, PA 15238
declares that the products:
Product Names: Thermox WDG “ATEX” Series of Flue Gas Analyzers using Series 2000 Controller:
WDG-IV WDG-IVC WDG-IVCM WDG-HPII
WDG-HPIIC WDG-UOP/RP WDG-UOP/RP HP
O2 Only RCU O2 & Comb RCU O2, Combustibles & Methane RCU
Conform to the following standards:
EMC compliance:
EMC Directive 2004/108/EC
Immunity:
EN 50082-2:1995 Generic - Heavy Industrial Equipment
EN 50082-1:1997 Generic - Residential, Commercial, Light Industrial Equipment
EN 61000-6-2:1999 Generic - Heavy Industrial Equipment
EN 61326:1997 Measuring Equipment (Heavy Industrial)
Emissions:
EN 55011:1998 Class A, ISM Equipment
ATEX Directive 94/9/EC
Examination in accordance with standards:
EN 13980 Potentially Explosive Atmospheres – Application of Quality Systems
EN 50014 (IEC 60079-0) Electrical Apparatus for Potentially Explosive Atmospheres - General
Requirements
EN 50016 (IEC 60079-2) Electrical Apparatus for Potentially Explosive Atmospheres - Pressurized
Apparatus “p” (sensors)
EN 50021 (IEC 60079-15) Electrical Apparatus for Potentially Explosive Atmospheres - Type of
Protection “n” (controls)
For which LCIE (0081) notification LCIE 03 ATEX Q 8022
And EC Examination Certificate LCIE 05 ATEX 6140 X were issued
Electrical Safety Compliance:
UL 3101-1 UL Listed Inspection and Measuring Electrical Equipment
CAN/CSA 22.2 No. 1010.1-92 cUL Listed Inspection and Measuring Electrical Equipment
EN61010-1:1993,
Amendment A2: 1995 Electrical Equipment for Measurement, Controls,
and Laboratory Use
Series 2000 Controller also has the following safety compliance:
UL 1604 UL Listed Process Control Equipment for Use in Hazardous Location
WDG Series analyzers with the suffix Div. 2, O2 Only RCU, O2 & Comb RCU, and O2, Combustibles &
Methane RCU also conform to the following safety standard:
UL 1604 UL Listed Process Control Equipment for Use in Hazardous Locations
Manufacturer’sAddressinEurope:
AMETEK Precision Instruments Europe GmbH
Rudolf-Diesel-Strasse 16
D-40670 Meerbusch, Germany
July 2005
Mark Coppler
Compliance Engineer

x | Thermox Series 2000 WDG-HPII / HPIIC -ATEX
WARRANTY AND CLAIMS
We warrant that any equipment of our own manufacture or manufactured for us pursuant to
our specifications which shall not be, at the time of shipment thereof by or for us, free from
defects in material or workmanship under normal use and service will be repaired or replaced
(at our option) by us free of charge, provided that written notice of such defect is received by
us within twelve (12) months from date of shipment of portable analyzers or within eighteen
(18) months from date of shipment or twelve (12) months from date of installation of permanent
equipment, whichever period is shorter. All equipment requiring repair or replacement under
the warranty shall be returned to us at our factory, or at such other location as we may
designate, transportation prepaid. We shall examine such returned equipment, and if it is
found to be defective as a result of defective materials or workmanship, it shall be repaired or
replaced as aforesaid. Our obligation does not include the cost of furnishing any labor in
connection with the installation of such repaired or replaced equipment or parts thereof, nor
does it include the responsibility or cost of transportation. In addition, instead of repairing or
replacing the equipment returned to us as aforesaid, we may, at our option, take back the
defective equipment, and refund in full settlement the purchase price thereof paid by Buyer.
The warranty shall not apply to any equipment (or part thereof) which has been tampered with
or altered after leaving our control or which has been replaced by anyone except us, or which
has been subject to misuse, neglect, abuse or improper use. Misuse or abuse of the equipment,
or any part thereof, shall be construed to include, but shall not be limited to, damage by
negligence, accident, fire or force of the elements. Improper use or misapplications shall be
construed to include improper or inadequate protection against shock, vibration, high or low
temperature, overpressure, excess voltage and the like, or operating the equipment with or in
a corrosive, explosive or combustible medium, unless the equipment is specifically designed
for such service, or exposure to any other service or environment of greater severity than that
for which the equipment was designed.
The warranty does not apply to used or secondhand equipment nor extend to anyone other
than the original purchaser from us.
THIS WARRANTY IS GIVEN AND ACCEPTED IN LIEU OF ALL OTHER WARRANTIES,
WHETHER EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION AND WAR-
RANTIES OF FITNESS OR OF MERCHANTABILITY OTHER THAN AS EXPRESSLY SET
FORTH HEREIN, AND OF ALL OTHER OBLIGATIONS OR LIABILITIES ON OUR PART. IN
NO EVENT SHALL WE BE LIABLE UNDER THIS WARRANTY OR ANY OTHER PROVI-
SION OF THIS AGREEMENT FOR ANY ANTICIPATED OR LOST PROFITS, INCIDENTAL
DAMAGES, CONSEQUENTIAL DAMAGES, TIME CHANGES OR ANY OTHER LOSSES
INCURRED BY THE ORIGINAL PURCHASER OR ANY THIRD PARTY IN CONNECTION
WITH THE PURCHASE, INSTALLATION, REPAIR OR OPERATION OF EQUIPMENT, OR
ANY PART THEREOF COVERED BY THIS WARRANTY OR OTHERWISE. WE MAKE NO
WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION ANY WAR-
RANTIES OF FITNESS OR OF MERCHANTABILITY, AS TO ANY OTHER
MANUFACTURER’S EQUIPMENT, WHETHER SOLD SEPARATELY OR IN CONJUNC-
TION WITH EQUIPMENT OF OUR MANUFACTURE. WE DO NOT AUTHORIZE ANY
REPRESENTATIVE OR OTHER PERSON TO ASSUME FOR US ANY LIABILITY IN CON-
NECTION WITH EQUIPMENT, OR ANY PART THEREOF, COVERED BY THIS WAR-
RANTY.

Overview |1-1
OVERVIEW
Designed for applications with high particulate levels in the gas stream,
the sensor mounts directly on the combustion process to provide continu-
ous measurement of oxygen (HPII), or oxygen and combustibles (HPIIC).
Since the sample inlet and return are inside the filter and at the same abso-
lute pressure as the process, there is no flow through the filter. The sample
in the filter flows through the sensor plumbing because of a convective
motive force. The sample in the vertical cell housing is heated to 695oC,
while the sample in the return vertical tube is at about 250oC. The tempera-
ture difference generates a density difference, which circulates the gas
through the system. Process gas enters and replenishes the gas inside the
filter by diffusion only. Thus the filter never blocks, making it ideal for
high particulate applications.
Follow these precautions when working on the sensor:
Remove AC power from the sensor and allow it to cool for at least
one hour before performing any maintenance or troubleshooting
activities.
The outside of the sensor cover and all sensor assembly components
are hot during normal operation (up to 500oF inside the furnace,
260oC inside the cover). Allow sensor components to cool for at
least an hour before working inside the sensor. Use caution and
wear appropriate gloves when handling components or when
touching the sensor cover!
!
WARNING

1-2 |Thermox Series 2000 WDG-HPII / HPIIC - ATEX
Basic Elements of the Sensor
The WDG-HPII analyzer consists of the following basic systems:
•The Plumbing
All inlet and outlet tubing (cell housing), the sensing cell, the sensing
cell fitting, and the combustibles flow block and detector (for com-
bustibles).
•The Measuring System
The sensing cell, combustibles detector, interconnecting wiring, and
the control unit.
•The Temperature System
The electrical cell heater (furnace), sensor case heaters with adjust-
able thermostat, the type "K" thermocouple (maintains cell operating
temperature), and the sensor board containing cold junction com-
pensation. The sensing cell operates at a constant temperature. The
circuit board in the sensor terminal box switches power to the fur-
nace from the AC mains connected to the sensor. This board also
provides cold junction compensation to the thermocouple circuit.
The Oxygen Measuring Cell
The sensing element itself is a closed-end tube or disk made from ceramic
zirconium oxide stabilized with an oxide of yttrium or calcium. Porous
platinum coatings on the inside and outside serve as a catalyst and as elec-
trodes. At high temperatures (generally above 1200°F/650°C), oxygen mol-
ecules coming in contact with the platinum electrodes near the sensor be-
come ionic. As long as the oxygen partial pressures on either side of the
cell are equal, the movement is random and no net flow of ions occurs. If,
however, gases having different oxygen partial pressures are on either side
of the cell, a potentiometric voltage is produced (See Figure 1-1). The mag-
nitude of this voltage is a function of the ratio of the two oxygen partial
pressures. If the oxygen partial pressure of one gas is known, the voltage
produced by the cell indicates the oxygen content of the other gas. A refer-
ence gas, usually air (20.9% O2), is used for one of the gases.
Since the voltage of the cell is temperature dependent, the cell is main-
tained at a constant temperature. Some newer high temperature insitu
models use the heat from the process to heat the sensor, and the process
temperature is continuously measured and used in the software calcula-
tion. The oxygen content is then determined from the Nernst equation:
E = RT
4F O1
O2
ln

Overview |1-3
Figure 1-1.
Zirconium oxide cell
principle of operation.
where R and F are constants, T is absolute temperature, and O1and O2are
the oxygen partial pressures on either side of the cell.
For measuring oxygen in non-combustibles gases, the calibration of an ana-
lyzer is obtained from the formula:
Where Ais a constant, Tis the cell temperature on an absolute scale (°C +
273) and O2 Unk% is the unknown oxygen concentration of the gas to be
analyzed, and which is calculated by the analyzer.
The cell produces zero voltage when the same amount of oxygen is on
both sides, and the voltage increases as the oxygen concentration of the
sample decreases. The voltage created by the difference in the sample gas
and the reference air is carried by a cable to the microprocessor control
unit, where it is linearized to an output signal.
Because of the high operating temperature of the cell, combustible
gases that are present may burn. When this occurs, the cell will gen-
erate high millivolts and cause the display to indicate less oxygen
than is actually in the gas (net oxygen content).
E = A*T*Log AT = 48.0 at 695°C
20.9%
O2 Unk%

NOTE

1-4 |Thermox Series 2000 WDG-HPII / HPIIC - ATEX
The Combustibles Detector
The Combustibles Detector is a dual element device; the elements differ
only in that one is coated with a catalyst. The catalyst causes oxidation to
occur at a lower than normal temperature. The temperature of the cata-
lyzed element changes as the combustible mixture burns. The temperature
change causes the resistance of the catalyzed element to change. The resis-
tance change is interpreted by the microprocessor and the corresponding
combustibles reading is displayed.
The Thermox catalytic combustibles detector will detect combustible gas
present in a sample. The sample must, however, contain enough oxygen to
fully burn the combustible present. The combustibles detector responds to
all unburned combustibles gases, such as CO and H2. We recommend us-
ing an even mixture of CO and H2as the combustibles component within
your span gas, although you can also use all CO if needed.

Overview |1-5
Common Operator Errors
These are some common errors to avoid; if they are avoided, your analyzer
will operate with a minimum of maintenance and troubleshooting.
•If your process is running and the analyzer is installed on the process,
the analyzer must have power applied to it to prevent plugged plumb-
ing and sensor component damage. The case heaters must be on if the
process is running to maintain sensor plumbing above the process gas
dewpoint.
•Do not use pipe dope or any other contaminant that gives off combus-
tible vapor on any joints of the sample tubing.
•For O2calibration gases, do not use calibration gases if they contain a
mixture of oxygen and combustibles. Note, however, that this is ac-
ceptable for combustibles span gases (used only if you purchased the
combustibles option).
•Always introduce calibration gases at the recommended flow rate.
•When working on the plumbing inside the sensor cabinet, turn the
power off - the oxygen cell heater has exposed windings and a short to
the plumbing will blow the fuse and could damage the furnace or ther-
mocouple.
•Do not handle the cell excessively. Do not try to clean the cell except by
rinsing. If you need to handle the cell, grasp by touching the seal fit-
ting at the top; never touch the bare part of the cell.
•Do not remove a cell or type "K" thermocouple that you may want to
use again when the inside of the furnace is still hot - severe thermal
shock can be destructive to either of them.
•Always replace the metal cell O-ring when replacing the oxygen cell.

1-6 |Thermox Series 2000 WDG-HPII / HPIIC - ATEX
Start Up Checklist
•Review the installation chapter before installing this system.
•Install the probe tubes (sample and exhaust) and filter assembly to the
rear of the sensor.
•Install the sensor on the process. The ambient temperature must not
exceed 70°C (160°F). If it does, the sensor board that is located in the
sensor terminal box must be relocated to a junction box not more than
25 feet from the sensor, but in a location not to exceed 70°C.
• If the sensor is on a pipe nipple, insulate the exposed portion of
the pipe (insulate from the process wall to the mounting flange
of the sensor).
•Install the control unit. The ambient temperature must not exceed
50°C. (120°F).
• Do not create any additional conduit entries in the control unit
enclosure.
•Interconnect the control unit and the sensor as described in the appro-
priate interconnecting drawing.
• The specified cable must be used to ensure the proper opera-
tion of the system.
• Keep the interconnecting located in the control unit as short as
possible. A service loop need not be used.
• Maintain the ordered wire pairs per the drawing.
• Terminate the shields or drains of the cable properly.
•Connect AC power to the control unit and the sensor. Make sure that
the AC voltage is within specified limits.

Overview |1-7
Technical Support
AMETEK/Thermox is committed to providing you the best technical sup-
port in the industry. If you need service or application assistance, please
call AMETEK at [phone], or your local AMETEK/Thermox represen-
tative. Before you call the factory for technical support, run test gases and
record the following values (you may be asked by the factory to provide
this information when receiving service):
• Cell millivolts
• Thermocouple millivolts
• Cell temperature
• Box temperature
See “Display” under the Setup key section in the Controller/User Inter-
face chapter for help on how to get this information displayed on your
Series 2000 control unit.
Return of Equipment
If you need to return equipment, you will be asked to provide the follow-
ing information before obtaining a Return Material Authorization (RMA)
number.
•Billing and shipping address
•Model number
•Serial number
•Purchase order number
•Telephone number
Before returning material, you must get an RMA number from the
factory.

NOTE

1-8 |Thermox Series 2000 WDG-HPII / HPIIC - ATEX
This page intentionally left blank.

Specifications |2-1
SPECIFICATIONS
Series 2000 Control Unit
Display
4-line x 20-character vacuum fluorescent. Selectable displays with pass-
word protection, programmable pressure compensation and context-
sensitive help.
AnalogOutput
Two isolated linear current outputs. One additional output for
cumbustibles. Each output can be 4-20mA or 0-20 mA and is fully scal-
able. Hold or track during calibration and select degree of damping.
Alarms
Two independent oxygen alarms, each high or low selectable. Two high
combustibles alarms. One loss of purge alarm (on Sensor). One alarm can
be assigned as oxygen, in calibrate or in verify. Set relays to energize or
de-energize on alarm. SPST type.
Contact Rating
1A, 30 V max., noninductive load, AC or DC
Diagnostics
Watchdog timer and service alarms. System test for A/D, RAM, EEPROM
and keypad. Display line 4 reserved for full text error and diagnostic
messages. Twenty entry event log.
Communications
RS-485 2-way addressable.

2-2 |Thermox Series 2000 WDG-HPII / HPIIC - ATEX
Environment
Ambient Temp: -10 – 50°C
Relative Humidity: 10% to 80%, non-condensing
IEC Installation (Overvoltage) Category: II
IEC Pollution Degree 2
Max. Altitude: 2000 meters
Enclosure
Weatherproof NEMA 4 (IP 56). NEMA4X (IP56) Stainless Steel available as
option..
Calibration
Oxygen cell lifetime extender. Calibrate or verify calibration. Store last cali-
bration and verification data. Selectable calibration gas run time and pro-
cess recovery time.
PowerRequirements
104-253 VAC, 30 VA
HazardousLocation
LCIE 05 ATEX 6140 X and LCIE 05 ATEX 6140 X/01,
II 3 G, EEx nA IIC T3, -10°C </- Ta </- 50°C
SystemCompliance
EMC Compliance: 2004/108/EC
Electronics Safety Compliance: 73/23/EEC
ATEX Directive 94/9/EC
