Ametek 933S Manual

Model 933S UV Analyzer
Operator’s Guide
With Essential Health and Safety Requirements
PN 903-8798, Rev. A
Canada
A DIVISION OF AMETEK PROCESS & ANALYTICAL INSTRUMENTS
Western Research

ii | Model 933S UV Analyzer
© 2018 AMETEK Canada, A Division of AMETEK Process & Analytical Instruments Printed in Canada
This manual is a guide for the use of the Model 933S UV Analyzer. Data herein has been veried and validated and is believed adequate for the intended
use of this instrument. If the instrument or procedures are used for purposes over and above the capabilities specied herein, conrmation of their validity
and suitability should be obtained; otherwise, AMETEK does not guarantee results and assumes no obligation or liability. This publication is not a license
to operate under, or a recommendation to infringe upon, any process patents.
O󰀩ces
For other offices not listed here, visit us at www.ametekpi.com.
USA – HEADQUARTERS
150 Freeport Road
Pittsburgh, PA 15238, USA
Tel: [phone]
Toll Free: 800-537-6044
Fax: [phone]
USA – Delaware
455 Corporate Boulevard
Newark, DE 19702, USA
Tel: [phone] (Main)
800-537-6044 (Service)
800-222-6789 (Ordering)
Fax: [phone]
USA – Texas
4903 West Sam Houston Parkway North
Suite A-400
Houston, TX 77041, USA
Tel: [phone]
Toll Free: 1-800-634-8990
Fax: [phone]
CANADA
AMETEK Canada
2876 Sunridge Way N.E.
Calgary, AB, T1Y 7H9, Canada
Tel: [phone]
Toll Free: 800-661-9198
Fax: [phone]
INDIA
AMETEK Instruments India Pvt. Ltd.
1st Floor, Prestige Featherlite Tech Park
Plot 148, EPIP Phase II
Whitefield, Bengaluru – 560066, Karnataka, India
Tel: [phone]
Fax: [phone]
GERMANY
AMETEK GmbH
Rudolf-Diesel Strasse 16
D-40670 Meerbusch, Germany
Tel: [phone]
Fax: [phone]
FRANCE
AMETEK – APIF
Rond point de l’epine des champs
Buroplus Bat D
78990 Elancourt, France
Tel: [phone]
Fax: [phone]
CHINA
AMETEK Commercial Enterprise (Shanghai) Co. Ltd.
Part A First Floor, 460 North
Fute Road
Waigaoqiao Free Trade Zone
Shanghai, 200131, China
Tel: [phone]
Fax: [phone]
Beijing Branch
Tel: [phone]
Fax: [phone]
Chengdu Branch
Tel: [phone]
Fax: [phone]
Guangzhou Branch
Tel: [phone]
Fax: [phone]
MIDDLE EAST – Dubai
P.O. Box 17067
Jebel Ali Free Zone
Dubai, UAE
Tel: [phone]
Fax: [phone]
SINGAPORE
AMETEK Singapore Pte. Ltd.
No. 43, Changi South
Avenue 2, #04-01
486164 Singapore
Tel: [phone]
Fax: [phone]

Contents | iii
Contents
Offices .................................................................................................................................. ii
Safety Notes .....................................................................................................................viii
Electrical Safety................................................................................................................viii
Grounding........................................................................................................................viii
Personnel and Equipment Safety Information............................................................. ix
Warnings ...................................................................................................................... ix
Cautions ........................................................................................................................ x
Warning Labels.................................................................................................................. xi
Environmental Information ............................................................................................ xi
UV Source Lamps Disposal ............................................................................................. xi
Electromagnetic Compatibility (EMC).......................................................................... xii
Special Warnings and Information............................................................................... xiii
Equipment Used in Class I, Division 2 Hazardous Locations........................... xiii
EU Declaration of Conformity ...................................................................................... xiv
Warranty and Claims...................................................................................................... xvi
CHAPTER 1 OVERVIEW....................................................................................................... 1-1
About the Analyzer......................................................................................................... 1-2
About the Analyzer Sample System............................................................................. 1-4
Working in This Manual ................................................................................................ 1-6
Supplemental Information – Where Can I Find It?................................................... 1-7
CHAPTER 2 SPECIFICATIONS ........................................................................................... 2-1
Methodology.................................................................................................................... 2-1
Full-Scale Ranges............................................................................................................. 2-1
Standard Range Measuring Cells (40 cm or Smaller)................................................ 2-1
Low Range Measuring (White) Cell Option (81.2 cm).............................................. 2-1
Response Time................................................................................................................. 2-2
Accuracy............................................................................................................................ 2-2
Repeatability .................................................................................................................... 2-2
Calibration........................................................................................................................ 2-2
Linearity............................................................................................................................ 2-2
Stability ............................................................................................................................. 2-2
Sensitivity ......................................................................................................................... 2-3
Cross-Talk.......................................................................................................................... 2-3
Temperature Drift............................................................................................................ 2-3
24-Hour Zero Drift .......................................................................................................... 2-3
Customer Connections................................................................................................... 2-4
Analog Outputs ........................................................................................................ 2-4
Digital Communication ........................................................................................... 2-4
Digital Inputs............................................................................................................. 2-4

iv | Model 933S UV Analyzer
Electrical Requirements.................................................................................................. 2-4
Maximum Start-Up Power ...................................................................................... 2-4
Supply Voltage / Maximum Current ..................................................................... 2-4
Sample Gas Flow Rate.................................................................................................... 2-4
Zero Gas............................................................................................................................ 2-5
Ambient Limits ................................................................................................................ 2-5
Temperature............................................................................................................... 2-5
Humidity.................................................................................................................... 2-5
Maximum Altitude ................................................................................................... 2-5
Sample Pressure Requirement...................................................................................... 2-5
Sample Stream Compatibility ....................................................................................... 2-6
Maximum Sample Gas Temperature............................................................................ 2-6
Maximum Sample Cell Pressure................................................................................... 2-6
Physical Dimensions (on Backpan).............................................................................. 2-6
Options ............................................................................................................................. 2-6
Carbon Dioxide Sensor................................................................................................... 2-7
Accuracy..................................................................................................................... 2-7
Cross-Talk................................................................................................................... 2-7
Temperature Drift..................................................................................................... 2-7
24-Hour Zero Drift ................................................................................................... 2-7
Approvals and Certifications......................................................................................... 2-8
ATEX and IECEx Certificates and Analyzer Markings....................................... 2-9
CSA Certificate and Analyzer Marking............................................................... 2-17
CHAPTER 3 INSTALLATION AND START-UP................................................................... 3-1
Safety Considerations..................................................................................................... 3-2
Pre-Installation Requirements....................................................................................... 3-2
Storage Prior to Installation .................................................................................... 3-2
Uncrating and Inspecting the Analyzer................................................................ 3-3
General Installation Information ........................................................................... 3-4
Tools and Equipment Required.............................................................................. 3-4
Installing the Mechanical Components....................................................................... 3-5
Installing the Analyzer............................................................................................. 3-5
Location and Environment...................................................................................3-5
Installing the Optical Bench Assembly ................................................................. 3-7
Installing the Sample System.................................................................................. 3-9
Installing the Sample Probe..................................................................................3-9
Installing the Sample and Vent Lines...................................................................3-9
Installing the Zero Gas Line...............................................................................3-11
Electrical Connections .................................................................................................. 3-12
Input/Output Signal Connections ....................................................................... 3-12
Digital Communication ......................................................................................... 3-13
Hardware Configuration (Modbus Serial Communication) ..............................3-13
Multiple-Analyzer (Multi-Drop) System Configuration...................................3-17
AC Power Connection and Fusing....................................................................... 3-19
European Installation.........................................................................................3-20
North American Installation ..............................................................................3-20

Contents | v
S93XS System 200 Configurator Software Installation............................................ 3-22
Minimum PC Requirements for Configurator Software.................................. 3-22
Installing the S93XS System 200 Configurator Software.................................. 3-23
Removing the Configurator Software................................................................. 3-25
Start-Up and Verification ............................................................................................. 3-26
Powering Up the Analyzer.................................................................................... 3-26
Start-Up Diagnostic Checklist ...........................................................................3-36
Sample System Leak Check......................................................................................... 3-38
Sample Conditioning System Optimization............................................................. 3-41
Column Switch Time Optimization .................................................................... 3-41
Hold Time Optimization ....................................................................................... 3-46
CHAPTER 4 CONTROLLER / USER INTERFACE............................................................. 4-1
System 200 Configurator Software Overview – Getting Started ............................ 4-2
Navigating in the Software..................................................................................... 4-2
Starting the Configurator Software and Establishing Communication
Between the Analyzer and Computer .................................................................. 4-4
Closing the Configurator Software........................................................................ 4-6
Configurator Software Troubleshooting ...............................................................4-7
General Tab................................................................................................................ 4-9
Modbus Serial / Modbus TCP Communication Setup.......................................4-11
User Interface .......................................................................................................... 4-14
Setting Up the Main Window............................................................................4-14
Viewing Device Activities ..................................................................................4-15
Saving Analyzer Configuration Parameters ......................................................4-16
Restoring Analyzer Configuration Parameters..................................................4-16
Modifying Analyzer Device Settings ......................................................................... 4-18
Working From the Setup Tab ................................................................................ 4-18
Saving Analyzer Configuration Parameters to an ASCII File ...........................4-21
Printing Analyzer Configuration Parameters....................................................4-21
Refreshing Configuration or Calibration Parameters.........................................4-22
Saving Configuration or Calibration Parameters to EEPROM.........................4-22
Optical Bench .....................................................................................................4-23
Cell/Miscellaneous (Compensations) Parameters...............................................4-28
Temperature Control ..........................................................................................4-31
Optical Bench Temperature Control ............................................................4-33
Measuring Cell (Oven) Temperature Control (Optional) ...........................4-34
Column Block Temperature Control ............................................................4-36
Output Setup .....................................................................................................4-37
Sensors Setup .....................................................................................................4-40
Modbus Settings.................................................................................................4-46
Matrix ................................................................................................................4-47
Analytical Parameters.........................................................................................4-48
Analog Inputs.....................................................................................................4-49
Setting Gas Calibration Parameters ...................................................................4-51

vi | Model 933S UV Analyzer
Alarm Setting and Stream Switch Parameters...................................................4-56
Analyzer Information .........................................................................................4-59
Column Timing ..................................................................................................4-61
Viewing Analyzer Data ................................................................................................ 4-62
Status Tab ................................................................................................................. 4-62
Analyzer Data Tab................................................................................................... 4-68
Optical Bench Data Tab ......................................................................................... 4-70
CHAPTER 5 CALIBRATION ................................................................................................. 5-1
Calibrating the Analyzer and Gas Sensors.................................................................. 5-2
Analog Output Calibration............................................................................................ 5-8
Current Calibration .................................................................................................. 5-8
Voltage Calibration ................................................................................................. 5-10
CHAPTER 6 MAINTENANCE AND TROUBLESHOOTING............................................... 6-1
Safety Considerations..................................................................................................... 6-1
Preventive Maintenance ................................................................................................ 6-3
Analyzer Preventive Maintenance Schedule....................................................... 6-4
Preventing, Detecting, and Locating a Plug in the Sample System................. 6-6
Changing Out Replaceable Parts ........................................................................... 6-8
Measuring Cell Maintenance...............................................................................6-9
Column Block Maintenance ...............................................................................6-18
Source Lamp Replacement..................................................................................6-25
When Do Source Lamps Need to be Replaced?............................................6-25
About the Source Lamps ..............................................................................6-26
Replacing the Source Lamps........................................................................6-26
When is an Auto-Setup Required / Not Required?......................................6-34
PMT Level and PMT Balance .....................................................................6-35
Auto-Setup Fault Message and Corrective Action ......................................6-36
The Auto-Setup Sequence ............................................................................6-36
Cancel Auto-Setup.......................................................................................6-37
Manipulating the PMT Level and PMT Balance........................................6-38
Source Lamp Alignment ..............................................................................6-40
Natural Gas Filterblock Maintenance ................................................................6-42
Filtration Stages...........................................................................................6-43
Vent Flow .....................................................................................................6-43
Replacing Parts in the Filterblock ................................................................6-44
Chopper Assembly Maintenance ........................................................................6-49
Examining and Caring for the Flamepaths ........................................................ 6-57
Upper/Lower Electronics Enclosure Flamepaths (Joining Surfaces)..................6-59
Troubleshooting and Diagnostics ............................................................................... 6-60
Host Controller Board Alarm Conditions and Corrective Action .................. 6-62
Microcontroller Board Alarm Conditions and Corrective Action .................. 6-71
Analyzer Reset ........................................................................................................ 6-80

Contents | vii
CHAPTER 7 SERVICE AND PARTS.................................................................................... 7-1
Technical Support............................................................................................................ 7-1
Returning Equipment..................................................................................................... 7-2
AMETEK SERVICE and AFTERMARKET SALES SUPPORT............................ 7-3
Recommended Preventive Maintenance Spare Parts ............................................... 7-4
Optical Bench/Sample System Spare Parts........................................................... 7-4
Spare Analyzer Fuses ............................................................................................... 7-6
Replacement Boards................................................................................................. 7-7
Ordering a Hard Copy of the Analyzer Operator’s Guide ................................ 7-7
APPENDIX A – DRAWINGS...................................................................................................A-1
Block Diagram, European Style (WX-933ATEX-1) .................................................... A-2
Block Diagram, North American Style (WX-933NA-1) ............................................ A-3
Sample Flow Diagram (Plumbing Schematic), North American Style
(WX-933NA-2)................................................................................................................. A-4
Backpan Component Layout, North American Style (WX-933NA-3A) ................ A-5
Backpan Dimensions, North American Style (WX-933NA-3) ................................. A-6
Conduit Entries, I/O and AC Power Connection Locations, North American
Style (WX-933NA-3B)..................................................................................................... A-7
Lower Enclosure Layout (WX-14838) ......................................................................... A-8
Customer Connections Wiring Schematic, North American Style/120 VAC ........ A-9
RS-232 Communications Cable Connections (300-9480) ....................................... A-10
Analyzer Wiring Diagram (WX-102860-1)................................................................ A-11
TC Sensor Wiring Diagram (WX-102860-2).............................................................. A-12
IR Sensor Wiring Diagram (WX-102860-3) ............................................................... A-13
Optional HMI and Ethernet Gateway Wiring Diagram (WX-102860-4) ............. A-14
Optical Bench Board (P/N 100-1662)......................................................................... A-15
PMT Buffer Board (100-0140) ..................................................................................... A-16
Sample Probe – North American/European Style................................................... A-17
Sample Probe, Recommended Mounting Details – North American (CSA)/
European (Zone 1/ATEX) ............................................................................................ A-18
Solenoid Block, North American Style (100-1791-1A) ............................................ A-19
Solenoid Block, European Style (100-1917-1A)........................................................ A-20
Inlet and Vent Flame Arrestor Locations, Environmental Purge Option
(100-1783-1A)................................................................................................................. A-21
Backpan Component Layout, Division 2 Analyzer with Sensor (Example)....... A-22
SUPPLEMENTAL INFORMATION ........................................................................................S-1

viii | Model 933S UV Analyzer
Safety Notes
WARNINGS, CAUTIONS, and NOTES contained in this manual emphasize critical instruc-
tions as follows:
An operating procedure which, if not strictly observed, may result in personal injury or envi-
ronmental contamination. Essential Health and Safety Requirements are also included in
– but are not limited to – Warnings.
An operating procedure which, if not strictly observed, may result in damage to the equipment.
Important information that should not be overlooked.
Electrical Safety
High voltages are present in the analyzer housings. Always shut down power source(s) before
performing maintenance or troubleshooting. Only a qualified electrician should make electrical
connections and ground checks.
Any use of the equipment in a manner not specified by the manufacturer may impair the safety
protection originally provided by the equipment.
Grounding
Instrument grounding is mandatory. Performance specifications and safety protection are void if
instrument is operated from an improperly grounded power source.
Verify ground continuity of all equipment before applying power.
!
WARNING
!
CAUTION
!
CAUTION

NOTE

Contents | ix
Personnel and Equipment Safety Information
This section describes important safety information to avoid personal injury and damage to the
equipment while installing, operating, maintaining, or servicing the equipment. All safety regu-
lations, standards, and procedures at the analyzer location must be followed.
All personnel involved with the installation, start-up, operation, maintenance, service, or trou-
bleshooting of the analyzer must review and follow these Warnings and Cautions.
Warnings
Review and follow these Warnings to avoid personal injury or environmental contamination.
Always disconnect main AC power and/or external power sources (example, for relay contacts)
to the analyzer before removing any sample system assemblies and components from the ana-
lyzer, or before opening any covers on the analyzer.
If it is necessary to open the Upper/Lower Ex d Electronics Enclosures while the circuits are
live, test the area for explosive gases and proceed only when the area is safe. When the Enclo-
sures are open, take appropriate precautions to avoid electrical shock. Hazardous voltages are
present inside.
All electrical connections, adjustments, or servicing of the analyzer should be performed only
by properly trained and qualified personnel.
All electrical connections, materials, and methods (plus all safety policies and procedures) must
be made in compliance with local wiring regulations and electrical code for the hazardous area,
and be approved by the Owner Company.
Before working on the sample system, confirm that the system is purged with Zero gas and is
isolated (blocked in) from the process.
Because ultraviolet radiation can harm your eyes, avoid direct viewing of the light emanating
through the end window of the source lamp. If the source lamp must be viewed while ener-
gized, wear safety glasses that block ultraviolet radiation.
For Division 1/Zone 1 Installations, all cable entry glands (one power cable entry and two
signal cable entries) into the flameproof Disconnect Enclosure must be Ex d certified. Conduit
or cable seals that comply with the flameproof enclosure cable entry sealing requirements of the
local authority must be installed at the entries to the enclosure. In all cases, each unused cable
entry port must be plugged with a certified Ex d plug.
!
WARNING
!
WARNING
!
WARNING
!
WARNING
!
WARNING

x | Model 933S UV Analyzer
If the analyzer uses the optional Measuring Cell heater, take precautions to avoid burning
yourself; the Measuring Cell and Heater Assembly are hot.
Cautions
Review and follow these Cautions to avoid damaging the equipment.
The electronic circuit boards and other static-sensitive components should be stored and trans-
ported in static-shielding carriers or packages.
For electrical-shock protection, the analyzer must be operated from a grounded power source
that has a securely connected protective-ground contact.
If it becomes necessary to handle any of the electronic circuit boards, do not subject the boards
to static discharge. The ideal solution is a static-safe work area. Since such areas typically are
not available at field installation sites, the use of a wrist strap connected directly to a ground
is recommended. If a wrist strap is not available, you should at the very least touch the metal
chassis (to ground yourself) before handling or touching the boards.
When handling the source lamps, it is very important not to touch the lamp windows because
residual oils from the fingers will absorb ultraviolet light. The window is the flat surface at the
end of the narrow glass tube. The lamp assembly is fragile and should be handled with care.
Do not exceed the maximum working pressure rating of the sample system under any circum-
stances:
• Systems with Filterblock Assembly: 13 790 KPAG (2000 PSIG).
• Systems without Filterblock Assembly: 20 700 KPAG (3000 PSIG).
If the analyzer is equipped with the Environmental Purge option, clean air or nitrogen can be
supplied to the inlet flame arrester at a pressure of 7–70 KPAG (1–10 PSIG).
!
CAUTION
!
CAUTION
!
CAUTION
!
CAUTION
!
CAUTION
!
CAUTION
!
WARNING
