Installation and
Operating Instructions
IntelliPoint RFTM RML Series
Point Level Switch
with Manual Calibration/Set Point
U.S. and Canada: 1-800-553-9092
24-Hour Service: 1-800-527-6297
International: +1 215-674-1234
Fax: +1 215-674-2731
Website: www.drexelbrook.com
AMETEK Drexelbrook makes no warranty of any kind with regard to the material contained in
this manual, including, but not limited to, implied warranties or fitness for a particular purpose.
Drexelbrook shall not be liable for errors contained herein or for incidental or consequential
damages in connection with the performance or use of material.
© AMETEK Drexelbrook
IntelliPointTM RF RML Series
Point Level Switch
with Manual Calibration/Set Point
RMLXX1-LM
EDO# 11-08-107
Issue# 11
205 Keith Valley Road, Horsham, PA 19044
U.S. and Canada: 1-800-553-9092
24-Hour Service: 1-800-527-6297
International: +1 215-674-1234
Fax: +1 215-674-2731
Website: www.drexelbrook.com
An ISO 9001 Certified Company
Extend your warranty!
...from 12 months to 36 months by
registering your purchase. Please
go to www.drexelbrook.com.
Click on "Contact Us"
then"Warranty Registration"
and fill out the form.
Contents
Contents
Section 1: Introduction .......................................................................................................... 1
1.1 System Description ................................................................................................ 1
1.2 Technology............................................................................................................. 1
1.3 Model Number ....................................................................................................... 2
1.4 Dual Compartment Housing .................................................................................. 4
Section 2: Installation ............................................................................................................ 5
2.1 Unpacking .............................................................................................................. 5
2.2 Mounting and Installation Guidelines ..................................................................... 5
2.3 Input Wiring............................................................................................................ 8
2.4 Output Wiring - Relay Version ................................................................................ 8
2.5 Spark Protection .................................................................................................... 9
2.6 Circuit Board .......................................................................................................... 9
2.7 Output and LED Status .......................................................................................... 11
2.8 Sensing Element Connection................................................................................. 12
Section 3: Calibration ............................................................................................................ 15
3.1 Setpoint Control ..................................................................................................... 15
3.2 Adjustable Differential Controls.............................................................................. 15
3.3 Calibration Procedures .......................................................................................... 15
Section 4: Spare Parts List.................................................................................................... 21
4.1 Spare Parts List ..................................................................................................... 21
Section 5: Troubleshooting ................................................................................................... 23
5.1 Testing Sensing Element ....................................................................................... 23
5.2 Testing Electronic Unit ........................................................................................... 24
5.3 Testing Relay Circuits............................................................................................. 24
5.4 Over Range............................................................................................................ 25
5.5 Under Range.......................................................................................................... 25
5.6 Testing Integral Cable ............................................................................................ 25
5.7 Testing Remote Cable............................................................................................ 26
5.8 Testing Power Supply............................................................................................. 26
5.9 Factory Assistance................................................................................................. 27
5.10 Field Service .......................................................................................................... 27
5.11 Customer Training .................................................................................................. 27
5.12 Equipment Return.................................................................................................. 28
Section 6: Specifications....................................................................................................... 29
Section 7: Control Drawings ................................................................................................. 31
7.1 FM Control Drawings ............................................................................................. 31
7.2 Mounting and Wiring for Spark Protector Drawings ............................................... 42
7.3 Adding a Padded Capacitor ................................................................................... 45
Appendix A Shortening or Lengthening Sensing Element................................................... A-1
Section 1
IntelliPoint RF RML Series Introduction
1
Section 1: Introduction
1.1 System Description
The AMETEK Drexelbrook, IntelliPoint RML and RGL
Series point level switches detect the presence or absence
of material and provide a relay output for control functions.
The RML and RGL IntelliPoint switches are calibrated
through a simple potentiometer adjustment.
Since the IntelliPoint RML Series requires calibration and
setpoint adjustments, it is not capable of operating in non-
dedicated tanks.
1.2 Technology
In a simple capacitance probe-type sensing element,
when the level rises and material covers the probe, the
capacitance within the circuit between the probe and the
media (conductive applications), or the probe and the vessel
wall (insulating applications), increases. This is due to
the dielectric constant (k) of the material which causes a
bridge imbalance. The signal is demodulated (rectied)
and amplied, then the output is increased. There are
drawbacks, however, especially when there is coating of the
probe.
An RF Admittance level transmitter is the next generation.
Although similar to the capacitance concept, IntelliPoint
employs a radio frequency signal and adds the Cote-Shield
circuitry within the Electronics Unit. This patented Cote-
Shield circuitry is designed into the IntelliPoint series and
enables the instrument to ignore the effect of buildup, that
is, material coating on the sensing element. The sensing
element is mounted in the vessel and provides a change
in RF admittance indicating the presence or absence of
material.
The Cote-Shield element of the sensor prevents the
transmission of RF current through the coating on the
sensing element. The only path to ground available for the
RF current is through the material being measured.
The result is an accurate measurement regardless of the
amount of coating on the probe, making it the most versatile
technology available by far. Not only does it work with all
types of materials, it's well suited to a very broad range
of conditions, from cryogenics to high temperature, from
vacuum all the way to 10,000psi
pressure.
Figure 1-1
Simple Capacitance
Probe
k
air
A
d
Ckmedia
C=kA
d
C = k A
d
A
k
air
d
C
kmedia
Figure 1-2
RF Admittance Probe
with Cote-Shield
IntelliPoint RF RML Series Introduction
2
1.3 Model Number
Continued on Next Page
Sensing Element
Application Sensing Element Pressure/Temperature Wetted Parts
00 General purpose 700-1202-001 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-021 integral
01 Floating roof with 700-1202-012 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS, Brass,
cable attachment 700-1202-022 integral and PEEK
and brass bottom weight
02 General purpose, 700-1202-014 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS and PEEK
longer insertion lengths 700-1202-024 integral
with cable attachment
and 316SS bottom weight
03 Proximity 700-1202-018 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-028 integral with 76 mm (3)
316SS proximity plate
04 General purpose, 700-1202-041 remote 69 bar @ 121°C (1000 PSI @ 250°F) 316SS and PEEK
high temperature 700-1202-042 integral 20.7 bar @ 232°C (300 PSI @ 450°F)
and pressure
06 General purpose with 700-1202-031 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
FDA approved 700-1202-032 integral PEEK
materials of construction
07 General purpose 700-1202-010 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK with
Granular materials 700-1202-020 integral 7/8 inch dia. 316SS collar
09 General purpose 700-1202-033 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
Granular materials with 700-1202-034 integral PEEK with 7/8 inch dia.
FDA approved 316SS collar
materials of construction
10 Corrosive liquids (2)(4)(9) 700-0001-018 remote 3.4 bar @ 149°C (50 PSI @ 300°F) PFA
11 General purpose, 700-0201-005 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
higher pressure 13.8 bar @ 232°C (200 PSI @ 450°F)
TFE compatibility required
12 Corrosive material, 700-0201-005 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) Hastelloy C and TFE
higher pressure Hastelloy C 13.8 bar @ 232°C (200 PSI @ 450°F)
13 Sanitary (3) 700-0201-036 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316/316L SS and TFE
13.8 bar @ 232°C (200 PSI @ 300°F)
14 General Purpose, 700-0202-002 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
low pressure 1.4 bar @ 232°C (20 PSI @ 450°F)
15 Heavy duty, agitated 700-0202-043 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
tanks or material 13.8 bar @ 232°C (200 PSI @ 450°F)
with high bulk density (1)
16 High Integrity Seal for 700-0002-360 int/rem 34.5 bar @ 149°C (500 PSI @ 300°F) PFA
Hazardous Materials
17 Sanitary (3) lowpressure 700-0202-036 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
18 Corrosive material, 700-0001-022 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) TFE
higher pressure with 34.5 bar @ 149°C (500 PSI @ 300°F)
waterlike viscosity (4)
19 Interface Measurement 700-0002-023 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
34.5 bar @ 149°C (500 PSI @ 300°F)
20 Miniature Pilot 700-0209-002 remote 6.9 bar @ 121°C (100 PSI @ 250°F) 316 SS and TFE
Plant Sensor (1)(7) 0 bar @ 232°C (0 PSI @ 450°F)
Fly Ash Precipitators, Baghouse, and Economizers (1) (6)
Application Sensing Element Pressure/Temperature Wetted Parts
31 No hopper Installation 700-0029-001 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
32 Hopper Installation 700-0029-002 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 200mm (8 inches)
33 Hopper Installation 700-0029-003 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 406mm (16 inches)
34 Hopper Instalation 700-0029-004 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 521mm (20.5 inches)
35 Hopper Installation 700-0029-005 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 635mm (25 inches)
Plugged Chute Detection (1) (5)
Application Sensing Element Pressure/Temperature Wetted Parts
50 Flush Mount Sensor 700-0207-001 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
305mm2(12 inches2) Polyurethane
heavy duty
51 Flush Mount Sensor 700-0207-002 remote 0.1 bar @ 149°C (1 PSI @ 300°F) 304 SS and TFE
305mm2(12 inches2)
higher temperature
52 Flush Mount Sensor 700-0207-003 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and Neoprene
305mm2(12 inches2)
with curved radius 153, 229, 305 mm (6, 9, or 12 inches)
53 Flush Mount Sensor 700-0207-004 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 410 SS and UHMW
305mm2(12 inches2) Polyethylene
extra heavy duty
55 Flush Mount Sensor 700-0207-006 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
203mm2 (8 inches2) Polyurethane
heavy duty
High Pressure / High Temperature
60 High Pressure & Temp. 700-0204-038 remote 137.9 bar @ 93°C (2000 PSI @ 200°F) 316SS and Ceramic
68.9 bar @ 260°C (1000 PSI @ 500°F)
61 High Temperature 700-0204-002 remote 0 bar @ 816°C (0 PSI @ 1500°F) 316SS and Ceramic
62 High Pressure & Temp. 700-0204-048 remote 275.8 bar @316°C (4000 PSI @ 600°F) 316SS
ZZ Sensing Element Not Listed
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options available with all
sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Sensing Element
Application Sensing Element Pressure/Temperature Wetted Parts
00 General purpose 700-1202-001 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-021 integral
01 Floating roof with 700-1202-012 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS, Brass,
cable attachment 700-1202-022 integral and PEEK
and brass bottom weight
02 General purpose, 700-1202-014 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS and PEEK
longer insertion lengths 700-1202-024 integral
with cable attachment
and 316SS bottom weight
03 Proximity 700-1202-018 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-028 integral with 76 mm (3)
316SS proximity plate
04 General purpose, 700-1202-041 remote 69 bar @ 121°C (1000 PSI @ 250°F) 316SS and PEEK
high temperature 700-1202-042 integral 20.7 bar @ 232°C (300 PSI @ 450°F)
and pressure
06 General purpose with 700-1202-031 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
FDA approved 700-1202-032 integral PEEK
materials of construction
07 General purpose 700-1202-010 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK with
Granular materials 700-1202-020 integral 7/8 inch dia. 316SS collar
09 General purpose 700-1202-033 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
Granular materials with 700-1202-034 integral PEEK with 7/8 inch dia.
FDA approved 316SS collar
materials of construction
10 Corrosive liquids (2)(4)(9) 700-0001-018 remote 3.4 bar @ 149°C (50 PSI @ 300°F) PFA
11 General purpose, 700-0201-005 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
higher pressure 13.8 bar @ 232°C (200 PSI @ 450°F)
TFE compatibility required
12 Corrosive material, 700-0201-005 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) Hastelloy C and TFE
higher pressure Hastelloy C 13.8 bar @ 232°C (200 PSI @ 450°F)
13 Sanitary (3) 700-0201-036 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316/316L SS and TFE
13.8 bar @ 232°C (200 PSI @ 300°F)
14 General Purpose, 700-0202-002 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
low pressure 1.4 bar @ 232°C (20 PSI @ 450°F)
15 Heavy duty, agitated 700-0202-043 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
tanks or material 13.8 bar @ 232°C (200 PSI @ 450°F)
with high bulk density (1)
16 High Integrity Seal for 700-0002-360 int/rem 34.5 bar @ 149°C (500 PSI @ 300°F) PFA
Hazardous Materials
17 Sanitary (3) lowpressure 700-0202-036 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
18 Corrosive material, 700-0001-022 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) TFE
higher pressure with 34.5 bar @ 149°C (500 PSI @ 300°F)
waterlike viscosity (4)
19 Interface Measurement 700-0002-023 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
34.5 bar @ 149°C (500 PSI @ 300°F)
20 Miniature Pilot 700-0209-002 remote 6.9 bar @ 121°C (100 PSI @ 250°F) 316 SS and TFE
Plant Sensor (1)(7) 0 bar @ 232°C (0 PSI @ 450°F)
Fly Ash Precipitators, Baghouse, and Economizers (1) (6)
Application Sensing Element Pressure/Temperature Wetted Parts
31 No hopper Installation 700-0029-001 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
32 Hopper Installation 700-0029-002 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 200mm (8 inches)
33 Hopper Installation 700-0029-003 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 406mm (16 inches)
34 Hopper Instalation 700-0029-004 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 521mm (20.5 inches)
35 Hopper Installation 700-0029-005 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 635mm (25 inches)
Plugged Chute Detection (1) (5)
Application Sensing Element Pressure/Temperature Wetted Parts
50 Flush Mount Sensor 700-0207-001 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
305mm2(12 inches2) Polyurethane
heavy duty
51 Flush Mount Sensor 700-0207-002 remote 0.1 bar @ 149°C (1 PSI @ 300°F) 304 SS and TFE
305mm2(12 inches2)
higher temperature
52 Flush Mount Sensor 700-0207-003 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and Neoprene
305mm2(12 inches2)
with curved radius 153, 229, 305 mm (6, 9, or 12 inches)
53 Flush Mount Sensor 700-0207-004 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 410 SS and UHMW
305mm2(12 inches2) Polyethylene
extra heavy duty
55 Flush Mount Sensor 700-0207-006 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
203mm2 (8 inches2) Polyurethane
heavy duty
High Pressure / High Temperature
60 High Pressure & Temp. 700-0204-038 remote 137.9 bar @ 93°C (2000 PSI @ 200°F) 316SS and Ceramic
68.9 bar @ 260°C (1000 PSI @ 500°F)
61 High Temperature 700-0204-002 remote 0 bar @ 816°C (0 PSI @ 1500°F) 316SS and Ceramic
62 High Pressure & Temp. 700-0204-048 remote 275.8 bar @316°C (4000 PSI @ 600°F) 316SS
ZZ Sensing Element Not Listed
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options available with all
sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Sensing Element
Application Sensing Element Pressure/Temperature Wetted Parts
00 General purpose 700-1202-001 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-021 integral
01 Floating roof with 700-1202-012 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS, Brass,
cable attachment 700-1202-022 integral and PEEK
and brass bottom weight
02 General purpose, 700-1202-014 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS and PEEK
longer insertion lengths 700-1202-024 integral
with cable attachment
and 316SS bottom weight
03 Proximity 700-1202-018 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-028 integral with 76 mm (3)
316SS proximity plate
04 General purpose, 700-1202-041 remote 69 bar @ 121°C (1000 PSI @ 250°F) 316SS and PEEK
high temperature 700-1202-042 integral 20.7 bar @ 232°C (300 PSI @ 450°F)
and pressure
06 General purpose with 700-1202-031 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
FDA approved 700-1202-032 integral PEEK
materials of construction
07 General purpose 700-1202-010 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK with
Granular materials 700-1202-020 integral 7/8 inch dia. 316SS collar
09 General purpose 700-1202-033 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
Granular materials with 700-1202-034 integral PEEK with 7/8 inch dia.
FDA approved 316SS collar
materials of construction
10 Corrosive liquids (2)(4)(9) 700-0001-018 remote 3.4 bar @ 149°C (50 PSI @ 300°F) PFA
11 General purpose, 700-0201-005 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
higher pressure 13.8 bar @ 232°C (200 PSI @ 450°F)
TFE compatibility required
12 Corrosive material, 700-0201-005 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) Hastelloy C and TFE
higher pressure Hastelloy C 13.8 bar @ 232°C (200 PSI @ 450°F)
13 Sanitary (3) 700-0201-036 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316/316L SS and TFE
13.8 bar @ 232°C (200 PSI @ 300°F)
14 General Purpose, 700-0202-002 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
low pressure 1.4 bar @ 232°C (20 PSI @ 450°F)
15 Heavy duty, agitated 700-0202-043 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
tanks or material 13.8 bar @ 232°C (200 PSI @ 450°F)
with high bulk density (1)
16 High Integrity Seal for 700-0002-360 int/rem 34.5 bar @ 149°C (500 PSI @ 300°F) PFA
Hazardous Materials
17 Sanitary (3) lowpressure 700-0202-036 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
18 Corrosive material, 700-0001-022 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) TFE
higher pressure with 34.5 bar @ 149°C (500 PSI @ 300°F)
waterlike viscosity (4)
19 Interface Measurement 700-0002-023 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
34.5 bar @ 149°C (500 PSI @ 300°F)
20 Miniature Pilot 700-0209-002 remote 6.9 bar @ 121°C (100 PSI @ 250°F) 316 SS and TFE
Plant Sensor (1)(7) 0 bar @ 232°C (0 PSI @ 450°F)
Fly Ash Precipitators, Baghouse, and Economizers (1) (6)
Application Sensing Element Pressure/Temperature Wetted Parts
31 No hopper Installation 700-0029-001 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
32 Hopper Installation 700-0029-002 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 200mm (8 inches)
33 Hopper Installation 700-0029-003 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 406mm (16 inches)
34 Hopper Instalation 700-0029-004 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 521mm (20.5 inches)
35 Hopper Installation 700-0029-005 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 635mm (25 inches)
Plugged Chute Detection (1) (5)
Application Sensing Element Pressure/Temperature Wetted Parts
50 Flush Mount Sensor 700-0207-001 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
305mm2(12 inches2) Polyurethane
heavy duty
51 Flush Mount Sensor 700-0207-002 remote 0.1 bar @ 149°C (1 PSI @ 300°F) 304 SS and TFE
305mm2(12 inches2)
higher temperature
52 Flush Mount Sensor 700-0207-003 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and Neoprene
305mm2(12 inches2)
with curved radius 153, 229, 305 mm (6, 9, or 12 inches)
53 Flush Mount Sensor 700-0207-004 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 410 SS and UHMW
305mm2(12 inches2) Polyethylene
extra heavy duty
55 Flush Mount Sensor 700-0207-006 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
203mm2 (8 inches2) Polyurethane
heavy duty
High Pressure / High Temperature
60 High Pressure & Temp. 700-0204-038 remote 137.9 bar @ 93°C (2000 PSI @ 200°F) 316SS and Ceramic
68.9 bar @ 260°C (1000 PSI @ 500°F)
61 High Temperature 700-0204-002 remote 0 bar @ 816°C (0 PSI @ 1500°F) 316SS and Ceramic
62 High Pressure & Temp. 700-0204-048 remote 275.8 bar @316°C (4000 PSI @ 600°F) 316SS
ZZ Sensing Element Not Listed
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options available with all
sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Sensing Element
Application Sensing Element Pressure/Temperature Wetted Parts
00 General purpose 700-1202-001 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-021 integral
01 Floating roof with 700-1202-012 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS, Brass,
cable attachment 700-1202-022 integral and PEEK
and brass bottom weight
02 General purpose, 700-1202-014 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS and PEEK
longer insertion lengths 700-1202-024 integral
with cable attachment
and 316SS bottom weight
03 Proximity 700-1202-018 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-028 integral with 76 mm (3)
316SS proximity plate
04 General purpose, 700-1202-041 remote 69 bar @ 121°C (1000 PSI @ 250°F) 316SS and PEEK
high temperature 700-1202-042 integral 20.7 bar @ 232°C (300 PSI @ 450°F)
and pressure
06 General purpose with 700-1202-031 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
FDA approved 700-1202-032 integral PEEK
materials of construction
07 General purpose 700-1202-010 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK with
Granular materials 700-1202-020 integral 7/8 inch dia. 316SS collar
09 General purpose 700-1202-033 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
Granular materials with 700-1202-034 integral PEEK with 7/8 inch dia.
FDA approved 316SS collar
materials of construction
10 Corrosive liquids (2)(4)(9) 700-0001-018 remote 3.4 bar @ 149°C (50 PSI @ 300°F) PFA
11 General purpose, 700-0201-005 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
higher pressure 13.8 bar @ 232°C (200 PSI @ 450°F)
TFE compatibility required
12 Corrosive material, 700-0201-005 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) Hastelloy C and TFE
higher pressure Hastelloy C 13.8 bar @ 232°C (200 PSI @ 450°F)
13 Sanitary (3) 700-0201-036 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316/316L SS and TFE
13.8 bar @ 232°C (200 PSI @ 300°F)
14 General Purpose, 700-0202-002 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
low pressure 1.4 bar @ 232°C (20 PSI @ 450°F)
15 Heavy duty, agitated 700-0202-043 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
tanks or material 13.8 bar @ 232°C (200 PSI @ 450°F)
with high bulk density (1)
16 High Integrity Seal for 700-0002-360 int/rem 34.5 bar @ 149°C (500 PSI @ 300°F) PFA
Hazardous Materials
17 Sanitary (3) lowpressure 700-0202-036 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
18 Corrosive material, 700-0001-022 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) TFE
higher pressure with 34.5 bar @ 149°C (500 PSI @ 300°F)
waterlike viscosity (4)
19 Interface Measurement 700-0002-023 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
34.5 bar @ 149°C (500 PSI @ 300°F)
20 Miniature Pilot 700-0209-002 remote 6.9 bar @ 121°C (100 PSI @ 250°F) 316 SS and TFE
Plant Sensor (1)(7) 0 bar @ 232°C (0 PSI @ 450°F)
Fly Ash Precipitators, Baghouse, and Economizers (1) (6)
Application Sensing Element Pressure/Temperature Wetted Parts
31 No hopper Installation 700-0029-001 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
32 Hopper Installation 700-0029-002 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 200mm (8 inches)
33 Hopper Installation 700-0029-003 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 406mm (16 inches)
34 Hopper Instalation 700-0029-004 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 521mm (20.5 inches)
35 Hopper Installation 700-0029-005 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 635mm (25 inches)
Plugged Chute Detection (1) (5)
Application Sensing Element Pressure/Temperature Wetted Parts
50 Flush Mount Sensor 700-0207-001 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
305mm2(12 inches2) Polyurethane
heavy duty
51 Flush Mount Sensor 700-0207-002 remote 0.1 bar @ 149°C (1 PSI @ 300°F) 304 SS and TFE
305mm2(12 inches2)
higher temperature
52 Flush Mount Sensor 700-0207-003 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and Neoprene
305mm2(12 inches2)
with curved radius 153, 229, 305 mm (6, 9, or 12 inches)
53 Flush Mount Sensor 700-0207-004 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 410 SS and UHMW
305mm2(12 inches2) Polyethylene
extra heavy duty
55 Flush Mount Sensor 700-0207-006 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
203mm2 (8 inches2) Polyurethane
heavy duty
High Pressure / High Temperature
60 High Pressure & Temp. 700-0204-038 remote 137.9 bar @ 93°C (2000 PSI @ 200°F) 316SS and Ceramic
68.9 bar @ 260°C (1000 PSI @ 500°F)
61 High Temperature 700-0204-002 remote 0 bar @ 816°C (0 PSI @ 1500°F) 316SS and Ceramic
62 High Pressure & Temp. 700-0204-048 remote 275.8 bar @316°C (4000 PSI @ 600°F) 316SS
ZZ Sensing Element Not Listed
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options available with all
sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Sensing Element
Application Sensing Element Pressure/Temperature Wetted Parts
00 General purpose 700-1202-001 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-021 integral
01 Floating roof with 700-1202-012 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS, Brass,
cable attachment 700-1202-022 integral and PEEK
and brass bottom weight
02 General purpose, 700-1202-014 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS and PEEK
longer insertion lengths 700-1202-024 integral
with cable attachment
and 316SS bottom weight
03 Proximity 700-1202-018 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-028 integral with 76 mm (3)
316SS proximity plate
04 General purpose, 700-1202-041 remote 69 bar @ 121°C (1000 PSI @ 250°F) 316SS and PEEK
high temperature 700-1202-042 integral 20.7 bar @ 232°C (300 PSI @ 450°F)
and pressure
06 General purpose with 700-1202-031 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
FDA approved 700-1202-032 integral PEEK
materials of construction
07 General purpose 700-1202-010 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK with
Granular materials 700-1202-020 integral 7/8 inch dia. 316SS collar
09 General purpose 700-1202-033 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
Granular materials with 700-1202-034 integral PEEK with 7/8 inch dia.
FDA approved 316SS collar
materials of construction
10 Corrosive liquids (2)(4)(9) 700-0001-018 remote 3.4 bar @ 149°C (50 PSI @ 300°F) PFA
11 General purpose, 700-0201-005 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
higher pressure 13.8 bar @ 232°C (200 PSI @ 450°F)
TFE compatibility required
12 Corrosive material, 700-0201-005 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) Hastelloy C and TFE
higher pressure Hastelloy C 13.8 bar @ 232°C (200 PSI @ 450°F)
13 Sanitary (3) 700-0201-036 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316/316L SS and TFE
13.8 bar @ 232°C (200 PSI @ 300°F)
14 General Purpose, 700-0202-002 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
low pressure 1.4 bar @ 232°C (20 PSI @ 450°F)
15 Heavy duty, agitated 700-0202-043 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
tanks or material 13.8 bar @ 232°C (200 PSI @ 450°F)
with high bulk density (1)
16 High Integrity Seal for 700-0002-360 int/rem 34.5 bar @ 149°C (500 PSI @ 300°F) PFA
Hazardous Materials
17 Sanitary (3) lowpressure 700-0202-036 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
18 Corrosive material, 700-0001-022 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) TFE
higher pressure with 34.5 bar @ 149°C (500 PSI @ 300°F)
waterlike viscosity (4)
19 Interface Measurement 700-0002-023 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
34.5 bar @ 149°C (500 PSI @ 300°F)
20 Miniature Pilot 700-0209-002 remote 6.9 bar @ 121°C (100 PSI @ 250°F) 316 SS and TFE
Plant Sensor (1)(7) 0 bar @ 232°C (0 PSI @ 450°F)
Fly Ash Precipitators, Baghouse, and Economizers (1) (6)
Application Sensing Element Pressure/Temperature Wetted Parts
31 No hopper Installation 700-0029-001 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
32 Hopper Installation 700-0029-002 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 200mm (8 inches)
33 Hopper Installation 700-0029-003 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 406mm (16 inches)
34 Hopper Instalation 700-0029-004 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 521mm (20.5 inches)
35 Hopper Installation 700-0029-005 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 635mm (25 inches)
Plugged Chute Detection (1) (5)
Application Sensing Element Pressure/Temperature Wetted Parts
50 Flush Mount Sensor 700-0207-001 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
305mm2(12 inches2) Polyurethane
heavy duty
51 Flush Mount Sensor 700-0207-002 remote 0.1 bar @ 149°C (1 PSI @ 300°F) 304 SS and TFE
305mm2(12 inches2)
higher temperature
52 Flush Mount Sensor 700-0207-003 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and Neoprene
305mm2(12 inches2)
with curved radius 153, 229, 305 mm (6, 9, or 12 inches)
53 Flush Mount Sensor 700-0207-004 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 410 SS and UHMW
305mm2(12 inches2) Polyethylene
extra heavy duty
55 Flush Mount Sensor 700-0207-006 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
203mm2 (8 inches2) Polyurethane
heavy duty
High Pressure / High Temperature
60 High Pressure & Temp. 700-0204-038 remote 137.9 bar @ 93°C (2000 PSI @ 200°F) 316SS and Ceramic
68.9 bar @ 260°C (1000 PSI @ 500°F)
61 High Temperature 700-0204-002 remote 0 bar @ 816°C (0 PSI @ 1500°F) 316SS and Ceramic
62 High Pressure & Temp. 700-0204-048 remote 275.8 bar @316°C (4000 PSI @ 600°F) 316SS
ZZ Sensing Element Not Listed
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options are available with all sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Output
08-16 mA Output
Housing
Technology
RRF Admittance
RNT SXRNTX RNL
Input
TTwo wire Power Supply, 13-30 Vdc
Measurement Type
LNo Calib., 2 pF Fixed Preload
PNo Calib., 0.5 pF Fixed Preload (Hi. Sens.)
MManual Calib.
GManual Calib. (Hi. Sens.)
Electronics
0Integral
1Remote, no cable
2Rmt. w/ 3 m (10 ft.) G.P. Cable
3Rmt. w/ 7.6 m (25 ft.) G.P. Cable
4Rmt. w/ 10.6 m (35 ft.) G.P. Cable
5Rmt. w/ 15.2 m (50 ft.) G.P. Cable
6Rmt. w/ 23 m (75 ft.) G.P. Cable
7Rmt. w/ (25 ft.) Tri-Ax Cable
8Rmt. w/ (50 ft.) Tri-Ax Cable
9Rmt. w/ (75 ft.) Tri-Ax Cable
ARmt. w/ (10 ft.) Hi-Temp. Cable
BRmt. w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRmt. w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRmt. w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERmt. w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRmt. w/ (5 ft.) G.P. Cable
GRmt. w/ (5 ft.) Tri-Ax Cable
HRmt. w/ (10 ft.) Tri-Ax Cable
JRmt. w/ (35 ft.) Tri-Ax Cable
KRmt. w/ (5 ft.) Hi-Temp. Cable
0No Approvals, Dual Compartment NEMA 4X/IP66, M20 x 1.5 conduit entries
1No Approvals, Dual Compartment NEMA 4X/IP66 ¾" NPT conduit entries
2ATEX Approved, Dual Compartment NEMA 4X/IP66 M20x1.5 conduit entries
3FM Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
4CSA Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
Output
08-16mA Output
Safety IntelliPoint RF TM
Housing
0No Approvals, Dual Compartment NEMA 4X/IP66, M20 x 1.5 conduit entries
1No Approvals, Dual Compartment NEMA 4X/IP66 ¾" NPT conduit entries
2CENELEC/ATEX Approved, Dual Compartment NEMA 4X/IP66 M20x1.5 conduit entries
3FM Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
4CSA Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
Technology
RRF Admittance
Input
TTwo Wire Power Supply 13-30 VDC
SIL
1SIL1
2SIL2
Safety Switch
S
R T 0
S
IMPORTANT:
Minimum Active Length for SIL Compliance is 8" (203mm)
Consult Factory for Shorter Lengths
Electronics
0Integral
1Remote, no cable
2Rmt.w/ 3 m (10 ft.) G.P. Cable
3Rmt.w/ 7.6 m (25 ft.) G.P.Cable
4Rmt.w/ 10.6 m (35 ft.) G.P. Cable
5Rmt.w/ 15.2 m (50 ft.) G.P. Cable
6Rmt.w/ 23 m (75 ft.) G.P. Cable
7Rmt.w/ (25 ft.) Tri-Ax Cable
8Rmt.w/ (50 ft.) Tri-Ax Cable
9Rmt.w/ (75 ft.) Tri-Ax Cable
ARmt.w/ (10 ft.) Hi-Temp.Cable
BRmt.w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRmt.w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRmt.w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERmt.w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRmt.w/ (5 ft.) G.P. Cable
GRmt.w/ (5 ft.) Tri-Ax Cable
HRmt.w/ (10 ft.) Tri-Ax Cable
JRmt.w/ (35 ft.) Tri-Ax Cable
KRmt.w/ (5 ft.) Hi-Temp. Cable
Measurement Type
LNo Calib., 2 pF Fixed Preload
Output
1Two SPDT Relays, relay #2 configured as alarm or fault (Min=100 mA / 12 VDC)
2Two SPDT Relay, gold plated contacts (Max 200 mA / 12 VDC)
IntelliPoint RF TM
IntelliPoint RF TM
Housing
0No Approvals, Dual Compartment NEMA 4X/IP66, M20 x 1.5 conduit entries
1No Approvals, Dual Compartment NEMA 4X/IP66 ¾" NPT conduit entries
2ATEX Approved, Dual Compartment NEMA 4X/IP66 M20x1.5 conduit entries
3FM Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
4CSA Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
Technology
RRF Admittance
Input
LUniversal Power Supply 21-100 VDC, 85-250 VAC, 0-400 Hz
Measurement Type
LNo Calib., 2 pF Fixed Preload
PNo Calib., 0.5 pF Fixed Preload (High Sensitivity)
MManual Calibration
GManual Calibration (High Sensitivity)
R L
Electronics
0Integral
1Remote, no cable
2Rmt. w/ 3 m (10 ft.) G.P. Cable
3Rmt. w/ 7.6 m (25 ft.) G.P. Cable
4Rmt. w/ 10.6 m (35 ft.) G.P. Cable
5Rmt. w/ 15.2 m (50 ft.) G.P. Cable
6Rmt. w/ 23 m (75 ft.) G.P. Cable
7Rmt. w/ (25 ft.) Tri-Ax Cable
8Rmt. w/ (50 ft.) Tri-Ax Cable
9Rmt. w/ (75 ft.) Tri-Ax Cable
ARmt. w/ (10 ft.) Hi-Temp. Cable
BRmt. w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRmt. w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRmt. w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERmt. w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRmt. w/ (5 ft.) G.P. Cable
GRmt. w/ (5 ft.) Tri-Ax Cable
HRmt. w/ (10 ft.) Tri-Ax Cable
JRmt. w/ (35 ft.) Tri-Ax Cable
KRmt. w/ (5 ft.) Hi-Temp. Cable
RML
Output
1Two SPDT Relays, relay #2 configured as alarm or fault (Min=100 mA / 12 VDC)
2Two SPDT Relay, gold plated contacts (Max 200 mA / 12 VDC)
IntelliPoint RF TM
Housing
0No Approvals, Dual Compartment NEMA 4X/IP66, M20 x 1.5 conduit entries
1No Approvals, Dual Compartment NEMA 4X/IP66 ¾" NPT conduit entries
2ATEX Approved, Dual Compartment NEMA 4X/IP66 M20x1.5 conduit entries
3FM Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
4CSA Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
Technology
RRF Admittance
Input
LUniversal Power Supply 21-100 VDC, 85-250 VAC, 0-400 Hz
Measurement Type
MManual Calibration
GManual Calibration (High Sensitivity)
R L
Electronics
0Integral
1Remote, no cable
2Rmt. w/ 3 m (10 ft.) G.P. Cable
3Rmt. w/ 7.6 m (25 ft.) G.P. Cable
4Rmt. w/ 10.6 m (35 ft.) G.P. Cable
5Rmt. w/ 15.2 m (50 ft.) G.P. Cable
6Rmt. w/ 23 m (75 ft.) G.P. Cable
7Rmt. w/ (25 ft.) Tri-Ax Cable
8Rmt. w/ (50 ft.) Tri-Ax Cable
9Rmt. w/ (75 ft.) Tri-Ax Cable
ARmt. w/ (10 ft.) Hi-Temp. Cable
BRmt. w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRmt. w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRmt. w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERmt. w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRmt. w/ (5 ft.) G.P. Cable
GRmt. w/ (5 ft.) Tri-Ax Cable
HRmt. w/ (10 ft.) Tri-Ax Cable
JRmt. w/ (35 ft.) Tri-Ax Cable
KRmt. w/ (5 ft.) Hi-Temp. Cable
RMT
Output
08-16 mA Output
IntelliPoint RF TM
Housing
0No Approvals, Dual Compartment NEMA 4X/IP66, M20 x 1.5 conduit entries
1No Approvals, Dual Compartment NEMA 4X/IP66 ¾" NPT conduit entries
2ATEX Approved, Dual Compartment NEMA 4X/IP66 M20x1.5 conduit entries
3FM Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
4CSA Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
Technology
RRF Admittance
Input
TTwo-Wire Power Supply, 13-30 Vdc
Measurement Type
MManual Calibration
GManual Calibration (High Sensitivity)
R T 0
Electronics
0Integral
1Remote, no cable
2Rmt. w/ 3 m (10 ft.) G.P. Cable
3Rmt. w/ 7.6 m (25 ft.) G.P. Cable
4Rmt. w/ 10.6 m (35 ft.) G.P. Cable
5Rmt. w/ 15.2 m (50 ft.) G.P. Cable
6Rmt. w/ 23 m (75 ft.) G.P. Cable
7Rmt. w/ (25 ft.) Tri-Ax Cable
8Rmt. w/ (50 ft.) Tri-Ax Cable
9Rmt. w/ (75 ft.) Tri-Ax Cable
ARmt. w/ (10 ft.) Hi-Temp. Cable
BRmt. w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRmt. w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRmt. w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERmt. w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRmt. w/ (5 ft.) G.P. Cable
GRmt. w/ (5 ft.) Tri-Ax Cable
HRmt. w/ (10 ft.) Tri-Ax Cable
JRmt. w/ (35 ft.) Tri-Ax Cable
KRmt. w/ (5 ft.) Hi-Temp. Cable
IntelliPoint RF RML Series Introduction
3
1.3 Model Number (continued)
Continued from Previous Page
Sensing Element
Application Sensing Element Pressure/Temperature Wetted Parts
00 General purpose 700-1202-001 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-021 integral
01 Floating roof with 700-1202-012 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS, Brass,
cable attachment 700-1202-022 integral and PEEK
and brass bottom weight
02 General purpose, 700-1202-014 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS and PEEK
longer insertion lengths 700-1202-024 integral
with cable attachment
and 316SS bottom weight
03 Proximity 700-1202-018 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-028 integral with 76 mm (3)
316SS proximity plate
04 General purpose, 700-1202-041 remote 69 bar @ 121°C (1000 PSI @ 250°F) 316SS and PEEK
high temperature 700-1202-042 integral 20.7 bar @ 232°C (300 PSI @ 450°F)
and pressure
06 General purpose with 700-1202-031 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
FDA approved 700-1202-032 integral PEEK
materials of construction
07 General purpose 700-1202-010 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK with
Granular materials 700-1202-020 integral 7/8 inch dia. 316SS collar
09 General purpose 700-1202-033 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
Granular materials with 700-1202-034 integral PEEK with 7/8 inch dia.
FDA approved 316SS collar
materials of construction
10 Corrosive liquids (2)(4)(9) 700-0001-018 remote 3.4 bar @ 149°C (50 PSI @ 300°F) PFA
11 General purpose, 700-0201-005 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
higher pressure 13.8 bar @ 232°C (200 PSI @ 450°F)
TFE compatibility required
12 Corrosive material, 700-0201-005 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) Hastelloy C and TFE
higher pressure Hastelloy C 13.8 bar @ 232°C (200 PSI @ 450°F)
13 Sanitary (3) 700-0201-036 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316/316L SS and TFE
13.8 bar @ 232°C (200 PSI @ 300°F)
14 General Purpose, 700-0202-002 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
low pressure 1.4 bar @ 232°C (20 PSI @ 450°F)
15 Heavy duty, agitated 700-0202-043 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
tanks or material 13.8 bar @ 232°C (200 PSI @ 450°F)
with high bulk density (1)
16 High Integrity Seal for 700-0002-360 int/rem 34.5 bar @ 149°C (500 PSI @ 300°F) PFA
Hazardous Materials
17 Sanitary (3) lowpressure 700-0202-036 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
18 Corrosive material, 700-0001-022 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) TFE
higher pressure with 34.5 bar @ 149°C (500 PSI @ 300°F)
waterlike viscosity (4)
19 Interface Measurement 700-0002-023 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
34.5 bar @ 149°C (500 PSI @ 300°F)
20 Miniature Pilot 700-0209-002 remote 6.9 bar @ 121°C (100 PSI @ 250°F) 316 SS and TFE
Plant Sensor (1)(7) 0 bar @ 232°C (0 PSI @ 450°F)
Fly Ash Precipitators, Baghouse, and Economizers (1) (6)
Application Sensing Element Pressure/Temperature Wetted Parts
31 No hopper Installation 700-0029-001 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
32 Hopper Installation 700-0029-002 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 200mm (8 inches)
33 Hopper Installation 700-0029-003 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 406mm (16 inches)
34 Hopper Instalation 700-0029-004 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 521mm (20.5 inches)
35 Hopper Installation 700-0029-005 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 635mm (25 inches)
Plugged Chute Detection (1) (5)
Application Sensing Element Pressure/Temperature Wetted Parts
50 Flush Mount Sensor 700-0207-001 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
305mm2(12 inches2) Polyurethane
heavy duty
51 Flush Mount Sensor 700-0207-002 remote 0.1 bar @ 149°C (1 PSI @ 300°F) 304 SS and TFE
305mm2(12 inches2)
higher temperature
52 Flush Mount Sensor 700-0207-003 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and Neoprene
305mm2(12 inches2)
with curved radius 153, 229, 305 mm (6, 9, or 12 inches)
53 Flush Mount Sensor 700-0207-004 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 410 SS and UHMW
305mm2(12 inches2) Polyethylene
extra heavy duty
55 Flush Mount Sensor 700-0207-006 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
203mm2 (8 inches2) Polyurethane
heavy duty
High Pressure / High Temperature
60 High Pressure & Temp. 700-0204-038 remote 137.9 bar @ 93°C (2000 PSI @ 200°F) 316SS and Ceramic
68.9 bar @ 260°C (1000 PSI @ 500°F)
61 High Temperature 700-0204-002 remote 0 bar @ 816°C (0 PSI @ 1500°F) 316SS and Ceramic
62 High Pressure & Temp. 700-0204-048 remote 275.8 bar @316°C (4000 PSI @ 600°F) 316SS
ZZ Sensing Element Not Listed
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options available with all
sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Sensing Element
Application Sensing Element Pressure/Temperature Wetted Parts
00 General purpose 700-1202-001 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-021 integral
01 Floating roof with 700-1202-012 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS, Brass,
cable attachment 700-1202-022 integral and PEEK
and brass bottom weight
02 General purpose, 700-1202-014 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS and PEEK
longer insertion lengths 700-1202-024 integral
with cable attachment
and 316SS bottom weight
03 Proximity 700-1202-018 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-028 integral with 76 mm (3)
316SS proximity plate
04 General purpose, 700-1202-041 remote 69 bar @ 121°C (1000 PSI @ 250°F) 316SS and PEEK
high temperature 700-1202-042 integral 20.7 bar @ 232°C (300 PSI @ 450°F)
and pressure
06 General purpose with 700-1202-031 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
FDA approved 700-1202-032 integral PEEK
materials of construction
07 General purpose 700-1202-010 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK with
Granular materials 700-1202-020 integral 7/8 inch dia. 316SS collar
09 General purpose 700-1202-033 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
Granular materials with 700-1202-034 integral PEEK with 7/8 inch dia.
FDA approved 316SS collar
materials of construction
10 Corrosive liquids (2)(4)(9) 700-0001-018 remote 3.4 bar @ 149°C (50 PSI @ 300°F) PFA
11 General purpose, 700-0201-005 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
higher pressure 13.8 bar @ 232°C (200 PSI @ 450°F)
TFE compatibility required
12 Corrosive material, 700-0201-005 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) Hastelloy C and TFE
higher pressure Hastelloy C 13.8 bar @ 232°C (200 PSI @ 450°F)
13 Sanitary (3) 700-0201-036 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316/316L SS and TFE
13.8 bar @ 232°C (200 PSI @ 300°F)
14 General Purpose, 700-0202-002 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
low pressure 1.4 bar @ 232°C (20 PSI @ 450°F)
15 Heavy duty, agitated 700-0202-043 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
tanks or material 13.8 bar @ 232°C (200 PSI @ 450°F)
with high bulk density (1)
16 High Integrity Seal for 700-0002-360 int/rem 34.5 bar @ 149°C (500 PSI @ 300°F) PFA
Hazardous Materials
17 Sanitary (3) lowpressure 700-0202-036 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
18 Corrosive material, 700-0001-022 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) TFE
higher pressure with 34.5 bar @ 149°C (500 PSI @ 300°F)
waterlike viscosity (4)
19 Interface Measurement 700-0002-023 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
34.5 bar @ 149°C (500 PSI @ 300°F)
20 Miniature Pilot 700-0209-002 remote 6.9 bar @ 121°C (100 PSI @ 250°F) 316 SS and TFE
Plant Sensor (1)(7) 0 bar @ 232°C (0 PSI @ 450°F)
Fly Ash Precipitators, Baghouse, and Economizers (1) (6)
Application Sensing Element Pressure/Temperature Wetted Parts
31 No hopper Installation 700-0029-001 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
32 Hopper Installation 700-0029-002 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 200mm (8 inches)
33 Hopper Installation 700-0029-003 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 406mm (16 inches)
34 Hopper Instalation 700-0029-004 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 521mm (20.5 inches)
35 Hopper Installation 700-0029-005 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 635mm (25 inches)
Plugged Chute Detection (1) (5)
Application Sensing Element Pressure/Temperature Wetted Parts
50 Flush Mount Sensor 700-0207-001 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
305mm2(12 inches2) Polyurethane
heavy duty
51 Flush Mount Sensor 700-0207-002 remote 0.1 bar @ 149°C (1 PSI @ 300°F) 304 SS and TFE
305mm2(12 inches2)
higher temperature
52 Flush Mount Sensor 700-0207-003 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and Neoprene
305mm2(12 inches2)
with curved radius 153, 229, 305 mm (6, 9, or 12 inches)
53 Flush Mount Sensor 700-0207-004 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 410 SS and UHMW
305mm2(12 inches2) Polyethylene
extra heavy duty
55 Flush Mount Sensor 700-0207-006 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
203mm2 (8 inches2) Polyurethane
heavy duty
High Pressure / High Temperature
60 High Pressure & Temp. 700-0204-038 remote 137.9 bar @ 93°C (2000 PSI @ 200°F) 316SS and Ceramic
68.9 bar @ 260°C (1000 PSI @ 500°F)
61 High Temperature 700-0204-002 remote 0 bar @ 816°C (0 PSI @ 1500°F) 316SS and Ceramic
62 High Pressure & Temp. 700-0204-048 remote 275.8 bar @316°C (4000 PSI @ 600°F) 316SS
ZZ Sensing Element Not Listed
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options available with all
sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Sensing Element
Application Sensing Element Pressure/Temperature Wetted Parts
00 General purpose 700-1202-001 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-021 integral
01 Floating roof with 700-1202-012 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS, Brass,
cable attachment 700-1202-022 integral and PEEK
and brass bottom weight
02 General purpose, 700-1202-014 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS and PEEK
longer insertion lengths 700-1202-024 integral
with cable attachment
and 316SS bottom weight
03 Proximity 700-1202-018 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-028 integral with 76 mm (3)
316SS proximity plate
04 General purpose, 700-1202-041 remote 69 bar @ 121°C (1000 PSI @ 250°F) 316SS and PEEK
high temperature 700-1202-042 integral 20.7 bar @ 232°C (300 PSI @ 450°F)
and pressure
06 General purpose with 700-1202-031 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
FDA approved 700-1202-032 integral PEEK
materials of construction
07 General purpose 700-1202-010 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK with
Granular materials 700-1202-020 integral 7/8 inch dia. 316SS collar
09 General purpose 700-1202-033 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
Granular materials with 700-1202-034 integral PEEK with 7/8 inch dia.
FDA approved 316SS collar
materials of construction
10 Corrosive liquids (2)(4)(9) 700-0001-018 remote 3.4 bar @ 149°C (50 PSI @ 300°F) PFA
11 General purpose, 700-0201-005 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
higher pressure 13.8 bar @ 232°C (200 PSI @ 450°F)
TFE compatibility required
12 Corrosive material, 700-0201-005 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) Hastelloy C and TFE
higher pressure Hastelloy C 13.8 bar @ 232°C (200 PSI @ 450°F)
13 Sanitary (3) 700-0201-036 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316/316L SS and TFE
13.8 bar @ 232°C (200 PSI @ 300°F)
14 General Purpose, 700-0202-002 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
low pressure 1.4 bar @ 232°C (20 PSI @ 450°F)
15 Heavy duty, agitated 700-0202-043 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
tanks or material 13.8 bar @ 232°C (200 PSI @ 450°F)
with high bulk density (1)
16 High Integrity Seal for 700-0002-360 int/rem 34.5 bar @ 149°C (500 PSI @ 300°F) PFA
Hazardous Materials
17 Sanitary (3) lowpressure 700-0202-036 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
18 Corrosive material, 700-0001-022 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) TFE
higher pressure with 34.5 bar @ 149°C (500 PSI @ 300°F)
waterlike viscosity (4)
19 Interface Measurement 700-0002-023 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
34.5 bar @ 149°C (500 PSI @ 300°F)
20 Miniature Pilot 700-0209-002 remote 6.9 bar @ 121°C (100 PSI @ 250°F) 316 SS and TFE
Plant Sensor (1)(7) 0 bar @ 232°C (0 PSI @ 450°F)
Fly Ash Precipitators, Baghouse, and Economizers (1) (6)
Application Sensing Element Pressure/Temperature Wetted Parts
31 No hopper Installation 700-0029-001 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
32 Hopper Installation 700-0029-002 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 200mm (8 inches)
33 Hopper Installation 700-0029-003 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 406mm (16 inches)
34 Hopper Instalation 700-0029-004 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 521mm (20.5 inches)
35 Hopper Installation 700-0029-005 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 635mm (25 inches)
Plugged Chute Detection (1) (5)
Application Sensing Element Pressure/Temperature Wetted Parts
50 Flush Mount Sensor 700-0207-001 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
305mm2(12 inches2) Polyurethane
heavy duty
51 Flush Mount Sensor 700-0207-002 remote 0.1 bar @ 149°C (1 PSI @ 300°F) 304 SS and TFE
305mm2(12 inches2)
higher temperature
52 Flush Mount Sensor 700-0207-003 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and Neoprene
305mm2(12 inches2)
with curved radius 153, 229, 305 mm (6, 9, or 12 inches)
53 Flush Mount Sensor 700-0207-004 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 410 SS and UHMW
305mm2(12 inches2) Polyethylene
extra heavy duty
55 Flush Mount Sensor 700-0207-006 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
203mm2 (8 inches2) Polyurethane
heavy duty
High Pressure / High Temperature
60 High Pressure & Temp. 700-0204-038 remote 137.9 bar @ 93°C (2000 PSI @ 200°F) 316SS and Ceramic
68.9 bar @ 260°C (1000 PSI @ 500°F)
61 High Temperature 700-0204-002 remote 0 bar @ 816°C (0 PSI @ 1500°F) 316SS and Ceramic
62 High Pressure & Temp. 700-0204-048 remote 275.8 bar @316°C (4000 PSI @ 600°F) 316SS
ZZ Sensing Element Not Listed
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options available with all
sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Sensing Element
Application Sensing Element Pressure/Temperature Wetted Parts
00 General purpose 700-1202-001 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-021 integral
01 Floating roof with 700-1202-012 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS, Brass,
cable attachment 700-1202-022 integral and PEEK
and brass bottom weight
02 General purpose, 700-1202-014 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS and PEEK
longer insertion lengths 700-1202-024 integral
with cable attachment
and 316SS bottom weight
03 Proximity 700-1202-018 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-028 integral with 76 mm (3)
316SS proximity plate
04 General purpose, 700-1202-041 remote 69 bar @ 121°C (1000 PSI @ 250°F) 316SS and PEEK
high temperature 700-1202-042 integral 20.7 bar @ 232°C (300 PSI @ 450°F)
and pressure
06 General purpose with 700-1202-031 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
FDA approved 700-1202-032 integral PEEK
materials of construction
07 General purpose 700-1202-010 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK with
Granular materials 700-1202-020 integral 7/8 inch dia. 316SS collar
09 General purpose 700-1202-033 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
Granular materials with 700-1202-034 integral PEEK with 7/8 inch dia.
FDA approved 316SS collar
materials of construction
10 Corrosive liquids (2)(4)(9) 700-0001-018 remote 3.4 bar @ 149°C (50 PSI @ 300°F) PFA
11 General purpose, 700-0201-005 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
higher pressure 13.8 bar @ 232°C (200 PSI @ 450°F)
TFE compatibility required
12 Corrosive material, 700-0201-005 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) Hastelloy C and TFE
higher pressure Hastelloy C 13.8 bar @ 232°C (200 PSI @ 450°F)
13 Sanitary (3) 700-0201-036 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316/316L SS and TFE
13.8 bar @ 232°C (200 PSI @ 300°F)
14 General Purpose, 700-0202-002 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
low pressure 1.4 bar @ 232°C (20 PSI @ 450°F)
15 Heavy duty, agitated 700-0202-043 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
tanks or material 13.8 bar @ 232°C (200 PSI @ 450°F)
with high bulk density (1)
16 High Integrity Seal for 700-0002-360 int/rem 34.5 bar @ 149°C (500 PSI @ 300°F) PFA
Hazardous Materials
17 Sanitary (3) lowpressure 700-0202-036 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
18 Corrosive material, 700-0001-022 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) TFE
higher pressure with 34.5 bar @ 149°C (500 PSI @ 300°F)
waterlike viscosity (4)
19 Interface Measurement 700-0002-023 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
34.5 bar @ 149°C (500 PSI @ 300°F)
20 Miniature Pilot 700-0209-002 remote 6.9 bar @ 121°C (100 PSI @ 250°F) 316 SS and TFE
Plant Sensor (1)(7) 0 bar @ 232°C (0 PSI @ 450°F)
Fly Ash Precipitators, Baghouse, and Economizers (1) (6)
Application Sensing Element Pressure/Temperature Wetted Parts
31 No hopper Installation 700-0029-001 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
32 Hopper Installation 700-0029-002 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 200mm (8 inches)
33 Hopper Installation 700-0029-003 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 406mm (16 inches)
34 Hopper Instalation 700-0029-004 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 521mm (20.5 inches)
35 Hopper Installation 700-0029-005 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 635mm (25 inches)
Plugged Chute Detection (1) (5)
Application Sensing Element Pressure/Temperature Wetted Parts
50 Flush Mount Sensor 700-0207-001 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
305mm2(12 inches2) Polyurethane
heavy duty
51 Flush Mount Sensor 700-0207-002 remote 0.1 bar @ 149°C (1 PSI @ 300°F) 304 SS and TFE
305mm2(12 inches2)
higher temperature
52 Flush Mount Sensor 700-0207-003 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and Neoprene
305mm2(12 inches2)
with curved radius 153, 229, 305 mm (6, 9, or 12 inches)
53 Flush Mount Sensor 700-0207-004 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 410 SS and UHMW
305mm2(12 inches2) Polyethylene
extra heavy duty
55 Flush Mount Sensor 700-0207-006 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
203mm2 (8 inches2) Polyurethane
heavy duty
High Pressure / High Temperature
60 High Pressure & Temp. 700-0204-038 remote 137.9 bar @ 93°C (2000 PSI @ 200°F) 316SS and Ceramic
68.9 bar @ 260°C (1000 PSI @ 500°F)
61 High Temperature 700-0204-002 remote 0 bar @ 816°C (0 PSI @ 1500°F) 316SS and Ceramic
62 High Pressure & Temp. 700-0204-048 remote 275.8 bar @316°C (4000 PSI @ 600°F) 316SS
ZZ Sensing Element Not Listed
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options available with all
sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Sensing Element
Application Sensing Element Pressure/Temperature Wetted Parts
00 General purpose 700-1202-001 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-021 integral
01 Floating roof with 700-1202-012 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS, Brass,
cable attachment 700-1202-022 integral and PEEK
and brass bottom weight
02 General purpose, 700-1202-014 remote 13.8 bar @ 177°C (200 PSI @ 350°F) 316SS and PEEK
longer insertion lengths 700-1202-024 integral
with cable attachment
and 316SS bottom weight
03 Proximity 700-1202-018 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK
700-1202-028 integral with 76 mm (3)
316SS proximity plate
04 General purpose, 700-1202-041 remote 69 bar @ 121°C (1000 PSI @ 250°F) 316SS and PEEK
high temperature 700-1202-042 integral 20.7 bar @ 232°C (300 PSI @ 450°F)
and pressure
06 General purpose with 700-1202-031 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
FDA approved 700-1202-032 integral PEEK
materials of construction
07 General purpose 700-1202-010 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and PEEK with
Granular materials 700-1202-020 integral 7/8 inch dia. 316SS collar
09 General purpose 700-1202-033 remote 13.8 bar @ 232°C (200 PSI @ 450°F) 316SS and FDA grade
Granular materials with 700-1202-034 integral PEEK with 7/8 inch dia.
FDA approved 316SS collar
materials of construction
10 Corrosive liquids (2)(4)(9) 700-0001-018 remote 3.4 bar @ 149°C (50 PSI @ 300°F) PFA
11 General purpose, 700-0201-005 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
higher pressure 13.8 bar @ 232°C (200 PSI @ 450°F)
TFE compatibility required
12 Corrosive material, 700-0201-005 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) Hastelloy C and TFE
higher pressure Hastelloy C 13.8 bar @ 232°C (200 PSI @ 450°F)
13 Sanitary (3) 700-0201-036 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316/316L SS and TFE
13.8 bar @ 232°C (200 PSI @ 300°F)
14 General Purpose, 700-0202-002 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
low pressure 1.4 bar @ 232°C (20 PSI @ 450°F)
15 Heavy duty, agitated 700-0202-043 remote 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
tanks or material 13.8 bar @ 232°C (200 PSI @ 450°F)
with high bulk density (1)
16 High Integrity Seal for 700-0002-360 int/rem 34.5 bar @ 149°C (500 PSI @ 300°F) PFA
Hazardous Materials
17 Sanitary (3) lowpressure 700-0202-036 int/rem 3.4 bar @ 149°C (50 PSI @ 300°F) 316SS and TFE
18 Corrosive material, 700-0001-022 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) TFE
higher pressure with 34.5 bar @ 149°C (500 PSI @ 300°F)
waterlike viscosity (4)
19 Interface Measurement 700-0002-023 int/rem 69 bar @ 38°C (1000 PSI @ 100°F) 316SS and TFE
34.5 bar @ 149°C (500 PSI @ 300°F)
20 Miniature Pilot 700-0209-002 remote 6.9 bar @ 121°C (100 PSI @ 250°F) 316 SS and TFE
Plant Sensor (1)(7) 0 bar @ 232°C (0 PSI @ 450°F)
Fly Ash Precipitators, Baghouse, and Economizers (1) (6)
Application Sensing Element Pressure/Temperature Wetted Parts
31 No hopper Installation 700-0029-001 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
32 Hopper Installation 700-0029-002 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 200mm (8 inches)
33 Hopper Installation 700-0029-003 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 406mm (16 inches)
34 Hopper Instalation 700-0029-004 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 521mm (20.5 inches)
35 Hopper Installation 700-0029-005 remote 0.1 bar @ 260°C (2 PSI @ 500°F) 316SS and TFE
up to 635mm (25 inches)
Plugged Chute Detection (1) (5)
Application Sensing Element Pressure/Temperature Wetted Parts
50 Flush Mount Sensor 700-0207-001 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
305mm2(12 inches2) Polyurethane
heavy duty
51 Flush Mount Sensor 700-0207-002 remote 0.1 bar @ 149°C (1 PSI @ 300°F) 304 SS and TFE
305mm2(12 inches2)
higher temperature
52 Flush Mount Sensor 700-0207-003 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and Neoprene
305mm2(12 inches2)
with curved radius 153, 229, 305 mm (6, 9, or 12 inches)
53 Flush Mount Sensor 700-0207-004 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 410 SS and UHMW
305mm2(12 inches2) Polyethylene
extra heavy duty
55 Flush Mount Sensor 700-0207-006 remote 0.1 bar @ 82°C (1 PSI @ 180°F) 304 SS and
203mm2 (8 inches2) Polyurethane
heavy duty
High Pressure / High Temperature
60 High Pressure & Temp. 700-0204-038 remote 137.9 bar @ 93°C (2000 PSI @ 200°F) 316SS and Ceramic
68.9 bar @ 260°C (1000 PSI @ 500°F)
61 High Temperature 700-0204-002 remote 0 bar @ 816°C (0 PSI @ 1500°F) 316SS and Ceramic
62 High Pressure & Temp. 700-0204-048 remote 275.8 bar @316°C (4000 PSI @ 600°F) 316SS
ZZ Sensing Element Not Listed
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options are available with all sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Output
08-16 mA Output
Housing
Technology
RRF Admittance
RNT SXRNTX RNL
Input
TTwo wire Power Supply, 13-30 Vdc
Measurement Type
LNo Calib., 2 pF Fixed Preload
PNo Calib., 0.5 pF Fixed Preload (Hi. Sens.)
MManual Calib.
GManual Calib. (Hi. Sens.)
Electronics
0Integral
1Remote, no cable
2Rmt. w/ 3 m (10 ft.) G.P. Cable
3Rmt. w/ 7.6 m (25 ft.) G.P. Cable
4Rmt. w/ 10.6 m (35 ft.) G.P. Cable
5Rmt. w/ 15.2 m (50 ft.) G.P. Cable
6Rmt. w/ 23 m (75 ft.) G.P. Cable
7Rmt. w/ (25 ft.) Tri-Ax Cable
8Rmt. w/ (50 ft.) Tri-Ax Cable
9Rmt. w/ (75 ft.) Tri-Ax Cable
ARmt. w/ (10 ft.) Hi-Temp. Cable
BRmt. w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRmt. w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRmt. w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERmt. w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRmt. w/ (5 ft.) G.P. Cable
GRmt. w/ (5 ft.) Tri-Ax Cable
HRmt. w/ (10 ft.) Tri-Ax Cable
JRmt. w/ (35 ft.) Tri-Ax Cable
KRmt. w/ (5 ft.) Hi-Temp. Cable
0No Approvals, Dual Compartment NEMA 4X/IP66, M20 x 1.5 conduit entries
1No Approvals, Dual Compartment NEMA 4X/IP66 ¾" NPT conduit entries
2ATEX Approved, Dual Compartment NEMA 4X/IP66 M20x1.5 conduit entries
3FM Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
4CSA Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
Output
08-16mA Output
Safety IntelliPoint RF TM
Housing
0No Approvals, Dual Compartment NEMA 4X/IP66, M20 x 1.5 conduit entries
1No Approvals, Dual Compartment NEMA 4X/IP66 ¾" NPT conduit entries
2CENELEC/ATEX Approved, Dual Compartment NEMA 4X/IP66 M20x1.5 conduit entries
3FM Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
4CSA Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
Technology
RRF Admittance
Input
TTwo Wire Power Supply 13-30 VDC
SIL
1SIL1
2SIL2
Safety Switch
S
R T 0
S
IMPORTANT:
Minimum Active Length for SIL Compliance is 8" (203mm)
Consult Factory for Shorter Lengths
Electronics
0Integral
1Remote, no cable
2Rmt.w/ 3 m (10 ft.) G.P. Cable
3Rmt.w/ 7.6 m (25 ft.) G.P.Cable
4Rmt.w/ 10.6 m (35 ft.) G.P. Cable
5Rmt.w/ 15.2 m (50 ft.) G.P. Cable
6Rmt.w/ 23 m (75 ft.) G.P. Cable
7Rmt.w/ (25 ft.) Tri-Ax Cable
8Rmt.w/ (50 ft.) Tri-Ax Cable
9Rmt.w/ (75 ft.) Tri-Ax Cable
ARmt.w/ (10 ft.) Hi-Temp.Cable
BRmt.w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRmt.w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRmt.w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERmt.w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRmt.w/ (5 ft.) G.P. Cable
GRmt.w/ (5 ft.) Tri-Ax Cable
HRmt.w/ (10 ft.) Tri-Ax Cable
JRmt.w/ (35 ft.) Tri-Ax Cable
KRmt.w/ (5 ft.) Hi-Temp. Cable
Measurement Type
LNo Calib., 2 pF Fixed Preload
Output
1Two SPDT Relays, relay #2 configured as alarm or fault (Min=100 mA / 12 VDC)
2Two SPDT Relay, gold plated contacts (Max 200 mA / 12 VDC)
IntelliPoint RF TM
IntelliPoint RF TM
Housing
0No Approvals, Dual Compartment NEMA 4X/IP66, M20 x 1.5 conduit entries
1No Approvals, Dual Compartment NEMA 4X/IP66 ¾" NPT conduit entries
2ATEX Approved, Dual Compartment NEMA 4X/IP66 M20x1.5 conduit entries
3FM Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
4CSA Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
Technology
RRF Admittance
Input
LUniversal Power Supply 21-100 VDC, 85-250 VAC, 0-400 Hz
Measurement Type
LNo Calib., 2 pF Fixed Preload
PNo Calib., 0.5 pF Fixed Preload (High Sensitivity)
MManual Calibration
GManual Calibration (High Sensitivity)
R L
Electronics
0Integral
1Remote, no cable
2Rmt. w/ 3 m (10 ft.) G.P. Cable
3Rmt. w/ 7.6 m (25 ft.) G.P. Cable
4Rmt. w/ 10.6 m (35 ft.) G.P. Cable
5Rmt. w/ 15.2 m (50 ft.) G.P. Cable
6Rmt. w/ 23 m (75 ft.) G.P. Cable
7Rmt. w/ (25 ft.) Tri-Ax Cable
8Rmt. w/ (50 ft.) Tri-Ax Cable
9Rmt. w/ (75 ft.) Tri-Ax Cable
ARmt. w/ (10 ft.) Hi-Temp. Cable
BRmt. w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRmt. w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRmt. w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERmt. w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRmt. w/ (5 ft.) G.P. Cable
GRmt. w/ (5 ft.) Tri-Ax Cable
HRmt. w/ (10 ft.) Tri-Ax Cable
JRmt. w/ (35 ft.) Tri-Ax Cable
KRmt. w/ (5 ft.) Hi-Temp. Cable
RML
Output
1Two SPDT Relays, relay #2 configured as alarm or fault (Min=100 mA / 12 VDC)
2Two SPDT Relay, gold plated contacts (Max 200 mA / 12 VDC)
IntelliPoint RF TM
Housing
0No Approvals, Dual Compartment NEMA 4X/IP66, M20 x 1.5 conduit entries
1No Approvals, Dual Compartment NEMA 4X/IP66 ¾" NPT conduit entries
2ATEX Approved, Dual Compartment NEMA 4X/IP66 M20x1.5 conduit entries
3FM Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
4CSA Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
Technology
RRF Admittance
Input
LUniversal Power Supply 21-100 VDC, 85-250 VAC, 0-400 Hz
Measurement Type
MManual Calibration
GManual Calibration (High Sensitivity)
R L
Electronics
0Integral
1Remote, no cable
2Rmt. w/ 3 m (10 ft.) G.P. Cable
3Rmt. w/ 7.6 m (25 ft.) G.P. Cable
4Rmt. w/ 10.6 m (35 ft.) G.P. Cable
5Rmt. w/ 15.2 m (50 ft.) G.P. Cable
6Rmt. w/ 23 m (75 ft.) G.P. Cable
7Rmt. w/ (25 ft.) Tri-Ax Cable
8Rmt. w/ (50 ft.) Tri-Ax Cable
9Rmt. w/ (75 ft.) Tri-Ax Cable
ARmt. w/ (10 ft.) Hi-Temp. Cable
BRmt. w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRmt. w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRmt. w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERmt. w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRmt. w/ (5 ft.) G.P. Cable
GRmt. w/ (5 ft.) Tri-Ax Cable
HRmt. w/ (10 ft.) Tri-Ax Cable
JRmt. w/ (35 ft.) Tri-Ax Cable
KRmt. w/ (5 ft.) Hi-Temp. Cable
RMT
Output
08-16 mA Output
IntelliPoint RF TM
Housing
0No Approvals, Dual Compartment NEMA 4X/IP66, M20 x 1.5 conduit entries
1No Approvals, Dual Compartment NEMA 4X/IP66 ¾" NPT conduit entries
2ATEX Approved, Dual Compartment NEMA 4X/IP66 M20x1.5 conduit entries
3FM Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
4CSA Approved, Dual Compartment NEMA 4X/IP66 ¾'' NPT conduit entries
Technology
RRF Admittance
Input
TTwo-Wire Power Supply, 13-30 Vdc
Measurement Type
MManual Calibration
GManual Calibration (High Sensitivity)
R T 0
Electronics
0Integral
1Remote, no cable
2Rmt. w/ 3 m (10 ft.) G.P. Cable
3Rmt. w/ 7.6 m (25 ft.) G.P. Cable
4Rmt. w/ 10.6 m (35 ft.) G.P. Cable
5Rmt. w/ 15.2 m (50 ft.) G.P. Cable
6Rmt. w/ 23 m (75 ft.) G.P. Cable
7Rmt. w/ (25 ft.) Tri-Ax Cable
8Rmt. w/ (50 ft.) Tri-Ax Cable
9Rmt. w/ (75 ft.) Tri-Ax Cable
ARmt. w/ (10 ft.) Hi-Temp. Cable
BRmt. w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRmt. w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRmt. w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERmt. w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRmt. w/ (5 ft.) G.P. Cable
GRmt. w/ (5 ft.) Tri-Ax Cable
HRmt. w/ (10 ft.) Tri-Ax Cable
JRmt. w/ (35 ft.) Tri-Ax Cable
KRmt. w/ (5 ft.) Hi-Temp. Cable
IntelliPoint RF RML Series Introduction
4
Locked Unlocked
Lid Locking
Mechanism
(CENELEC Systems)
140 mm
(5.5 inches)
114 mm
(4.5 inches)
165 mm (6.5 inches)
Sensing Element
and
Circuit Board
Input and Output Module
External
Tag Loop (2)
External Lid Lock (2)
M4 2.5 mm Hex Drive
Conduit Entries (2)
¾-inch NPT (FM/CSA Systems)
M20 x 1.5 (CENELEC Systems)
LABEL
(see below)
Equipotential Connection
Figure 1-3
Dual Compartment Housing Detail
The Input/Output Module (IOM) is located on Customer Connection
side; sensing element/circuit board are on opposite side.
1.4 Dual Compartment Housing
SENSING
ELEMENT,
CIRCUIT
BOARD
SIDE
INPUT/OUTPUT
CUSTOMER
CONNECTION
SIDE
IntelliPoint RF RML Series Installation
5
Section 2: Installation
2.1 Unpacking
Carefully remove the contents of the shipping carton and
check each item against the packing list before destroying
any packing material. If there is any shortage or damage
report it to the factory immediately.
2.2 Mounting and Installation Guidelines
The IntelliPoint RF instrument can be mounted vertically,
horizontally, or at an angle. The mounting location should
be as free as possible from vibration, corrosive atmospheres,
and the possibility of mechanical damage. Ambient
temperatures at the electronics should be between -30 to
70ºC (-22 to 158ºF).
The IntelliPoint RF utilizes a dual compartment housing and
a completely encapsulated input/output module, to reduce
the possibility of damage occuring from water migrating into
the housing through the conduit.
To further reduce the possibility of damage caused by water
in the conduit, install a drip loop and breather drain to purge
any accumulating moisture. Refer to Figure 2-1.
When properly installed, the GREEN LED will illuminate
when power is applied. The two (2) RED LEDs should not be
ashing.
If either of the RED LEDs are ashing, refer to Section 4,
Troubleshooting.
Cable ttings
supplied are weather-
resistant. They are
NOT certied as
explosionproof (XP) or
ameproof (d) unless
they are specically
marked.
Figure 2-1
Recommended Conduit Connection
IntelliPoint RF RML Series Installation
6
2.2 Mounting and Installation Guidelines (continued)
WARNING:
IntelliPoint RF equipment is rated explosion-proof.
When installing in areas where explosion is a concern [rated
“potentially hazardous” (EU) or “hazardous classied”
(USA)] observe all national and local regulations as well as
specications in the certicate.
Mount the sensing element using the installation guidelines
in Figure 2-2.
When installing IntelliPoint RF instrument, ambient
temperature at electronics must not exceed 70°C (158°F).
When installing ange-mounted sensing elements, keep
mating surfaces and bolts free of paint and corrosion to
ensure proper electrical contact with vessel. Avoid using
excessive amounts of TFE tape when installing
threaded sensing elements.
NOZZLE
NOZZLE
Wall build-up
does not extend
past first
insulator.
Cote-shield must
extend through
nozzle and wall
build-up.
Wrong
Nozzle too long;
Cote-shield too short.
Factory-supplied Cote-shield
extends through nozzle and
wall build-up.
Best
Best
No Nozzle
Good
Long Nozzle
Figure 2-2
Installation Considerations
Install systems with threaded NPT connection via wrench
ats on the process connection ONLY.
IntelliPoint RF RML Series Installation
7
2.2 Mounting and Installation Guidelines (continued)
Mount the sensing element as to avoid enhancing
electrostatic discharge from the process medium, as is good
practice with any thermowell, displacer, or sampler. This
includes correct bonding to the tank or silo wall.
If installation area is rated explosion-proof and requires
conduit seal ttings, they should be used in accordance with
company standards and local codes.
Mounting the sensing element inside a pipe is not
recommended.
Do not mount a Cote-Shield sensing element through a
nozzle that exceeds the length of rst insulator.
Ensure there are no obstructions or agitator blades to
interfere with sensing element.
Rigid sensing elements can be mounted either vertically or
horizontally.
2.2.1 Installation of Flush-Mounted Sensing Elements
These instructions apply to all ush on/off sensing elements,
models 700-0207-001, 700-0207-002, 700-0207-003, 700-0207-
004, 700-0207-006. These systems will sense presence of
material (no ow or plugged chute) and absence of material
(ow or empty chute) at the sensing element. The Flush
Sensing Element will ignore free falling material.
Material Backed-Up Above
Sensing Element
(No Flow)
Sensing Element at the Top of a Chute.
• The ush sensing element should be mounted In
The Flow Stream. These sensing elements are
designed and built to withstand the impact of coal,
rock, wood, chips, etc. This location is important
to prevent excessive build up of material on the
face of the sensing element.
• Excessive build up, typically consisting of wet and/
or sticky nes, can occur if the sensing element is
protected from falling material.
Sensing Element in an angle chute.
• Do not mount on the top or bottom.
• Best mounted on either side
Sensing Element at the Bottom
• Mount on any side.
• Low-Level sensors can be used to detect
a plug or to insure that a seal is present
(chute is full at this point).
IntelliPoint RF RML Series Installation
8
2 31 5 64 7 8
L2 NOL1 NC NOC C NC
85 to 250 Vac
21 to 100 Vdc
Auto-Detecting
Relay #1 Relay #2
Figure 2-4 Relay Wiring
M3 / 2.5mm
Hex Drive
8
7
6
5
4
2
1
3
M3 / 2.5mm
Hex Drive
M5 / Slotted Drive
#8-32 / Phillips-Slotted
Drive
M4 / 2.5mm Hex Drive
Alarm Alarm
3 5 64 7 8
NO NC NOC C NC
One 5A DPDT Alarm
2.4 Output Wiring - Relay Version
The IntelliPoint RF series instrument is supplied with two
sets of contacts. These contacts can be used as a single 5A
DPDT alarm relay:
Customer
Connections
View
2.3 Input Wiring
WARNING: If the IntelliPoint instrument is located in a
hazardous environment, do not open the enclosure cover
or make/break any electrical connections without rst
disconnecting electrical power at the source. Ensure the
wiring, electrical ttings, and conduit connections conform to
electrical codes for the specic location and hazard level.
The IntelliPoint RF instrument utilizes a universal power
supply and can be operated from any source between 85 to
250 VAC or 21 to 100 VDC. The universal power supply
automatically detects the input voltage regardless of polarity
and does not require jumper changes.
To access, remove the housing lid on the customer
connections side to reveal the input/output module (IOM).
The IOM is an encapsulated assembly that contains the
power supply, outputs, and eight wiring terminals. IOM is
held in place with three screws. See Figure 2-3.
M3 / 2.5mm
Hex Drive
8
7
6
5
4
2
1
3
M3 / 2.5mm
Hex Drive
M5 / Slotted Drive
#8-32 / Phillips-Slotted
Drive
M4 / 2.5mm Hex Drive
Figure 2-3
Input Wiring
2 31 5 64 7 8
L2 NOL1 NC NOC C NC
85 to 250 Vac
21 to 100 Vdc
Auto-Detecting
Relay #1 Relay #2
IntelliPoint RF RML Series Installation
9
2.6 Circuit Board
The circuit board is located on the sensing element/circuit
side of the housing (marked on label). Remove the housing
lid to access the status LEDs, time delay adjustment, and
conguration jumpers. See Figure 2-5.
2.6.1 Time Delay
The TIME DELAY adjustment is located on the
sensing element/circuit board side of the housing. It is used
to help stop an oscillating relay output due to agitation or
waves in the vessel. The time delay
adjustment can be eld-adjusted from 0 to 60 seconds. The
unit is shipped with the TIME DELAY setting at zero (0)
seconds.
The Time Delay adjustment is a 270-Degree turn pot and is
at zero seconds when in the full counter-clockwise position.
Do not force the pot past the stop or damage will occur.
LLFS
FAILSAFE
HLFS
LLFS
FAILSAFE
HLFS
TIME DELAY
0-60 SECONDS
0 60
FWD
TD
REV
FWD
TD
REV
POST
PAD TERMINALS
SETPOINT
CLOCKWISE WILL RAISE
OPERATING LEVEL
COUNTERCLOCKWISE
WILL LOWER OPERATING LEVEL
PRESS FOR FUNCTION CHECK
DIFFERENTIAL
CLOCKWISE TO RAISE
DIFFERENTIAL
COUNTERCLOCKWISE
TO LOWER DIFFERENTIAL
(25 Turn) (25 Turn)
RED
ALARM
GREEN
POWER
UNUSED
FAULT
RELAY #2
ALARM
FAULT
RELAY #2
ALARM
Figure 2-5 Circuit Board (Sensing Element Circuits View)
2.5 Spark Protection
Applications involving insulating granulars and insulating
liquids may produce a static discharge that can damage
the electronics. The RF series instrument is supplied with
integral heavy-duty spark protection to prevent static
discharges from damaging the electronic units.
IntelliPoint RF RML Series Installation
10
2.6.3 Failsafe
Failsafe describes the level condition that causes the output
relay to de-energize and also the state of the relay upon loss
of power.
• High Level Failsafe (HLFS) is condition when probe
is covered. Relay will de-energize when level is high,
indicating high level upon loss of power. (N.O. contacts
open and N.C. contacts closed).
• Low Level Failsafe (LLFS) is condition when probe
is uncovered. Relay will de-energize when level is low,
indicating low level upon loss of power. (N.O. contacts
open and N.C. contacts closed).
• Instrument is supplied with failsafe jumper set in high
level (HLFS) position.
• Failsafe is eld-selectable using a jumper located on
sensing element/circuit board side of housing.
2.6.4 Relay #2 Assignment
RELAY #2 assignment refers to operation of RELAY #2, and
congures relays as (1) SPDT alarm and (1) SPDT fault relay
or (1) DPDT alarm relay. RELAY #1 is always an alarm
relay.
• Alarm: RELAY #2 will follow RELAY #1, providing a
DPDT alarm relay.
• Fault: RELAY #2 is used to indicate a fault.
• Instrument is supplied with RELAY #2 jumper set in
alarm position.
• RELAY #2 assignment is eld-selectable using a jumper
located on sensing element/circuit board side of housing.
2.6.5 Function Check
The Function Check (High Level Fail Safe Only)
test feature performs a condence test of the system by
duplicating the same signal as a high-level alarm condition
without requiring the system to be removed from the tank.
Simulating a high level with the Function Check feature:
• Checks the relay connections to other control devices.
The Function Check test is initiated with the press of the
Function Check button located on the sensing element/
2.6.2 Time Delay Action
Time delay action describes whether the relay
contacts are delayed from going into the alarm state or
recovering from an alarm state.
• FWD: Delays system from coming out of alarm.
• REV:Delays system from going into alarm.
• Instrument is supplied with TIME DELAY action set in
forward mode (FWD) position.
• Time delay action is eld-selectable using jumper
located on sensing element/circuit board side of
housing.
IntelliPoint RF RML Series Installation
11
circuit side of the housing. After pressing the button, the
green LED ashes for 5 seconds and the two red LEDs light.
The relay contacts are moved to the alarm condition for 2
seconds. If the two red LEDs do not light, and the relay
contacts do not move to the alarm condition, the Manual
Certify test has detected a fault. Consult the trouble-
shooting section of this Instruction Manual.
2.6.6 Setpoint and Differential Controls
See Calibration Section 3.0.
2.7 Output and LED Status
There are three status LEDs
located on the sensing element/circuit board side of the
housing. One is used to indicate that the unit has power. The
remaining two LEDs are used to indicate the condition of
relay #1 and relay #2. See Figure 2-6.
Figure 2-6
Output and LED Status
LED
On
LED
Off
LED
Off
Relay 1
RED
Relay 2
RED
Power
GREEN
3 5 64 7 8
NO NC NOC C NC
High Level FailSafe
Tank Empty
3 5 64 7 8
NO NC NOC C NC
High Level FailSafe
Tank Full
3 5 64 7 8
NO NC NOC C NC
Low Level FailSafe
Tank Full
3 5 64 7 8
NO NC NOC C NC
Low Level FailSafe
Tank Empty
LED
On
LED
On
LED
On
Relay 1
RED
Relay 2
RED
Power
GREEN
LED
On
LED
On
LED
On
Relay 1
RED
Relay 2
RED
Power
GREEN
LED
On
LED
Off
LED
Off
Relay 1
RED
Relay 2
RED
Power
GREEN
Tank Relay and LED
Condition Output Status
2.6.5 Function Check (Continued)
IntelliPoint RF RML Series Installation
12
2.8 Sensing Element Connection
Figure 2-7
Sensing Element Connection
(Integral Housing)
Sensing element connects to the rear side of the circuit board
and is factory-installed.
The sensing element is sealed to the housing and cannot be
removed without permanent damage.
For IntelliPoint RF instruments that are mounted remotely
from the sensing element, the cable connections from the
sensing element to the electronic unit are made to the
terminals on the sensing element side of the housing. See
Figure 2-8. Connect Green (Ground) wire to green screw,
Red (Shield) wire to red screw, and Blue (Center) wire to blue
screw.
This manual suits for next models
1
Table of contents
Other Ametek Switch manuals
Ametek
Ametek IntelliPoint RF RNT Series Assembly instructions
Ametek
Ametek SIL IntelliPoint RF S*R*L Series User manual
Ametek
Ametek Magnetrol3 Series User manual
Ametek
Ametek IntelliPoint RF RMT Series User manual
Ametek
Ametek Drexelbrook IntelliPoint RF RNL Series User manual
Ametek
Ametek SWI L072 User manual
Ametek
Ametek Gemco 1995L Assembly instructions
Ametek
Ametek esd NX30 User manual
Ametek
Ametek Magnetrol Thermatel TD1 User manual
Ametek
Ametek Magnetrol SOLITEL User manual
Popular Switch manuals by other brands
Allied Telesis
Allied Telesis SBx8112 Command reference
Panasonic
Panasonic AV3 FS product catalog
ATEN
ATEN VM7104 quick start guide
TP-Link
TP-Link JetStream T1500-28TC installation guide
Network Technologies
Network Technologies SM-nXm-C5AV-LCD Installation and operation manual
FIBERROAD
FIBERROAD FR-6R3204 user manual
