Installation and
Operating Instructions
IntelliPoint RFTM RNT Series
Two-Wire Point Level Switch
NOTICE: The AutoVerify™ feature in The
IntelliPoint™ switch is shipped DISABLED.
For critical High Level applications we
recommend enabling the AutoVerify™
feature.
Telephone: [phone]
Fax: [phone]
E-mail: drex[email protected]
Website: www.drexelbrook.com

AMETEK Drexelbrook makes no warranty of any kind with regard to the material contained
in this manual, including, but not limited to, implied warranties or fitness for a particular
purpose. Drexelbrook shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the performance or use of material.
© AMETEK Drexelbrook

IntelliPoint RF Series
Two-Wire Point Level Switch
RNTXX1-LM
Issue# 19
205 Keith Valley Road, Horsham, PA 19044
Telephone: [phone]
Fax: [phone]
E-mail: drexelbrook.inf[email protected]
Website: www.drexelbrook.com
An ISO 9001 Certified Company

Contents

Contents
Section 1: Introduction
1.1 System Description ......................................................................................1
1.2 Technology...................................................................................................1
1.3 Model Number .............................................................................................2
1.4 Sensing Element List ...................................................................................3
1.5 Dual Compartment Housing Detail ..............................................................4
Section 2: Installation
2.1 Unpacking ....................................................................................................5
2.2 Mounting and Installation Guidelines ...........................................................5
2.3 Input Wiring..................................................................................................8
2.4 Spark Protection .........................................................................................8
2.5 Circuit Board ...............................................................................................10
2.6 Output & Status LEDs..................................................................................14
2.7 Sensing Element Connection.......................................................................15
2.8 Calibration....................................................................................................17
Section 3: Spare Parts List..........................................................................................20
Section 4: Troubleshooting
4.1 RF Point Level Troubleshooting Guide.........................................................22
4.2 Testing Electronic Unit .................................................................................23
4.3 Over Range..................................................................................................24
4.4 Under Range................................................................................................24
4.5 Testing The Sensing Element ......................................................................24
4.6 Testing the Integral Cable ............................................................................27
4.7 Testing the Remote Cable............................................................................27
4.8 Testing the Power Supply.............................................................................28
4.9 Factory Assistance.......................................................................................29
4.10 Field Service ................................................................................................29
4.11 Customer Training ........................................................................................29
4.12 Equipment Return........................................................................................30
Section 5: Specifications
5.1 Approvals .....................................................................................................33
Section 6: Control Drawings
6.1 FM / FMc Control Drawings ........................................................................34
6.2 ATEX Control Drawings................................................................................50
6.3 CE Mark Declaration of Conformity .............................................................59
6.4 IECEx Control Drawings ..............................................................................60
6.5 Mounting and Wiring for Spark Protector Drawings .....................................68
6.6 Adding a Padded Capacitor .........................................................................71
6.7 Dual Seal Assembly for 700 Series Sensing Elements................................74
Appendix A:
Shortening or Lengthening the Sensing Element...................................................A-1
CE Installation Supplement.......................................................................................A-2
CE Installation Supplement (Continued) .................................................................A-3

Section 1

Introduction
1
Section 1: Introduction
1.1 System Description
Installation is simple and easy on the AMETEK Drexelbrook
IntelliPoint™Series products. Simply apply power and the
IntelliPoint system is ready to detect the presence or absence
of material. Since the IntelliPoint instrument does not require
calibration or setpoint adjustments, it is capable of operating in
non-dedicated tanks regardless of the material being measured.
Notice: Material to be Measured Must Be Below
Sensor when Power is Applied.
The AutoVerify™ self-testing function continuously monitors
the entire system to ensure proper operation. Manual
Certify™ changes the outputs in order to test the loop current
and ensure proper operation of the control systems.
1.2 Technology
In a simple capacitance probe-type sensing element, when
the level rises and material covers the probe, the capacitance
within the circuit between the probe and the media (conductive
applications) or the probe and the vessel wall (insulating
applications) increases. This is due to the dielectric constant
(k) of the material, which causes a bridge mis-balance. The
signal is demodulated (rectied), amplied, and the output is
increased. There are drawbacks, however, especially when
there is coating of the probe.
An RF Admittance level transmitter is the next generation.
Although similar to the capacitance concept, The IntelliPoint
employs a radio frequency signal and adds the Cote-Shield™
circuitry within the Electronics Unit.
This patented Cote-Shield™ circuitry is designed into the
IntelliPoint series and enables the instrument to ignore the
effect of buildup or material coating on the sensing element. The
sensing element is mounted in the vessel and provides a change
in RF admittance indicating presence or absence of material.
The Cote-Shield element of the sensor prevents the
transmission of RF current through the coating on the sensing
element. The only path to ground available for the RF current
is through the material being measured.
The result is an accurate measurement regardless of the amount
of coating on the probe, making it by far the most versatile
technology, good for very wide range conditions from cryogenics
to high temperature, from vacuum to 10,000psi pressure, and
works with all types of materials.
Figure 1-1
Simple Capacitance Probe
(Insulating Media Shown)
k
air
A
d
Ckmedia
C=kA
d
C = k A
d
A
k
air
d
C
kmedia
Figure 1-2
RF Admittance Probe
with Cote-Shield

RNTXX - IntelliPoint RF Series User's Manual
2
1.3 Model Number
Sensing Element (Reference Section 1.4 for Probe Selections)
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options available with all
sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Sensing Element (Reference Section 1.4 for Probe Selections)
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options available with all
sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Sensing Element (Reference Section 1.4 for Probe Selections)
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options available with all
sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Sensing Element (Reference Section 1.4 for Probe Selections)
IL CSL
xxxG 457 mm (18") 0 mm (0")
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
A1BX IL/CSL factory set for Fly Ash
xxxZ Other
IL CSL
xxx1 457 mm (18") 152 mm (6")
xxx2 305 mm (12") 152 mm (6")
xxxA 152 mm (6") 51 mm (2")
xxxB 305 mm (12") 51 mm (2")
xxxC 305 mm (12") 89 mm (3.5")
xxxD 457 mm (18") 51 mm (2")
xxxE 457 mm (18") 89 mm (3.5")
xxxF 457 mm (18") 254 mm (10")
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options available with all
sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Sensing Element (Reference Section 1.4 for Probe Selections)
IL CSL
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
xxxZ Other
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options are available with all sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Output
08-16 mA Output
Housing
Technology
RRF Admittance
RNT SXRXTX RNL
Input
TTwo wire Power Supply, 13-30 Vdc
Measurement Type
NAuto Calibration (2pf)
HAuto Calibration (0.5pf)
L2pf Fixed Calibration
TAuto Calibration (10pf)
V10pf Fixed Calibration
P0.5pf Fixed Calibration
Electronics
0Integral
1Remote, no cable
2Remote w/ 3 m (10 ft.) G.P. Cable
3Remote w/ 7.6 m (25 ft.) G.P. Cable
4Remote w/ 10.6 m (35 ft.) G.P. Cable
5Remote w/ 15.2 m (50 ft.) G.P. Cable
6Remote w/ 23 m (75 ft.) G.P. Cable
7Remote w/ (25 ft.) Tri-Ax Cable
8Remote w/ (50 ft.) Tri-Ax Cable
9Remote w/ (75 ft.) Tri-Ax Cable
ARemote w/ (10 ft.) Hi-Temp. Cable
BRemote w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRemote w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRemote w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERemote w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRemote w/ (5 ft.) G.P. Cable
GRemote w/ (5 ft.) Tri-Ax Cable
HRemote w/ (10 ft.) Tri-Ax Cable
JRemote w/ (35 ft.) Tri-Ax Cable
KRemote w/ (5 ft.) Hi-Temp. Cable
Output
08-16mA Output
Safety IntelliPoint RF TM
Housing
Technology
RRF Admittance
Input
TTwo Wire Power Supply 13-30 VDC
SIL
2SIL2
Safety Switch
S
R T 0
S
IMPORTANT:
Minimum Active Length for SIL Compliance is 24" (610mm)
Consult Factory for Shorter Lengths
Electronics
0Integral
1Remote, no cable
2Rmt. w/ 3 m (10 ft.) G.P. Cable
3Rmt. w/ 7.6 m (25 ft.) G.P. Cable
4Rmt. w/ 10.6 m (35 ft.) G.P. Cable
5Rmt. w/ 15.2 m (50 ft.) G.P. Cable
6Rmt. w/ 23 m (75 ft.) G.P. Cable
7Rmt. w/ (25 ft.) Tri-Ax Cable
8Rmt. w/ (50 ft.) Tri-Ax Cable
9Rmt. w/ (75 ft.) Tri-Ax Cable
ARmt. w/ (10 ft.) Hi-Temp. Cable
BRmt. w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRmt. w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRmt. w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERmt. w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRmt. w/ (5 ft.) G.P. Cable
GRmt. w/ (5 ft.) Tri-Ax Cable
HRmt. w/ (10 ft.) Tri-Ax Cable
JRmt. w/ (35 ft.) Tri-Ax Cable
KRmt. w/ (5 ft.) Hi-Temp. Cable
Measurement Type
NAuto Calibration (2pf)
HAuto Calibration (0.5pf)
L2pf Fixed Calibration
Output
1Two SPDT Relays, relay #2 configured as alarm or fault (Min=100 mA / 12 VDC)
2Two SPDT Relay, gold plated contacts (Max 200 mA / 12 VDC)
IntelliPoint RF TM
IntelliPoint RF TM
Housing
Technology
RRF Admittance
Input
LUniversal Power Supply 21-100 VDC, 85-250 VAC, 0-400 Hz
Measurement Type
L2pf Fixed Calibration
HAuto Calibration (0.5pf)
TAuto Calibration (10pf)
V10pf Fixed Calibration
NAuto Calibration (2pf)
P0.5pf Fixed Calibration
R L
Electronics
0Integral
1Remote, no cable
2Remote w/ 3 m (10 ft.) G.P. Cable
3Remote w/ 7.6 m (25 ft.) G.P. Cable
4Remote w/ 10.6 m (35 ft.) G.P. Cable
5Remote w/ 15.2 m (50 ft.) G.P. Cable
6Remote w/ 23 m (75 ft.) G.P. Cable
7Remote w/ (25 ft.) Tri-Ax Cable
8Remote w/ (50 ft.) Tri-Ax Cable
9Remote w/ (75 ft.) Tri-Ax Cable
ARemote w/ (10 ft.) Hi-Temp. Cable
BRemote w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRemote w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRemote w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERemote w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRemote w/ (5 ft.) G.P. Cable
GRemote w/ (5 ft.) Tri-Ax Cable
HRemote w/ (10 ft.) Tri-Ax Cable
JRemote w/ (35 ft.) Tri-Ax Cable
KRemote w/ (5 ft.) Hi-Temp. Cable
RML
Output
1Two SPDT Relays, relay #2 configured as alarm or fault (Min=100 mA / 12 VDC)
2Two SPDT Relay, gold plated contacts (Max 200 mA / 12 VDC)
IntelliPoint RF TM
Housing
Technology
RRF Admittance
Input
LUniversal Power Supply 21-100 VDC, 85-250 VAC, 0-400 Hz
Measurement Type
MManual Calibration (Std. Sensitivity)
GManual Calibration (High Sensitivity)
R L
Electronics
0Integral
1Remote, no cable
2Remote w/ 3 m (10 ft.) G.P. Cable
3Remote w/ 7.6 m (25 ft.) G.P. Cable
4Remote w/ 10.6 m (35 ft.) G.P. Cable
5Remote w/ 15.2 m (50 ft.) G.P. Cable
6Remote w/ 23 m (75 ft.) G.P. Cable
7Remote w/ (25 ft.) Tri-Ax Cable
8Remote w/ (50 ft.) Tri-Ax Cable
9Remote w/ (75 ft.) Tri-Ax Cable
ARemote w/ (10 ft.) Hi-Temp. Cable
BRemote w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRemote w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRemote w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERemote w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRemote w/ (5 ft.) G.P. Cable
GRemote w/ (5 ft.) Tri-Ax Cable
HRemote w/ (10 ft.) Tri-Ax Cable
JRemote w/ (35 ft.) Tri-Ax Cable
KRemote w/ (5 ft.) Hi-Temp. Cable
RMT
Output
08-16 mA Output
IntelliPoint RF TM
Housing
Technology
RRF Admittance
Input
TTwo-Wire Power Supply, 13-30 Vdc
Measurement Type
MManual Calibration (Standard Sensitivity)
GManual Calibration (High Sensitivity)
R T 0
Electronics
0Integral
1Remote, no cable
2Remote w/ 3 m (10 ft.) G.P. Cable
3Remote w/ 7.6 m (25 ft.) G.P. Cable
4Remote w/ 10.6 m (35 ft.) G.P. Cable
5Remote w/ 15.2 m (50 ft.) G.P. Cable
6Remote w/ 23 m (75 ft.) G.P. Cable
7Remote w/ (25 ft.) Tri-Ax Cable
8Remote w/ (50 ft.) Tri-Ax Cable
9Remote w/ (75 ft.) Tri-Ax Cable
ARemote w/ (10 ft.) Hi-Temp. Cable
BRemote w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRemote w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRemote w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERemote w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRemote w/ (5 ft.) G.P. Cable
GRemote w/ (5 ft.) Tri-Ax Cable
HRemote w/ (10 ft.) Tri-Ax Cable
JRemote w/ (35 ft.) Tri-Ax Cable
KRemote w/ (5 ft.) Hi-Temp. Cable
0No Approvals, NEMA 4X/IP66, M20 X 1.5 conduit entries
1No Approvals, NEMA 4X/IP66, ¾” NPT conduit entries
2ATEX / IECEx Approved, NEMA 4X/IP66, M20 X 1.5 conduit entries
3FM / FMc Approved, NEMA 4X/IP66, ¾” NPT conduit entries
5No Approvals, NEMA 4X/IP66, M20 X 1.5 conduit entries, Dual Seal, Perm-a-Seal sensors – only
6No Approvals, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Perm-a-Seal sensors – only
7FM / FMc Approved, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Perm-a-Seal sensors – only
9No Approvals, NEMA 4X/IP66, M20 X 1.5 conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
ANo Approvals, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
BFM / FMc Approved, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
2ATEX /IECEx Approved, NEMA 4X/IP66, M20 X 1.5 conduit entries
3FM Approved, NEMA 4X/IP66, ¾” NPT conduit entries
7FM Approved, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Perm-a-Seal sensors – only
BFM Approved, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
SXRXLX
0No Approvals, NEMA 4X/IP66, M20 X 1.5 conduit entries
1No Approvals, NEMA 4X/IP66, ¾” NPT conduit entries
2ATEX / IECEx Approved, NEMA 4X/IP66, M20 X 1.5 conduit entries
3FM / FMc Approved, NEMA 4X/IP66, ¾” NPT conduit entries
5No Approvals, NEMA 4X/IP66, M20 X 1.5 conduit entries, Dual Seal, Perm-a-Seal sensors – only
6No Approvals, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Perm-a-Seal sensors – only
7FM / FMc Approved, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Perm-a-Seal sensors – only
9No Approvals, NEMA 4X/IP66, M20 X 1.5 conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
ANo Approvals, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
BFM / FMc Approved, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
0No Approvals, NEMA 4X/IP66, M20 X 1.5 conduit entries
1No Approvals, NEMA 4X/IP66, ¾” NPT conduit entries
2ATEX / IECEx Approved, NEMA 4X/IP66, M20 X 1.5 conduit entries
3FM/FMc Approved, NEMA 4X/IP66, ¾” NPT conduit entries
5No Approvals, NEMA 4X/IP66, M20 X 1.5 conduit entries, Dual Seal, Perm-a-Seal sensors – only
6No Approvals, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Perm-a-Seal sensors – only
7FM/FMc Approved, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Perm-a-Seal sensors – only
9No Approvals, NEMA 4X/IP66, M20 X 1.5 conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
ANo Approvals, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
BFM/FMc Approved, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
0No Approvals, NEMA 4X/IP66, M20 X 1.5 conduit entries
1No Approvals, NEMA 4X/IP66, ¾” NPT conduit entries
2ATEX / IECEx Approved, NEMA 4X/IP66, M20 X 1.5 conduit entries
3FM / FMc Approved, NEMA 4X/IP66, ¾” NPT conduit entries
5No Approvals, NEMA 4X/IP66, M20 X 1.5 conduit entries, Dual Seal, Perm-a-Seal sensors – only
6No Approvals, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Perm-a-Seal sensors – only
7FM / FMc Approved, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Perm-a-Seal sensors – only
9No Approvals, NEMA 4X/IP66, M20 X 1.5 conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
ANo Approvals, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
BFM / FMc Approved, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
TAuto Calibration (10pf)
V10pf Fixed Calibration
P0.5pf Fixed Calibration
Sensing Element (Reference Section 1.4 for Probe Selections)
IL CSL
xxxH 914 mm (36") 254 mm (10")
xxxJ 914 mm (36") 0 mm (0")
xxxK 1219 mm (48") 254 mm (10")
xxxL 1524 mm (60") 254 mm (10")
P00X IL/CSL Other
xxxZ Other
Mounting Type (See separate Mounting Chart for first three digits)
(1) Available with remote electronics only
(2) Use A1P mounting option
(3) Choose only sanitary mounting options
(4) Available with 0-inch CSL only
(5) Use P00X mounting option
(6) Use A1B mounting option
(7) Use A8B mounting option (¼-inch NPT)
(8) Choose from flange mounting only
(9) FM approved with remote electronics only
Not all mounting options are available with all sensing elements
Notes: CSL (Cote-Shield Length) should extend through Nozzle + Typical "Wall Buildup" + 2 Inches
NPT Threads
A1B ¾"NPT 316SS
A1C ¾"NPT Hastelloy C
A1P ¾"NPT PFA
A2B 1"NPT 316SS
A2C 1"NPT Hastelloy C
Sanitary TriClamps
C2B 1"TriClamp 316SS
C3B 1½"TriClamp 316SS
C4B 2"TriClamp 316SS
ANSI Flanges
DA1 1" 150# RF 316/316L SS
DB1 1½" 150# RF 316/316L SS
DC1 2" 150# RF 316/316L SS
DD1 2½" 150# RF 316/316L SS
DE1 1" 300# RF 316/316L SS
DF1 1½" 300# RF 316/316L SS
DG1 2" 300# RF 316/316L SS
DH1 2½" 300# RF 316/316L SS
DI1 3" 150# RF 316/316L SS
DJ1 3" 300# RF 316/316L SS
DK1 4" 150# RF 316/316L SS
DL1 4" 300# RF 316/316L SS
DM1 6" 150# RF 316/316L SS
DN1 6" 300# RF 316/316L SS
DA2 1" 150# RF CS
DB2 1½" 150# RF CS
DC2 2" 150# RF CS
DD2 2½" 150# RF CS
DE2 1" 300# RF CS
DF2 1½" 300# RF CS
DG2 2" 300# RF CS
DH2 2½" 300# RF CS
DI2 3" 150# RF CS
DJ2 3" 300# RF CS
DK2 4" 150# RF CS
DL2 4" 300# RF CS
DM2 6" 150# RF CS
DN2 6" 300# RF CS
DIN Flanges
E01 25 mm 16 bar RF 316/316L SS
EP1 25 mm 40 bar RF 316/316L SS
EQ1 50 mm 16 bar RF 316/316L SS
ER1 50 mm 40 bar RF 316/316L SS
ES1 80 mm 16 bar RF 316/316L SS
ET1 80 mm 40 bar RF 316/316L SS
EU1 100 mm 16 bar RF 316/316L SS
EV1 100 mm 40 bar RF 316/316L SS
EW1 150 mm 16 bar RF 316/316L SS
EX1 150 mm 40 bar RF 316/316L SS
E02 25 mm 16 bar RF CS
EP2 25 mm 40 bar RF CS
EQ2 50 mm 16 bar RF CS
ER2 50 mm 40 bar RF CS
ES2 80 mm 16 bar RF CS
ET2 80 mm 40 bar RF CS
EU2 100 mm 16 bar RF CS
EV2 100 mm 40 bar RF CS
EW2 150 mm 16 bar RF CS
EX2 150 mm 40 bar RF CS
Output
1Two SPDT Relays, Relay #2 configured as alarm or fault (Min=100mA / 12 VDC)
2Two SPDT Relays, Gold plated contacts (Max 200mA / 12 VDC
Safety IntelliPoint RF TM
Housing
Technology
RRF Admittance
Input
LUniversal Power Supply 21-100VDC, 85-250VAC, 0-400 Hz
SIL
2SIL2
Safety Switch
S
R T 0
S
IMPORTANT:
Minimum Active Length for SIL Compliance is 24" (610mm)
Consult Factory for Shorter Lengths
Electronics
0Integral
1Remote, no cable
2Rmt. w/ 3 m (10 ft.) G.P. Cable
3Rmt. w/ 7.6 m (25 ft.) G.P. Cable
4Rmt. w/ 10.6 m (35 ft.) G.P. Cable
5Rmt. w/ 15.2 m (50 ft.) G.P. Cable
6Rmt. w/ 23 m (75 ft.) G.P. Cable
7Rmt. w/ (25 ft.) Tri-Ax Cable
8Rmt. w/ (50 ft.) Tri-Ax Cable
9Rmt. w/ (75 ft.) Tri-Ax Cable
ARmt. w/ (10 ft.) Hi-Temp. Cable
BRmt. w/ (25 ft.) 1st 10ft Hi-Temp. Cbl.
CRmt. w/ (35 ft.) 1st 10ft Hi-Temp. Cbl.
DRmt. w/ (50 ft.) 1st 10ft Hi-Temp. Cbl.
ERmt. w/ (75 ft.) 1st 10ft Hi-Temp. Cbl.
FRmt. w/ (5 ft.) G.P. Cable
GRmt. w/ (5 ft.) Tri-Ax Cable
HRmt. w/ (10 ft.) Tri-Ax Cable
JRmt. w/ (35 ft.) Tri-Ax Cable
KRmt. w/ (5 ft.) Hi-Temp. Cable
Measurement Type
NAuto Calibration (2pf)
HAuto Calibration (0.5pf)
L2pf Fixed Calibration
2ATEX / IECEx Approved, NEMA 4X/IP66, M20 X 1.5 conduit entries
3FM Approved, NEMA 4X/IP66, ¾” NPT conduit entries
7FM Approved, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Perm-a-Seal sensors – only
BFM Approved, NEMA 4X/IP66, ¾” NPT conduit entries, Dual Seal, Non Perm-a-Seal sensors – only
TAuto Calibration (10pf)
V10pf Fixed Calibration
P0.5pf Fixed Calibration

Introduction
3
1.4 Sensing Element List
#
Application SensingElementPartNumber Pressure/Temperature WettedParts
700‐1202‐001Remote
700‐1202‐021Integral
700‐1202‐014Remote
700‐1202‐024Integral
700‐1202‐018Remote
700‐1202‐028Integral
700‐1202‐041Remote 69bar@121°C(1000PSI@250°F)
700‐1202‐042Integral 20.7bar@232°C(300PSI@450°F)
700‐1202‐031Remote
700‐1202‐032Integral
700‐1202‐010Remote
700‐1202‐020Integral
700‐1202‐033Remote
700‐1202‐034Integral
10 Corrosiveliquids 700‐0001‐018Remote 3.4bar@149°C(50PSI@300°F) PFA
69bar@38°C(1000PSI@100°F)
13.8bar@232°C(200PSI@450°F)
69bar@38°C(1000PSI@100°F)
13.8bar@232°C(200PSI@450°F)
3.4bar@149°C(50PSI@300°F)
1.4bar@232°C(20PSI@450°F)
69bar@38°C(1000PSI@100°F)
13.8bar@232°C(200PSI@450°F)
16 Highintegritysealforhazardousmaterials 700‐0002‐360IntegralorRemote 34.5bar@149°C(500PSI@300°F) PFA
17 Sanitarylowpressure 700‐0202‐029IntegralorRemote 34.5bar@149°C(50PSI@300°F) 316/316LSSandTFE
69bar@38°C(1000PSI@100°F)
34.5bar@149°C(500PSI@300°F)
69bar@38°C(1000PSI@100°F)
34.5bar@149°C(500PSI@300°F)
69bar@121°C(1000PSI@250°F)
0bar@232°C(0PSI@450°F)
69bar@38°C(1000PSI@100°F)
13.8bar@232°C(200PSI@450°F)
69bar@38°C(1000PSI@100°F)
13.8bar@232°C(200PSI@450°F)
700‐0005‐485Integral
700‐0005‐285Remote
700‐0005‐485Integral
700‐0005‐285Remote
26 Extraheavydutyrearmount 700‐0220‐001Remote 20psi@180°F 316/316LSSandFEP
50psi@300°F
20psi@450°F
700‐1202‐051Remote 1500PSI@250°F
700‐1202‐052Integral 500psi@450°F
31 NoHopperInstallation 700‐0029‐001Remote 0.1bar@260°C(2PSI@500°F) 316/316LSSandTFE
32 HopperInstallationupto200mm(8") 700‐0029‐002Remote 0.1bar@260°C(2PSI@500°F) 316/316LSSandTFE
33 HopperInstallationupto406mm(16") 700‐0029‐003Remote 0.1bar@260°C(2PSI@500°F) 316/316LSSandTFE
34 HopperInstallationupto521mm(20.5") 700‐0029‐004Remote 0.1bar@260°C(2PSI@500°F) 316/316LSSandTFE
35 HopperInstallationupto635mm(25") 700‐0029‐005Remote 0.1bar@260°C(2PSI@500°F) 316/316LSSandTFE
36 Mountingdirectlyonhopper,insulation2"max. 700‐0029‐102Remote 2psi@1500°F 316/316LSSandCeramic
37 Maxrecommendednozzlelength9.5" 700‐0029‐103Remote 2psi@1500°F 316/316LSSandCeramic
38 Maxrecommendednozzlelength19" 700‐0029‐104Remote 2psi@1500°F 316/316LSSandCeramic
39 Maxrecommendednozzlelength22" 700‐0029‐105Remote 2psi@1500°F 316/316LSSandCeramic
40 Maxrecommendednozzlelength25" 700‐0029‐106Remote 2psi@1500°F 316/316LSSandCeramic
50 FlushMountSensor,305mm
2
(12inches
2
),HeavyDuty 700‐0207‐001Remote 0.1bar@82°C(1PSI@180°F) 304SSandPolyurethane
51 FlushMountSensor,305mm
2
(12inches
2
),HigherTemp 700‐0207‐002Remote 0.1bar@149°C(1PSI@300°F) 304SSandTFE
52 FlushMountSensor,305mm
2
(12inches
2
),w/Curvedradius153,229,305mm(6,9or12") 700‐0207‐003Remote 0.1bar@82°C(1PSI@180°F) 304SSandNeoprene
53 FlushMountSensor,305mm
2
(12inches
2
),ExtraHeavyDuty 700‐0207‐004Remote 0.1bar@82°C(1PSI@180°F) 410SSandUHMWPolyethylene
55 FlushMountSensor,203mm
2
(18inches
2
),HeavyDuty 700‐0207‐006Remote 0.1bar@82°C(1PSI@180°F) 304SSandPolyurethane
137.9bar@93°C(2000PSI@200°F)
68.9bar@260°C(1000PSI@500°F)
1psi@700°F
0bar@816°C(0PSI@1500°F)
62 Veryhighpressure‐notforsteam 700‐0204‐048Remote 4000psi@600°F 316/316LSS,VespelandCeramic
64 Highpressureandhightemperature 700‐0204‐024Remote 1000psi@750°F 316/316LSS,Monel400andAluminaCeramic
1000psi@100°F
200psi@800°F
72 Retractable,barecenterrod 700‐0201‐027IntegralorRemote 150psi@300°F 316/316LSSandTFE
73 Retractable,insulatedcenterrod 700‐0201‐028IntegralorRemote 150psi@300°F 316/316LSSandTFE
80 2"Clearline 700‐4200‐020Remote 7bar@121°C(100psi@250°F) 316/316LSSandPEEK
81 3"Clearline 700‐4200‐030Remote 7bar@121°C(100psi@250°F) 316/316LSSandPEEK
82 4"Clearline 700‐4200‐040Remote 7bar@121°C(100psi@250°F) 316/316LSSandPEEK
83 6"Clearline 700‐4200‐060Remote 7bar@121°C(100psi@250°F) 316/316LSSandPEEK
85 Leakdetection 700‐9000‐494Remote 0psi@185°F 316/316LSSandTFE
86 SILfloatingroofandhydrocarbonliquids‐3/4" 700‐0005‐594Integral 0psi@185°F BrassPolyolefinandFEP‐.75inchdiameterprobe
87 SILfloatingroofandhydrocarbonliquids‐1.5" 700‐0005‐595Integral 0psi@185°F BrassPolyolefinandFEP‐1.5inchdiameterprobe
90 Perforatedconcentricshield 700‐0201‐059IntegralorRemote 300psi@300°F 316/316LSSandTFE
700‐1202‐015Remote
700‐1202‐016Integral
700‐1202‐045Remote 1000PSI@250°F
700‐1202‐046Integral 300psi@450°F
700‐1202‐055Remote 1500PSI@250°F
700‐1202‐056Integral 500psi@450°F
69bar@121°C(1000PSI@250°F)
0bar@232°C(0PSI@450°F)
NN RetrofitKit
ZZ SensingElementNotListed
03 Proximity 13.8bar@232°C(200PSI@450°F) 316/316LSSandPEEKwith76mm(3)216SSproximityplate
02 Generalpurpose,longerinsertionlengthsw/cableattachmentand316/316LSSbottomweight 13.8bar@177°C(200PSI@350°F) 316/316LSSandPEEK
00 Generalpurpose 13.8bar@232°C(200PSI@450°F) 316/316LSSandPEEK
09 Generalpurposeforgranularmaterialsw/FDAapprovedmaterialsofconstruction 13.8bar@232°C(200PSI@450°F) 316/316LSSandFDAgradePEEKwith7/8inchdia.316/316LSS
collar
07 Generalpurposeforgranularmaterials 13.8bar@232°C(200PSI@450°F) 316/316LSSandPEEKwith7/8inchdia.316/316LSScollar
04 Generalpurpose,hightemperatureandpressure
�
316/316LSSandPEEK
06 GeneralpurposewithFDAapprovedmaterialsofconstruction 13.8bar@232°C(200PSI@450°F) 316/316LSSandFDAgradePEEK
Corrosivematerial,higherpressure 700‐0201‐005IntegralorRemote(HastelloyC) HastelloyCandTFE
13
Generalpurpose,higherpressure,TFEcompatibilityrequired 700‐0201‐005IntegralorRemote 316/316LSSandTFE
12
11
HeavyDutyagitatedtanksormaterialw/bulkdensity 700‐0202‐043IntegralorRemote 316/316LSSandTFE
18
Generalpurpose,lowpressure 700‐0202‐002IntegralorRemote 316/316LSSandTFE
15
Sanitary 700‐0201‐019IntegralorRemote 316/316LSSandTFE
14
MiniaturePilotPlantSensor 700‐0209‐002Remote 316/316LSSandTFE
21
InterfaceMeasurement 700‐0002‐023IntegralorRemote 316/316LSSandTFE
20
Corrosivematerial,higherpressurewithwaterlikeviscosity 700‐0001‐022IntegralorRemote TFE
19
700‐0202‐043withproximityplate 700‐0202‐044IntegralorRemote 316/316LSSandTFE
24 Inactivecableprobewithactiveweight‐liquidsonly 200psi@200°F 316/316LSSandFEP
HeavyDutyagitatedtanksormaterialw/bulkdensityandcorrosive 700‐0202‐043IntegralorRemote HastelloyCandTFE
22
Extraheavyduty 700‐0221‐002Remote 316/316LSSandFEP
28 Generalpurposeveryhighpressure 316/316LSSandPEEK
27
25 Inactivecableprobewithactiveweight‐corrosiveliquids 200psi@200°F HastelloyCandFEP
700‐0204‐002withsecondaryseal‐verticalonlyinliquids 700‐0204‐022Remote 316/316LSSandCeramic
61 HighTemperature 700‐0204‐002Remote 316/316LSSandCeramic
60 HighPressureandHighTemperature 700‐0204‐038Remote 316/316LSSandCeramic
Specialty
IntegratedGround
Refewrence
General&ApplicationSpecificSensingElements
MiniaturePilotPlantSensorwithconcentricshield 700‐0209‐024Remote 316/316LSSandTFE
13.8bar@149°C(200psi@300°F)
FlyAshPrecipitators,
Baghouse,andEconomizers
PluggedChute
Detection
High
Pressure/Temperature
Retractable
ClearLine(In‐
LineStyle)
94
92 Generalpurposehigherpressurewithperforatedconcentricshield 316/316LSSandPEEK
93 Generalpurposeveryhighpressurewithperforatedconcentricshield 316/316LSSandPEEK
91 Generalpurposewithperforatedconcentricshield 13.8bar@232°C(200PSI@450°F) 316/316LSSandPEEK
66
J:\Engineering\Projects\SIL2‐IntelliPoint\TechnicalRequirementsDocuments\ProbeAddendumComparison_12112017.xlsx

RNTXX - IntelliPoint RF Series User's Manual
4
1.5 Dual Compartment Housing Detail
140 mm
(5.5 inches)
114 mm
(4.5 inches)
165 mm (6.5 inches)
Sensing Element
Circuit Board
Input/Output Module
External
Tag Loop (2)
External Lid Lock (2)
M4 2.5 mm Hex Drive
Conduit Entries (2)
¾-inch NPT (FM/FMc Systems)
M20 x 1.5 (ATEX/IECEx Systems)
LABEL
(see below)
Equipotential Connection
Locked Unlocked
Lid Locking
Mechanism
(ATEX Systems)
Figure 1-3
Dual Compartment Housing Detail
The Input/Output Module (IOM) is located on
Customer Connection side; sensing element/circuit
board are on opposite side.

Installation
5
Section 2: Installation
2.1 Unpacking
Carefully remove the contents of the shipping carton and check
each item against the packing list before destroying any packing
material. If there is any shortage or damage, report it to the
factory immediately.
2.2 Mounting and Installation Guidelines
CAUTION:
The IntelliPoint RF instrument must be powered AFTER it
is installed in the application and with material BELOW the
sensing element.
The IntelliPoint RF instrument can be mounted vertically or
horizontally at any angle. The mounting location should be
as free as possible from vibration, corrosive atmospheres, and
any possibility of mechanical damage. Ambient temperatures
at electronics should be between limits as specied by control
drawings in section 6.
The IntelliPoint RF instrument uses a dual compartment
housing and a completely encapsulated input/output module
to reduce the possibility that damage may occur from water
migrating into the housing through the conduit. To further
reduce the possibility of damage caused by water in the conduit,
install a drip loop and breather drain to purge any accumulating
moisture. Refer to Figure 2-1.
Figure 2-1
Recommended Conduit Connection

RNTXX - IntelliPoint RF Series User's Manual
6
After system is installed and level is below the sensing element,
apply power. The RF Series instrument automatically calibrates
and is ready to detect change in level. If properly installed, the
Green LED lights when power is applied. The Red LED should
not be ashing. If the Red LED is ashing, refer to Section 4:
Troubleshooting.
Cable fittings supplied are weather-resistant.
They are NOT certied as explosion-proof (XP)
or flameproof (d) unless they are specifically
marked.
The IntelliPoint RF instrument is rated Intrinsically
Safe (I.S.) when power is provided from an I.S.
supply.
WARNING:
IntelliPoint RF equipment is rated explosion-proof. When
installing in explosion hazardous areas [rated “potentially
hazardous” (EU) or “hazardous classied” (USA)] observe all
national and local regulations as well as specications in the
certicate.
Mount sensing element using the following installation
guidelines. See Figure 2-2.
When installing IntelliPoint RF instrument, ambient
temperature at electronics must not exceed 70°C (158°F).
When installing ange-mounted sensing elements, keep mating
surfaces and bolts free of paint and corrosion to ensure proper
electrical contact with vessel. Avoid using excessive amounts of
Teon™ tape when installing threaded sensing elements.
Install systems with threaded NPT connection via wrench ats
on the process connection ONLY.
Locate sensing element to avoid enhancing electrostatic
discharge from process medium, as is good practice with any
thermowell, displacer, or sampler. This includes correct bonding
to the tank or silo wall.
If installation area is rated explosion-proof and requires conduit
seal ttings, they should be used in accordance with company
standards and local codes.
2.2 Mounting and Installation Guidelines (Continued)

Installation
7
Mounting sensing element inside a pipe is not recommended.
Do not mount a Cote-Shield sensing element through a nozzle
that exceeds length of rst insulator.
Ensure that there are no obstructions or agitator blades to
interfere with sensing element.
Rigid sensing elements can be mounted either vertically or
horizontally.
Figure 2-2
Installation Considerations
NOZZLE
NOZZLE
Wall build-up
does not extend
past first
insulator.
Cote-shield must
extend through
nozzle and wall
build-up.
Wrong
Nozzle too long;
Cote-shield too short.
Factory-supplied Cote-shield
extends through nozzle and
wall build-up.
Best
Best
No Nozzle
Good
Long Nozzle
2.2 Mounting and Installation Guidelines (Continued)

RNTXX - IntelliPoint RF Series User's Manual
8
2.3 Input Wiring
WARNING:
If The IntelliPoint instrument is located in a hazardous
environment, do not open the enclosure cover or make/break
any electrical connections without rst disconnecting electrical
power at the source. Ensure that the wiring, electrical ttings
and conduit connections conform to electrical codes for the
specic location and hazard level.
The IntelliPoint RF instrument requires a 13-30 Vdc supply
to operate. To access, remove the housing lid on the customer
connections side to reveal the Input/Output Module (IOM).
The IOM is an encapsulated assembly that contains the power
supply, outputs and eight wiring terminals. IOM is held in
place with three screws. See Figure 2-3.
2.4 Spark Protection
Applications involving insulating granulars and insulating
liquids may produce a static discharge that can damage the
electronics. The RF series instrument is supplied with integral
heavy-duty spark protection to prevent static discharges from
damaging the electronic circuits.
Figure 2-3
Input Wiring
M3 / 2.5mm
Hex Drive
8
7
6
5
4
2
1
3
M3 / 2.5mm
Hex Drive
M5 / Slotted Drive
Ground Connection
#8-32 / Phillips-Slotted
Drive
M4 / 2.5mm Hex Drive
1 2 3 4 5 6 7 8
+ - + - A B
Loop
13-30 VDC
Remote
Certify™
Multimeter
Connection to
Monitor Loop
Current

Installation
9
LLFS
FAILSAFE
HLFS
LLFS
FAILSAFE
HLFS
TIME DELAY
0-60 SECONDS
060
FWD
TD
REV
FWD
TD
REV
PRESS FOR
MANUAL CERTIFY
VERIFY
AUTO
ONOFF
OFF ON
AUTO
VERIFY
5mA - FAULT
16mA - ALARM
8mA - NORMAL
22mA - FAULT
16mA - NORMAL
8mA - ALARM RED
ALARM
GREEN
POWER
LEDs
JP5
TIME DELAY
SELECTION
JUMPER
ReCal
PRESS FOR
POST
TP1
OUTPUT CURRENT
UNUSED
NOTE: Do NOT
push the ReCal button
without first ensuring
that the material being
measured is below the
sensing element.
1 2 3
Figure 2-4
Circuit Board
Do NOT push the ReCal button without rst ensuring the
material being measured is below the sensing element
2.5 Circuit Board
The circuit board is located on the sensing element/circuit side of
the housing (marked on label). Remove the housing lid to access
the status LEDs, time delay adjustment, and conguration
jumpers. See Figure 2-4.
Sensing Element
Circuits Side

RNTXX - IntelliPoint RF Series User's Manual
10
2.5.1 Time Delay
The "Time Delay" adjustment is located on the sensing element/
circuit board side of the housing (marked on label). It is used to
help stop an oscillating current output due to agitation or waves
in the vessel. The time delay adjustment can be eld adjusted
from 0 to 60 seconds. The unit is shipped with the Time Delay
set to zero (0) seconds.
The Time Delay adjustment is a 270-Degree turn pot and is at
zero seconds when in the full counter-clockwise position. Do
not force the pot past the stop or damage will occur.
2.5.2 Time Delay Action
"Time Delay Action" describes if loop current is delayed from
going into alarm state or recovering after an alarm state.
• The Time Delay Action is eld-selectable using the TD
jumper on sensing element side of the housing.
• FWD: delays system from coming out of alarm.
• REV: delays system from going in alarm.
• The instrument is supplied with time delay action set in
forward mode (FWD) position.
2.5.3 Failsafe
"Failsafe" describes the level condition that causes the
transmitter to go into alarm.
• The Failsafe is eld-selectable using a jumper located on
the sensing element/circuit board side of the housing.
• High Level Failsafe (HLFS): When the probe is covered, the
unit is in alarm.
• Low Level Failsafe (LLFS) When the probe is uncovered,
the unit is in alarm.
• The instrument is supplied with the failsafe jumper set in
high level (HLFS) position.
2.5.4 Current Output Assignment
The Output Current can be congured using the jumpers as
follows:
• Jumper on pin #1 and #2:
8mA - Alarm, 16mA - Normal, 22mA - Fault
• Jumper on pin #2 and #3:
8mA - Normal, 16mA - Alarm, 5mA - Fault

Installation
11
2.5.5 Manual / Remote Certify™
The "Certify" test feature performs a condence test of the
system by duplicating the same signal as a high-level alarm
condition without requiring the system to be removed from the
tank. Simulating a high level with the Manual/Remote Certify
feature:
• Checks the AutoVerify™ and system circuits to ensure
proper operation.
• Checks the integrity and continuity of the wiring
connections.
• Veries that the sensing element is working properly.
The "Manual Certify" test is initiated with the press of the
Manual Certify Button located on the sensing element / circuit
side of the housing.
The "Remote Certify" test is initiated by creating a momentary
short between contacts 7 and 8 located on the power supply
side of the housing. This can be done with a push button or
relay closure.
After initializing the Certify test, the green LED ashes for 5
seconds and the red LED will illuminate. The current moves
to the alarm condition for 2 seconds. If the red LED does not
turn on, and the current does not move to the alarm condition,
the Certify has detected a fault.
Consult Section 4: Troubleshooting.
Certify feature operates when system is congured
for HLFS.
CAUTION:
Unlike the previous AMETEK Drexelbrook Two Wire Point level
Product (LCT), the IntelliPoint Two Wire Point Level Switch
is designed with on board "AutoVerify" integrity testing. As
such, it requires special instructions to be used with previous
versions of AMETEK Drexelbrook receivers and cannot be used
with some receiver versions. Please refer to Table 2-1.

RNTXX - IntelliPoint RF Series User's Manual
12
2.5.5 Manual / Remote Certify™ (Continued)
Table 2-1
Receiver Versions
Receiver Model
Number Description Use with IntelliPoint Comments
401-04X0-001 Series Single Channel Re-
ceiver OK
401-04X1-001 Series
Single Channel Re-
ceiver with Manual
Verify Push Button
OK - Conditional:
Activating Manual Verify
on receiver will have NO
effect.
To initiate Manual Certify, operator
must press manual certify button on
IntelliPoint circuit board or, by customer-
supplied contact closure attached to
terminals 7 & 8.
401-04X3-001 Series
Single Channel Re-
ceiver with Manual
Verify Magnetic Key
OK - Conditional:
Activating Manual Verify
on receiver will have NO
effect.
To initiate Manual Certify, operator
must press manual certify button on
IntelliPoint circuit board or, by customer-
supplied contact closure attached to
terminals 7 & 8.
401-04X4-001 Series Single Channel Re-
ceiver with AutoVerify
Can Not Be Used With
Intellipoint. Consult Factory
401-3100 Series
401-3800 Series
6 Channel Receiver
OK - Conditional:
Activating Manual Verify
on receiver will have NO
effect.
To initiate Manual Certify, operator
must press manual certify button on
IntelliPoint circuit board or, by customer-
supplied contact closure attached to
terminals 7 & 8.
401-3400 Series 6 to 24 Channel Re-
ceiver
OK - Conditional:
Activating Manual Verify
on receiver will have NO
effect.
To initiate Manual Certify, operator
must press manual certify button on
IntelliPoint circuit board or, by customer-
supplied contact closure attached to
terminals 7 & 8.
LCR-3200 Series
Models 601-30XX-XXX 8-32 point receiver OK
LCR-3200 Series
Models 601-31XX-XXX 8-32 point receiver
OK - Conditional:
If with optional Manual
Verify buttons, activating
Manual Verify on receiver
will have NO effect.
To initiate Manual Certify, operator
must press manual certify button on
IntelliPoint circuit board or, by customer-
supplied contact closure attached to
terminals 7 & 8.
LCR-3200 Series
Models 601-320X-XXX 8-32 point receiver
OK - Conditional:
Activating Manual Verify
on receiver will have NO
effect.
To initiate Manual Certify, operator
must press manual certify button on
IntelliPoint circuit board or, by customer-
supplied contact closure attached to
terminals 7 & 8.
LCR-3200 Series
Models 601-321X-XXX 8-32 point receiver
OK - Conditional:
Turn off AutoVerify
feature. Activating Manual
Verify on receiver will
have NO effect.
To initiate Manual Certify, operator
must press manual certify button on
IntelliPoint circuit board or, by customer-
supplied contact closure attached to
terminals 7 & 8.

Installation
13
2.5.6 AutoVerify™
"AutoVerify" is a self-testing function that continuously checks the system for proper
operation when the unit is in the High Level Failsafe (HLFS) mode and in normal
condition.
• AutoVerify is eld-selectable using a jumper located on the sensing element side of
the housing.
• On: If a fault is detected during the AutoVerify cycle, both LEDs will ash
alternately, and the current will go to the fault output of 5mA or 22mA.
• Off: The AutoVerify self-testing function is not active.
• The instrument is supplied with the AutoVerify jumper set in the off position.
The AutoVerify™ feature in The IntelliPoint™ switch is shipped DISABLED. For
critical High Level applications we recommend enabling the AutoVerify™ feature.
Nonvolatile Memory
The IntelliPoint has nonvolatile memory, allowing the unit to re-start after power
outages without recalibrating.
When unit is powered for the rst time the internal microprocessor records and stores
the “Air” value. This is the uncovered value of the sensor mounted in the vessel. The
unit will also store the last covered value and the last uncovered value.
Whenever the unit is powered it uses these values as a reference point to determine
its current condition (normal or alarm).
The nonvolatile memory will retain the recorded values even if power is lost for months.
When the unit regains power, the microprocessor compares the stored values to the
current measured value. Then determines its current status.
AutoVerify Criteria
1. AutoVerify feature must be enabled.
2. In order for the IntelliPoint to correctly detect a disconnected sensor the active
sensor length (active length = insertion length – cote shield length) must be greater
than 24 inches (610 mm).
3. Consult Factory for specialty sensors that may be available for shorter length
requirements.
4. Sensors that do not meet the above requirement can perform reliably for level
measurement detection, and will pass AutoVerify / Manual Certify tests, but will
not be able to detect a sensor that is, or has become, electrically disconnected from
the transmitter.
Do not push the "ReCal" Button without rst ensuring the Intellipoint is properly
installed and is below the sensing element.
If reset is unsuccessful a red LED will ash.
The system is now ready for installation.
2.5.7 Re-Calibration

RNTXX - IntelliPoint RF Series User's Manual
14
Figure 2-5
Output and LED Status
LED Output Status
LED
On
LED
Off
RED
Power
GREEN
High Level Failsafe
Tank Empty
High Level Failsafe
Tank Full
Low Level Failsafe
Tank Full
Low Level Failsafe
Tank Empty
Tank Condition
AutoVerify = disabled
LED
On
LED
On
RED
Power
GREEN
LED
On
LED
On
RED
Power
GREEN
LED
On
LED
Off
RED
Power
GREEN
LED Output Status
AutoVerify = enabled
High Level Failsafe
Tank Empty
Fault Condition
Detected
RED
Power
GREEN
LED
Flashes Alternately
LED
High Level Failsafe only
LED Output Status
LED
On
LED
Off
RED
Power
GREEN
High Level Failsafe
Tank Empty
High Level Failsafe
Tank Full
Low Level Failsafe
Tank Full
Low Level Failsafe
Tank Empty
Tank Condition
AutoVerify = disabled
LED
On
LED
On
RED
Power
GREEN
LED
On
LED
On
RED
Power
GREEN
LED
On
LED
Off
RED
Power
GREEN
LED Output Status
AutoVerify = enabled
High Level Failsafe
Tank Empty
Fault Condition
Detected
RED
Power
GREEN
LED
Flashes Alternately
LED
High Level Failsafe only
LED Output Status
LED
On
LED
Off
RED
Power
GREEN
High Level Failsafe
Tank Empty
High Level Failsafe
Tank Full
Low Level Failsafe
Tank Full
Low Level Failsafe
Tank Empty
Tank Condition
AutoVerify = disabled
LED
On
LED
On
RED
Power
GREEN
LED
On
LED
On
RED
Power
GREEN
LED
On
LED
Off
RED
Power
GREEN
LED Output Status
AutoVerify = enabled
High Level Failsafe
Tank Empty
Fault Condition
Detected
RED
Power
GREEN
LED
Flashes Alternately
LED
High Level Failsafe only
LED Output Status
LED
On
LED
Off
RED
Power
GREEN
High Level Failsafe
Tank Empty
High Level Failsafe
Tank Full
Low Level Failsafe
Tank Full
Low Level Failsafe
Tank Empty
Tank Condition
AutoVerify = disabled
LED
On
LED
On
RED
Power
GREEN
LED
On
LED
On
RED
Power
GREEN
LED
On
LED
Off
RED
Power
GREEN
LED Output Status
AutoVerify = enabled
High Level Failsafe
Tank Empty
Fault Condition
Detected
RED
Power
GREEN
LED
Flashes Alternately
LED
High Level Failsafe only
LED Output Status
LED
On
LED
Off
RED
Power
GREEN
High Level Failsafe
Tank Empty
High Level Failsafe
Tank Full
Low Level Failsafe
Tank Full
Low Level Failsafe
Tank Empty
Tank Condition
AutoVerify = disabled
LED
On
LED
On
RED
Power
GREEN
LED
On
LED
On
RED
Power
GREEN
LED
On
LED
Off
RED
Power
GREEN
LED Output Status
AutoVerify = enabled
High Level Failsafe
Tank Empty
Fault Condition
Detected
RED
Power
GREEN
LED
Flashes Alternately
LED
High Level Failsafe only
2.6 Output & Status LEDs
There are two status LEDs located on the sensing element/
circuit board side of the housing. One is used to indicate that
the unit has power. The second LED is used to indicate the
status of the unit: Normal or Alarm. See Figure 2-5.
Second Red LED is not used on the two wire transmitter.
The setpoint is stored in memory to indicate the last status of
the switch. So, when the unit regains power the microprocessor
reads the current value of the sensor and determines the status
based on the stored values. It will only re-calibrate if the re-call
button is pressed.
2.5.7 Re-Calibration (Continued)
Normal
Normal
Alarm
Alarm
