AMF Model K User manual

MODEL K DIVIDER
HEAD
New Design Improvements
•Solid stainless steel cylinder (no welded wrap). This design eliminates the potential for vacuum leaks due to
weld failures.
•Quick change cut-off wire assembly significantly reduces downtime due to cut-off wire breakage.
•Pneumatic gauges on both vacuum shoes for easy operator monitoring of vacuum performance.
Maximum Scaling Performance
•Obround piston shafts eliminate shaft flexing to improve scaling performance.
•New precision-machined segment gear assembly provides exact operating performance.
•
Reliable Bun Dividing Performance
• Improved Design for Extended Machine Life and More Precise
Scaling
Features &
Benefits

•Dual Oil Pumping System
•Hopper Block-off Assemblies
•Piston Block-off Assemblies
•2” diameter pistons in place of standard 2 1/2”
diameter pistons (Scaling range of 7/8 oz. to 3 oz.)
•Round operating shaft in lieu of Obround for
increased scaling range
•250 lb. (113 Kg) stainless steel extension hopper
•500 lb. (226 Kg) stainless steel extension hopper
•Air clutch in lieu of manual clutch
•Right hand controls
•Oil mist collector systems
•Quick change wire assembly
•Tool kit
•Spare parts kit
MODEL K DIVIDER HEAD
Specifications
Options
Design
Drawing
left hand shown,
with 250 lb. hopper
Mechanical
Features
•New precision-machined steel hopper with
maximum low-friction design
•Solid stainless steel drum (no wrap)
•Brass vacuum and pressure shoes
•Static body one-piece pistons with removable brass
caps
•Obround piston shaft
•Precision segment gear assembly
•Bronze bearings
•Front drip and rear spray oilers
•Heavy duty, shock-absorbing manual clutch
•Stainless steel rear cover with Schmersal key safety
interlock
•Pneumatic gauges on vacuum shoes
POM Proofer
Vertical
Section
For more information please call
your Account Manager or 1-800-BAKERS-1.
Headquarters
AMF Bakery Systems
2115 West Laburnum Avenue
Richmond, Virginia 23227
1-800-225-3771 or 804-355-7961
FAX: [phone]
www.amfbakery.com [e-mail]
European operation
West Park Ring Road
Leeds LS16 6QQ England
Tel.: [phone]
Fax: [phone]
06/2001
AMF’s continuing engineering is constantly improving product performance. Consequently machinery specifications are subject to change without notice.
