AMG AMG5801-DF User manual

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 1 of 8
AMG5801-DF Instruction Sheet
D22213-00.doc
AMG5801-DF
Instruction Manual
100BASE-TX Ethernet Media Converter Transmit Unit for a
Multimode Dual Fibre Link
The AMG5801-DF is a standalone Ethernet Media Converter transmit unit designed to provide
100BASE-TX full duplex Ethernet connectivity over two Multimode fibres.
The AMG5801-DF is designed to be powered using an AMG2001 standalone power supply.
The AMG5801-DF is designed to operate with an AMG5802-DF standalone or AMG5802R-DF
rackmount Ethernet data receive unit in a point to point configuration.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 2 of 8
AMG5801-DF Instruction Sheet
D22213-00.doc
Contents
Introduction 3
Unit Functional Schematic.................................................................................................................. 3
Optical Connection ............................................................................................................................. 3
Connections 4
Optical Connection Multimode............................................................................................................ 4
Power Connection .............................................................................................................................. 4
Ethernet Connection........................................................................................................................... 4
Front Panel Indicators 5
Power LED.......................................................................................................................................... 5
Ethernet Data LEDs............................................................................................................................ 5
Ethernet Operation 6
Physical Information 7
Dimensions......................................................................................................................................... 7
Mounting Details................................................................................................................................. 7
Safety 7
Maintenance and Repair 7

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 3 of 8
AMG5801-DF Instruction Sheet
D22213-00.doc
Introduction
Unit Functional Schematic
The AMG5801-DF transmits Ethernet data
to the AMG5802R-DF receive unit.
It also receives Ethernet data transmitted
from the AMG5802R-DF.
Optical Connection
The AMG5801-DF connections are illustrated in the following example which shows an AMG5801-DF
standalone Media Converter transmit unit together with an AMG5802R-DF rackmount Media
Converter receive unit configured as a point to point system.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 4 of 8
AMG5801-DF Instruction Sheet
D22213-00.doc
Connections
Optical Connection Multimode
Optical Fibres.......................................Multimode 50/125 or 62.5/125**
Connectors ..........................................SC/PC
Minimum Optical Launch Power..........-15dBm
Transmit Wavelength...........................1310nm
Minimum Optical Sensitivity.................-34dBm
Receive Wavelength............................1310nm
Minimum Optical Dynamic Range .......19dB.
**Note : the maximum transmission distance is 2km. This is limited by the bandwidth of the Multimode
optical fibres.
Power Connection
Connector Type...................................Removable 2-pin, 3.81mm, Screw Terminal
Connector Partno.................................Phoenix 1803578
Supply Voltage.....................................+12 to +15 Volts DC
Maximum Power..................................5 Watts
Ethernet Connection
Ethernet Data Connector ....................RJ45
Interface...............................................Auto MDI/MDIX 100BASE-TX
Ethernet Data Rate..............................Maximum 100Mb/s full duplex

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 5 of 8
AMG5801-DF Instruction Sheet
D22213-00.doc
Front Panel Indicators
Power LED
POWER...............................................Green - Power is present
Off - Power is not present
VIDEO ...............................................Off - Not used
OPTO TX.............................................Green - Tx opto. present
Off - Tx opto. is not present
OPTO RX ............................................Green - Rx opto. sync.
Off - Rx opto. is not sync.
Ethernet Data LEDs
Link not Present ..................................Yellow - Link not present
Off - Link is present
Link Integrity........................................Green - Link integrity is good, Idle state
GBlink - Data transfer
Off - Link not present

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 6 of 8
AMG5801-DF Instruction Sheet
D22213-00.doc
Ethernet Operation
The Ethernet interface supports "Auto-Negotiation" and will operate at either 10Mbits/s half duplex or
100Mbit/s full duplex. Data is transmitted from one port the other port with minimum delay or buffering.
The port also implements "Auto MDI/MDIX" i.e. it may be connected with aeither a straight-though or
cross-over cable to an appropriate device such as external switch, PC or other DCE/DTE.
Two LED indicators are provided adjacent to the RJ-45 port: Green indicates Link / Data transfer and
Yellow when in half-duplex mode.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 7 of 8
AMG5801-DF Instruction Sheet
D22213-00.doc
Physical Information
Dimensions
Height..................................................112mm
Width ...................................................170mm (excluding connectors)
Depth...................................................35mm
Weight .................................................1000grams
Mounting Details
The AMG unit is supplied with a clip-on mounting bracket which should be attached to a panel or wall
using 2 off 4.0mm screws, see diagram on page 1 for dimensions. The unit is clipped into the
mounting bracket, and is then held firmly in position.
Safety
AMG Optical Fibre Products use Class 1 laser systems in accordance with EN 60825-2:2000.
It is always advisable to follow good practice when working with optical fibre systems. This includes:
Do not stare with unprotected eyes or with any unapproved collimating device at fibre
ends or connector faces, or point them at other people.
Use only approved filtered or attenuating viewing aids
For other safety issues and advice on good practice associated with optical fibre systems, please see
EN 60825-2:2000 or your local safety officer.
Maintenance and Repair
There are no user serviceable parts within AMG products. See unit data sheet for full specification.
In case of problem or failure, please call your local support centre or contact: AMG Systems Ltd. at
3 The Omega Centre, Stratton Business Park, Biggleswade, Beds., SG18 8QB, UK.
Phone [phone]
Technical Support [phone]
Email [e-mail]
