AMG4783BxE-SF
Instruction Manual
8 Channel Video Transmit Unit with up to 2 Bi-directional
Data and Audio Channels plus Ethernet for a Singlemode
Fibre Link
The AMG4783BxE-SF is a standalone eight channel video transmit unit designed to transmit 8 video
signals and transmit and receive up to 2 data or audio signals plus full duplex 100BaseT Ethernet
connectivity over one Singlemode optical fibre.
The AMG4783BxE-SF is designed to be powered using an AMG2003 standalone power supply.
The AMG4783BxE-SF is designed to operate with AMG4784BxE-SF or rackmount equivalent
AMG4784BxER-SF eight channel video receive unit in a point to point configuration.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 2 of 12 AMG4783BxE-SF Instruction Sheet
D18967-00.doc
Contents
Introduction 3
Unit Functional Schematic .................................................................................................................. 3
Optical Connection ............................................................................................................................. 3
Connections 4
Video Input Connections .................................................................................................................... 4
Optical Connections ........................................................................................................................... 4
Power Connection .............................................................................................................................. 4
Ethernet Connection ........................................................................................................................... 4
Data and Audio Channel Connections ............................................................................................... 4
Front Panel Indicators 5
Power LED.......................................................................................................................................... 5
Video Input LED’s ............................................................................................................................... 5
Fibre Optic LED’s ............................................................................................................................... 5
Low Speed Data LEDs ....................................................................................................................... 5
Ethernet Operation 7
Data and Audio Channel Configuration 8
Data and Audio Channel Configuration .............................................................................................. 8
Data Interface Connections Channel A .............................................................................................. 8
Data Channel A Configuration ............................................................................................................ 8
Data / Audio Channel B Configuration ............................................................................................... 9
Data Interface Daughter Board Options ............................................................................................. 9
Audio / Data Interface Connections RJ45 - Channel B ...................................................................... 9
Physical Information 10
Dimensions ....................................................................................................................................... 10
Mounting Details ............................................................................................................................... 10
Removal / replacement from / to the Case ....................................................................................... 10
Safety 10
Maintenance and Repair 10

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 3 of 12 AMG4783BxE-SF Instruction Sheet
D18967-00.doc
Introduction
Unit Functional Schematic
The
AMG4783BxE-SF
transmits up to 8
video and 2 data signals to the
AMG4784BxE-SF.
It also receives 2 data signal transmitted
from the AMG4784BxE-SF.
Ethernet connectivity is also provided
between the two units.
Optical Connection
The AMG4783BxER-SF is connected as illustrated below when used with an AMG4784BxER-SF 8-
channel receive unit acting as a point to point system.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 4 of 12 AMG4783BxE-SF Instruction Sheet
D18967-00.doc
Connections
Video Input Connections
No. of channels .................................... 8
Connector ............................................ 75 ohm BNC Socket.
Input Impedance .................................. 75 ohm terminated.
Input Level ........................................... 1 volt p-p nominal
Frequency Response ........................... 10Hz to 7MHz.
Optical Connections
PRIMARY OPTO OUT
Connector ............................................ LC/PC
Optical Fibre ........................................ One fibre - Singlemode
Primary Optical Launch Power ............ -5dBm
Wavelength .......................................... 1510nm
Primary Optical Sensitivity ................... -22dBm
Wavelength .......................................... 1310nm
Power Connection
Connector Type ................................... 2.1mm screw lock long power jack – centre positive
Connector Partno. ................................ Switchcraft S761K, AMG G16125-00
Supply Voltage ..................................... 13.5 to 18.0 Volts DC.
Maximum Power ................................. 10 Watts
Ethernet Connection
Ethernet Data Connector .................... RJ45
Interface ............................................... Auto-negotiation up to 100BASE-TX full duplex
Ethernet Data Rate .............................. Maximum 50Mbits/s total Ethernet traffic on fibre
Data and Audio Channel Connections
Total No. of Data Channels ................. 2 channels
DATA CHANNEL A
Data Connector .................................... RJ45
Channel A Interface On Board Data Interface – RS232, RS422 or RS485. Selected by slide switch
above the RJ45 connector.
RS232 – switch position - high (closest to BNC connections)
RS422 – switch position – middle
RS485 – switch position – low (furthest from BNC connections)
DATA CHANNEL B
Data Connector .................................... RJ45
Channel B Interface ............................. Defined by data/audio interface daughter board fitted into Slot 1
on main board and indicated by the 'x' in the AMG partno.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 5 of 12 AMG4783BxE-SF Instruction Sheet
D18967-00.doc
Front Panel Indicators
Power LED
Power .................................................. Green - unit powered
Off - no power applied to unit
Video Input LED’s
Video Present CH1-8 .......................... Green - video signal present on input BNC
R/G - channel present but no video on I/P BNC
Fibre Optic LED’s
Primary Opto Sync TX ......................... Green - optical channel transmitting
Off - optical channel not transmitting
Primary Opto Sync RX ........................ Green - optical channel receiving
Org - optical channel receiving but not sync.
Off - optical channel not transmitting
Low Speed Data LEDs
Channel A
Data Present TX (RS485 or RS422) ... Green - logic zero (+V, -V) present on IN+, IN-
Red - logic one (-V,V+) present on IN+, IN-
Off - tri-state off or no connection on IN+, IN-
Data Present TX (RS232) ................... Green - logic zero (+V) present on input IN+
Red - logic transitions present on input IN+
Off - logic one (-V) present on input IN+
This represents the data signals being transmitted on the optical fibre
Data Present RX (RS485 or RS422) ... Green - logic zero (+V,-V) present on OUT+, OUT-
Red - logic one (-V,+V) present on OUT+, OUT-
Off - tri-state off or no connection on OUT+, OUT-
Data Present RX (RS232) ................... Green - logic zero (+V) present on OUT+
Red - logic transitions present on OUT+
Off - logic one (-V) present on OUT+
This represents the data signals being received on the optical fibre
Channel B (When RS232 data daughter board fitted)
Data Present TX .................................. Green - logic zero (+V) present on IN+
Red - logic transitions present on IN+
Off - logic one (-V) present on IN+
This represents the data signals being transmitted on the optical fibre
Data Present RX.................................. Green - logic zero (+V) present on OUT+
Red - logic transitions present on OUT+
Off - logic one (-V) present on OUT+
This represents the data signals being received on the optical fibre

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 6 of 12 AMG4783BxE-SF Instruction Sheet
D18967-00.doc
Channel B (When RS485 / RS422 data daughter board fitted)
Data Present TX .................................. Green - logic zero (+V, -V) present on IN+, IN-
Red - logic transitions present on IN+, IN-
Off - logic one (-V, +V) present on IN+, IN-
This represents the data signals being transmitted on the optical fibre
Data Present RX .................................. Green - logic zero (+V, -V) present on OUT+, OUT-
Red - logic transitions present on OUT+, OUT-
Off - logic one (-V , +V) present on OUT+, OUT-
This represents the data signals being received on the optical fibre
Channel B (When audio daughter board fitted)
Audio Present TX ................................. Green - audio present > -40dBm
Red - audio present > 0dBm (overload at +6dBm)
Off - audio not present or < -40dBm
This represents the audio signals being transmitted on the optical fibre
Audio Present RX ................................ Green - audio present > -40dBm
Red - audio present > 0dBm (overload at +6dBm)
Off - audio not present or < -40dBm
This represents the audio signals being received from the optical fibre.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 7 of 12 AMG4783BxE-SF Instruction Sheet
D18967-00.doc
Ethernet Operation
In order for the AMG system to transmit Ethernet signals, an onboard RJ45 Ethernet interface or
X16003 Ethernet interface adaptor should be fitted to both the Transmit unit and the Receive unit.
The Ethernet interface can operate at either 10Mbits/s half duplex, or 100Mbit/s full duplex, and data is
transmitted from one port the other port with the minimum of delay or buffering. The maximum
bandwidth (at 100Mbit/s full duplex) available for transmission across the fibre link is nominally
50MBit/s.
The 100BaseT port does not implement MDI/MDIX; it should be connected with a straight though
cable to an external switch port and with a cross over cable when connected directly to a PC or DTE.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 8 of 12 AMG4783BxE-SF Instruction Sheet
D18967-00.doc
Data and Audio Channel Configuration
Data and Audio Channel Configuration
The AMG4783BxE-SF and rackmount equivalent AMG4783BxER-SF sends and receives data
to/from Channel A and Channel B. Channel A is a single data interface selectable by the user with the
slide switch on the rear panel. Channel B carries a second channel of data / audio, the function and
physical interface being determined by the type of daughter board fitted to the B Channel data slot.
Data Interface Connections Channel A
RJ45 Pin
No.
Channel A
Cat 5/6 Cable
Colour Code T568B
RS485
[switch low]
RS422 [switch
mid]
RS232
[switch high]
1
IN + (A) GND
White/orange
2
IN - (B) IN
Orange
3
White/green
4
Blue
5
White/blue
6
Green
7
IN/OUT + (A) OUT + (A) N/A
White/brown
8
IN/OUT - (B) OUT - (B) OUT
Brown
Note: (A) or (B) in brackets in above table refers to RS485 / RS422 data specification, not Channel A,
Channel B.
Data Channel A Configuration
Channel A is always present and allows for a RS232, RS422 (full duplex, four wire) or RS485 (half
duplex, two wire) interface depending on the position of the switch located above the RJ45 connector.
The switch signifies the presence of the X16004 Low Speed Data/Audio Interface Board. If there are
LED's present on the RJ45 connector then an X16003 Ethernet Interface Board is fitted.
The data input for both the RS485 and the RS422 modes detects a tri-state input condition by
monitoring the differential voltage level across the input. A differential level below 600mV positive or
negative will be detected as a tri-state condition. A level above 600mV positive or negative will be
detected as a logic 1 or logic zero respectively. It is important therefore to terminate the RS485 bus or
the RS422 input bus using 120Ω if a pre-bias is present on the RS485 or RS422 bus.
A large number of third party equipment manufacturers apply a pre-bias on their RS485 bus. This pre-
bias is applied by pulling one arm of the RS485 bus high (+5 volts) and the other arm low (0 volts)
using high value resistors within the third party equipment. In order to ensure that the AMG equipment
detects a tri-state condition, then these resistors should have a value above 5kΩ. If the third party
bias resistors are less the 750Ω the bus can be double or triple terminated as required to ensure that a
tri-state level is detected.
Note: The Data Channel A is shipped from the factory set up for RS485 operation unless otherwise
requested.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 9 of 12 AMG4783BxE-SF Instruction Sheet
D18967-00.doc
Data / Audio Channel B Configuration
Data Channel B is operational when fitted with the appropriate daughter board.
Data Interface Daughter Board Options
The data interface daughter board options are as follows:
Option Code
'x'
Part No.
Description
0 X12542 4 Wire Audio Interface Daughter Board
1 X04057 RS422/485 Data Interface Daughter Board
2 X04049 RS232 Data Interface Daughter Board
3 X04058 20mA Current Loop Data Interface Daughter Board
4 X12579 TTL Data Interface Daughter Board
5 X12578 Contact Closure Data Interface Daughter Board
6 X13038 FTT10A Echelon Lonworks Data Interface Daughter Board
Audio / Data Interface Connections RJ45 - Channel B
RJ45 Channel B low speed data/audio interface connections:
RJ45 Pin
No.
Channel B
Cat 5/6 Cable
Colour Code T568B
Data / Audio
Daughter Board
1
White/orange
2
Orange
3
OUT + (A)
White/green
4
IN - (B)
Blue
5
IN + (A)
White/blue
6
OUT - (B)
Green
7
White/brown
8
Brown
Note: (A) or (B) in brackets in above table refers to RS485 / RS422 data specification, not Channel A,
Channel B.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 10 of 12 AMG4783BxE-SF Instruction Sheet
D18967-00.doc
Physical Information
Dimensions
Height................................................... 112mm
Width .................................................... 170mm (excluding connectors)
Depth ................................................... 70mm
Weight .................................................. 1000grams
Mounting Details
The AMG unit is supplied with a clip-on mounting bracket which should be attached to a panel or wall
using 2 off 4.0mm screws, see diagram on page 1 for dimensions. The unit is clipped into the
mounting bracket, and is then held firmly in position.
Removal / replacement from / to the Case
Note: - The AMG unit PCB's are static sensitive. Handle with proper care and use normal electrostatic
discharge (ESD) procedures. Use properly grounded protection (for example, wrist straps) when
handling the PCB.
To remove units from the case to access the data expansion boards and the daughter boards, remove
the 2 or 4 fixing screws on the rear panel and slide the PCB's out of the case.
Ensure that the fibres do not snag or get trapped.
To replace the PCB's into the case, slide the PCB's gently into the case aligning the boards with the
appropriate slots. Ensure that the fibre do not snag or get trapped.
Safety
AMG Optical Fibre Products use Class 1 laser systems in accordance with EN 60825-2:2000.
It is always advisable to follow good practice when working with optical fibre systems. This includes:
 Do not stare with unprotected eyes or with any unapproved collimating device at fibre
ends or connector faces, or point them at other people.
 Use only approved filtered or attenuating viewing aids
For other safety issues and advice on good practice associated with optical fibre systems, please see
EN 60825-2:2000 or your local safety officer.
Maintenance and Repair
There are no user serviceable parts within AMG products. See unit data sheet for full specification.
In case of problem or failure, please call your local support centre or contact: AMG Systems Ltd. at
3 The Omega Centre, Stratton Business Park, Biggleswade, Beds., SG18 8QB, UK.
Phone [phone]
Technical Support [phone]
Email [e-mail]

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 11 of 12 AMG4783BxE-SF Instruction Sheet
D18967-00.doc
This page is intentionally blank.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 12 of 12 AMG4783BxE-SF Instruction Sheet
D18967-00.doc
This page is intentionally blank.
