AMG4787BER-SF
Instruction Manual
8 Channel Video Transmit Unit with 9 Bi-directional Data
and Audio Channels plus Ethernet for a Singlemode Single
Fibre Link
The AMG4787BER-SF is a rackmount eight channel video transmit unit designed to transmit 8 video
signals and transmit and receive up to 9 data or audio signals plus full duplex 100BaseT Ethernet
connectivity over one Singlemode fibre. The 9 data/audio channel interfaces, whether RS232, RS422,
RS485, 20mA, TTL, Contact Closure, Lonworks or Audio, are defined at manufacture by the addition
of daughter boards fitted onto the Data Expansion Board B.
The AMG4787BER-SF is designed to plug into an AMG2009 or AMG2015 subrack, which in turn fits
into a 19" rack system.
The AMG4787BER-SF is designed to operate with AMG4788BEN-SF or rackmount equivalent
AMG4788BERN-SF eight channel video receive unit in a point to point configuration.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 2 of 12 AMG4787BER-SF Instruction Sheet
D18314-00.doc
Contents
Introduction 3
Unit Functional Schematic.................................................................................................................. 3
Optical Connection ............................................................................................................................. 3
Connections 4
Video Input Connections .................................................................................................................... 4
Optical Connections ........................................................................................................................... 4
Power Connection .............................................................................................................................. 4
Ethernet Connection........................................................................................................................... 4
Data and Audio Channel Connections ............................................................................................... 4
Data and Audio Channel Configuration 5
Data and Audio Channels................................................................................................................... 5
Data Channel A Configuration............................................................................................................ 5
Data Interface Connections Channel A .............................................................................................. 5
Bank B Data........................................................................................................................................ 6
Data Interface Daughter Board Options ............................................................................................. 6
Data and Audio Channel Configuration.............................................................................................. 6
Daughter Board Layout ...................................................................................................................... 6
Data and Audio Daughter Board Fitting Instruction............................................................................ 6
Data and Audio Connections Bank B ................................................................................................. 7
Ethernet Operation 8
Front Panel Indicators 9
Power LED.......................................................................................................................................... 9
Video Input LED’s............................................................................................................................... 9
Fibre Optic LED’s ............................................................................................................................... 9
Low Speed Data LEDs ....................................................................................................................... 9
Physical Information 11
Dimensions ....................................................................................................................................... 11
Mounting Details............................................................................................................................... 11
Removal / replacement from / to the Case....................................................................................... 11
Safety 11
Maintenance and Repair 11

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 3 of 12 AMG4787BER-SF Instruction Sheet
D18314-00.doc
Introduction
Unit Functional Schematic
The AMG4787BER-SF transmits up to 8
video and 9 data signals to the
AMG4788BEN-SF.
It also receives 9 data signal transmitted
from the AMG4788BEN-SF.
Ethernet connectivity is also provided
between the two units.
Optical Connection
The AMG4787BER-SF is connected as illustrated below when used with an AMG4788BERN-SF 8-
channel receive unit acting as a point to point system.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 4 of 12 AMG4787BER-SF Instruction Sheet
D18314-00.doc
Connections
Video Input Connections
No. of channels....................................8
Connector ............................................75 ohm BNC Socket.
Input Impedance ..................................75 ohm terminated.
Input Level ...........................................1 volt p-p nominal
Frequency Response...........................10Hz to 7MHz.
Optical Connections
PRIMARY OPTO OUT
Connector ............................................LC/PC
Optical Fibre ........................................One fibre - Singlemode
Primary Optical Launch Power ............-5dBm
Wavelength..........................................1310nm
Primary Optical Sensitivity ...................-22dBm
Wavelength..........................................1310nm
Power Connection
Power supply .......................................from plug in connection on the AMG2009 / AMG2015 subrack
Power consumption .............................10 Watts max.
Ethernet Connection
Ethernet Data Connector ....................RJ45
Interface ...............................................Auto-negotiation up to 100BASE-TX full duplex
Ethernet Data Rate ..............................Maximum 50Mbits/s total Ethernet traffic on fibre
Data and Audio Channel Connections
Total No. of Data Channels .................9 channels
DATA CHANNEL A
Data Channel A ...................................1 channel
Data Connector....................................RJ45
Channel A Interface On Board Data Interface – RS232, RS422 or RS485. Selected by slide switch
below RJ45 connector.
RS232 – switch position - high (closest to BNC connections)
RS422 – switch position – middle
RS485 – switch position – low (furthest from BNC connections)
DATA BANK B
Data/Audio Channels – BANK A .........Not Used
Data/Audio Channels – BANK B .........8 channels
Connector ............................................37-way D-Type female connector - shielded.
Connections.........................................See appropriate section for connection and configuration details
For the data or audio channels to be present, appropriate data daughter boards must be fitted onto the
data expansion board slots.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 5 of 12 AMG4787BER-SF Instruction Sheet
D18314-00.doc
Data and Audio Channel Configuration
Data and Audio Channels
The AMG4787BE-SF and rackmount equivalent AMG4787BER-SF sends and receives data to/from
Channel A and Bank B. Channel A is a single data interface selectable by the user with the slide
switch on the rear panel. Bank B carries up to 8 channels of data / audio, the physical interface of
which is determined by fitment of AMG data or audio daughter boards onto the B Channel data
expansion board slots.
Data Channel A Configuration
Channel A is always present and allows for a RS232, RS422 (full duplex, four wire) or RS485 (half
duplex, two wire) interface depending on the position of the switch located above the RJ45 connector.
The switch signifies the presence of the X16004 Low Speed Data/Audio Interface Board. If there are
LED's present on the RJ45 connector then an X16003 Ethernet Interface Board is fitted.
The data input for both the RS485 and the RS422 modes detects a tri-state input condition by
monitoring the differential voltage level across the input. A differential level below 600mV positive or
negative will be detected as a tri-state condition. A level above 600mV positive or negative will be
detected as a logic 1 or logic zero respectively. It is important therefore to terminate the RS485 bus or
the RS422 input bus using 120Ω if a pre-bias is present on the RS485 or RS422 bus.
A large number of third party equipment manufacturers apply a pre-bias on their RS485 bus. This pre-
bias is applied by pulling one arm of the RS485 bus high (+5 volts) and the other arm low (0 volts)
using high value resistors within the third party equipment. In order to ensure that the AMG equipment
detects a tri-state condition, then these resistors should have a value above 5kΩ. If the third party
bias resistors are less the 750Ω the bus can be double or triple terminated as required to ensure that a
tri-state level is detected.
Note: The Data Channel A is shipped from the factory set up for RS485 operation unless otherwise
requested.
Data Interface Connections Channel A
Channel A
RJ45 Pin
No. RS485
[switch low]
RS422 [switch
mid]
RS232
[switch high]
Cat 5/6 Cable
Colour Code T568B
1IN + (A) GND White/orange
2IN - (B) IN Orange
3 White/green
4 Blue
5 White/blue
6 Green
7IN/OUT + (A) OUT + (A) N/A White/brown
8IN/OUT - (B) OUT - (B) OUT Brown
Note: (A) or (B) in brackets in above table refers to RS485 / RS422 data specification, not Channel A,
Channel B.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 6 of 12 AMG4787BER-SF Instruction Sheet
D18314-00.doc
Bank B Data
Data Bank B channels are operational when fitted with appropriate daughter boards.
Data Interface Daughter Board Options
The data interface daughter board options are as follows:
Option Code
'x'
Part No. Description
0 X12542 4 Wire Audio Interface Daughter Board
1 X04057 RS422/485 Data Interface Daughter Board
2 X04049 RS232 Data Interface Daughter Board
3 X04058 20mA Current Loop Data Interface Daughter Board
4 X12579 TTL Data Interface Daughter Board
5 X12578 Contact Closure Data Interface Daughter Board
6 X13038 FTT10A Echelon Lonworks Data Interface Daughter Board
Data and Audio Channel Configuration
The data expansion board slots are accessed by removing the AMG unit from its case. A data channel
is active when a daughter board is installed in the required data channel slot. Each data interface
board enables one bi-directional channel.
Daughter Board Layout
The channel slots are as follows:
Data and Audio Daughter Board Fitting Instruction
The data and audio daughter boards pushed on to the pin headers mounted on the data expansion
boards. Ensure that the connectors are lined up correctly and not offset before pushing firmly in place.
Note that the data and audio channel numbers are associated with each slot. This allocates the pin
numbers on the rear panel connector together with the front panel LED indicators.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 7 of 12 AMG4787BER-SF Instruction Sheet
D18314-00.doc
Data and Audio Connections Bank B
The BANK B data/audio channels pin connections on the rear panel connectors are as follows:
Pin
No.
Description Bank Pin
No.
Description Bank
1 Audio/Data CH1 IN + (A) B 20 Audio/Data CH1 OUT + (A) B
2 Audio/Data CH1 IN - (B) B 21 Audio/Data CH1 OUT - (B) B
3 Audio/Data CH2 IN + (A) B 22 Audio/Data CH2 OUT + (A) B
4 Audio/Data CH2 IN - (B) B 23 Audio/Data CH2 OUT - (B) B
5 Audio/Data CH3 IN + (A) B 24 Audio/Data CH3 OUT + (A) B
6 Audio/Data CH3 IN - (B) B 25 Audio/Data CH3 OUT - (B) B
7 Audio/Data CH4 IN + (A) B 26 Audio/Data CH4 OUT + (A) B
8 Audio/Data CH4 IN - (B) B 27 Audio/Data CH4 OUT - (B) B
9 GND B 28 GND B
10 GND B 29 GND B
11 GND B 30 Audio/Data CH5 OUT + (A) B
12 Audio/Data CH5 IN + (A) B 31 Audio/Data CH5 OUT - (B) B
13 Audio/Data CH5 IN - (B) B 32 Audio/Data CH6 OUT + (A) B
14 Audio/Data CH6 IN + (A) B 33 Audio/Data CH6 OUT - (B) B
15 Audio/Data CH6 IN - (B) B 34 Audio/Data CH7 OUT + (A) B
16 Audio/Data CH7 IN + (A) B 35 Audio/Data CH7 OUT - (B) B
17 Audio/Data CH7 IN - (B) B 36 Audio/Data CH8 OUT + (A) B
18 Audio/Data CH8 IN + (A) B 37 Audio/Data CH8 OUT - (B) B
19 Audio/Data CH8 IN - (B) B
Note: (A) or (B) in brackets in above table refers to RS485/RS422 data specification not Bank A, B.
See Data or Audio Daughter Board Instruction Sheet for meaning of Audio/Data IN+, Audio/Data IN-
Audio/Data OUT+, and Audio/Data OUT- for each data type.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 8 of 12 AMG4787BER-SF Instruction Sheet
D18314-00.doc
Ethernet Operation
In order for the AMG system to transmit Ethernet signals, an onboard RJ45 Ethernet interface or
X16003 Ethernet interface adaptor should be fitted to both the Transmit unit and the Receive unit.
The Ethernet interface can operate at either 10Mbits/s half duplex, or 100Mbit/s full duplex, and data is
transmitted from one port the other port with the minimum of delay or buffering. The maximum
bandwidth (at 100Mbit/s full duplex) available for transmission across the fibre link is nominally
50MBit/s.
The 100BaseT port does not implement MDI/MDIX; it should be connected with a straight though
cable to an external switch port and with a cross over cable when connected directly to a PC or DTE.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 9 of 12 AMG4787BER-SF Instruction Sheet
D18314-00.doc
Front Panel Indicators
Power LED
Power .................................................. Green - unit powered
Off - no power applied to unit
Video Input LED’s
Video Present CH1-8 .......................... Green - video signal present on input BNC
R/G - channel present but no video on I/P BNC
Fibre Optic LED’s
Primary Opto Sync TX.........................Green - optical channel transmitting
Off - optical channel not transmitting
Primary Opto Sync RX ........................ Green - optical channel receiving
Org - optical channel receiving but not sync.
Off - optical channel not transmitting
Low Speed Data LEDs
Channel A
Data Present TX (RS485 or RS422) ... Green - logic zero (+V, -V) present on IN+, IN-
Red - logic one (-V,V+) present on IN+, IN-
Off - tri-state off or no connection on IN+, IN-
Data Present TX (RS232) ................... Green - logic zero (+V) present on input IN+
Red - logic transitions present on input IN+
Off - logic one (-V) present on input IN+
This represents the data signals being transmitted on the optical fibre
Data Present RX (RS485 or RS422)... Green - logic zero (+V,-V) present on OUT+, OUT-
Red - logic one (-V,+V) present on OUT+, OUT-
Off - tri-state off or no connection on OUT+, OUT-
Data Present RX (RS232) ................... Green - logic zero (+V) present on OUT+
Red - logic transitions present on OUT+
Off - logic one (-V) present on OUT+
This represents the data signals being received on the optical fibre
BANK B (When RS232 data daughter board fitted)
Data Present CH1-8 TX ...................... Green - logic zero (+V) present on IN+
Red - logic transitions present on IN+
Off - logic one (-V) present on IN+
This represents the data signals being transmitted on the optical fibre
Data Present CH1-8 RX ...................... Green - logic zero (+V) present on OUT+
Red - logic transitions present on OUT+
Off - logic one (-V) present on OUT+
This represents the data signals being received on the optical fibre

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 10 of 12 AMG4787BER-SF Instruction Sheet
D18314-00.doc
BANK B (When RS485 / RS422 data daughter board fitted)
Data Present CH1-8 TX.......................Green - logic zero (+V, -V) present on IN+, IN-
Red - logic transitions present on IN+, IN-
Off - logic one (-V, +V) present on IN+, IN-
This represents the data signals being transmitted on the optical fibre
Data Present CH1-8 RX ......................Green - logic zero (+V, -V) present on OUT+, OUT-
Red - logic transitions present on OUT+, OUT-
Off - logic one (-V , +V) present on OUT+, OUT-
This represents the data signals being received on the optical fibre
BANK B (When audio daughter board fitted)
Audio Present CH1-8 TX .....................Green - audio present > -40dBm
Red - audio present > 0dBm (overload at +6dBm)
Off - audio not present or < -40dBm
This represents the audio signals being transmitted on the optical fibre
Audio Present CH1-8 RX.....................Green - audio present > -40dBm
Red - audio present > 0dBm (overload at +6dBm)
Off - audio not present or < -40dBm
This represents the audio signals being received from the optical fibre.

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 11 of 12 AMG4787BER-SF Instruction Sheet
D18314-00.doc
Physical Information
Dimensions
Height .................................................. 3U Plug-in
Width ................................................... 21HP
Depth ................................................... 170mm excluding connectors
Weight ................................................. 1200grams
Mounting Details
The unit is designed to be mounted within an AMG2009 or AMG2015 Subrack on standard card
guides.
Removal / replacement from / to the Case
Note: - The AMG unit PCB's are static sensitive. Handle with proper care and use normal electrostatic
discharge (ESD) procedures. Use properly grounded protection (for example, wrist straps) when
handling the PCB.
To remove units from the case to access the data expansion boards and the daughter boards, remove
the 2 or 4 fixing screws on the rear panel and slide the PCB's out of the case.
Ensure that the fibres do not snag or get trapped.
To replace the PCB's into the case, slide the PCB's gently into the case aligning the boards with the
appropriate slots. Ensure that the fibre do not snag or get trapped.
Safety
AMG Optical Fibre Products use Class 1 laser systems in accordance with EN 60825-2:2000.
It is always advisable to follow good practice when working with optical fibre systems. This includes:
Do not stare with unprotected eyes or with any unapproved collimating device at fibre
ends or connector faces, or point them at other people.
Use only approved filtered or attenuating viewing aids
For other safety issues and advice on good practice associated with optical fibre systems, please see
EN 60825-2:2000 or your local safety officer.
Maintenance and Repair
There are no user serviceable parts within AMG products. See unit data sheet for full specification.
In case of problem or failure, please call your local support centre or contact: AMG Systems Ltd. at
3 The Omega Centre, Stratton Business Park, Biggleswade, Beds., SG18 8QB, UK.
Phone [phone]
Technical Support [phone]
Email [e-mail]

AMG Systems Ltd. reserves the right to make changes to this
document without notice. The information herein is believed to
be accurate. No responsibility is assumed by AMG for its use.
Page 12 of 12 AMG4787BER-SF Instruction Sheet
D18314-00.doc
This page is intentionally blank.
