AMG 770-416 User manual

Padded
Bathtub
Transfer Bench
770-416
Instruction Manual

Please read carefully before use
• Examine the product for shipping damage. Do not use the
product if there is apparent damage. Please contact your
dealer for repair and / or return information.
• Verify that all screws and bolts are tightly secured.
Assembly instructions
1.Snap the armrest into position, making sure the side
buttons pass through armrest holes.
Fig. 1

2.Determine on which side of the unit you want to install the
backrest. Make sure the unit will be facing the faucets with
the armrest on the inside of the bathtub (See Fig. 1)
3.To install the seat and backrest assembly, place the front
seat z-clamps under the front frame support tube. Lower
the seat back and snap the back seat white clips into place.
4.Adjust the unit to the desired height by pressing in the leg
push-button and sliding the leg upward or downward until
the button snaps into desired hole.
NOTE:
The transfer bench should be level. It is therefore possible
that the legs inside the bathtub may be adjusted to a height
different from the legs outside the bathtub.
5.Place the transfer bench as shown in Fig. 1. The inner legs
should be as close to the far wall of the tub as possible.
6.To remove the seat and backrest assembly from the unit,
lift the back portion of the seat while holding the frame
firmly in place. This will disengage the rear seat clips from
the frame tube.

CAUTION:
When lifting the seat off the frame, always pull the metal
tube and not the seat / backrest pads.
User safety instructions
1.Make sure all the push buttons are popped out and fully
engaged in selected holes.
2.Before using the transfer bench, always test for stability.
3.Weight limit is 350 lbs (158 kg ).

REV. 1.0 0703
Maintenance
1.We recommend that you regularly verify that all bolts and
screws are properly tightened.
2.Clean the pads with soap and water or mild liquid
householder cleaners. Avoid the use of harsh cleaning
solvents, such as acetone, which may attack the plastic
parts.
3.If a mechanical defect appears, do not attempt to use the
unit. Contact your dealer for repair.
