Kit Core Upgrade-EMB-B75B Without Modem
Kit #22166905
These instructions outline the procedures to install the EMB-B75B motherboard
into your existing Computer Core Chassis. There may be unused parts in this kit
depending on the style of Core being upgraded.
Tools Required
1/4” and 11/32” nut driver, #2 Philips Screw driver
Parts Included with this Kit:
Item # Part Number Description Quantity
1 40924214 Computer Board Assy EMB-B75B 1
2 22219001 SATA Hard Drive U.S. 1
3 40980801 Bracket Hard Drive Tray Replacement 1
4 40980802 Bracket SATA Mounting Adapter 1
5 22144401 Cover Computer Card (Not Shown) 1
6 34072201 Cover PSI Low Profile (Not Shown) 1
7 34052405 Power On/Reset CBA 1
8 22132276 Cable Assembly ON/Reset 1
9 34037946 Harness Assembly ATX Power 1
10 22132277 Cable Assembly DB9 1
11 EC0358-01 Cable SATA Data 1
12 EC0359-01 Harness SATA Power 1
13 21889250 DB9 Hardware (Not Shown) 1
14 80402304 #6-32 x ¼” Phillips (Not Shown) 4
15 80351604 #4-40 x ¼” Phillips (Not Shown) 4
16 28277901 M3 x 6 Phillips (Not Shown) 4
17 70800106 Tie Wrap (Not Shown) 2
18 22190901 Bracket Mounting (Hard Drive) 1
These Instructions
NOTE: If you are installing this kit into a Blue View Core Computer assembly, you will need to
order one additional harness. Order part number 22132280.
Installation Instructions

Page 2 of 12
22166955
REV. C
Figure 1
3
2
1
4
7
8
9
10
11
12
18

Page 3 of 12
22166955
REV. C
Caution: When installing this EMB-B75B motherboard, care should be taken to avoid
static discharges that can damage the motherboard. The motherboard installation should
be done on a static dissipative mat along with a grounding wrist strap.
Removing the Motherboard and ON/OFF reset board
1. Turn the jukebox off and unplug the power cord from the wall outlet.
2. Open the jukebox door and disconnect all the harnessing to the Computer Core. Note where
the cables plug into the Computer Core Assembly for later reinstallation. Remove the
Computer Core from the jukebox.
3. Rowe has six major Computer Cores as shown in Figure 2. Each Core has slightly different
variations (fans, lights, etc.) depending on your jukebox model. It is important to note these
variations and ensure they are connected after the motherboard installation.
Figure 2
4. Remove all necessary components and covers to access the motherboard. Unplug and remove
all ribbon cables from the motherboard. Disconnect all of the ATX power supply connections
and the IDE Cable from the hard drive. Remove the modem card and its PCI cover (if
present) from the motherboard; they will not be reused. Replacement PCI Covers (Items #5
and #6) are provided in this kit.
5. Remove the old ON/OFF reset board (340524XX) and the DB9 cable assembly from its
mounting bracket; they will not be reused. Save the mounting bracket and hardware for later
use.
6. Remove the seven screws that secure the motherboard to the core chassis. The motherboard
and the front panel will not be reused; save the screws for later use.

Page 4 of 12
22166955
REV. C
Installing the EMB-B75B Motherboard and 34052405 ON/OFF reset board
7. Insert the front panel into position and carefully align the new motherboard (Item #1) with
the four existing studs on the computer core chassis. Secure the motherboard with four of the
seven screws removed in step #6.
8. Mount the ON/OFF reset board 34052405 (Item #7) and the DB9 Cable Assembly 22132277
(Item #10) and its hardware (Item #13) to your previously removed mounting bracket and
reinstall into your Computer Core. Connect the ON/RESET cable 22132276 (Item #8) into
the keyed 10-pin header of the ON/RESET circuit board assembly. Refer to Figure 3.
9. Figure 3 shows all the electrical connections to your new motherboard. Connect the two
ribbon cables as shown in Figure 3. Connect the 20-pin connector to the 24-pin housing on
the motherboard. If your ATX power supply does not have the 4-pin connector, use the ATX
Power Harness 34037946 (Item #9) provided with this kit. If you have a chassis fan, connect
it to a spare 4-pin connector of the ATX power supply. Refer to Figure 3.
Figure 3
20-PIN ATX POWER
SUPPLY
CONNECTION
DB9 SERIAL CABLE 22132277
Note: FOR BLUE VIEW CORE
USE SERIAL CABLE 22132280
(not included in this kit)
SATA/POWER
CONNECTION
EC0359-01
SATA/DATA
CONNECTIONS
EC0358-01
ON/RESET CABLE
CONNECTIONS
22132276
4-PIN ATX
POWER
SUPPLY
CONNECTION

Page 5 of 12
22166955
REV. C
Assembling the SATA Hard Drive with the Adapter Mounting Bracket
10. Secure the SATA hard drive 22219001 (Item #2) to the SATA Mounting Adapter Bracket
40980802 (Item #4) using the four M3 x 6 metric screws 28277901 (Item #16) as shown in
Figure 4.
Figure 4
The following pages describe installing the hard drive in the different computer core models.
Continue to the step # relating to the core you are reworking.
221674XX Step 11
611765XX Step 14
61171001 Step 15
61171002 Step 16
70260-1A Step 17
View Core Step 18
Connecting the SATA Hard Drive to the 221674XX Series Computer Core
11. Disconnect the 4-pin power cable and IDE cable from the hard drive tray. Remove the four
screws that mount the hard drive tray. The tray will not be reused, but you must save the
screws for use in the following step. See Figure 4.
Figure 5
HARD
DRIVE
M3X6 METRIC
SCREWS
(TWO ON
EITHER SIDE)
ADAPTOR
BRACKET
REMOVE
POWER AND
IDE CABLES
REMOVE THE
SCREWS TWO
ON EITHER
SIDE

Page 6 of 12
22166955
REV. C
12. Mount the replacement Hard Drive Tray Bracket 40980801 (Item #3) on the inside cover of
your computer core using the four screws previously removed. Ensure the bracket properly
covers the front opening. Thread the four 6-32 x ¼” screws 80402304 (Item #14) into the
mounting adapter leaving approximately 1/16-inch gap. Insert the screw heads through the
four keyholes on the hard drive tray replacement bracket and slide the hard drive down to
secure it into the slots. Tighten the four screws. See Figure 6.
13. Connect the SATA/Power Cable EC0359-01 (Item #12) to a 4-pin connector of the ATX
power supply. Connect the SATA/Data Cable EC0358-01 (Item #11) to the motherboard.
Refer to Figure 3 for motherboard connections. Continue with step #19.
Figure 6
HARD DRIVE
REPLACEMENT
TRAY
FOUR
KEYHOLES
SATA/POWER
22132253 SATA/DATA
CABLE
22132252

Page 7 of 12
22166955
REV. C
Connecting the SATA Hard Drive to the 611765XX Series Computer Core.
14. Disconnect the power and IDE Cables from the hard drive. Loosen the thumbscrew and
remove the hard drive from the housing; it will not be reused. Insert the hard drive adapter
bracket and hard drive assembled in step #10 into the housing and secure with the four
fasteners. Reassemble the housing to the computer core and connect the SATA/Power Cable
EC0359-01 (Item #12) to a 4-pin connector of the ATX power supply. Connect the
SATA/Data Cable EC0358-01 (Item #11) to the motherboard. Refer to Figure 3 for
motherboard connections. Continue with step #19.
Figure 7
SATA/DATA
AND
SATA/POWER
ASSEMBLED
HARD DRIVE
ATX POWER
SUPPLY
CONNECTION

Page 8 of 12
22166955
REV. C
Connecting the SATA Hard Drive to the 61171001 Computer Core
15. Disconnect the power and IDE Cables from the hard drive. Loosen the four screws and
remove the hard drive and bracket, it will not be reused. Attach the hard drive adapter bracket
and hard drive (assembled in step #10) to the new Hard Drive Mounting Bracket 22190901
(Item #18) by aligning it with the slots and securing it with four screws 80402304 (Item #14).
Connect the SATA/Power Cable EC0359-01 (Item #12) to a 4-pin connector of the ATX
power supply. Connect the SATA/Data Cable EC0358-01 (Item #11) to the motherboard
(refer to Figure 3). Connect the SATA Data and SATA Power cables to the hard drive as
shown in Figure 8. Attach the hard drive assembly to the computer core. Refer to Figure 3 for
motherboard connections. Reassemble the remaining components to the computer core.
Continue with step #19.
Figure 8
SATA/DATA
AND
SATA/POWER
HARD
DRIVE
ASSEMBLY
HARD DRIVE
MOUNTING
BRACKET
ATX
POWER
SUPPLY

Page 9 of 12
22166955
REV. C
Connecting the SATA Hard Drive to the 61171002 Computer Core
16. Disconnect the power and IDE Cables from the hard drive. Remove the two thumbscrews
and the two hard drive brackets from the hard drive (the hard drive will not be reused).
Attach these two brackets to the hard drive adapter bracket and hard drive assembled in step
#10 and secure with the same four screws. Reassemble the hard drive assembly to the
computer core. Connect the SATA/Power Cable EC0359-01 (Item #12) to a 4-pin connector
of the ATX power supply. Connect the SATA/Data Cable EC0358-01 (Item #11) to the
motherboard. Refer to Figure 3 for motherboard connections. Continue with step #19.
Figure 9
SATA/DATA
AND POWER
CONNECTIONS
ATX
POWER
SUPPLY

Page 10 of 12
22166955
REV. C
Connecting the SATA Hard Drive to the 70260-1A Series Rock-Ola Computer
Core
17. Disconnect the power and IDE Cables from the hard drive. Remove the four thumbscrews
from the hard drive (the hard drive will not be reused). Install the four thumbscrews into the
adapter bracket and hard drive assembled in step #10. Reassemble the hard drive assembly to
the Computer Core as shown in Figure 10. Connect the SATA/Power Cable EC0359-01
(Item #12) to a 4-pin connector of the ATX power supply. Connect the SATA/Data Cable
EC0358-01 (Item #11) to the motherboard. Refer to Figure 3 for the motherboard
connections. Continue with step #19.
Figure 10
HARD
DRIVE
ASSEMBLY
SATA/DATA
AND POWER
CONNECTIONS

Page 11 of 12
22166955
REV. C
Connecting the SATA Hard Drive to the Modified View Computer Core
18. Disconnect the power and IDE Cables from the hard drive. Remove the four screws that
mount the hard drive (the hard drive will not be reused). Install the adapter bracket and hard
drive assembled in step #10. Reassemble the hard drive assembly to the Computer Core as
shown in Figure 11. Connect the SATA/Power Cable EC0359-01 (Item #12) to a 4-pin
connector of the ATX power supply. Connect the SATA/Data Cable EC0358-01 (Item #11)
to the motherboard. Refer to Figure 3 for the motherboard connections.
Figure 11
19. Reinstall the modified Computer Core into the jukebox and reconnect all cables removed in
step #2. Take a moment to visually inspect the jukebox to ensure proper connections before
powering up the jukebox. Plug the jukebox back into the wall outlet and turn the jukebox on.
Follow the on-screen instructions and load your choice of music. Check for proper jukebox
operation such as sound, money collection and proper credit and pricing. This concludes the
Kit installation.
SATA/DATA
AND POWER
CONNECTIONS
HARD
DRIVE
ASSEMBLY
