INSTRUCTION MANUAL
BUILT-IN ELECTRIC OVEN
IOAK-1719 / 8048867
(10.2010./1)
1143.4TfYDbOQVJXSp

2
DEAR CUSTOMER,
The oven is exceptionally easy to use and extremely efcient. After reading the instruction
manual, operating the oven will be easy.
Before being packaged and leaving the manufacturer, the oven was thoroughly checked with
regard to safety and functionality.
Before using the appliance, please read the instruction manual carefully.
By following these instructions carefully you will be able to avoid any problems in using the
appliance.
It is important to keep the instruction manual and store it in a safe place so that it can be
consulted at any time.
It is necessary to follow the instructions in the manual carefully in order to avoid possible
accidents.
Caution!
Do not use the oven until you have read this instruction manual.
The oven is intended for household use only.
The manufacturer reserves the right to introduce changes which do not affect the
operation of the appliance.

3
TABLE OF CONTENTS
Safety instructions ............................................................................................................. 4
Description of the appliance ............................................................................................. 7
Installation........................................................................................................................... 9
Operation............................................................................................................................11
Baking in the oven – practical hints ............................................................................... 27
Cleaning and maintenance.............................................................................................. 29
Technical data................................................................................................................... 33

4
SAFETY INSTRUCTIONS
The appliance becomes hot during operation. Take care not to touch the hot parts
inside the oven.
Always keep children away from the oven.
While in operation direct contact with the oven may cause burns!
Ensure that small items of household equipment, including connection leads, do
not touch the hot oven as the insulation material of this equipment is usually not
resistant to high temperatures.
 Donotleavetheovenunattendedwhenfrying.Oilsandfatsmaycatchredue
to overheating or boiling over.
Do not put pans weighing over 15 kg on the opened door of the oven.
Do not use harsh cleaning agents or sharp metal objects to clean the door as they
can scratch the surface, which could then result in the glass cracking.
 Donotusetheovenintheeventofatechnicalfault.Anyfaultsmustbexedby
anappropriatelyqualiedandauthorisedperson.
In the event of any incident caused by a technical fault, disconnect the power and
report the fault to the service centre to be repaired.
The rules and provisions contained in this instruction manual should be strictly
observed. Do not allow anybody who is not familiar with the contents of this instruc-
tion manual to operate the oven.
This appliance is not intended for use by persons (including children) with reduced
physical,sensoryormentalcapabilities,orlackofexperienceandknowledge,
unless they have been given supervision or instruction concerning use of the ap-
pliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appli-
ance.
The oven should not be cleaned using steam cleaning equipment.

5
Using energy in a respon-
sible way not only saves
money but also helps the
environment. So let’s save
energy! And this is how you
can do it:
Do not uncover the pan too often
(a watched pot never boils!).
Do not open the oven door unnecessarily
often.
 Only use the oven when cooking larger
dishes.
Meat of up to 1 kg can be prepared more
economically in a pan on the cooker hob.
Make use of residual heat from the
oven.
If the cooking time is greater than 40 minutes
switch off the oven 10 minutes before the
end time.
Important! When using the timer,
set appropriately shorter cooking
times according to the dish being
prepared.

Make sure the oven door is properly
closed.
Heat can leak through spillages on the door
seals. Clean up any spillages immediately.
Do not install the cooker in the direct
vicinity of refrigerators/freezers.
Otherwise energy consumption increases
unnecessarily.
HOW TO SAVE ENERGY

6
During transportation, protec-
tive packaging was used to
protect the appliance against
any damage. After unpack-
ing, please dispose of all
elements of packaging in a
way that will not cause dam-
age to the environment.
All materials used for packaging the appli-
ance are environmentally friendly; they are
100% recyclable and are marked with the
appropriate symbol.
Caution! During unpacking, the packag-
ing materials (polythene bags, polystyrene
pieces, etc.) should be kept out of reach of
children.
UNPACKING DISPOSAL OF THE APPLIANCE
Old appliances should not sim-
ply be disposed of with normal
household waste, but should
be delivered to a collection and
recycling centre for electric and
electronic equipment. A symbol
shown on the product, the
instruction manual or the packaging shows
that it is suitable for recycling.
Materials used inside the appliance are
recyclable and are labelled with information
concerning this. By recycling materials or
other parts from used devices you are making
asignicantcontributiontotheprotectionof
our environment.
Information on appropriate disposal centres
for used devices can be provided by your
local authority.

7
DESCRIPTION OF THE APPLIANCE
Oven door
handle
Electronic pro-
grammer
Setting selection sensor eld
Setting selection sensor eld
Conrmation sensor led
Time setting sensor eld
Stand by / menu sensor eld
Temperature selection sensor
eld

8
SPECIFICATIONS OF THE APPLIANCE
Cookerttings:
Baking tray Grill grate
(drying rack)
Roasting tray
Fork and rotisserie frame
Side
racks
Telescopic
runners*
*optional

9
Installing the oven
The kitchen area should be dry and aired
andequipped withefcientventillation.
When installing the oven, easy access to
all control elements should be ensured.
This is a Y–type design built–in oven,
which means that its back wall and one
sidewall canbeplaced nextto ahigh
piece of furniture or a wall. Coating or
veneerusedonttedfurnituremustbe
applied with a heat–resistant adhesive
(100°C). This prevents surface deforma-
tion or detachment of the coating.
Hoods should be installed according to
the manufacturer’s instructions.
Make an opening with the dimensions
given in the diagram for the oven to be
tted.
Make sure the mains plug is disconnected
and then connect the oven to the mains
supply.
Insert the oven completely into the open-
ing without allowing the four screws in the
places shown in the diagram to fall out.
INSTALLATION

10
2
1
230V 1N~
INSTALLATION
Electrical connection
Warning: This appliance must be earthed.
The appliance must be installed by a com-
petent electrician using a double pole control
unit of 16 ampere minimum capacity with
3mm minimum contact separation at all
poles.
We recommend that the appliance is con-
nectedbyaqualiedelectricianwhoismem-
ber of the N.C.E.I.C. and who will comply with
the I.E.E. and local regulation.
Access to the main terminal is gained by
opening the terminal block cover at the
rear of the appliance (use a small at-
bladed screwdriver).
Connection shuld be made with 1,5mm2
twin and earth cable.
First strip the wires, then push the cab-
lethrough the cable clamp in the terminal
block cover.
Connect the cable to the terminal block
and tighten the cable clamp screw (see
diagram).
 Closetheterminalbox,ensuringthatthe
cover is engaged on the locking tabs.
Live
(Red or Brown)
Neutral
(Black or Blue)
Earth
(Green/Yellow
or sleeving)
Cable clamp

11
OPERATION
Before using the appliance for
the rst time
●Remove packaging, clean the interior of
the oven,
● Takeoutandwashtheoventtingswith
warm water and a little washing-up liquid,
●Switch on the ventilation in the room or
open a window,
●Heat up the oven (to a temperature of
250°Cfor approximately30minutes),
remove any stains and wash the interior
carefully. (see section: Electronic pro-
grammer operation and oven control)
Important!
To clean the oven, only use a cloth
well wrung out with warm water to
which a little washing-up liquid has
been added.
Note!
Before using an oven whose type
containstheletter„O”checkttingof
the heating element in the oven’s side
chamber walls. If the heating element
isnotcorrectlytted,liftitandinsert
into the grooves in the chamber’s
side walls.
Important!
Oven is equipped with a programmer
withdisplaycontrolledbysixsensor
eldslocatedsymmetricallyonboth
sides of the display. To activate each
sensoreld,touchtheglassabovethe
sensor (indicated by a pictogram). An
acoustic signal will be heard, which
was selected in the menu. (See sec-
tion: Electronic programmer operation
and oven control.)
Sensor eld surfaces must be kept
clean.

12
OPERATION
Function symbols
Electronic programmer operation and
oven control
- time setting sensor
-eld
- temperature
-selectionsensoreld
-standby/menusensoreld
-settingselectionsensoreld
- power cut-off
- temperature adjustment
- end time
- cook time
- Child Lock
Sensor eld functions

13
OPERATION
Switching on the appliance and selecting
language.
After connecting the appliance to the mains,
electronic programmer starts in menu: setup
/ language.
Using the sensor fields search the
contents of the language menu. Touch
sensoreldtoselectthehighlightedlangu-
age in which you want the messages to be
displayed.
When mains power is cut and restored (loss
of power), electronic programmer automa-
tically goes into standby and immediately
displays the current time.
Set current time.
Oncelanguageisselected,conrmthetime
displayed on the display using the sen-
soreldorchangeitusingthe sensor
elds.
Time can be set in the range from 0:00 to
23:59 for 24-hour clock system or from 0:00
to 12:00 for the 12-hour clock system.
When current time is set, electronic program-
mer goes into standby mode in which the
display shows the current time only.
To activate the appliance from standby and
set current time, touch the sensoreld.
When menu is displayed, select “setup” using
the sensoreldsandconrmbytouch-
ing . Upon accessing the “time” menu using
the sensorelds,select“currenttime”
andconrmbytouching .

14
OPERATION
Menu \ Setup
Touch sensoreldtoenterthemenu.Use
sensoreldstoselectthe“setup”menu
andconrmtheselectionbytouching .
The following setup menu items are avail-
able:
- language,
- time
- lighting,
- sound,
- themes,
- brightness,
- service,
- factory settings,
-exit.
Menu
Touch . to activate the appliance from
standby. Use sensoreldstonavigate
the menu.
The following main menu items are avail-
able:
- setup,
- heating functions,
- preset programmes,
- user programmes,
- cleaning,
-exit.
Touch  sensor eldto select anymenu
item.
If no changes are made within 60 seconds,
the appliance enters standby mode. To im-
mediatelyexitfromthemenuandswitchthe
appliancetostandbymode,selecttheexit
icon and touch .toconrm.Toimmediately
exitfromthemenuandswitchtheappliance
to standby mode simultaneously touch
sensoreldand .
Use .sensoreldstonavigatethemenu.
Touch to select the chosen item.
Toexitfromthesetupmenu,selectexitand
touch toconrm.Toimmediatelyexitfrom
the setup menu and switch the appliance to
standby mode simultaneously touch
sensoreldand .
Menu \ Setup \ Language
Select the required language using the
sensoreldsandconrmselectionbytouch-
ing .
The following language menu items are
available:
- Deutsch,
- English,
- Polski,
-Пopyccки,
-Česky,
- Srbski,
- Lietuviškai,
- Eesti,
- Latviski,
- Français,
- Español,
- Türkçe,
- Svenska,
- Norsk,
- Suomi,
- Dansk,
- Italiano,
-Exit,

15
OPERATION
For details on how to select language, please
refer to section Switching on the appliance
and selecting language.
To exit fromthe language menuto setup
menu,selectexitusingthe navigation
sensoreldsandtouch toconrm.
Toimmediatelyexitfromthelanguagemenu
to setup menu and then to main menu touch
sensoreldand .
Menu \ Setup \ Time
Select the time menu using the sensor
eldsandconrmselectionbytouching
The following time menu items are avail-
able:
- current time,
- kitchen timer,
- clock type,
- time format,
-exit.
Usethenavigationsensorelds to se-
lect one of the menu items above and touch
sensoreldtoconrm.
Menu \ Setup \ Time \ Current Time
For details on how to set current time, please
refer to section Setting current time.
Setting cook time (for a heating func-
tion)
Once heating function is selected, touch
sensoreld.When ,startstoashonthe
display,nearbox1displayingthetempera-
ture,box2willappeardisplayingCOOKTIME
and the time display shows “0:00”.
The display before setting cook time or cook
timeandendtime-box2isinactive.
The display showing cook time for cook time
andendtime-box2isactive
If no change in setting is made within 5
seconds the display will show target and cur-
renttemperature,box2willbedeactivated
and .
symbolwillstopashing.
Touch navigationsensorelds toset
cook time in 1 minute steps. Cook time is
stored after 5 seconds or after touching
sensoreld.
21
12

16
OPERATION
COOKTIMEchangestoENDTIMEinbox
2.Entered cooktime,for example0:30,
changes to the actual end time, while the
remaining time is displayed on the red bar
below the actual end time .
symbol is displayed continuously. Once
cook time has elapsed, an acoustic signal
is sounded (2 beeps / pause / 2 beeps). The
sequence is repeated every 3 seconds for
about a minute, symbolisashing.
Touch to acknowledge and mute the
acoustic signal. After this, the appliance
switches to standby mode.
Setting Cook Time and End Time (for a
heating function)
For details on how to set Cook Time,
please refer to the preceding paragraph.
Setting End Time.
When is displayed continuously, touch
sensoreldagain.While symbol continues
to be displayed, ,symbolsstartsashing
and End Time is shown on the display.
If no change in setting is made within 5 sec-
onds, the appliance will return to previous
settings of cook time and the selected heating
function. Touch navigationsensorelds
to set cook time in 1 minute steps.
Cook time is stored after 5 seconds or after
touching sensoreld.
COOKTIMEchangestoSTARTTIMEinbox
2. Entered cook time changes to the actual
start time, while the time remaining to start
time is displayed on the red bar below the
actual start time , symbol is displayed con-
tinuously, while symbolisextinguished.If
no changes are made within 60 seconds, the
appliance enters standby mode. When any
sensoreldistouched,theapplianceisacti-
vated and the display shows last settings.
Appliance operation in selected mode
When the current time is reaches start time,
the appliance will start the selected heating
function. START TIME changes to END TIME
inbox2.Thedisplayshowsendtimeandthe
time remaining to end time is displayed on
the red bar below the actual end time. When
cook time countdown begins the , symbol
isextinguishedand symbol illuminates.
12

17
OPERATION
Once cook time has elapsed, an acoustic
signal is sounded (4 beeps / pause / 4 beeps).
The sequence is repeated every 3 seconds
for about a minute symbolisashing.
Touch to acknowledge and mute the
acoustic signal. The appliance switches to
standby mode.
Menu \ Setup \ Time \ Timer
Afterconrmingtheselectionofkitchentimer
with the appliance displays the time in the
format: 00:00.
If no changes are made within 5 seconds, the
appliance enters standby mode.
Touchnavigationsensoreldstosetkitchen
timer time in 1 minute steps. Counting down
starts after 5 seconds or after touching
sensoreld.
Once set time has elapsed, an acoustic sig-
nal is sounded (2 beeps / pause / 2 beeps).
The sequence is repeated and 00:00 is
displayed.
Touch to acknowledge and mute the
acoustic signal. After this, the appliance
switches to standby mode.
Menu \ Setup \ Time \ Clock type
Select clock type menu and touch The
following items will be available:
- Standard
- digital,
- analogue
Select the clock type using the sensor
eldsandconrmselectionbytouching .
The selection is stored by the appliance and
upper level menu is automatically displayed.
The selected clock will now appear in the
upper right corner of the display and during
standby.
Menu \ Setup \ Time \ Time Format
Select Time Format menu and touch The
following items will be available
- 24h,
- AM / PM.
Select the time format using the sen-
soreldsandconrmselectionbytouching
. The selection is stored by the appliance
and upper level menu is automatically dis-
played.
This option is only available for a standard
and digital clock.

18
OPERATION
Menu \ Setup \ Lighting
Select Lighting menu and touch , The fol-
lowing items will be available:
- continuous,
- intermittent.
Select the oven chamber lighting option using
the sensoreldsandconrmselection
by touching . The selection is stored by the
appliance and upper level menu is automati-
cally displayed.
Continuous
When continuous lighting is selected, light
will be on continuously during a programme
(heating function) or when oven door is
opened.
Intermittent
When intermittent lighting is selected, light
will be on for 30 seconds from starting a
programme (heating function) and then light
isturnedoff.Touchanysensoreldtoturn
the light back on during oven operation. Light
will be turned off again after 30 seconds of
touchingthesensoreld.Whenovendoor
is opened, light is turned on for as long as
the oven door is open, but no longer than 10
minutes, after which the light is turned off.
Menu \ Setup \ Sound
Select Sound menu and touch , The fol-
lowing items will be available:
- Tone_1
- Tone_2
- Tone_3
- silent (this applies to keys, not the alarm)
Select the sound option using the sen-
soreldsandconrmselectionbytouching
.
The selection is stored by the appliance
and upper level menu is automatically dis-
played.
Menu \ Setup \ Themes
Select Themes menu and touch , The fol-
lowing items will be available:
- Theme_1
- Theme_2
- Theme_3
Select the theme option using the sen-
soreldsandconrmselectionbytouching
.
The selection is stored by the appliance
and upper level menu is automatically dis-
played.

19
OPERATION
Menu \ Setup \ Brightness
Select Brightness menu and touch , The
following screen will be displayed:
Touch navigationsensoreldstoadjust
display brightness within 0-100% range in 1%
steps. Touch to store the selected display
brightness level. The selection is stored by
the appliance and upper level menu is auto-
matically displayed.
Menu \ Setup \ Service
Select Service menu and touch , The fol-
lowing screen will be displayed:
If the appliance detects an error, its code will
be displayed as shown above.
If E1 error is detected by the appliance, meat
temperature probe can’t be used. If an at-
tempt is made to select a programme where
the meat probe is used, the appliance will
display service screen showing E1 error and
its brief description. You can continue to use
the appliance on the programs do not require
meat probe. Touch to acknowledge service
screen and go to main menu.
Ifnosensoreldistouchedwithin10seconds
when E1 error service screen is displayed, the
appliance will automatically go into standby.
Menu \ Setup \ Factory Settings
Select Factory Settings menu and touch ,
The following screen will be displayed:
Touch navigationsensoreldstoselect
whether to restore the factory settings or
leave the current settings. To keep current
settings,select“No”andconrmbytouching
sensoreld.Theappliancegoestoupper
menu level.
To restore factory settings select “Yes” and
conrmbytouching sensoreld.Thefac-
tory settings will be restored.

20
OPERATION
Menu \ Heating Functions
Select the Heating Functions menu using the
sensoreldsandconrmselectionby
touching .
The following heating functions are avail-
able:
- conventional,
- cake,
- turnspit *,
- grill,
- turbo grill,
- super grill,
- fan cooking,
- pizza,
- browning,
- roasting,
- defrosting,
- super spit *.
Overview of functions, oven elements to implement them and the range of possible tempera-
ture settings and default settings.
* for models equipped with turnspit
No. Function
Description
Oven elements Temperature Default
tempera-
ture
Oven
level
min.max.
1Conventional, bottom heater + top heater 30 280 180 3
2Cake, bottom heater + top heater + fan 30 280 170 3
3Turnspit grill + turnspit 30 280 280 -
4Grill grill 30 280 280 4
5Turbo grill grill + fan 30 280 200 2
6Super grill grill + top heater 30 280 280 4
7Fan cooking fan heater + fan 30 280 170 3
8Pizza fan heater + bottom heater + fan 30 280 220 2
9Browning top heater 30 230 180 -
10 Raosting, bottom heater 30 240 200 -
11 Defrosting fan 30 - - 3
12 Super spit grill+ top heater + turnspit 30 280 280 -
