AML TRITON SVC-EW7500 User manual

Getting StartedGetting Started Getting Started
Front View Back View
Getting Started
Top and Bottom Views
800.648.4452
www.amltd.com
01032014
Get Updates from AML
Don’t forget to register your product(s)
online at www.amltd.com/register to
receive updates about AML products
and software.
Learn more about the Triton at:
www.amltd.com/triton
or
Give us a call at
800.648.4452
1Load the main battery 2Charge the Triton for
at least 4 hours 3Using the Integrated
Barcode Scan Engine 4Learn More about
the AML Trition
1. 2.
3. 4.
Turn the access latch
counter-clockwise
Remove the battery
door by hinging it upward
Turn the access
latch clockwise
Insert battery in rear and slide
towards the front to engage
1
2
Charging Port
& RS-232
USB Port
Bottom
Top
LCD
Scan Key
Backlight Key
Power Key
Scan Engine
Window
Laser Safety
Label
Battery
Door
Battery Latch
Wireless Terminal
Quick-Start Guide
Battery Charge Times
Before Initial Use = 4 hours
For Full Charge = 6 hours
5V DC
Power Jack
Scan Button
Laser - The laser scan
engines require proper
alignment of the bar code
under the scanner window.
2D Imager - Capable of
scanning bar codes at any
orientation as long as the
entire symbol is visible to the
scanner and illuminated.
Scan Engine
Window
Scan Trigger

Switch Menu to Text-ModeSwitch Menu to Graphical-Mode Accessories
Setup a Wireless Connection Setup a Wireless Connection
Setup a Host Setting Power Management
