B&D TRI-TRAN HANDSET CODING INSTRUCTIONS
Storing the Transmitter Code
1. Ensure that the battery is inserted into the transmitter.
2. Press the CODE SET button and release.
The CODE SET LED will illuminate to indicate the opener
is in Code Learn mode. If a valid code is not stored within
15 seconds the opener will exit Code Learn
3. Press the transmitter button (one of four) that you want
to control the door. The CODE SET LED will begin to flash.
4. Press the same transmitter button again. The CODE SET
LED will illuminate for one second and then go out.
The transmitter is now coded to operate the door –press the
button to test.
Setting the Transmitter to Operate the
Courtesy Light
Although the courtesy light comes on with each operation of the
opener, it may also be controlled by a transmitter without
operating the door.
1. Press the CODE SET button twice. The CODE SET LED will
illuminate and the courtesy light will turn on to indicate
that the light code learning is active
2. Choose a transmitter button not already coded into the
receiver. Press this button and the CODE SET LED will
begin to flash.
3. Press the same transmitter button again. The CODE SET
LED will illuminate for one second and then go out.
The transmitter is now coded to operate the light –press the
button to test.


: 07 3290 4444 : 6/5-15 Lapis St, Underwood : [e-mail]
: 07 3290 1614 ABN: 55 147 545 195 : www.ammodoors.com.au
Setting the Transmitter to Operate
Vacation Mode
The opener can be programmed into a “Vacation Mode” where
the opener will not respond to any transmitter except one
pre-programmed unit.
1. Press CODE SET button three times. The CODE SET LED
will illuminate and the courtesy light will flash slowly
(once every two seconds) to indicate Vacation learning
mode is active.
2. Choose a transmitter button not already coded into the
receiver. Press this button and the CODE SET LED will
begin to flash.
3. Press the same transmitter button again. The CODE SET
LED will illuminate for one second and then go out, and
the courtesy light will also switch off. This indicates the
code has been stored
To activate Vacation Mode, close the garage door and press the coded button on the transmitter for 5
seconds. The CODE SET LED will illuminate and beep x 2 to indicate that the opener is in Vacation Mode.
To exit Vacation Mode press the transmitter button momentarily until the CODE SET LED turns off and
beeps x 1.
Setting the Transmitter to Operate the
Auxiliary Output
It is possible to operate other devices (e.g. alarm systems) using
one of the spare buttons of a multi-channel transmitter coded
into the Auxiliary Output feature.
1. Press CODE SET button four times. The CODE SET LED
will illuminate and the courtesy light will flash quickly
(twice per second) to indicate that learning mode for
the Auxiliary Output is active.
2. Choose a transmitter button not already coded into the
receiver. Press this button and the CODE SET LED will
begin to flash.
3. Press the same transmitter button again. The CODE SET
LED will illuminate for one second and then go out, and
the courtesy light will also switch off. This indicates the
code has been stored


: 07 3290 4444 : 6/5-15 Lapis St, Underwood : [e-mail]
: 07 3290 1614 ABN: 55 147 545 195 : www.ammodoors.com.au
Setting the Transmitter to Operate Pet
(Pedestrian) Mode
The opener can be programmed into a “Pet Mode” where the
door opens partially to allow pets to enter/exit the garage:
1. Press the CODE SET button five times, the CODE SET
LED will illuminate and the courtesy light will flash
quickly (twice per second) to indicate learning mode
for Pet Mode is active.
2. Choose a transmitter button not already coded into
the receiver. Press this button and the CODE SET LED
will begin to flash.
3. Press the same transmitter button again. The CODE
SET LED will illuminate for one second and then go
out, and the courtesy light will also switch off. This
indicates the code has been stored.
To Erase Programmed Codes
If the CODE SET button is pressed and held for 6 seconds
the CODE SET LED will blink rapidly for one second to
indicate that all programmed codes have been erased.
