amnimo AG10 User manual

Edge Gateway
Getting Started Guide
IM AMD03A03-01EN 8th Edition

Table of Contents 2
Table of Contents
Table of Contents........................................................................................................................2
Introduction..................................................................................................................................4
Safety Precautions......................................................................................................................5
About Edge Gateway ..................................................................................................................6
Note on Edge Gateway ............................................................................................................. 6
About This Book ..........................................................................................................................7
Notes on this document ........................................................................................................... 7
Manual List ................................................................................................................................ 7
Icons and symbols used in this manual ................................................................................. 8
Confirmation of Packaged Goods.............................................................................................9
Edge Gateway Set ..................................................................................................................... 9
What you need to prepare .......................................................................................................10
Accessories we sell (sold separately) .................................................................................. 10
What you need to prepare....................................................................................................... 10
Overall system diagram............................................................................................................11
Step 1 Activate/connect..........................................................................................................12
For Indoor Type Edge Gateway ............................................................................................. 12
For Outdoor Type Edge Gateway .......................................................................................... 14
Step 2 Sign in to the Edge Gateway......................................................................................17
Change the IP address of the PC.......................................................................................... 17
First sign in............................................................................................................................... 22
Sign in ............................................................................................................................................22
Step 3 Configure the Edge Gateway settings ......................................................................24
Configure simple settings ...................................................................................................... 24
Set the time.............................................................................................................................. 32
Set the time zone.........................................................................................................................32
Set the time ..................................................................................................................................33
Configure SSH settings .......................................................................................................... 37
Configure PPP settings. ......................................................................................................... 40
Configure storage settings..................................................................................................... 42
Save settings in the gateway................................................................................................. 44

Table of Contents 3
Frequently Asked Questions ...................................................................................................46
Option Setting Guide ................................................................................................................48
Connecting to a network camera............................................................................................49
Configure VMS settings ...........................................................................................................50
Install the desktop client........................................................................................................ 50
Connecting to a Media Server ............................................................................................... 52
Configure initial system settings..............................................................................................52
Connect to the configured system ...........................................................................................54
Check the device .........................................................................................................................56
Save VMS settings .................................................................................................................. 59
Save Nx Witness password and settings................................................................................59
Configure the integrated video management system..........................................................61
Enable Edge Gateway ............................................................................................................. 62
Configure authentication information for VMS................................................................... 64
Detecting cameras .................................................................................................................. 65
Configure the device management system...........................................................................67
Enable Edge Gateway ............................................................................................................. 68
Configure remote.it settings....................................................................................................70
Create a remote.it account .................................................................................................... 71
Configure remote.it settings .................................................................................................. 72
Connecting to services using remote.it................................................................................ 79
Licenses and Trademarks........................................................................................................82
License...................................................................................................................................... 82
trademark ................................................................................................................................. 82
Revision History.........................................................................................................................83

Introduction 4
Introduction
Thank you very much for adopting our amnimo Edge Gateway ("Edge Gateway").
The Edge Gateway Startup Guide ("this document") describes how to set up the Edge Gateway. Please be sure
to read it before using the Edge Gateway.
After completing the setup, keep this manual in a place where it can be found at all times.

Safety Precautions 5
Safety Precautions
Before using the Edge Gateway, please read the "Before Using" document included with the Edge Gateway to
ensure safe and proper handling.

About Edge Gateway 6
About Edge Gateway
Note on Edge Gateway
Edge Gateway does not guarantee backward compatibility of product versions with respect to
configuration data.

About This Book 7
About This Book
Notes on this document
The contents of this document are subject to change without notice.
Reproduction or reprinting of the contents of this document, in whole or in part, without permission is
prohibited.
While every effort has been made to ensure the accuracy of the information contained in this document,
if you have any questions or find any errors, please contact our customer support.
Contact: amnimo Customer Support
E-mail: [e-mail]
URL: https://support.amnimo.com/
Please note that revisions may not be made for specification changes, structural changes, or changes in
parts used that are not considered to be particularly detrimental to functionality/performance.
Manual List
amnimo G series Edge Gateway user's manual
https://amnimo.com/manual/edge_gw/ja/edge_gw_users_manual.pdf
amnimo Gateway series GUI User's Manual
https://amnimo.com/manual/edge_gw/gui/en/gui_users_manual.pdf
amnimo Gateway series CLI User's Manual
https://amnimo.com/manual/edge_gw/cli/en/cli_users_manual.pdf
Nx Witness VMS Guide
https://amnimo.com/manual/edge_gw/vms/ja/index.htm
Device Management System Manual
https://amnimo.com/manual/edge_gw/alpine/dms/en/index.htm
Enhanced Video Management System Manual
https://amnimo.com/manual/edge_gw/evms/en/index.htm
Edge Gateway Startup Guide (this document)
https://amnimo.com/manual/edge_gw/sg/en/edge_gw_sg.pdf

About This Book 8
Icons and symbols used in this manual
Icons and symbols in this manual have the following meanings
Information of special note regarding functions and operation.
Supplemental information regarding functions and operation is provided.

This section contains references to information within this document and to other documents.
Indicates that the command can be operated in general user mode.
Indicates that the command can be operated in administrator mode.
Indicates that the command can be operated in setting mode.

Confirmation of Packaged Goods 9
Confirmation of Packaged Goods
First, please make sure that all packing materials are present.
Edge Gateway Set
Indoor Type Edge Gateway
Indoor Type Edge Gateway

Indoor type Edge Gateway main unit x 1

Outdoor type Edge Gateway main unit x 1

Before use x 1

Before use x 1

Rubber feet x 4

Grommet (main unit device) x 2

Cable ties (for fixing cables) x 2

What you need to prepare 10
What you need to prepare
When configured as described in this manual, the following optional accessories must be provided.
Optional items are not included in the Edge Gateway's warranty coverage.
Accessories we sell (sold separately)
Please refer to “amnimo G Series Edge Gateway User's Manual” for specifications and standards.
Indoor Type Edge Gateway
Indoor Type Edge Gateway

AC adapter (DC12V/1A)
Rod antenna x 2
External antenna x 2
External antennas may be required if the
sensitivity of the rod antenna is poor.
GPS Antenna
Main body fixing metal fittings
Console conversion (RJ-45 - D-Sub 9-pin)
DC power cable

Rainproof AC Cable
3P-
5m, with round crimp terminals. Outer
diameter 9.15mm
Cable Glands (for Ethernet cable)
Applicable wire diameter 6 to 10mm
Cable gland (for power supply only)
Applicable wire diameter 9 to 14mm
Wall mounting brackets (stainless steel, 4 sets)
Pole mounting brackets (stainless steel, 2 sets)
Pole mounting bands (stainless steel, 2 sets)
What you need to prepare
SIM Card
Please prepare for mobile connection.
Please refer to “amnimo G Series Edge Gateway User's Manual” for specifications and standards.
PC for configuration
Required for various settings of the Edge Gateway.
This manual uses Windows 10.
LAN cable (recommended category: CAT5e or higher)
Required for connecting Edge Gateway to a PC.

Overall system diagram 11
Overall system diagram
This manual describes how to set up a network using the following configuration as an example.
Mobile Connection
Connect to the Internet using a SIM.
WAN connection
Connects to the Internet using the eth0 interface.
LAN Connection
LAN connection to a private network using LAN0-3 interfaces.
Factory network settings
eth0: dhcpv4
lan0:.
lan1:.
lan2:.
lan3:.
br0: 192.168.0.254/24
- lan0/lan1/lan2/lan3

Step 1 Activate/connect 12
Step 1 Activate/connect
This step describes how to activate the Edge Gateway.
For Indoor Type Edge Gateway
1Insert the SIM card to be used into the back of the Edge Gateway.
Insert the SIM card so that its contacts are on the far side.
2Connect the LAN0 port of the Edge Gateway to the PC using a LAN cable.
Power outlet
AC
adapter
Micro-SIM
card
LAN cable

Step 1 Activate/connect 13
3Set the configuration DIP switch on the front of the Edge Gateway to Linux boot mode.
Explanation of DIP switch icons
DIP switch
Description.
ON state
OFF state
The No. 4 DIP switch can be ON or OFF. It is not referenced by the boot loader (used only on
the application side).
4Connect the AC adapter to the Edge Gateway.
Power is automatically turned on and the Edge Gateway is activated.

Step 1 Activate/connect 14
For Outdoor Type Edge Gateway
1Insert the SIM card to be used in the Edge Gateway and connect the PC to the LAN0 port of the Edge
Gateway with a LAN cable as shown in the figure below.
Insert the SIM card so that its contacts are on the far side.
2Set the configuration DIP switch on the top of the Edge Gateway to Linux boot mode.
LAN cable
Micro-SIM Card

Step 1 Activate/connect 15
Explanation of DIP switch icons
DIP switch
Description.
ON state
OFF state
The No. 4 DIP switch can be ON or OFF. It is not referenced by the boot loader (used only on
the application side).
3Connect the AC power cable to the Edge Gateway.
Turn on the power switch to activate the Edge Gateway.
For details, please refer to the "Outdoor Type Installation Guide (Edge Gateway/IoT Router
Outdoor Type)" included with the product.
AC power cable
Power switch

Step 1 Activate/connect 16
To shut down the Edge Gateway
Shutdown can be accomplished in one of the following ways During shutdown, the LED PWR will flash; when the
LED PWR turns red, the shutdown is complete.
Turn off the power by pressing down the PUSH switch on the main unit with a thin, pointed tip for at least 3
seconds during startup.
Indoor Type Edge Gateway
Indoor Type Edge Gateway
Shut down with the following command
Refer to the Edge Gateway Series CLI User's Manual for command usage.
admin@amnimo:~$ sudo systemctl poweroff

sudo password for admin: ←Enter root password and press Enter
Stopping Docomo of user admin.
Stopping Unpack initramfs on shutdown...
(Omitted.)
Starting Power-Off
NOTICE: You can turn off the power.
LED indication during shutdown process
Items
PWR
ANT
MOB
ST1
ST2
ST3
remarks
Shutdown process in
progress
500ms interval
Power disconnected
Notes on the automatic startup function
Since the Edge Gateway is intended to operate 24 hours a day, it has the ability to
automatically recover in the event of a shutdown, such as in the event of a failure.
Therefore, if the Edge Gateway is shut down in the manner described in this section, but
power is still supplied by the power connector, it will restart.
If you wish to put the Edge Gateway in a power-off state, shut it down and wait until the
LEDs are in a power-off ready state (power LED lit red) before pulling the power plug.
PUSH
switch
PUSH
switch

Step 2 Sign in to the Edge Gateway 17
Step 2 Sign in to the Edge Gateway
This step describes the procedure for signing in to the Edge Gateway.
Change the IP address of the PC
To sign in to the GUI configuration screen, the Edge Gateway and PC must belong to the same network. Change
the IP address of your PC to match the IP address of the Edge Gateway "192.168.0.254".
This manual is explained using Windows 10.
In this document, the IP address of your PC is changed to "192.168.0.10" to match the IP address
of the Edge Gateway "192.168.0.254".
1Under Windows Settings, click Network & Internet.

Step 2 Sign in to the Edge Gateway 18
2Click Network and Sharing Center.
3Click Change adapter settings.
4Right-click on "Ethernet" and select Properties from the menu that appears.

Step 2 Sign in to the Edge Gateway 19
5Select "Internet Protocol Version 4 (TCP/IPv4)" and click Properties.
6Set the IP address.
❶Select Use the following IP address.
❷Enter "192.168.0.10" for "IP Address" and "255.255.255.0" for "Subnet Mask".
❸Click OK.

Step 2 Sign in to the Edge Gateway 20
