Ampetronic CLD1 System manual

CLD1 INSTALLATION HANDBOOK
Box Contents
1 x CLD1
1 x AC to12V power adapter
DC
1 x A6 Induction loop logo
1 x 'CLD1 Installation Handbook'’
1 x Loop coil and fixings (if requested)
1 x Microphone option (if requested)
Handbook Contents
!
!Introduction
!Quick Start
!Installation
!Operation
!Troubleshooting
!Technical Specification
!Warranty
!Declaration Of Conformity
Safety
This symbol is used to alert the user to important
operating or maintenance instructions.
The Lightning bolt triangle is used to alert the user
to the risk of electric shock.
SAFETY
1. It is important to read these instructions, and to follow them.
2. Keep this instruction manual in an accessible place.
3. Do not install this equipment near any heat sources such as radiators, heating
vents or other apparatus that produces heat.
4. Refer all servicing to qualified personnel.
WARNING: Disconnect power before servicing or replacing fuse.
5. The amplifier generates some heat during normal operation and needs
adequate ventilation.
WARNING: Do not install the apparatus in a fully enclosed space.
6. No objects filled with liquids, such as vases, shall be placed on the apparatus.
WARNING: Do not expose to dripping or splashing.
7. Clean only with a dry cloth.

INTRODUCTION
The CLD1 Compact Loop Driver has been designed as a high quality stand-alone
induction loop driver for ticket counters, banks or other point of sales systems.
The unit is designed to drive the standard multi-turn loop coil (if supplied), or a
small area perimeter loop up to an area of 40m². Consult designing induction
loops handbook for more details.
The CLD1 features include:
Microphone input - for use with unbalanced electret microphones.
Selectable microphone or unbalanced line level input. (Mic' mode as
above)
12V input - suitable AC power adapter supplied.
DC
Loop output with spring clamp connections.
Individual level controls for each signal input, MLC (Metal Loss
Correction) style tone control and loop output.
Separate indication of power, input signal and loop current for easy set
up.
INPUT 1 INPUT 2
MLC LOOP
CURRENT
POWER
LOOP
CURRENT
INPUT
SIGNAL
LOOP
OUTPUT
COMPACT
LOOP
DRIVER
CLD1
INPUT 2
SELECT
Line - Mic
DC IN
12V
1.0A
Designed and engineered in the UK
1
1
2
3
4
5
6
56
2 3 4

QUICK START
1. Fit CLD1 to a panel or wall under the counter, away from contact by the system
user. Ensure the cables are positioned such that they are not vulnerable to
damage and are unlikely to be snagged or disconnected from the unit.
2. Fit either the loop coil (provided) or perimeter loop:
· Unfold the loop coil and fit vertically inside the front panel of the counter
using the adhesive fixings provided. The top of the loop coil should ideally
be at a height of 800mm above the floor.
Glass screen
(if fitted)
Place coil
immediately
below counter
Obstruction
Figure 2
Glass screen
(if fitted)
Counter
or
Desk
(customer side)
Counter
or
Desk
(customer side)
Place coil
immediately
below counter
Figure 1
Do not position
coil in this
position
· If a perimeter loop is to be used, the feed wires to the amplifier should
be twisted together. See 'Designing Induction Loops handbook' for details.
3. Connect the loop wires to 'LOOP OUTPUT' terminals. Polarity is not important.
To insert the wire, open the spring clamps using a lever action with a small flat
bladed screwdriver.
4. Connect signal to 'INPUTS 1 and 2' as required (see: Connection details).
5. Position 'INPUT 2 SELECT' slide switch for Line or Mic as required.
6. Using a small flat bladed screwdriver, turn 'INPUT 1', 'INPUT 2', 'MLC' and
'LOOP CURRENT' controls fully anticlockwise (minimum).
7. Connect 12V adapter to 'DC IN' socket on the unit. Connect adapter to AC
DC
supply.
8. Switch on external AC power: Check green 'POWER' LED illuminates.
9. Apply input signal (e.g. by speaking into mic') and increase corresponding
'INPUT 1 or 2' control until the green 'INPUT SIGNAL' LED begins to light.
10. Repeat item 9 for the second input (if used). Only apply one audio signal at a
time when setting up the system.
11. Adjust the 'LOOP CURRENT' control until the yellow 'LOOP CURRENT' LED
lights at peaks in the input signal.
12. Test the performance of the system using a loop receiver or field strength
meter and adjust 'MLC' & 'LOOP CURRENT' to achieve acceptable
performance.
Note: Once the 'LOOP CURRENT' control is set, do not adjust it again.

Fixing hole centres 117mm apart
MOUNTING DETAILS
I/P 1
I/P 2
mic -60
I/P 2
I/P 1
line
-60
-20
mic
line
select
switch
40dB mlc
drive
O/P
BLOCK DIAGRAM
Balanced Input
A+
B-
Screen
Connect screen and -ve
signal lead together
+
Stereo Source
Left
Right
Screen
Keep all wires very short
10k
10k
L
R
Screen
Ideally fit the two 10k, ¼W, summing
resistors within the body of the jack plug
10k
CONNECTION (LINE LEVEL INPUT)

INSTALLATION
Tools
You will require the following:
· Small flat bladed screwdriver
· Screws, fixings and appropriate tools for mounting CLD1 on wall etc.
Location
The amplifier should be mounted where:
· It is in close proximity to the loop.
· it is protected from drips or sprays of water.
· it is not vulnerable to mechanical damage.
· the controls can be accessed during set-up.
· the cables will not be inadvertently caught or pulled out from the unit.
· any heat generated during normal operation can escape.
·The induction loop itself is a critical to correct system performance,
either:
· Unfold the loop coil and fit vertically inside the front panel of the counter
using the adhesive fixings provided. The top of the loop coil should ideally
be at a height of 800mm above the floor. See diagram in Quick start.
2 2
·To cover a larger area, a perimeter loop using 0.5mm to 1.5mm cross-
section wire or equivalent. Return the feed to the amplifier with a
twisted pair. Refer to 'Designing Induction Loops handbook' for details.
Please consult Ampetronic if you need more advice about the loop design.
Connections
LOOP: Connect the loop cable to the 'LOOP OUTPUT' socket.
1. Open the spring clamp terminal - insert a flat bladed screwdriver into the small
slot above the hole.
2 Insert the wire (remove 7mm of insulation from end).
3. Remove the screwdriver - clamping the wire in place.
INPUTS: Both inputs are 3.5mm two pole (mono) jack sockets. They will not
interface directly to any stereo signal source. Connect inputs as shown in the
connection details.
INPUT 1 Unbalanced electret microphone only.
INPUT 2 Microphone as INPUT 1, or Line level input. Note: Set the 'INPUT 2
SELECT' switch to the appropriate position for the type of signal source used.
DC POWER: The 'DC IN' socket accepts 12V . Connect the 12V power
DC DC
supply provided to a convenient AC power socket.

TROUBLESHOOTING
For correct operation, with input signal(s), you should have the following LEDs illuminated:
'POWER' (Green)
'INPUT SIGNAL' (Green) only whilst audio signal is applied to an input
'LOOP CURRENT' (Yellow) only at peaks of audio signal
Power LED not illuminated
No 12V power to unit - Check cable has not been unintentionally disconnected.
DC
No external AC power - Check cable has not been unintentionally disconnected.
Ensure external AC power supply is switched ON.
Internal Fuse Blown - Disconnect from supply and fit a correctly rated
replacement. See SAFETY clause 4.
INPUT SIGNAL LED not illuminated at any time
No inputs connected - Connect an input as described in INSTALLATION.
‘INPUT' control too low - Adjust control as appropriate see: OPERATION.
Input signal level too low - Check that signal level is the correct level for the chosen
input see: TECHNICAL SPECIFICATIONS
'LOOP CURRENT' LED not illuminated (even at peaks of signal)
Loop not connected or open circuit - Check loop continuity using a resistance meter.
‘INPUT SIGNAL' LED not illuminated - See above.
'LOOP CURRENT' control too low - Adjust control as appropriate see: OPERATION.
Low or no field received in the loop area
If 'LOOP CURRENT' LED is illuminated, but no field is received in the loop area, either:
the loop is installed in the wrong place, or
there is a short circuit between the ends of the feed cable.
If 'LOOP CURRENT LED is illuminated, but there is only a very low or dull field strength.
there is significant metal in the desk / counter near the loop consult Ampetronic.
If 'LOOP CURRENT' LED is not illuminated - See above.
1. Using the small flat bladed screwdriver, ensure that 'INPUT 1', 'INPUT 2',
'MLC' and 'LOOP CURRENT' controls are fully anti-clockwise (minimum).
2. Switch on external AC power supply. Check green 'POWER' LED on CLD1
illuminates.
3. Apply input signal and increase corresponding 'INPUT 1 or 2' control until the
green 'INPUT SIGNAL' LED begins to light.
4. Repeat item 3 for the second input (if used). Only apply one audio signal at a
time when setting up the system.
5. Adjust the 'LOOP CURRENT' control until the yellow 'LOOP CURRENT' LED
lights at peaks in the input signal.
6. Listen to the audio signal using an induction loop tester or headphone receiver
(such as the ILR3) whilst standing in the area covered by the loop. Check that
adequate volume is received (volume control at mid-position on the ILR3).
7. Adjust the 'MLC' control for best sound quality.
OPERATION

CLD1 Power Supply: Frequency Response:
Supply range: 12-15V 80Hz - 5.0kHz ±1.5dB, at low level
DC
measured as loop current with no MLC.
Nominal voltage: 12VDC
Fuse: T 1.6A L MLC (Metal Loss Correction):
Supply currents (with nominal voltage): 0dB to 4dB per octave boost.
Nominal (pink noise): 600mA Fully anticlockwise - flat response.
Quiescent: 55mA
Maximum: 1.0A Environmental:
Ambient temperature: -20°C to +50°C
'DC IN' terminal: IP rating: Ip20.
Centre positive (+) concentric socket.
Ø = 5.5mm/2.1mm. Physical:
Weight: 280g
12V Power Adaptor Supply (AC):
DC Width: 127mm
Refer to markings on unit supplied. Height: 35mm
Must be capable of delivering 1.0A from Depth: 75mm
12V output.
DC
Standards:
Audio signal inputs: Meets relevant CE, EMC and safety
2-pole 3.5mm Jack sockets standards.
INPUT 1: IEC 60118-4 AFILS
Input Impedance: 8.5kW
Sensitivity: -60dBu (775uVrms)Please contact Ampetronic if you need further
Overload: -13dBu (173mVrms)assistance.
Microphone cables must be <= 3m
INPUT 2:
Line - Mic mode selectable with switch.
'Mic' mode: same as Input 1
'Line' mode:
Input Impedance: 820kW
Sensitivity: -20dBu (77.5mVrms)
Overload: +20dBu (7.75Vrms)
Note: This input is not isolated.
Compression (AGC):
40dB dynamic range
Controlled by adjusting input level.
Attack and decay time constants optimized
for speech.
Loop Design:
Standard loop coil (supplied) or perimeter
loop. See 'Designing Induction Loops
Handbook' for details.
Consult Ampetronic for advice.
Loop Output:
Current: >2.4A or 3.4A @ 1kHz
RMS pk
Voltage: >3.2V or 4.5V @ 1kHz
RMS pk
Loop Resistance: 0.3W to 1.0W
Loop Impedance: 1.3W max @ 1.6kHz.
Spring terminal connections accept
stranded or single core wire.
Acceptable wire gauge:
2
CSA: 0.5 to 1.5mm
AWG: 22 to 16.
TECHNICAL SPECIFICATIONS

This product carries a five year parts and labour warranty from date of
shipment from Ampetronic. To qualify for the five year warranty, the product
must be registered at www.ampetronic.co (products/warranty), without which
the warranty will be valid for two years only.
The warranty could be invalidated if the instructions in this handbook are not
followed correctly, or if the unit is misused in any way.
Note: The power adapter supplied with this product is only covered by the
manufacturers warranty period.
Manufacturer: Ampetronic Ltd.,
Unit 2, Trentside Business Village
Farndon Road
Newark
NG24 4XB
Declares that the product:
Description: Induction Loop Driver
Type name: CLD1
Conforms to the following Directive(s) and Norm(s):
Directive 2014/35/EU
EMC: EN55032:2015 Emission
EN55103-2:2009 Immunity
Directive 2014/30/EU
Safety: EN 60065:2014
Directive 2011/65/EU RoHS
Date: August 2017
J.R. Pieters
Managing Director
Ampetronic Ltd.
WARRANTY
DECLARATION OF CONFORMITY
UP15701-14
