AmpliVox Lectern Base S-260 User manual

Packing List:
• Table top
• Shelf
• Left Side Panel
• Right Side Panel
• Front panel
• 4 Casters - 2 locking
Easy Step-By-Step Instructions
Featuring Quickfit-Expando-6 Connectors
for S-260 Lectern Base Assembly
The Lectern Base is designed for
easy assembly. If you have any ques-
tions about assembling your new
lectern base, or if you want more
information about accessories, call
AmpliVox’s customer service line.
The lectern base is carefully packed
to minimize shipping damage. If your
unit was damaged in shipping call
our toll-free customer service line or
visit our web site at:
http://www.ampli.com
1-800-267-5486
Top Panel
How the Quickfit-Expando-6
Connectors work.
Do not over tighten the connectors.
They will break if turned too far. Turn
only 1/2 turn clockwise to lock. The
steel Quickfit-6 expanding dowels and
the Quickfit-Expando-6-Connectors lock
together for easy assembly.
3. Inspect the Quickfit Expando-6
Connectors. The flat edge on the con-
nector must be facing the outer edge of
the board. Use a phillips screwdriver to
rotate them, if needed.
Untightened
(unlocked)
To tighten
(to lock)
Edge of board
Edge of board
To untighten
(to unlock)
Tightened
(locked)
1. Unpack all the pieces. Be sure to
save the packing and the box in case
you need to return the lectern for any
reason. Check that you have all the
pieces and that they are not damaged.
2. Insert the steel pins. With your
thumb(use phillips screwdriver to ease
insertion), push the steel pins into the
holes in the 2 side, front and top pan-
els. Make sure the plastic collar is flush
with the wood surface.
F:\docs\productinstructions\r-260assembly.qxd
Quickfit-6 Expanding Dowel
Hardware:
•18 Quickfit-Expando-6 Connectors
pre-installed
•18 Push-in Quickfit-6 Expanding dowels
Tools Needed:
•Phillips Screwdriver - for 1/2 turn of pre-
inserted Quickfit-Expando-6 Connectors
Turn counterclockwise to unlock
Front Panel
Shelf
Left Side Panel
Right Side Panel

4. Attach the top panel. Lay Front
panel on clean surface (carpet) and
attach top panel.
Use a phillips screwdriver to tighten the
2 Quick-fit-Expando-6 Connectors. Turn
only 1/2 turn clockwise. Over tightening
will break the connectors.
F:\docs\productinstructions\r-260assembly.qxd
5. Attach the right side panel
Slide right side panel Quick-fit-Expando-6
connectors over steel pins in front and top
panels. Tighten the 5 Quick-fit-Expando-
6 Connectors.
6. Attach the Left side Panel
Slide left side panel Quick-fit-Expando-6
Connectors over steel pins in front and
top panels. Tighten the 5 Quick-fit-
Expando-6 Connectors.
7. Attach the shelf. Slide shelf Quick-
fit-Expando-6 Connectors over steel pins
in front and side panels. Tighten the 6
Quickfit-Expando-6 Connectors.
8. Attach casters. Insert 2 non-locking
casters on bottom of side panels closest to
the front panel. Insert 2 locking casters
on bottom of side panels closest to the
open end.
9. Carefully stand up Lectern Base.
Stand up lectern base carefully to rest on
casters
Your Lectern Base is now complete and
ready to accept matching S/W250
Tabletop Lectern or be used as a mobile
Equipment Stand/Video Cart.
Thousands of AmpliVox sound products
have been in use since we first began
shipping in 1961. We hope you enjoy
many years of use from your new Lectern
Base.
If you have any questions or comments,
call customer service line.
1-800-267-5486
Tighten
Front Panel
Top
Panel
Tighten
Front Panel
Top Panel
Right
Side
Panel
Top Panel
Front
Panel
Tighten
Right Side Panel
Left Side Panel
