AmpliVox Presidential Plus W-450 Assembly instructions

Easy Step-By-Step Instructions for
W/S/SW-450 Presidential Plus Lectern Assembly
Featuring Quickfit-Expando 6 Connectors
1-800-267-5486
The Presidential Plus Lectern is designed
for easy assembly. If you have any questions
about assembling or using your new sound
system, or if you want more information
about accessories, call AmpliVox’s customer
service line.
The lectern is carefully packed
to minimize shipping damage. If your unit
was damaged in shipping call our toll-free
customer service line or visit our web site at
http://www.ampli.com
NOTES ON ASSEMBLY
Use CAUTION during assembly
board edges can be sharp and
may chip if mishandled.
Remove staples from carton and
use carton to set parts on during
assembly.
ASSEMBLY INSTUCTIONS
1. Unpack all the pieces. Be sure
to save the packing and the box
in case you need to return the
lectern. Check that you have all
the pieces and that they are not
damaged. [figure 1]
2. Insert the steel pins. With your
thumb [use phillips screwdriver
to ease insertion], push the steel
pins into the holes in the two
sides. Make sure the plastic
collar is flush with the wood
surface. [figure 2]
Hardware :
14 Quickfit-Expando 6 Connectors
[pre-installed]
14 Push-in Quickfit 6 Expanding
dowels
4 Minibloc Connectors[pre-installed]
8 Minibloc Screwpins
4 Plate Casters [2 Locking]
16 #10 x 3/4 PPH Screws
Tools Needed :
Phillips Screwdriver
POWER TOOLS ARE NOT
RECOMMENDED
Edge of board
Edge of board
3. Inspect the Quickfit-Expando 6
Connectors. The flat edge of the
connector must be facing the
outer edge of the board.
Use phillips screwdriver to rotate,
if needed.
UNLOCKED LOCKED
TURN COUNTERCLOCKWISE
TO UNLOCK
LOCKED UNLOCKED
#10 x 3/4 PPH Screw
[16 required]
Plate Caster
Locking
[2 required]
Plate Caster
Nonlocking
[2 required]
Quickfit-6
Expanding Dowel
[14 required]
Quickfit-Expando 6
Connectors
[14 required]
Pre-inserted
Quickfit-Expando Minibloc
Connectors
[4 required]
Pre-inserted
Packing List:
Reading Table
Bottom Panel
2 Side Panels, left and right
Front-Dual Speaker Panel
Center Shelf
Black Speaker Grille [S/SW450]
Hand Held Microphone [S/SW450]
Microphone Cable [S/SW450]
Gooseneck [S/SW450]
Shock Mount Microphone Holder [S/SW450]
Amplifier [S450]
Wireless Amplifier [SW450]
figure 1
Minibloc Screwpins
[8 required]

figure 2
figure 3 figure 4
4. Attach front panel to left side. With the
left side panel laying on the work surface,
attach the front panel by sliding the connectors
over the steel pins. Both bottom unfinished
edges should be on the side. Use a phillips
screwdriver to tighten the 3 Quickfit-Expando 6
connectors. Turn 1/2 turn clockwise.
Do not overtighten the connectors.
Over tightening can break the connectors.
[figure 3]
5. Install bottom panel. Place bottom panel in
the slot on the left side panel, flat unfinished
edge against the front panel. Using a phillips
screwdriver, install 4 Minibloc Screwpins through
the Minibloc holes into the predrilled holes in
the side panel. [figure 4]
6. Attach right side panel. Place the right side
onto the front and bottom panel, tighten the 3
Quickfit-Expando 6 connectors in the front panel
and install 4 Minibloc Screwpins in the 2
Minibloc connectors on the bottom panel.
Carefully roll unit onto front panel.
7. Install reading table and shelf. Slide reading
table over steel pins and tighten 4 Quickfit-
Expando 6 connectors. Slide shelf over steel pins
and tighten 4 Quickfit-Expando 6 connectors.
Install 2 locking casters on the finished side of
the bottom panel and 2 non-locking casters
using the #10 x 3/4 PPH screws.
Carefully stand unit up and install sound system
using amplifier instructions.
