AMX NXI User manual

netlinx®integrated controller
Boasting a sleek modular design and compact in size, the AMX NetLinx
Integrated Controller packs extremely powerful control and affectively
manages extensive networking capabilities.
Take instant command over any piece of integrated equipment - from
projectors and window treatments to security, lighting and even the
personal computer - with a full array of RS-232/422/485 ports, IR/Serial
ports, Inputs/Output channels and relays.
Experience anywhere, anytime control through exclusive AMX integration!
Solutions applications, which combine the dynamics of NetLinx with the
features of the World Wide Web. Use any Internet connection for off-site
control at the touch of a button on personalized control Web pages.

NXI (FG2101)
•Provides versatile, multiport control
• 6 data ports for RS-232/422/485 control,
with XON/XOFF and CTS/RTS, 300-
230,4000 baud
•8IR/Serial ports for control of up to
1.14 MHz carrier frequency
•8I/O channels for closure, 0-5 VDC
voltage sensing, or interactive power
sensing for IR ports
•Provides 12 relays
OTHER FEATURES
•Accepts the NXC-ME260 NetLinx Master
and NetLinx Hub Processor cards
•Supports graphical setup, status, and
testing from NetLinx Studio software
•Includes NetLinx faceplate with smoked
gray translucent window to view LEDs.
•Faceplate attaches magnetically to front
panel for easy access. It also locks onto
the front panel with screws hidden
behind a snap-in window
FRONT PANEL
CARD SLOT
•Accepts compatible NetLinx Master:
NXC-ME260 NetLinx Master-Ethernet
Card/Module
•Accepts compatible NetLinx Hub Card:
NXC-HS (Hub Server)
NXC-HE (Hub Expander)
RS-232/422
•12 LEDs for RS-232/422/485 ports, TX (red) and
RX (yellow)
RELAYS
•12 LEDs (red) for relays
IR/SERIAL
•8LEDs (red) for IR/Serial ports
I/O
•8LEDs (yellow) for I/O channels
ENCLOSURE
•Metal with black matte finish
DIMENSIONS (HWD)
•1.72" x 17.00" x 8.81" - 1 Rack Unit
(4.37 cm x 43.18 cm x 22.37 cm)
WEIGHT (WITHOUT PROCESSOR)
•4.0 lbs (1.8 kg)
POWER
•1.09 A @ 12 VDC
OPTIONS
•12 VDC power supply
•CSB Cable Support Bracket
•CC-N232 RS-232/422 cables
•CC-NIRC IR cables
•CC-NREL Relay cables
•CC-NSER IR/Serial cables
REAR PANEL
ID BUTTON
•Pushbutton sets device ID (in conjunction with
NetLinx Studio software program)
ICSP
•Green ICSNet status LED
RELAY CONNECTORS 1-12 (PORT 7)
•Three 8-pin terminals, 750 mA, 28 VAC/24 VDC
normally open
I/O CONNECTORS 1-8 (PORT 16):
•One 10-pin terminal, I/O 1-8, Common, +12
VDC power tap, 200 mA, closure or 0-5 VDC
sensing IR/Serial connectors 1-8 (ports 8-15):
•Eight 2-pin terminals for IR and IR/Serial
connections
RS-232 1-6
•Six 10-pin terminals, RS-232/422/485,
XON/XOFF, CTS/RTS, 300-230,400 baud
INCLUDES
•4CC-NIRC emitters
•Metal tab strips for commoning adjacent relays
•Rack-mount brackets adapt for rack, wall, or
shelf mounting
•NetLinx faceplate
17.00 [431.80mm]
8.81 [223.65mm]
0.54 [13.59mm]
NXI (Top Views)
1.72 [43.69mm]
1.81 [45.85mm]
NXI (Right Side)
19.00 [482.60mm]
NXI (with Bezel)
netlinx®integrated controller
ARGENTINA • AUSTRALIA • BELGIUM • BRAZIL • CANADA • CHINA • ENGLAND • FRANCE • GERMANY • GREECE • HONG KONG • INDIA • INDONESIA • ITALY • JAPAN
LEBANON • MALAYSIA • MEXICO • NETHERLANDS • NEW ZEALAND • PHILIPPINES • PORTUGAL • RUSSIA • SINGAPORE • SPAIN • SWITZERLAND • THAILAND • TURKEY • USA
ATLANTA • BOSTON • CHICAGO • CLEVELAND • DALLAS • DENVER • INDIANAPOLIS • LOS ANGELES • MINNEAPOLIS • PHILADELPHIA • PHOENIX • PORTLAND • SPOKANE • TAMPA
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • 469.624.8000 • +1.469.624.7400 • 469.624.7153 fax • www.amx.com
01.2006 ©2006 AMX. All rights reserved. AMX and the AMX logo are all trademarks of AMX. AMX reserves the right to alter specifications without notice at any time.
1.72 (43.69MM)
8.81 (223.65MM)
17.00 (431.80MM)
19.00 (482.60MM)
1.72
(45.85 MM)
0.54 (13.59MM)
