AMX ALD-1000D User manual

dimmers / switches
LIGHTING THE WAY
AMX, a leader in control system technology,and Lutron, a leader in lighting
controls, have combined forces to create a single lighting solution that
includes the popular Lutron Vareo-Style Local Lighting Controls (Dimmers
and Switches). The AMX Inconcert With Lutron Network Lighting Solution
delivers truly seamless integration between AMX Control Systems and
lighting systems throughout commercial and residential installations.
TOTAL PACKAGE
The AMX Network Lighting Solution offers everything necessary to outfit
alighting installation, including Vareo Dimmers and Switches in standard
single, two, three and four gang boxes. The D48 Dimmer Interface is
available exclusively from AMX.
LUTRON LIGHTING CONTROLS
The AMX Network Lighting Solution integrates Lutron’s Vareo-Style
Dimmers/Switches that are used in both localized and optimized lighting
control designs. These lighting controls function much like standard
dimmers and switches, yet come with an integral microprocessor that
allows them to be incorporated into a lighting control system.

dimmers / switches
ARGENTINA • AUSTRALIA • BELGIUM • BRAZIL • CANADA • CHINA • ENGLAND • FRANCE • GERMANY • GREECE • HONG KONG • INDIA • INDONESIA • ITALY • JAPAN
LEBANON • MALAYSIA • MEXICO • NETHERLANDS • NEW ZEALAND • PHILIPPINES • PORTUGAL • RUSSIA • SINGAPORE • SPAIN • SWITZERLAND • THAILAND • TURKEY • USA
ATLANTA • BOSTON • CHICAGO • CLEVELAND • DALLAS • DENVER • INDIANAPOLIS • LOS ANGELES • MINNEAPOLIS • PHILADELPHIA • PHOENIX • PORTLAND • SPOKANE • TAMPA
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • 469.624.8000 • +1.469.624.7400 • 469.624.7153 fax • www.amx.com
©2006 AMX. All rights reserved. AMX and the AMX logo are all trademarks of AMX. AMX reserves the right to alter specifications without notice at any time.
ALD-600D • 600W DIMMING CONTROL
LOAD TYPES
•Incandescent, magnetic low-voltage, tungsten
halogen, electronic low-voltage (using Lutron ELVI-
1000 Interface). Output is compatible with Lutron
NGRX-PB-WH and HP 2-4-6 Power Boosters for
dimming applications up to 30,000W per dimmer
MAXIMUM LOAD (WITH NO FINS BROKEN)
•600W
MAXIMUM LOAD (WITH ONE FIN BROKEN)
•500W
MAXIMUM LOAD (WITH TWO FINS BROKEN)
•300W
MINIMUM LOAD REQUIRED
•40W
LINE-VOLTAGE WIRING
•Standard single-pole and 3-way wiring.
SHIPPING WEIGHT
•0.6 lbs (.3 kg)
ALD-1000D • 1000W DIMMING CONTROL
LOAD TYPES
•Incandescent, magnetic low-voltage , tungsten
halogen, electronic low-voltage (using Lutron ELVI-
1000 Interface). Output is compatible with Lutron
NGRX-PB-WH and HP 2-4-6 Power Booster for
applications up to 30,000W.
MAXIMUM LOAD (WITH NO FINS BROKEN)
•1000W
MAXIMUM LOAD (WITH ONE FIN BROKEN)
•900W
MAXIMUM LOAD (WITH TWO FINS BROKEN)
•700W
MINIMUM LOAD REQUIRED
•40W
LINE-VOLTAGE WIRING
•Standard single-pole and 3-way wiring.
SHIPPING WEIGHT
•0.6 lbs. (0.3 kg)
ALD-1000NS1000W
SWITCHING CONTROL WITH NEUTRAL WIRE
LOAD TYPES
•Incandescent, magnetic low-voltage, electronic low-
voltage, fluorescent with magnetic ballasts.
MAXIMUM LOAD (WITH NO FINS BROKEN)
•1000W
MAXIMUM LOAD (WITH ONE FIN BROKEN)
•700W
MAXIMUM LOAD (WITH TWO FINS BROKEN)
•550W
MINIMUM LOAD REQUIRED
•5W
LINE-VOLTAGE WIRING
•Requires a neutral-wire connection in the wallbox.
SHIPPING WEIGHT
•1.0 lbs. (0.4 kg)
ALD-VETS-R: AUXILIARY TAP SWITCH
SHIPPING WEIGHT
•0.6 lbs. (0.3 kg)
INPUT VOLTAGE
•110-130 VAC 60Hz
REGULATORY APPROVALS
•UL, CSA, NOM
AIR GAP
•Air gap provided by FASS
(Front Accessible Service Switch).
MOUNTING
•Controls mount in standard U.S. wallboxes. For easier
installation, Lutron recommends using 3-1/2" (89mm)
deep wallboxes.
GANGING
•When ganging Vareo-Style Local Lighting Controls, it
is necessary to remove side fins and to derate the
control.
VERTICAL SPACING
•If mounting one control above another, leave at least
4-1/2" (11.4cm) vertical spacing between them.
LOW-VOLTAGE PRE-WIRING
• 1 pair twisted shielded #18-22 AWG (0.5-1.0mm) Class
2or Class 3 wiring.
WIRING CONFIGURATION
•Daisy-chain, star, T-tap, home run. Link terminator not
required. Total length of wire on any Dimmer Interface
bus cannot exceed 500 ft. (150m) Maximum of 4
devices per Dimmer Interface bus.
LOW-VOLTAGE CONNECTIONS
•Butt-splice (provided).
ADDRESSING
•Address via DIP switch located on front of unit
underneath the wallplate. The device may be
addressed without removing it from the wall.
AUXILIARY CONTROLS
•Use only Lutron Auxiliary Tapswitches (model # VETS-
R); mechanical 3- or 4-way switches will not work. Up
to 9 VETS-R Auxiliary Tapswitches may be used with
one Vareo-Style Local Dimming or Switching Control.
ENVIRONMENT
•Ambient operating temperature: 0-40° C, 32-104° F
Ambient operating humidity: 0-90% humidity, non-
condensing; Indoor use only
DIMENSIONS
•2.75" x 4.5" x 1.31"
(70mm x 114mm x 32.7mm)
COOLING METHOD
•Passive cooling
SURGE PROTECTION
•Meet or exceed ANSI/IEEE standard c62.41
ESD PROTECTION
•Yes
FAIL-SAFE OPERATION
•In the unlikely event that communication with the
Processor is interrupted, all Vareo-Style Local Lighting
Controls will still operate, offering local control.
ALD-600D
ALD-1000D
1000NS600D
ALD-VETS-R
