amzchef JS3005-1 User manual

MODEL: JS3005-1
120V 60Hz 150W
SLOW JUICER
INSTRUCTION MANUAL

2
Contents
Section I. Pre c a u t i o n s f or S a f et y U s e ................................ 3
Section II. Parts and Functions.................................................. 5
Section III. Method of Operation ......................................... 7
Section IV. How to assemble........................................................... 8
Section V. Tipsfor Ingredients Selection .................................. 11
Section VI. Maintenance . .......................................................13
Section VII. Safety Index.............................................................................14
Section VIII. Trouble Shooting........................................................ 15
Warranty.......................................................................................... 16

3
Section I. P r ec au t ion s f o r S a fe t y U s e
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Power of 120V~60Hz shall be supplied to this product. Please confirm
your power supply before use.
2.
Be sure to disconnect the power supply before dis-assembly/re-
assembly or adjustment to this product.
3.
In case of any damage to the flexible wire, to avoid anyhazard,
contact our customer service or send it to ourauthorized service
center for replacement, and do not try to disassemble it without our
authorization.
4.
Prior to use, please check the power cable, plug, juice filter,
Auger ,
damage, stop using this product and contact our customer service
immediately without unauthorized dis-assembly or repair to avoid any
potential hazard.
5.
For need of any repair during use,return appliance to our authorized
service facility for examination, repair or electrical adjustment.
6.
Before connecting with power supply,
make sure that any such
removable parts as extractor body, auger, juice filter and extractor
cover have been mounted inplace.
7. DO NOT put your fingers or other objects into the juicer opening
while it is in operation. If food becomes lodged in the opening, use
the plunger or another piece of fruit to push it down. When this
method is not possible, turn the motor off and disassemble juicer
to remove the remaining food.
8.
The food material needsto be cut into proper pieces so as topass
th r ou g h th e inl e t to ex tr a c to r / c ho pp e r/ g ri n d . A n y frui t / v e g e t a b le s h a ll
haveanyhardcore,seed,skinor shell removed before processing.
9.
Proper amount of force shall be used to push the food material in, not
excessive but sufficient to have it cut off exactly.
10.
The juice filter, extractor cover, or auger may be dyed by the juice
during operation, which is a normal phenomenon and has no effect on
Juicing screen, Drum and other parts, and in case of any

4
edibility and does no harm to health.
11.
This product is equipped with intelligent protection chips, making it stop
automatically for every 20 minutes' operation. And in such case, rest it for
20-30 minutes before restarting it, so as to cool the motor down and
prolong product servicelife.
12.
This product is designed to limit the flow rate. During processing of
any hard material, the motor will be locked and the current will rise up.
When the current goes higher than2 A , the equipmentwill beep
and the motor will stop operation for over-current protection and
extension of life span.
13.
In case that currentlimit protection is triggered or the motor is locked
and stops automatically, the power switch should be transferred to
If the problem continues, it is
recommended to remove any food material inside
auger
before restart
so as to protect the motor.
14.
After the completion of operation, remove any removable part
only after the motor/auger/shredder/slicer/grinder screw has
stopped rotating and the power hasbeen disconnected.
15.
Any part in contact with food material is clean, safe and reliable in
compliance with related food hygiene codes.
16.
To protect against risk of electrical shock, do not put the motor base in
water or other liquid.
17.
Do not use any steel wool, abrasive cleaning agent or corrosive
liquid such as gasoline or acetone to clean this product.
18.
This product should be stored in a place that children can’t reach. Not
allow persons with unsound extremities and sensation or mental
disorders and persons who are short of related experience and
knowledge( including children ) to use or play with this product.
19.
This product is used for individual or family only.
20.
This product is of Class-Iprotection grade,and the socket used for it
must be grounded properly.
the “REV” state, and the ingredients should be withdrawn. Then
the power switch should be transferred to the “ON” state to ensure
the normal use of the machine.
All parts are not allowed to be disinfected with hot water over 80°C
and microwave ovens to avoid thermal deformation damage.

5
Section II. Parts and Functions

6
No.
Compon
e
nt Name
Function Description
1
Powe
r
Cable
For connection to power supply.
2
Ho
u
sing
The main unit containin
g
motor and other
components,providing power output.
3
On-O
ff
Switch
For control of product operation,such as
forward/backward rotation and close-down.
4
Lockin
g
Button
For locking of extract or to prevent unexpected
release out of the housing.To unload the extractor of
the housing, press down and hold this button.
5
J
u
ice
Con
t
ainer
To hold and collect the juice extracted by the
extractor.
6
Po
m
ace
Con
t
ainer
To hold and collect any Pomaces separated by the
extractor.
7
Plu
n
ger
To squeeze and make the load food material
contact completely with the auger so as to maximize
extracting efficiency
8
T
r
ay
For interim storage of food material to process.
9
Fee
d
chute
Feeding food and load down to Drum
10
D
r
um
One of the main components to extract juice,where
the food material is loaded from the Feed chute at
the top, while the juice and Pomaces are discharged
from the outlet.
11
A
u
ger
One of the main components to extract juice,where
the food material is transferred and ground against
juice filter or extruder.
12
Juicin
g
screen
Work with Auger to grind food material and filter the
juice.(applicable to fruits,vegetables and beams)
13
En
d
cap
Coupled with extractor to provide protection.
14
En
d
cap
silico
n
e loop
It is placed at the joint between the drum and end
cap (to increase the tightness between both and
prevent juice from flowing out from the joint)

7
Section III. Method of Operation
Prior to first use,Please thoroughly clean any parts in contact with food
material. (See Section IV. Maintenance for more details)
Operation instructions of power switch (gear):
“OFF” state: close, stop gear
“Soft”low gear for normal operation (Suitable for
squeezing soft fruits like oranges, grapes, water-
melon, cherry tomatoes)
“Hard”state:high gear for normal operation
(Suitable for squeezing hard fruits and vegeta-
bles like carrots, apples, pears, celery)
“REV” state: when slag discharge is not
smooth or locked-rotor, this gear shall be used.
(Hint: when slag discharge is not smooth or
locked-rotor, turn the power switch to “REV”
gear. When the auger begins to reverse, turn
the switch to “Hard”or“Soft”gear and recover
corotation and resume working.)

8
Section IV. How to assemble
1
Connect Drum with Housing:
Connect the Drum with the Housing by
aligning the “ ” on Feed chute with “ ” on
the Housin g, push the Drum hard and rotate the
Drum anticlockwise until aligning “ ” on Feed
chute with “ ” on the Housin g.
(You will hear
“Tick”
sound to confirm fasten it tightly and
correctly ).
2
Place the augerinto the drum.
3
Insert the juicing screen
into the dru
m.

9
4
Place the end cap onto the drum and
rotate
the cap counter- clockwise.
5
Place Juice Cup and Pomace Container under
the drum set
.
6
Mount tray onto the upper end of Feed chute.
7
Connect to power supply and get ready for start
up.
(Beforepower-on,make surethe switch is
in Off position.)
8
Clean the material and cut it into pieces small
sufficiently
which can pass through the Feed Chute
and place them
onto the tray.
Note: Any hard core, seed, skin or shell from
fruits and vegetables shall be removed in
advance.
9
Turn the power switch and let the indicator on
switch aligns with the “Hard”or“Soft”gear, the
product starts to work. The working time is equal
or less than 10 minutes.
Do not touch the power switch with wet hands to
avoid electric shock, electric leakage or fire.

10
10
Place the few pieces of cut fruit or vegetables
into the Feed chute, push them down the drum
gently with plunger.
Properamountofforce shallbeusedtopushthe
food material in, not excessive but sufficient to
have it cut off exactly.
(Donotput your finger or anyotherobjectinto
the Feed chute! If the Pomace/Juice Cup is
full,
disconnect the power supply and clear it up
before restart.
11
Upon completion, shutdown the switch when no
juice flows out of the outlet and disconnect the
power supply. Do not remove the Juice Cup off
the outlet until the spiral propeller and juice filter
have stopped rotating completely. The extracted
juice should be drunk as soon as possible as it will
have degraded taste andnutrientcontent if
exposed in the
air for a time.
ThePomaces shall not be stored fora long
time.
Do not touch the power switch with wet
hand to avoid electric shock, leakage or
fire.

11
Section V. Tips for Ingredients Selection
FRUIT JUICE EXTACTOR
Efficiently juices hard and soft fruits: even citrus fruits, usually one of the
hardest fruits to juice.
Jam can not be achieved, some fruit can not squeeze juice (such as bananas,
mangoes, dried fruit, sugar cane, etc.).
VEGETABLE JUICE
Cut vegetables tostrips(less than 3.9inch/10cm).
Juices all kinds of vegetables including carrots, beets, celery, peppers,
and radishes without destroying the natural flavor and nutrition benefits.
Fresh taste and full nutrition are guaranteed withthis unique extraction
process.
WHEATGRASS AND LEAFY GREENS
Cut it to strips(less than 3.9inch/10cm).
Wheat grass, kale, cabbage, spinach and pine tree needles are just some of
the natural products that can be juiced with the Aobosi juicer. Enjoy the best
that nature offers in raw foods of all kinds and juice them for full nutritional
benefits.
Instructions on Selection of Fruits
1. Select fresh fruits and vegetables, which contain more juice. The proper
fruits include: pineapple, beet root, celery stalk, apple, cucumber, spinach,
melons, tomato, orange and grape.
2. Thick skin on fruits such as orange, pineapple and raw beet root instead
of thin skin on fruit/vegetable needs to be removed. Seeds in oranges
should be removed as well, which may make the juice taste a little bitter.
3. Concentration of juice extracted from apple depends on what type of
apple is selected. Juice extracted from juicier apple is less thick, so select
the proper type of apple depending on your desired juice concentration.
4. Just extracted apple juice will turn brown very soon,and this process can
be slowed by adding drops of lemon juice into it.
5. Leaves and stems (such as those of lettuce) can be put into theextractor
to extract juice.

12
The typical nutrient ingredient contained in fruits/vegetables are shown
below:
Fruit/Vegetable
Vitamin/Mineral
Calorie
Apple
Vitamin C
Apricot
Dietary fiber and potassium
Beet
Folic acid, dietary fiber, Vitamin C
and potassium
Blueberry
Vitamin C
Brussels Sprouts
Vitamins C, B, B6 and E, folic acid
and dietary fiber
Cabbage
Vitamin C, folic acid, potassium,
Vitamin B6 and dietary fiber
Carrot
Vitamins A, C and B6, and dietary
fiber
Celery Vitamin C and potassium
Cucumber
Vitamin C
Fennel
Vitamin C and dietary fiber
Grape
Vitamins C and B6, and potassium
Yangtao
Vitamin C and potassium
Muskmelon
Vitamins C and A, folic acid and
dietary fiber
Nectarine
Vitamins C and B3, potassium and
dietary fiber
Peach
Vitamins C and B3, potassium and
dietary fiber
Pear
Dietary fiber
Pineapple
Vitamin C
Raspberry
Vitamin C, iron, potassium and
magnesium
Tomato
Vitamins C, E and A, dietary fiber
and folic acid
0.44LB(200g)=300KJ(72 Calorie)
0.07LB(30g)=85KJ(20 Calorie)
0.35LB(160g)=190KJ(45 Calorie)
0.28LB(125g)=295KJ(70 Calorie)
0.22LB(100g)=110KJ(26 Calorie)
0.22LB(100g)=110KJ(26 Calorie)
0.22LB(100g)=110KJ(26 Calorie)
0.18LB(80g)=55KJ(13 Calorie)
0.62LB(280g)=120KJ(29 Calorie)
0.66LB(300g)=145KJ(35 Calorie)
0.28LB(125g)=355KJ(85 Calorie)
0.22LB(100g)=100KJ(40 Calorie)
0.44LB(200g)=210KJ(50 Calorie)
0.4LB(180g)=355KJ(85 Calorie)
0.33LB(150g)=205KJ(49 Calorie)
0.33LB(150g)=250KJ(60 Calorie)
0.33LB(150g)=245KJ(59 Calorie)
0.28LB(125g)=130KJ(31 Calorie)
0.22LB(100g)=90KJ(22 Calorie)

13
Section VI . Maintenance
1.
Before cleaning this product, be sure to shut down the switch to
disconnect the power supply.
2.
Clean this product after using it.
3.
The Housing cannot be washed under water, and must be cleaned
with twisted wet clothinstead.
4.
Before storing it, make sure this product is clean and dry.
5.
Disassemble this product to wash the components by the following
steps:
1 Firstremovethe plungerandtray.
2
Press down and hold the locking
button ,and rotate the drum
clockwise to remove it.
Afterremovingextractor,detachthe
end cap ,juice screen and auger in turn, all
removable components can be washed
withwater.
WARNING
Do not immerse the motor base in water or any other liquid. Do not use
water jet to clean the motor base.
3

14
Section VII. Safety Index
Rated Voltage
120V ~
Rated Power
150W
Rated Frequency
60Hz
Continuous Operating Time
Interval Time
Juice Container
6
50ml
Pomace Container
1000
ml
≤10 minutes
≥20 minutes

15
Section VIII.Trouble Shooting
Fault
Phenomenon
Analysis of cause Fault resolution
After connecting
power supply
and turning on
the switch, the
product failsto
work
1. The power plug is not
plugged in properly.
2. The outlet is in poor
contact.
3. The internal cable of
the main unit is off or the
circuit board is damaged
1. Re-plug it properly
2. Replace the socket and
try again,
3. Contact a fter Sales
Support Email:
[email protected].
During the early
uses, the motor
generates
unpleasant smell
It is a normal
phenomenon
If this phenomena occurs
frequently, send it to our
authorized service center
nearest toyoufor inspection.
This machine
stop during
operation
1.
Too lowvoltage
2. Excessiveamountof
food material hasbeen
loaded
3.
The machine has
operated continuously
for long time.
1.
Check whether thevoltage
is too low
2.
Disconnect the power
supply and remove
excessive foodmaterial
3.
It is a normal phenomenon
andthemotorwillresume
after a breaktime.
Noise is
generated
during
operation.
1.
The machine operates
inanunbalancedstate
due tofailure to
mount
augerorjuice
filterinplace.
2.
The starting motor in
theframe hasbeen
damaged.
1.
Mount
auger
or juice
filter in place or
Contact a fter Sales
Support Email:
[email protected].

16
Warranty
Thank you for purchasing our product, which has been made to meet high
quality standards. The manufacturer's warranty covers the product for a
period of 12 months from the date of purchase against manufacturing faults.
All Amzchef warranties are automatically kept track of in our system, so there
is no need to register your product.
Due to continuous product improvement, we reserve the right to change the
product specification without prior notice.
Article:
Model:
Owner s Name:
‘
‘
Address:
Address:
Tel:
Purchase Date:
Dealer s Name&Stamp:
Tel:
Please fill in this table and email within 10 days from the date of purchase.
For 12 months' extra free warranty, please register at our official website
www.iamzchef.com or fill in and take picture of bellow Warranty Card sending
to [email protected].
