Analog Devices EVAL-ADF411xEBZ1 User manual

Evaluation Board User Guide
UG-161
One Technology Way •P. O. Box 9106 •Norwood, MA 02062-9106, U.S.A. •Tel: [phone] •Fax: [phone] •www.analog.com
PLL Frequency Synthesizer Evaluation Board
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS. Rev. 0 | Page 1 of 12
FEATURES
General-purpose PLL evaluation board (the synthesizer, VCO,
and loop filter for generating generic PLL standards are
not included in the evaluation board package)
Compatible with
ADF4110, ADF4111
ADF4116, ADF4117
ADF4107
Accompanying software allows complete control of
synthesizer functions from a PC
Battery operated: choice of 3 V or 5 V supplies
Rogers material substrate for improved RF performance
GENERAL DESCRIPTION
The EVAL-ADF411xEBZ1 evaluation board is designed to evaluate
the performance of the ADF4110, ADF4111, ADF4116, ADF4117,
and ADF4107 frequency synthesizers for phase-locked loops
(PLLs). Figure 1 is the functional block diagram of the board
and shows the frequency synthesizer, a PC connector, and an
SMA connector for the reference input, the power supplies, and
an RF output. There are also footprints for a loop filter and a
voltage controlled oscillator (VCO) incorporated on the board. A
cable is included in the evaluation board package to connect the
evaluation board to a PC printer port.
The evaluation board package contains Windows® based software
to allow easy programming of the frequency synthesizer.
FUNCTIONAL BLOCK DIAGRAM
VCO
PC CONNECTOR
9V BATTERY
ADF411x
EVAL-ADF411xEBZ1
V
P
CE
MUXOUT
RF
OUT
REF
IN
V
VCO
V
DD
TCXO
SMA
SOCKET
POWERSWITCH
ON OFF
TEST
TEST FILTER
0
9146-001
Figure 1.
www.BDTIC.com/ADI

UG-161 Evaluation Board User Guide
Rev. 0 | Page 2 of 12
TABLE OF CONTENTS
Features .............................................................................................. 1
General Description ......................................................................... 1
Functional Block Diagram .............................................................. 1
Revision History ............................................................................... 2
Evaluation Board Hardware............................................................ 3
Hardware Description.................................................................. 3
Loop Design ...................................................................................3
Evaluation Board Software...............................................................5
Integer-N Software Description ..................................................5
Fractional-N Software Description.............................................6
Evaluation Board Schematics...........................................................7
Bill of Materials..................................................................................9
REVISION HISTORY
8/11—Revision 0: Initial Version
www.BDTIC.com/ADI

Evaluation Board User Guide UG-161
Rev. 0 | Page 3 of 12
EVALUATION BOARD HARDWARE
HARDWARE DESCRIPTION
The evaluation board package includes a cable for connecting the
EVAL-ADF411xEBZ1 to the printer port of a PC. The silkscreen
and cable diagram for the evaluation board are shown in Figure 2
and Figure 3. The test setup configuration is shown in Figure 4.
The board schematics are shown in Figure 7 and Figure 8.
09146-002
Figure 2. Evaluation Board Silkscreen
The evaluation board is powered from a single 9 V battery. The
power supply circuitry allows the user to individually choose
either 3 V or 5 V for the VDD of the frequency synthesizer, the
VPof the frequency synthesizer, and the supply of the VCO. The
default settings are 3 V for the VDD of the frequency synthesizer
and 5 V for the VPof the frequency synthesizer and for the
supply of the VCO.
It is important to note that the VDD of the frequency synthesizer
should never exceed the VPof the frequency synthesizer because
damage to the device may result.
All components necessary for LO generation are catered for on
board. A temperature compensated crystal oscillator (TCXO)
connector provides the necessary reference input. The PLL
comprises the frequency synthesizer, the passive loop filter, and
the VCO. The output is available at RFOUT through a standard
SMA connector. A different reference input and different power
supplies than those included with the evaluation board package
can be used, if desired. In this case, insert SMA connectors as
shown in the silkscreen (Figure 2) and the cable diagram (Figure 3).
114
215
316
417 PC
5
1
2
3
4
6
7
8
9518
619
720
821
922
10 23
11 24
12
PURPLE
BLUE
YELLOW
RED—LE
BLACK—CLK
BROWN—DATA
ORANGE—CE
WHITE—GND
13 25
25-WAY
MALE D-TYPE
TO
PC PRINTER PORT
9-WAY
FEMALE D-TYPE
TO
ADF411x
EVALUATION
BOARD
E
V
A
L-ADF411xEBZ1
0
9146-003
Figure 3. PC Cable Diagram
LOOP DESIGN
The evaluation board package does not include a VCO, loop
filter, or frequency synthesizer. The frequency synthesizer and
VCO are chosen by the user, depending on the frequency and
application requirements. The filter can then be designed based
on these requirements by using the ADIsimPLL software. This
software, which is provided on the CD-ROM included in the
evaluation board package, allows the user to enter the loop
parameters. The software then designs the filter and shows the
frequency and time domain analysis of the filter response. The
software also offers useful schematic and report options.
www.BDTIC.com/ADI

UG-161 Evaluation Board User Guide
Rev. 0 | Page 4 of 12
09146-006
OSCILLOSCOPE
SPECTRUM ANALYZER
PC CONNECTOR
9V BATTERY
ADF411x
EVAL-ADF411xEBZ1
MUXOUT
RF
OUT
POWER SWITCH
ON OFF
PC
VCO
TCXO
SMA
SOCKET
SMA
SOCKET
Figure 4. Evaluation Setup
www.BDTIC.com/ADI

Evaluation Board User Guide UG-161
Rev. 0 | Page 5 of 12
EVALUATION BOARD SOFTWARE
3. A dialog box appears asking which device is to be evaluated.
Select the appropriate device, and click OK. The Main
Interface Page window appears (see Figure 5).
INTEGER-N SOFTWARE DESCRIPTION
The Integer-N software is provided on the CD-ROM included
in the evaluation board package. 4. Click REF IN Frequency, and the Reference Frequency
window appears. Type the reference frequency into the
appropriate box, and click OK.
Installing the Software
To load the software, open the Integer-N Software folder,
double-click setup.exe, and then follow the on-screen instructions
from the installation wizard. The software is installed into the
default directory C:\Program Files\Analog Devices\ADF_Rev3.x\.
5. Click RF VCO Output Frequency, and the Output
Frequency window appears. Type the RF output frequency
and PFD reference frequency into the appropriate boxes,
and click OK.
Using the Software 6. Click RF Charge Pump Current Setting 2 or RF Charge
Pump Current Setting 1, and the Current Setting window
appears. Set the charge pump current setting to the value
used for the loop filter, and click OK.
To run the sof tware,
1. Ensure that the evaluation board is turned on and that the
interface cable is connected.
7. Click RF PD Polarity to set the RF PD polarity bit.
2. From the C:\Program Files\Analog Devices\ADF_Rev3.x\
directory, double-click ADF_Rev3_x.exe. The data is then set up, and other features can be examined.
09146-007
Figure 5. Main Interface Page Window
www.BDTIC.com/ADI

UG-161 Evaluation Board User Guide
Rev. 0 | Page 6 of 12
FRACTIONAL-N SOFTWARE DESCRIPTION
The Fractional-N software is provided on the CD-ROM included
in the evaluation board package.
Installing the Software
To load the software, open the Fractional-N Software folder,
double-click setup.exe, and then follow the on-screen instructions
from the installation wizard. The software is installed into the
default directory C:\Program Files\Analog Devices\ADF_Frac\.
Running the Software
To run the sof tware,
1. Ensure that the evaluation board is turned on and that the
interface cable is connected.
2. From the C:\Program Files\Analog Devices\ADF_Frac\
directory, double-click ADF_Frac_Revx.exe.
3. A dialog box appears asking which device is to be evaluated.
Select the appropriate device, and click OK. The Analog
Devices Evaluation Software window appears (see Figure 6).
4. Click RF VCO Output Frequency, and the Output
Frequency window appears. Type the RF output frequency,
PFD frequency, reference frequency, and channel spacing
into the appropriate boxes, and click Update RO and R1
and then Exit.
5. Click RF Charge Pump Current Setting, and the Current
Setting window appears. Set the charge pump current setting
to the value used for the loop filter, and click OK.
6. Click RF PD Polarity to set the RF PD polarity bit.
7. Click Update all RF Registers.
The data is then set up, and other features can be examined.
09146-008
Figure 6. Analog Devices Evaluation Software Window
www.BDTIC.com/ADI

Evaluation Board User Guide UG-161
Rev. 0 | Page 7 of 12
EVALUATION BOARD SCHEMATICS
09146-004
Figure 7. Evaluation Board Circuit Diagram (Page 1)
www.BDTIC.com/ADI

UG-161 Evaluation Board User Guide
Rev. 0 | Page 8 of 12
09146-005
Figure 8. Evaluation Board Circuit Diagram (Page 2)
www.BDTIC.com/ADI

Evaluation Board User Guide UG-161
Rev. 0 | Page 9 of 12
BILL OF MATERIALS
Table 1. Bill of Materials for the EVAL-ADF411xEBZ1
Name Part Type Value PCB Decal Stock Code SMD Assemble
C1 Capacitor 0805 Yes No
C2 Capacitor 0805 Yes No
C3 Capacitor 0805 Yes No
C4 Capacitor 0.1 F 0603 FEC 499-675 Yes Yes
C5 Capacitor 10 pF 0603 FEC 499-110 Yes Yes
C6 Capacitor 0.1 F 0603 FEC 499-675 Yes Yes
C7 Capacitor 10 pF 0603 FEC 499-110 Yes Yes
C8 Capacitor+ 22 µF, 6.3 V CAP\TAJ_A FEC 197-038 Yes Yes
C9 Capacitor 10 pF 0603 FEC 499-110 Yes Yes
C10 Capacitor 0.1 F 0603 FEC 499-675 Yes Yes
C11 Capacitor 10 pF 0603 FEC 499-110 Yes Yes
C12 Capacitor+ 22 F, 6.3V CAP\TAJ_A FEC 197-038 Yes Yes
C13 Capacitor 10 pF 0603 FEC 499-110 Yes Yes
C14 Capacitor 1 nF 0603 FEC 317-202 Yes Yes
C15 Capacitor 1 nF 0603 FEC 317-202 Yes Yes
C16 Capacitor 100 pF 0603 FEC 499-122 Yes Yes
C17 Capacitor 100 pF 0603 FEC 499-122 Yes Yes
C18 Capacitor 100 pF 0603 FEC 499-122 Yes Yes
C19 Capacitor 100 pF 0603 FEC 499-122 Yes Yes
C20 Capacitor+ 1 F CAP\TAJ_A FEC 498-701 Yes Yes
C21 Capacitor 10 nF 0603 FEC 499-146 Yes Yes
C22 Capacitor+ 4.7 F, 10 V CAP\TAJ_A FEC 498-658 Yes Yes
C23 Capacitor+ 1 F CAP\TAJ_A FEC 498-701 Yes Yes
C24 Capacitor 10 nF 0603 FEC 499-146 Yes Yes
C25 Capacitor+ 4.7 F, 10 V CAP\TAJ_A FEC 498-658 Yes Yes
D1 LED Green LED FEC 657-141 No No
D2 Diode DO35 FEC 365-117 No Yes
D3 SD103C 6.2 V DO35 SD103C No Yes
D4 LED Red LED FEC 657-130 No Yes
J1 CON-DB9HM DB9-HM FEC 150-750 No Yes
J2 SMA SMA_90DEG Pasternack PE4118 No Yes
J3 SMA SMA_90DEG Pasternack PE4118 No No
J4 SMA SMA_90DEG Pasternack PE4118 No No
J5 SMA SMA_90DEG Pasternack PE4118 No No
J6 SMA SMA_90DEG Pasternack PE4118 No No
J7 SMA SMA_90DEG Pasternack PE4118 No No
J8 SMA SMA_90DEG Pasternack PE4118 No No
J9 SMA SMA_90DEG Pasternack PE4118 No No
J10 SMA SMA_90DEG Pasternack PE4118 No No
LK1 JUMPER2\SIP3 LINK-3P FEC 512-047 and FEC 150-410 No Yes
LK2 JUMPER-2 JUMPER_2 FEC 12-035 and FEC 150-410 No Yes
LK3 JUMPER2\SIP3 LINK-3P FEC 512-047 and FEC 150-410 No Yes
LK4 JUMPER2\SIP3 LINK-3P FEC 512-047 and FEC 150-410 No Yes
LK5 JUMPER2\SIP3 LINK-3P FEC 512-047 and FEC 150-410 No Yes
P1 BATT_PP3 BATT_PP3 FEC 723-988 No Yes
P1 BATT_PP3 9 V Battery FEC 908-526 No Yes
R1A Resistor 0805 Yes No
R1 Resistor 0805 Yes No
R2 Resistor 0805 Yes No
R3 Resistor 4.7 kΩ 0603 FEC 911-318 Yes Yes
www.BDTIC.com/ADI

Name Part Type Value PCB Decal Stock Code SMD Assemble
R4 Resistor 330 Ω 0603 FEC 911-143 Yes Yes
R5 Resistor 330 Ω 0603 FEC 911-143 Yes Yes
R6 Resistor 330 Ω 0603 FEC 911-143 Yes Yes
R7 Resistor 18 Ω 0603 FEC 911-021 Yes Yes
R8 Resistor 18 Ω 0603 FEC 911-021 Yes Yes
R9 Resistor 18 Ω 0603 FEC 911-021 Yes Yes
R10 Resistor 51 Ω 0603 Digikey 311-51GCT-ND Yes Yes
R11 Resistor 10 kΩ 0603 FEC 911-355 Yes Yes
R12 Resistor 10 kΩ 0603 FEC 911-355 Yes Yes
R13 Resistor 10 kΩ 0603 FEC 911-355 Yes Yes
R14 Resistor 0 Ω 0603 FEC 772-227 Yes Yes
R15 Resistor 0 Ω 0603 FEC 772-227 Yes No
R16 Resistor 0 Ω 0603 FEC 772-227 Yes Yes
R17 Resistor 51 Ω 0603 Digikey 311-51GCT-ND Yes No
R18 Resistor 0 Ω 0603 FEC 772-227 Yes Yes
R19 Resistor 330 kΩ 0603 FEC 911-537 Yes Yes
R20 Resistor 330 kΩ 0603 FEC 911-537 Yes Yes
R21 Resistor 4.7 kΩ 0805 FEC 911-318 Yes Yes
S1 SW_POWER SW_SIP-3P FEC 150-559 No Yes
T1 Test point TESTPOINT FEC 240-345 No Yes
T2 Test point TESTPOINT FEC 240-345 No Yes
T3 Test point TESTPOINT FEC 240-345 No Yes
T4 Test point TESTPOINT FEC 240-345 No Yes
T5 Test point TESTPOINT FEC 240-345 No Yes
T6 Test point TESTPOINT FEC 240-345 No Yes
T7 Test point TESTPOINT FEC 240-345 No Yes
T8 Test point TESTPOINT FEC 240-345 No Yes
T9 Test point TESTPOINT FEC 240-345 No Yes
T10 Test point TESTPOINT FEC 240-345 No Yes
T11 Test point TESTPOINT FEC 240-345 No Yes
T12 Test point TESTPOINT FEC 240-345 No Yes
T13 Test point TESTPOINT FEC 240-345 No Yes
U1 ADF411x1TSSOP-16 Yes No
U2 ADP3300 SOT23-6 ADP3300ART-5 Yes Yes
U3 ADP3300 SOT23-6 ADP3300ART-3 Yes Yes
Y1 VCO19V-XXXXT VCO19V-XXXXT Yes No
Y2 OSC_TCXO 10.0 MHz OSC_TCXO T-1185 Yes Yes
1ADF411x = ADF4110, ADF4111, ADF4116, ADF4117, or ADF4107.
www.BDTIC.com/ADI
