Evaluating the ADuC7026 MicroConverter
Rev. B | Page 1 of 16
FEATURES
Full featured evaluation system for the ADuC7026
2-layer PCB (4” × 5” form factor)
9 V power supply regulated to 3.3 V on board
4-pin UART header to connect to RS-232 interface cable
20-pin standard JTAG connector
Demonstration circuit
32.768 kHz watch crystal to drive the PLL clock
ADR2912.5 V external reference chip
Reset/download/IRQ0 push-buttons
Power indicator/general-purpose LEDs
Access to all ADC inputs and DAC output from external
header. All device ports are brought out to external
header pins.
Surface-mount and through-hole general-purpose
prototype area
External memory and latch footprint
QUICKSTART DEVELOPMENT SYSTEM KIT
CONTENTS
ADuC7026 evaluation board
Serial download cable
International power supply
CD containing
evaluation software
ADuC7026 data sheet
example code
QUICKSTART PLUS DEVELOPMENT SYSTEM KIT
CONTENTS
ADuC7026 evaluation board
mIDAS-Link JTAG emulator
USB cable
Serial download cable
International power supply
CD containing
evaluation software
ADuC7026 data sheet
example code
GENERAL DESCRIPTION
This user guide, which replaces AN-744, refers to revision B2
of the ADuC7026 MicroConverter® evaluation boards. Two
models of the development kit are available: E VA L -ADuC7026QSZ
is the QuickStart™ Development System; E VA L -ADuC7026QSPZ
is the QuickStart Plus Development System. All references in
this user guide to the physical orientation of components on the
evaluation board are made with respect to a component-side
view of the board with the prototype area appearing at the
bottom of the board. The evaluation board is laid out to
minimize coupling between the analog and digital sections of
the board. To this end, the ground plane is split with the analog
section on the left side and a digital plane on the right side of
the board. The regulated 3.3 V power supply is routed directly
to the digital section and is filtered before being routed into the
analog section of the board.
EVALUATION BOARD
05032-101
Figure 1. Typical Evaluation Board

UG-669 EVAL-ADuC7026 User Guide
Rev. B | Page 2 of 16
TABLE OF CONTENTS
Features .............................................................................................. 1
QuickStart Development System Kit Contents ............................ 1
QuickStart Plus Development System Kit Contents.................... 1
General Description ......................................................................... 1
Evaluation Board .............................................................................. 1
Revision History ............................................................................... 2
Getting Started with the Evaluation Hardware ............................ 3
Power Supply................................................................................. 3
RS-232 Interface ........................................................................... 3
Emulation Interface...................................................................... 3
Crystal Circuit............................................................................... 3
External Reference (ADR291) .................................................... 3
Reset/Download/IRQ0 Push-buttons........................................ 3
Power Indicator/General-Purpose LEDs .................................. 4
Analog I/O Connections ............................................................. 4
General-Purpose Prototype Area............................................... 4
External Memory and Latch Footprint ..................................... 4
DIP Switch Link Options................................................................. 5
S1-1 VREF ........................................................................................ 5
S1-2 VOCM........................................................................................5
S1-3 POT ........................................................................................5
S1-4 ADC3 .....................................................................................5
S1-5 VIN− ......................................................................................5
S1-6 VIN+ ......................................................................................5
S1-7 ADC4 .....................................................................................5
S1-8 LED.........................................................................................5
External Connectors .........................................................................6
Analog I/O Connector J3 .............................................................6
Power Supply Connector J5 .........................................................6
Emulation Connector J4...............................................................6
Serial Interface Connector J1.......................................................6
Digital I/O Connector J2..............................................................6
External Memory Interface ..............................................................8
Connections ...................................................................................8
Potentiometer Demonstration Circuit ........................................ 10
Schematic and Artwork ................................................................. 11
Bill of Materials............................................................................... 13
REVISION HISTORY
2/14—Rev. A to Rev. B
Reorganized Layout (from AN-744 to UG-669)............Universal
Added Figure 1; Renumbered Sequentially and Changes to
General Description Section........................................................... 1
Change to Figure 6 ......................................................................... 12
Changes to Table 5.......................................................................... 13
2/07—Rev. 0 to Rev. A
Reorganized Layout............................................................Universal
Added Table 4 and changes to Figure 2......................................... 9
Changes to Figure 4........................................................................ 11
Changes to Table 5.......................................................................... 13
2004—Revision 0: Initial Version

EVAL-ADuC7026 User Guide UG-669
Rev. B | Page 3 of 16
GETTING STARTED WITH THE EVALUATION HARDWARE
POWER SUPPLY
Connect the 9 V power supply via the 2.1 mm input power
socket (J5). The input connector is configured as a center
negative, that is, as GND on the center pin and +9 V on the
outer shield.
The 9 V supply is regulated via the Linear Voltage Regulator U5.
The 3.3 V regulator output is used to drive the digital side of the
board directly. The 3.3 V supply is also filtered and then used to
supply the analog side of the board.
When on, the LED (D3) indicates that a valid 3.3 V supply is
being driven from the regulator circuit. All active components
are decoupled with 0.1 µF at device supply pins to ground.
RS-232 INTERFACE
The ADuC7026 (U1) P1.1 and P1.0 lines are connected to the
RS-232 interface cable via Connector J1. The interface cable
generates the required level shifting to allow direct connection
to a PC serial port. Ensure that the cable supplied is connected
to the board correctly, that is, DVDD is connected to DVDD
and DGND is connected to DGND.
EMULATION INTERFACE
Nonintrusive emulation and download are possible on the
ADuC7026, via JTAG, by connecting a JTAG emulator to the
J4 connector.
CRYSTAL CIRCUIT
The board is fitted with a 32.768 kHz crystal, from which the
on-chip PLL circuit can generate a 41.78 MHz clock.
EXTERNAL REFERENCE (ADR291)
The external 2.5 V Reference Chip U2 has two functions. It is
provided on the evaluation board to demonstrate the external
reference option of the ADuC7026,but its main purpose is
to generate the VOCM voltage of the differential amplifier if
required.
RESET/DOWNLOAD/IRQ0 PUSH-BUTTONS
A reset push-button is provided to allow the user to reset the
part manually. When the button is pushed, the reset pin of the
ADuC7026 is pulled to DGND. Because the reset pin on the
ADuC7026 is Schmidt triggered internally, there is no need to
use an external Schmidt trigger on this pin.
When pushed, the IRQ0 push-button switch drives P0.4/IRQ0
high. This can be used to initiate an external interrupt 0.
To enter serial download mode, the user must pull the P0.0/BM
pin low while reset is toggled. On the evaluation board, serial
download mode can easily be initiated by holding down the
serial download push-button (S2) while inserting and releasing
the reset button (S3) as shown in Figure 2.
S3
(RESET = 1) S2
(BM = 1)
(A) S3 AND S2 RELEASED
S2
(BM = 0)
S3
(RESET = 1)
(B) PUSH S2
S3
(RESET = 1) S2
(BM = 0)
(D) RELEASE S3
S2
(BM = 0)
S3
(RESET = 0)
(C) PUSH S3
S2
(BM = 1)
S3
(RESET = 1)
(E) RELEASE S2
05032-001
Figure 2. Entering Serial Download Mode on the Evaluation Board

UG-669 EVAL-ADuC7026 User Guide
Rev. B | Page 4 of 16
POWER INDICATOR/GENERAL-PURPOSE LEDS
A power LED (D3) is used to indicate that a sufficient supply is
available on the board. A general-purpose LED (D2) is directly
connected to P4.2 of the ADuC7026. When P4.2 is cleared, the
LED is turned on, and when P4.2 is set, the LED is turned off.
ANALOG I/O CONNECTIONS
All analog I/O connections are brought out on Header J3.
ADC0 and ADC1 are buffered using an AD8606 to evaluate
single-ended and pseudo differential mode. A potentiometer
can be connected to ADC0 (buffered).
ADC3 and ADC4 can be buffered with a single-ended to
differential op amp on-board, with the AD8132 used to evaluate
the ADC in fully differential mode.
ADC2 and ADC5 to ADC11 are not buffered. Be sure to follow
the data sheet recommendations when connecting signals to
these inputs.
DAC1 can be used to control the brightness of the LED D1,
when connected via the S1 switch.
GENERAL-PURPOSE PROTOTYPE AREA
General-purpose prototype areas are provided at the bottom
of the evaluation board for adding external components as
required in the user’s application. AVDD, AGND, VDDIO, and
DGND tracks are provided in the prototype area.
EXTERNAL MEMORY AND LATCH FOOTPRINT
Footprints for a 32 k × 16 static RAM (CY7C1020CV33), a
64 k × 16 flash (AT29LV1024), and a16-bit latch are also
on board. See the External Memory Interface section.

EVAL-ADuC7026 User Guide UG-669
Rev. B | Page 5 of 16
DIP SWITCH LINK OPTIONS
S1-1 VREF
Function
Connects the output of the 2.5 V external reference (ADR291)
to the VREF pin (Pin 68) of the ADuC7026.
Use
Slide S1-1 to the on position to connect the external reference
to the ADuC7026.
Slide S1-1 to the off position to use the internal 2.5 V reference
or a different external reference on the VREF pin of Header J3.
S1-2 VOCM
Function
Connects 1.67 V to the VOCM pin of the AD8132. No extra
dc voltage is required on the board to use the ADC in
differential mode.
Use
Slide S1-2 to the on position to connect VOCM of the differential
amplifier to the 1.67 V divided output of the ADR291reference.
Slide S1-2 to the off position to use a different voltage for VOCM
by connecting a dc voltage to the VOCM pin of Header J3. Note
that the VOCM value is dependent on the reference value, as
shown in Table 1.
Table 1. VOCM Range
VREF VOCM Minimum VOCM Maximum
2.5 V 1.25 V 2.05 V
2.048 V 1.024 V 2.276 V
1.25 V 0.75 V 2.55 V
S1-3 POT
Function
Connects the potentiometer output to ADC0. This input is
buffered by an AD8606. This is for demonstration purposes.
Use
Slide S1-3 to the on position to connect the potentiometer to
the op amp of the ADC0 input channel.
Slide S1-3 to the off position to use the ADC0 input on Header J3.
S1-4 ADC3
Function
Brings out ADC3 (Pin 80) on Header J3.
Use
Slide S1-4 to the on position to connect ADC3 of Header J3
directly to the ADC3 pin (Pin 80) of the ADuC7026.
Slide S1-4 to the off position to disconnect ADC3 of Header J3
from the ADC3 pin (Pin 80) of the ADuC7026.
S1-5 VIN−
Function
Connects the −OUT pin of the single-ended to differential op
amp (AD8132) to ADC3. S1-5 and S1-6 must be used together.
When VIN− is in the on position, VIN+ must also be in the on
position to use the differential op amp on Channel ADC3 and
Channel ADC4.
Use
Slide S1-5 to the on position to connect −OUT of the AD8132
to ADC3.
Slide S1-5 to the off position to use ADC3 without the AD8132.
S1-6 VIN+
Function
Connects the +OUT pin of the single-ended to differential op
amp (AD8132) to ADC4. When VIN+ is in the on position,
VIN− must also be in the on position to use the differential op
amp on Channel ADC3 and Channel ADC4.
Use
Slide S1-6 to the on position to connect +OUT of the AD8132
to ADC4.
Slide S1-6 to the off position to use ADC4 without the AD8132.
S1-7 ADC4
Use
Slide S1-7 to the on position to connect ADC4 of Header J3
directly to the ADC4 pin (Pin 1) of the ADuC7026.
Slide S1-7 to the off position to disconnect ADC4 of Header J3
from the ADC4 pin (Pin 1) of the ADuC7026.
S1-8 LED
Function
Connects the DAC1 output to the green LED of the
demonstration circuit, D1.
Use
Slide S1-8 to the on position to connect the DAC1 output to D1.
Slide S1-8 to the off position to use the DAC1 output on
Header J3.

UG-669 EVAL-ADuC7026 User Guide
Rev. B | Page 6 of 16
EXTERNAL CONNECTORS
ANALOG I/O CONNECTOR J3
Connector J3 provides external connections for all ADC inputs,
reference inputs and DAC outputs. The pinout of the connector
is shown in Table 2.
POWER SUPPLY CONNECTOR J5
Connector J5 allows for the connection between the evaluation
board and the 9 V power supply provided in the ADuC7026
development system.
EMULATION CONNECTOR J4
Connector J4 provides a connection of the evaluation board
to the PC via a USB cable and mIDAS link provided in the
ADuC7026 QuickStart Plus development system only.
SERIAL INTERFACE CONNECTOR J1
Connector J1 provides a simple connection of the evaluation
board to the PC via a PC serial port cable provided with the
ADuC7026 development system.
DIGITAL I/O CONNECTOR J2
Connector J2 provides external connections for all GPIOs. The
pinout of the connector is shown in Table 3.
Table 2. Pin Functions for Analog I/O Connector J3
Pin No. Pin Description
J3-1 AVDD
J3-2
AGND
J3-3 VREF
J3-4 DACREF
J3-5 ADC0
J3-6 ADC1
J3-7 ADC2
J3-8 ADC3
J3-9 ADC4
J3-10 ADC5
J3-11 ADC6
J3-12 ADC7
J3-13 ADC8
J3-14 ADC9
J3-15 ADC10
J3-16 ADC11
J3-17 VDIFF
J3-18 VOCM
J3-19
DAC0
J3-20 DAC1
J3-21 DAC2
J3-22 DAC3
J3-23 ADCNEG
J3-24 AGND

EVAL-ADuC7026 User Guide UG-669
Rev. B | Page 7 of 16
Table 3. Pin Functions for Digital I/O Connector J2
Pin No. Pin Description
J2-1 DGND
J2-2 P4.5
AD13/PLAO[13]
J2-3 P4.4
AD12/PLAO[12]
J2-4 P4.3
AD/11PLAO[11]
J2-5 P4.2
AD10/PLAO[10]
J2-6 P1.0
T1/SIN/SCL0/PLAI[0]
J2-7 P1.1
SOUT/SDA0/PLAI[1]
J2-8 P1.2
RTS/SCL1/PLAI[2]
J2-9
P1.3
CTS/SDA1/PLAI[3]
J2-10 P1.4
IRQ2/RI/CLK/PLAI[4]
J2-11 P1.5
IRQ3/DCD/MISO/PLAI[5]
J2-12 P4.1
AD9/PLAO[9]
J2-13 P4.0
AD8/PLAO[8]
J2-14 P1.6
DSR/MOSI/PLAI[6]
J2-15 P1.7
DTR/CSL/PLAO[0]
J2-16 P2.2
PWM0L/RS/PLAO[7]
J2-17 P2.1
PWM0H/WS/PLAO[6]
J2-18 P2.7
PWM1L/MS3
J2-19 P3.7
PWMSYNC/AD7/PLAI[15]
J2-20
P3.6
PWMTRIP/AD6/PLAI[14]
J2-21 P0.7
ECLK/XCLK/SIN/PLAO[4]
Pin No. Pin Description
J2-22 P2.0
CONVSTART/SOUT/PLAO[5]
J2-23 P0.5
IRQ1/ADCBUSY/MS0/PLAO[2]
J2-24 P0.4
IRQ0/PWMTRIP/MS1/PLAO[1]
J2-25 P3.5
PWM2L/AD5/PLAI[13]
J2-26 P3.4
PWM2H/AD4/PLAI[12]
J2-27 P2.6
PWM1H/MS2
J2-28 P2.5
PWM0L/MS1
J2-29 P0.3
TRST/A16/ADCBUSY
J2-30 P2.4
PWM0H/MS0
J2-31 P3.3
PWM1L/AD3/PLAI[11]
J2-32
P3.2
PWM1H/AD2/PLAI[10]
J2-33 P3.1
PWM0L/AD1/PLAI[9]
J2-34 P3.0
PWM0H/AD0/PLAI[8]
J2-35 P0.2
PWM2L/BHE
J2-36 P0.6
T1/MRST/AE/PLAO[3]
J2-37 P0.0
CMP/MS2/PLAI[7]
J2-38 P4.7
AD15/PLAO[15]
J2-39 P4.6
AD14/PLAO[14]
J2-40 P2.3
AE
J2-41 P0.1
PWM2H/BLE
J2-42 DGND

UG-669 EVAL-ADuC7026 User Guide
Rev. B | Page 8 of 16
EXTERNAL MEMORY INTERFACE
A footprint for a 32 k × 16 SRAM, a 64 k × 16 flash, and a
16-bit D-latch are provided on board because address and data
are multiplexed on the external bus.
The memory footprints are for a CY7C1020CV33 and
AT29LV1024. The latch footprint is for a 74LVT16373AGG.
Note that you can use different versions of the CY7C1020CV33
memory, with different access times. Wait states can be added in
the XMxPAR register to allow for interfacing to slower memory,
if required.
CONNECTIONS
Table 4.
Connection Description
Controls RS, WS, and AE are the minimum control signals of any memory interface.
MS0 and MS1, memory select signals, are connected to the CE of the SRAM and the flash, respectively, to enable the
memory when necessary.
BHE and BLE allows the high or low byte of the 16-bit SRAM to be selected.
Data 16 bits of address data, (AD[15:0]), are directly connected from the ADuC7026 to the memory circuitry.
Addresses 16 bits of address IO[16:1] are connected from the ADuC7026 to AD[15:0] of the memory devices. AD[0] addresses a byte.
To address the 32 k of the SRAM only, 14-bit addresses are required.
15-bit addresses are required for the 64 k flash.

EVAL-ADuC7026 User Guide UG-669
Rev. B | Page 9 of 16
05032-002
U7 DECOUPLING CAPACITORS U8 DECOUPLING CAPACITORS U6 DECOUPLING CAPACITORS
5A0
4A1
3A2
2A3
18 A4
44 A5
43 A6
42 A7
27 A8
26 A9
25 A10
24 A11
21 A12
20 A13
19 A14
6CE
41 OE
17 WE
29
IO9
8
IO2 9
IO3 10
IO4 13
IO5 14
IO6 15
IO7 16
IO8
33
VCC
12
VSS
38
IO16
40 BHE
7
IO1
30
IO10 31
IO11 32
IO12 35
IO13 36
IO14 37
IO15
11
VCC
39 BLE 34
VSS
U8
CY7C1020CV33-12
47 1D0
46 1D1
44 1D2
43 1D3
41 1D4
40 1D5
38 1D6
37 1D7
36 2D0
35 2D1
33 2D2
32 2D3
30 2D4
29 2D5
27 2D6
11OE
24 2OE
25 2LE
13
2Q0
3
1Q1 5
1Q2 6
1Q3 8
1Q4 9
1Q5 11
1Q6 12
1Q7
15
GND
28
GND
23
2Q7
2
1Q0
14
2Q1 16
2Q2 17
2Q3 19
2Q4 20
2Q5 22
2Q6
10
GND
34
GND
26 2D7
48 1LE
7VCC
18 VCC
31 VCC
42 VCC
21
GND
39
GND 45
GND
4
GND
U7
74LVT16373ADGG
C25
0.1µF
C26
0.1µF
C27
0.1µF
C28
0.1µF
C29
0.1µF
C30
0.1µF
2A0
3A1
4A2
5A3
6A4
7A5
9A6
10 A7
11 A8
12
VSS
13 A9
14 A10
15 A11
17 A12
18 A13
19 A14
20 A15
22 WE
23 VCC
27 CE
28
O15
29
O14
30
O13
31
O12
32
O11
34
O10
35
O9
36
O8
37
VSS
38
O7
39
O6
40
O5
42
O4
43
O3
44
O2
45
O1
46
O0
47
OE
U6
AT29LV1024
C31
0.1µF
R23
0Ω
A
D[0:15]
VDDIO
ADR[0:15]
ADR0
ADR1
ADR2
ADR3
ADR4
ADR5
ADR6
ADR7
ADR8
ADR9
ADR10
ADR11
ADR12
ADR13
ADR14
BLE
BHE
WS
RS
MS0
ADR0
ADR1
ADR2
ADR3
ADR4
ADR5
ADR6
ADR7
ADR8
ADR9
ADR10
ADR11
ADR12
ADR13
ADR14
AE
VDDIO
AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
AD10
AD11
AD12
AD13
AD14
AD15
AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
AD10
AD11
AD12
AD13
AD14
AD15
VDDIO VDDIO
ADR15
MS1
WS
RS
VDDIO
ADR0
ADR1
ADR2
ADR3
ADR4
ADR5
ADR6
ADR7
ADR8
ADR9
ADR10
ADR11
ADR12
ADR13
ADR14
ADR15
AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
AD10
AD11
AD12
AD13
AD14
AD15
VDDIO
Figure 3. External Memory Connections

UG-669 EVAL-ADuC7026 User Guide
Rev. B | Page 10 of 16
POTENTIOMETER DEMONSTRATION CIRCUIT
By using the sample code in pot.c located in the code example
folder on the accompanying CD, the variation in the
potentiometer resistance can be seen on the output LED.
Note that the internal and external reference are 2.5 V,
which gives an ADC input range of 0 V to 2.5 V in single-ended
mode. The potentiometer can give a voltage between 0 V and
AVDD = 3.3 V.
AVDD
AVDD
APPLICATION
CODE
DACADC
05032-003
Figure 4. Circuit Diagram of the RTD Circuit
