ADSP-BF533 EZ-KIT Lite®
Evaluation System Manual
Revision 3.2, July 2012
Part Number
82-000730-01
Analog Devices, Inc.
One Technology Way
Norwood, Mass. 02062-9106

Copyright Information
© 2012 Analog Devices, Inc., ALL RIGHTS RESERVED. This docu-
ment may not be reproduced in any form without prior, express written
consent from Analog Devices, Inc.
Printed in the USA.
Disclaimer
Analog Devices, Inc. reserves the right to change this product without
prior notice. Information furnished by Analog Devices is believed to be
accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use; nor for any infringement of patents or other rights of
third parties which may result from its use. No license is granted by impli-
cation or otherwise under the patent rights of Analog Devices, Inc.
Trademark and Service Mark Notice
The Analog Devices logo, Blackfin, CrossCore, EngineerZone, EZ-KIT
Lite, and VisualDSP++ are registered trademarks of Analog Devices, Inc.
All other brand and product names are trademarks or service marks of
their respective owners.

Regulatory Compliance
The ADSP-BF533 EZ-KIT Lite is designed to be used solely in a labora-
tory environment. The board is not intended for use as a consumer end
product or as a portion of a consumer end product. The board is an open
system design which does not include a shielded enclosure and therefore
may cause interference to other electrical devices in close proximity. This
board should not be used in or near any medical equipment or RF devices.
The ADSP-BF533 EZ-KIT Lite has been certified to comply with the
essential requirements of the European EMC directive 89/336/EEC
amended by 93/68/EEC and therefore carries the “CE” mark.
The ADSP-BF533 EZ-KIT Lite has been appended to Analog Devices,
Inc. Technical Construction File (TCF) referenced ‘DSPTOOLS1’ dated
December 21, 1997 and was awarded CE Certification by an appointed
European Competent Body as listed below.
Technical Certificate No: Z600ANA1.011
Issued by:
Technology International (Europe) Limited
60 Shrivenham Hundred Business Park
Shrivenham, Swindon, SN6 8TY, UK
The EZ-KIT Lite evaluation system contains ESD (electrostatic discharge)
sensitive devices. Electrostatic charges readily accumulate on the human
body and equipment and can discharge without detection. Permanent
damage may occur on devices subjected to high-energy discharges. Proper
ESD precautions are recommended to avoid performance degradation or
loss of functionality. Store unused EZ-KIT Lite boards in the protective
shipping package.

ADSP-BF533 EZ-KIT Lite Evaluation System Manual v
CONTENTS
PREFACE
Product Overview ......................................................................... xi
Purpose of This Manual .............................................................. xiii
Intended Audience ...................................................................... xiii
Manual Contents ......................................................................... xiv
What’s New in This Manual ......................................................... xiv
Technical Support ......................................................................... xv
Supported Processors .................................................................... xvi
Product Information .................................................................... xvi
Analog Devices Web Site ........................................................ xvi
EngineerZone ........................................................................ xvii
Related Documents .................................................................... xviii
Notation Conventions ................................................................ xviii
USING THE ADSP-BF533 EZ-KIT LITE
Package Contents .......................................................................... 1-3
Default Configuration ................................................................... 1-3
CCES Install and Session Startup .................................................. 1-5
Session Startup ........................................................................ 1-6

Contents
vi ADSP-BF533 EZ-KIT Lite Evaluation System Manual
VisualDSP++ Install and Session Startup ....................................... 1-9
CCES Evaluation License ........................................................... 1-10
VisualDSP++ Evaluation License ................................................. 1-11
Memory Map ............................................................................. 1-12
SDRAM Interface ....................................................................... 1-13
Flash Memory ............................................................................ 1-15
Flash Memory Map ............................................................... 1-15
Flash General-Purpose IO ..................................................... 1-16
Configuring Flash Memory ................................................... 1-19
LEDs and Push Buttons .............................................................. 1-19
Audio Interface ........................................................................... 1-20
Video Interface ........................................................................... 1-21
Board Design Database ............................................................... 1-22
Example Programs ...................................................................... 1-22
ADSP-BF533 EZ-KIT LITE HARDWARE REFERENCE
System Architecture ...................................................................... 2-2
External Bus Interface Unit ..................................................... 2-3
SPORT Audio Interface .......................................................... 2-3
SPI Interface ........................................................................... 2-4
Programmable Flags ................................................................ 2-4
PPI Interface ........................................................................... 2-5
Video Output Mode ........................................................... 2-7
Video Input Mode .............................................................. 2-7

ADSP-BF533 EZ-KIT Lite Evaluation System Manual vii
Contents
UART Port .............................................................................. 2-7
Expansion Interface ................................................................. 2-8
JTAG Emulation Port .............................................................. 2-8
Jumper and Switch Settings ........................................................... 2-9
UART Loop Jumper (JP4) ....................................................... 2-9
Boot Mode Switch (SW11) .................................................... 2-10
Test DIP Switches (SW1 and SW2) ........................................ 2-10
Video Configuration Switch (SW3) ....................................... 2-10
Push Button Enable Switch (SW9) ......................................... 2-11
SPIS1/SPISS Select Switch (SW10) ........................................ 2-12
SPORT0 Switch (SW12) ....................................................... 2-12
LEDs and Push Buttons .............................................................. 2-12
Programmable Flag Push Buttons (SW4–7) ............................ 2-13
Reset Push Button (SW8) ...................................................... 2-14
Power LED (LED1) ............................................................... 2-14
Reset LED (LED2) ................................................................ 2-14
User LEDs (LED4–9) ............................................................ 2-15
USB Monitor LED (ZLED3) ................................................. 2-15
Connectors ................................................................................. 2-16
Expansion Interface (J1–3) .................................................... 2-17
Audio (J4 and J5) .................................................................. 2-17
Video (J8) ............................................................................. 2-18
Power (J9) ............................................................................. 2-18
FlashLINK (P1) .................................................................... 2-19

Contents
viii ADSP-BF533 EZ-KIT Lite Evaluation System Manual
RS-232 (P2) ......................................................................... 2-19
SPORT1 (P3) ....................................................................... 2-20
JTAG (ZP4) .......................................................................... 2-20
SPI (P6) ................................................................................ 2-21
ADSP-BF533 EZ-KIT LITE BILL OF MATERIALS
ADSP-BF533 EZ-KIT LITE SCHEMATIC
INDEX

ADSP-BF533 EZ-KIT Lite Evaluation System Manual ix
PREFACE
Thank you for purchasing the ADSP-BF533 EZ-KIT Lite®, Analog
Devices, Inc. evaluation system for Blackfin®processors.
Blackfin processors embody a type of embedded processor designed specif-
ically to meet the computational demands and power constraints of
today’s embedded audio, video, and communications applications. They
deliver breakthrough signal-processing performance and power efficiency
within a reduced instruction set computing (RISC) programming model.
Blackfin processors support a media instruction set computing (MISC)
architecture. This architecture is the natural merging of RISC, media
functions, and digital signal processing (DSP) characteristics. Blackfin
processors deliver signal-processing performance in a microprocessor-like
environment.
Based on the Micro Signal Architecture (MSA), Blackfin processors com-
bine a 32-bit RISC instruction set, dual 16-bit multiply accumulate
(MAC) DSP functionality, and eight-bit video processing performance
that had previously been the exclusive domain of very-long instruction
word (VLIW) media processors.

x ADSP-BF533 EZ-KIT Lite Evaluation System Manual
The evaluation board is designed to be used in conjunction with the
CrossCore®Embedded Studio (CCES) and VisualDSP++®development
environments to test the capabilities of the ADSP-BF533 Blackfin proces-
sors. The development environment gives you the ability to perform
advanced application code development and debug, such as:
• Create, compile, assemble, and link application programs written
in C++, C, and ADSP-BF533 assembly
• Load, run, step, halt, and set breakpoints in application programs
• Read and write data and program memory
• Read and write core and peripheral registers
• Plot memory
Access to the ADSP-BF533 processor from a personal computer (PC) is
achieved through a USB port or an optional JTAG emulator. The USB
interface gives unrestricted access to the ADSP-BF533 processor and the
evaluation board peripherals. Analog Devices JTAG emulators offer faster
communication between the host PC and target hardware. Analog Devices
carries a wide range of in-circuit emulation products. To learn more about
Analog Devices emulators and processor development tools, go to
http://www.analog.com/dsp/tools.
The ADSP-BF533 EZ-KIT Lite provides example programs to demon-
strate the capabilities of the evaluation board.

ADSP-BF533 EZ-KIT Lite Evaluation System Manual xi
Preface
Product Overview
The board features:
• Analog Devices ADSP-BF533 Blackfin processor
• Performance up to 600 MHz
• 160-pin mini-BGA package
• 27 MHz CLKIN oscillator
• Synchronous dynamic random access memory (SDRAM)
• MT48LC32M16 - 64 MB (32M x 16 bits)
• Flash memories
• 2 MB (512K x 16 x 2chips)
• Analog audio interface
• AD1836 – Analog Devices 96 kHz audio codec
• 4 input RCA phono jacks (2 channels)
• 6 output RCA phono jacks (3 channels)
• Analog video interface
• ADV7183 video decoder w/ 3 input RCA phono jacks
• ADV7171 video encoder w/ 3 output RCA phono jacks
• Universal asynchronous receiver/transmitter (UART)
• ADM3202 RS-232 line driver/receiver
• DB9 male connector

Product Overview
xii ADSP-BF533 EZ-KIT Lite Evaluation System Manual
•LEDs
• 10 LEDs: 1 power (green), 1 board reset (red), 1 USB (red),
6 general-purpose (amber), and 1 USB monitor (amber)
• Push buttons
• 5 push buttons with debounce logic: 1 reset,
4 programmable flags
• Expansion interface
•PPI, SPI, EBIU, Timers2-0, UART, programmable flags,
SPORT0, SPORT1
• Other features
• JTAG ICE 14-pin header
The EZ-KIT Lite board has two flash memories with a total of 2 MB of
memory. The flash memories can be used to store user-specific boot code,
allowing the board to run as a stand-alone unit. For more information, see
“Flash Memory” on page 1-15. The board also has 64 MB of SDRAM,
which can be used by the user at runtime.
SPORTs interface with the AD1836 audio codec to aid development of
audio signal processing applications. SPORT0 also attaches to an off-board
connector for communication with other serial devices. For information
about SPORT0, see “SPORT Audio Interface” on page 2-3.
The parallel peripheral interface (PPI) of the processor connects to both a
video encoder and video decoder, facilitating development of video signal
processing applications.
The UART of the processor connects to an RS-232 line driver and a DB9
male connector, providing an interface to a PC or other serial device.
Additionally, the EZ-KIT Lite board provides access to most of the pro-
cessor’s peripheral ports. Access is provided in the form of a

ADSP-BF533 EZ-KIT Lite Evaluation System Manual xiii
Preface
three-connector expansion interface. For information about the expansion
interface, see “Expansion Interface” on page 2-8.
Purpose of This Manual
The ADSP-BF533 EZ-KIT Lite Evaluation System Manual provides
instructions for installing the product hardware (board). The text
describes the operation and configuration of the board components and
provides guidelines for running your own code on the ADSP-BF533
EZ-KIT Lite. Finally, a schematic and a bill of materials are provided as a
reference for future designs.
Intended Audience
The primary audience for this manual is a programmer who is familiar
with Analog Devices processors. This manual assumes that the audience
has a working knowledge of the appropriate processor architecture and
instruction set.
Programmers who are unfamiliar with Analog Devices processors can use
this manual but should supplement it with other texts that describe your
target architecture. For the locations of these documents, see “Related
Documents”.
Programmers who are unfamiliar with CCES or VisualDSP++ should refer
to the online help and user’s manuals.

Manual Contents
xiv ADSP-BF533 EZ-KIT Lite Evaluation System Manual
Manual Contents
The manual consists of:
• Chapter 1, “Using the ADSP-BF533 EZ-KIT Lite” on page 1-1
Describes the EZ-KIT Lite functionality from a programmer’s per-
spective and provides an easy-to-access memory map.
• Chapter 2, “ADSP-BF533 EZ-KIT Lite Hardware Reference” on
page 2-1
Provides information on the EZ-KIT Lite hardware components.
• Appendix A, “ADSP-BF533 EZ-KIT Lite Bill Of Materials” on
page A-1
Provides a list of components used to manufacture the EZ-KIT
Lite board.
• Appendix B, “ADSP-BF533 EZ-KIT Lite Schematic” on page B-1
Provides the resources to allow board-level debugging or to use as a
reference design. Appendix B is part of the online help.
What’s New in This Manual
This is revision 3.2 of the ADSP-BF533 EZ-KIT Lite Evaluation System
Manual. The manual has been updated to include CCES information.
Additional changes include the following.
• The “Configuring Flash Memory” section has been updated to
reflect obsoleted flash memory devices.
• Modifications and corrections based on errata reports against the
previous manual revision have been made.
For the latest version of this manual, please refer to the Analog Devices
Web site.

ADSP-BF533 EZ-KIT Lite Evaluation System Manual xv
Preface
Technical Support
You can reach Analog Devices processors and DSP technical support in
the following ways:
• Post your questions in the processors and DSP support community
at EngineerZone®:
http://ez.analog.com/community/dsp
• Submit your questions to technical support directly at:
http://www.analog.com/support
• E-mail your questions about processors, DSPs, and tools develop-
ment software from CrossCore Embedded Studio or
VisualDSP++:
Choose Help > Email Support. This creates an e-mail to
[email protected] and automatically attaches
your CrossCore Embedded Studio or VisualDSP++ version infor-
mation and license.dat file.
• E-mail your questions about processors and processor applications
to:
[email protected] or
[email protected] (Greater China support)
•IntheUSA only, call 1-800-ANALOGD (1-800-262-5643)
• Contact your Analog Devices sales office or authorized distributor.
Locate one at:
www.analog.com/adi-sales

Supported Processors
xvi ADSP-BF533 EZ-KIT Lite Evaluation System Manual
• Send questions by mail to:
Processors and DSP Technical Support
Analog Devices, Inc.
Three Technology Way
P.O. Box 9106
Norwood, MA 02062-9106
USA
Supported Processors
This evaluation system supports Analog Devices ADSP-BF533 Blackfin
embedded processors.
Product Information
Product information can be obtained from the Analog Devices Web site
and the online help system.
Analog Devices Web Site
The Analog Devices Web site, www.analog.com, provides information
about a broad range of products—analog integrated circuits, amplifiers,
converters, and digital signal processors.
To access a complete technical library for each processor family, go to
http://www.analog.com/processors/technical_library. The manuals
selection opens a list of current manuals related to the product as well as a
link to the previous revisions of the manuals. When locating your manual
title, note a possible errata check mark next to the title that leads to the
current correction report against the manual.
Also note, myAnalog is a free feature of the Analog Devices Web site that
allows customization of a Web page to display only the latest information

ADSP-BF533 EZ-KIT Lite Evaluation System Manual xvii
Preface
about products you are interested in. You can choose to receive weekly
e-mail notifications containing updates to the Web pages that meet your
interests, including documentation errata against all manuals.
myAnalog provides access to books, application notes, data sheets, code
examples, and more.
Visit myAnalog to sign up. If you are a registered user, just log on. Your
user name is your e-mail address.
EngineerZone
EngineerZone is a technical support forum from Analog Devices. It allows
you direct access to ADI technical support engineers. You can search
FAQs and technical information to get quick answers to your embedded
processing and DSP design questions.
Use EngineerZone to connect with other DSP developers who face similar
design challenges. You can also use this open forum to share knowledge
and collaborate with the ADI support team and your peers. Visit
http://ez.analog.com to sign up.

Related Documents
xviii ADSP-BF533 EZ-KIT Lite Evaluation System Manual
Related Documents
For additional information about the product, refer to the following
publications.
Notation Conventions
Text conventions used in this manual are identified and described as
follows.
Table 1. Related Processor Publications
Title Description
ADSP-BF531/ADSP-BF532/ADSP-BF533
Blackfin Embedded Processor Data Sheet
General functional description, pinout, and
timing of the processor
ADSP-BF533 Blackfin Processor Hardware
Reference
Description of the internal processor architec-
ture and all register functions
Blackfin Processor Programming Reference Description of all allowed processor assembly
instructions
Example Description
Close command
(File menu)
Titles in reference sections indicate the location of an item within the
development environment’s menu system (for example, the Close com-
mand appears on the File menu).
{this | that} Alternative required items in syntax descriptions appear within curly
brackets and separated by vertical bars; read the example as this or
that. One or the other is required.
[this | that] Optional items in syntax descriptions appear within brackets and sepa-
rated by vertical bars; read the example as an optional this or that.
[this,…] Optional item lists in syntax descriptions appear within brackets delim-
ited by commas and terminated with an ellipse; read the example as an
optional comma-separated list of this.
.SECTION Commands, directives, keywords, and feature names are in text with
letter gothic font.

ADSP-BF533 EZ-KIT Lite Evaluation System Manual xix
Preface
filename Non-keyword placeholders appear in text with italic style format.
Note: For correct operation, ...
A Note provides supplementary information on a related topic. In the
online version of this book, the word Note appears instead of this
symbol.
Caution: Incorrect device operation may result if ...
Caution: Device damage may result if ...
A Caution identifies conditions or inappropriate usage of the product
that could lead to undesirable results or product damage. In the online
version of this book, the word Caution appears instead of this symbol.
Warning: Injury to device users may result if ...
A Warning identifies conditions or inappropriate usage of the product
that could lead to conditions that are potentially hazardous for the
devices users. In the online version of this book, the word Warning
appears instead of this symbol.
Example Description




Notation Conventions
xx ADSP-BF533 EZ-KIT Lite Evaluation System Manual
