ADSP-BF506F EZ-KIT Lite®
Evaluation System Manual
Revision 1.1, July 2012
Part Number
82-000226-01
Analog Devices, Inc.
One Technology Way
Norwood, Mass. 02062-9106

Copyright Information
© 2012 Analog Devices, Inc., ALL RIGHTS RESERVED. This docu-
ment may not be reproduced in any form without prior, express written
consent from Analog Devices, Inc.
Printed in the USA.
Disclaimer
Analog Devices, Inc. reserves the right to change this product without
prior notice. Information furnished by Analog Devices is believed to be
accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use; nor for any infringement of patents or other rights of
third parties which may result from its use. No license is granted by impli-
cation or otherwise under the patent rights of Analog Devices, Inc.
Trademark and Service Mark Notice
The Analog Devices logo, Blackfin, CrossCore, EngineerZone,
EZ-Extender, EZ-KIT Lite, and VisualDSP++ are registered trademarks of
Analog Devices, Inc.
All other brand and product names are trademarks or service marks of
their respective owners.

Regulatory Compliance
The ADSP-BF506F EZ-KIT Lite is designed to be used solely in a labora-
tory environment. The board is not intended for use as a consumer end
product or as a portion of a consumer end product. The board is an open
system design which does not include a shielded enclosure and therefore
may cause interference to other electrical devices in close proximity. This
board should not be used in or near any medical equipment or RF devices.
The ADSP-BF506F EZ-KIT Lite has been certified to comply with the
essential requirements of the European EMC directive 2004/108/EC and
therefore carries the “CE” mark.
The ADSP-BF506F EZ-KIT Lite has been appended to Analog Devices,
Inc. EMC Technical File (EMC TF) referenced DSPTOOLS1, issue 2
dated June 4, 2008 and was declared CE compliant by an appointed Noti-
fied Body (No.0673) as listed below.
Notified Body Statement of Compliance: Z600ANA2.038 dated
June 21 2010.
Issued by: Technology International (Europe) Limited
56 Shrivenham Hundred Business Park
Shrivenham, Swindon, SN6 8TY, UK
The EZ-KIT Lite evaluation system contains ESD (electrostatic discharge)
sensitive devices. Electrostatic charges readily accumulate on the human
body and equipment and can discharge without detection. Permanent dam-
age may occur on devices subjected to high-energy discharges. Proper ESD
precautions are recommended to avoid performance degradation or loss of
functionality. Store unused EZ-KIT Lite boards in the protective shipping
package.

ADSP-BF506F EZ-KIT Lite Evaluation System Manual v
CONTENTS
PREFACE
Product Overview ........................................................................... xi
Purpose of This Manual ................................................................ xiii
Intended Audience ........................................................................ xiii
Manual Contents ........................................................................... xiv
What’s New in This Manual ........................................................... xiv
Technical Support ........................................................................... xv
Supported Processors ...................................................................... xvi
Product Information ...................................................................... xvi
Analog Devices Web Site .......................................................... xvi
EngineerZone .......................................................................... xvii
Related Documents ...................................................................... xviii
Notation Conventions .................................................................. xviii

Contents
vi ADSP-BF506F EZ-KIT Lite Evaluation System Manual
USING ADSP-BF506F EZ-KIT LITE
Package Contents ......................................................................... 1-2
Default Configuration .................................................................. 1-3
CCES Install and Session Startup .................................................. 1-3
Session Startup ........................................................................ 1-6
VisualDSP++ Install and Session Startup ....................................... 1-8
Session Startup ........................................................................ 1-9
CCES Evaluation License ........................................................... 1-10
VisualDSP++ Evaluation License ................................................. 1-11
Memory Map ............................................................................. 1-12
Internal Flash Memory Interface ................................................. 1-13
SPI Flash Memory Interface ........................................................ 1-13
Power-On-Self Test ..................................................................... 1-14
LEDs and Push Buttons .............................................................. 1-14
JTAG Interface ........................................................................... 1-15
Expansion Interface II ................................................................. 1-15
VDDINT Programmable Regulator ............................................ 1-16
Power Measurements .................................................................. 1-17
Example Programs ...................................................................... 1-18
Board Design Database ............................................................... 1-18

ADSP-BF506F EZ-KIT Lite Evaluation System Manual vii
Contents
ADSP-BF506F EZ-KIT LITE HARDWARE REFERENCE
System Architecture ...................................................................... 2-2
Programmable Flags ...................................................................... 2-3
Push Buttons and Switches ............................................................ 2-7
UART Setup Switch (SW1) ..................................................... 2-8
Boot Mode Select Switch (SW2) .............................................. 2-8
Push Button Enable Switch (SW3) ........................................... 2-9
ADC Enable Switch (SW4) ...................................................... 2-9
CAN Enable Switch (SW5) ...................................................... 2-9
Reset Push Button (SW6) ........................................................ 2-9
Programmable Flag Push Buttons (SW7–8) .............................. 2-9
ADC Loopback Switches (SW9–10) ....................................... 2-10
Jumpers ...................................................................................... 2-11
SPI FLASH CS Enable Jumper (JP1) ..................................... 2-11
Voltage Reference Select Jumper (JP2) ................................... 2-12
VDDEXT Power Jumper (JP3) .............................................. 2-12
VDDINT Power Jumper (JP4) .............................................. 2-12
VDDFLASH Power Jumper (JP5) .......................................... 2-12
ADC Voltage Reference (JP6) ................................................ 2-13
LEDs .......................................................................................... 2-14
Reset LED (LED1) ................................................................ 2-15
GPIO LEDs (LED2–4) ......................................................... 2-15
Power LED (LED5) ............................................................... 2-15

Contents
viii ADSP-BF506F EZ-KIT Lite Evaluation System Manual
Connectors ................................................................................. 2-16
RS-232 Connector (J1) ......................................................... 2-17
CAN Connector (J2) ............................................................ 2-17
SD Connector (J3) ................................................................ 2-17
JTAG Connector (P1) ........................................................... 2-17
Expansion Interface II Connectors (P2 and P4) ..................... 2-18
Expansion Interface II Connector (P3) .................................. 2-18
DMAX Land Grid Array Connectors (P5–6) ......................... 2-19
ADC Input Connector (P7) .................................................. 2-19
Power Connector (P9) ........................................................... 2-19
ADSP-BF506F EZ-KIT LITE BILL OF MATERIALS
ADSP-BF506F EZ-KIT LITE SCHEMATIC
INDEX

ADSP-BF506F EZ-KIT Lite Evaluation System Manual ix
PREFACE
Thank you for purchasing the ADSP-BF506F EZ-KIT Lite®, Analog
Devices, Inc. evaluation system for the ADSP-BF504/BF506F Blackfin®
processors.
Blackfin processors embody a type of embedded processor designed specif-
ically to meet the computational demands and power constraints of
today’s embedded audio, video, and communications applications. They
deliver breakthrough signal-processing performance and power efficiency
within a reduced instruction set computing (RISC) programming model.
Blackfin processors support a media instruction set computing (MISC)
architecture. This architecture is the natural merging of RISC, media
functions, and digital signal processing (DSP) characteristics. Blackfin
processors deliver signal-processing performance in a microprocessor-like
environment.
Based on the Micro Signal Architecture (MSA), Blackfin processors com-
bine a 32-bit RISC instruction set, dual 16-bit multiply accumulate
(MAC) DSP functionality, and eight-bit video processing performance
that had previously been the exclusive domain of very-long instruction
word (VLIW) media processors.

x ADSP-BF506F EZ-KIT Lite Evaluation System Manual
The evaluation board is designed to be used in conjunction with the
CrossCore®Embedded Studio (CCES) and VisualDSP++®development
environments to test capabilities of the ADSP-BF504/BF506F Blackfin
processors. The development environment aids advanced application code
development and debug, such as:
• Create, compile, assemble, and link application programs written
in C++, C, and ADSP-BF506F assembly
• Load, run, step, halt, and set breakpoints in application programs
• Read and write data and program memory
• Read and write core and peripheral registers
• Plot memory
Access to the processor from a personal computer (PC) is achieved
through a USB port or an external JTAG emulator. The USB interface
provides unrestricted access to the ADSP-BF506F processor and evalua-
tion board peripherals. Analog Devices JTAG emulators offer faster
communication between the host PC and target hardware. Analog Devices
carries a wide range of in-circuit emulation products. To learn more about
Analog Devices emulators and processor development tools, go to
http://www.analog.com/dsp/tools.
The ADSP-BF506F EZ-KIT Lite provides example programs to demon-
strate the evaluation board capabilities.

ADSP-BF506F EZ-KIT Lite Evaluation System Manual xi
Preface
Product Overview
The board features:
• Analog Devices ADSP-BF506F Blackfin processor
• Core performance up to 400 MHz
• External bus performance up to 80 MHz
• 120-pin LQFP package
•25MHzcrystal
• Programmable VDDINT core power
• Analog Devices AD5258 TWI digital potentiometer
• Analog Devices ADP1715 low dropout linear regulator
• Internal parallel flash memory
• Numonyx M58WT032 – 4 MB (2M x 16 bits)
• SPI flash memory
• Numonyx M25P16 – 16 Mb
• Internal ADC
• Analog Devices AD7266 2 MSPS, 12-bit, 3-channel SAR
analog-to-digital converter
• Twelve single-ended inputs
• Six differential inputs

Product Overview
xii ADSP-BF506F EZ-KIT Lite Evaluation System Manual
• Universal asynchronous receiver/transmitter (UART)
• ADM3202 RS-232 line driver/receiver
• DB9 female connector
•LEDs
• Five LEDs: one board reset (red), three general-purpose
(amber), and one power (green)
• Push buttons
• Three push buttons: one reset and two programmable flags
with debounce logic
• Expansion interface II
• Provides access to most of the processor signals
• Land grid array
• Easy probing of all port pins
• Other features
• JTAG ICE 14-pin header
• Processor power measurement jumpers
For information about the hardware components of the EZ-KIT Lite,
refer to Chapter 2, “ADSP-BF506F EZ-KIT Lite Hardware Reference”.

ADSP-BF506F EZ-KIT Lite Evaluation System Manual xiii
Preface
Purpose of This Manual
The ADSP-BF506F EZ-KIT Lite Evaluation System Manual provides
instructions for installing the product hardware (board). The text
describes operation and configuration of the board components and pro-
vides guidelines for running your own code on the ADSP-BF506F
EZ-KIT Lite. Finally, a schematic and a bill of materials are provided for
reference.
Intended Audience
The primary audience for this manual is a programmer who is familiar
with Analog Devices processors. This manual assumes that the audience
has a working knowledge of the appropriate processor architecture and
instruction set.
Programmers who are unfamiliar with Analog Devices processors can use
this manual but should supplement it with other texts that describe your
target architecture. For the locations of these documents, see “Related
Documents”.
Programmers who are unfamiliar with CCES or VisualDSP++ should refer
to the online help and user’s manuals.

Manual Contents
xiv ADSP-BF506F EZ-KIT Lite Evaluation System Manual
Manual Contents
The manual consists of:
• Chapter 1, “Using ADSP-BF506F EZ-KIT Lite” on page 1-1.
Describes EZ-KIT Lite functionality from a programmer’s perspec-
tive and provides an easy-to-access memory map.
• Chapter 2, “ADSP-BF506F EZ-KIT Lite Hardware Reference” on
page 2-1.
Provides information on the EZ-KIT Lite hardware components.
• Appendix A, “ADSP-BF506F EZ-KIT Lite Bill Of Materials” on
page A-1.
Provides a list of components used to manufacture the EZ-KIT
Lite board.
• Appendix B, “ADSP-BF506F EZ-KIT Lite Schematic” on
page B-1.
Provides the resources to allow board-level debugging or to use as a
reference guide. Appendix B is part of the online help.
What’s New in This Manual
This is revision 1.1 of the ADSP-BF506F EZ-KIT Lite Evaluation System
Manual. The manual has been updated to include CCES information. In
addition, modifications and corrections based on errata reports against the
previous manual revision have been made.
For the latest version of this manual, please refer to the Analog Devices
Web site.

ADSP-BF506F EZ-KIT Lite Evaluation System Manual xv
Preface
Technical Support
You can reach Analog Devices processors and DSP technical support in
the following ways:
• Post your questions in the processors and DSP support community
at EngineerZone®:
http://ez.analog.com/community/dsp
• Submit your questions to technical support directly at:
http://www.analog.com/support
• E-mail your questions about processors, DSPs, and tools develop-
ment software from CrossCore Embedded Studio or
VisualDSP++:
Choose Help > Email Support. This creates an e-mail to
[email protected] and automatically attaches
your CrossCore Embedded Studio or VisualDSP++ version infor-
mation and license.dat file.
• E-mail your questions about processors and processor applications
to:
[email protected] or
[email protected] (Greater China support)
•IntheUSA only, call 1-800-ANALOGD (1-800-262-5643)
• Contact your Analog Devices sales office or authorized distributor.
Locate one at:
www.analog.com/adi-sales

Supported Processors
xvi ADSP-BF506F EZ-KIT Lite Evaluation System Manual
• Send questions by mail to:
Processors and DSP Technical Support
Analog Devices, Inc.
Three Technology Way
P.O. Box 9106
Norwood, MA 02062-9106
USA
Supported Processors
This evaluation system supports Analog Devices ADSP-BF504,
ADSP-BF504F, and ADSP-BF506F Blackfin embedded processors.
Product Information
Product information can be obtained from the Analog Devices Web site
and the online help system.
Analog Devices Web Site
The Analog Devices Web site, www.analog.com, provides information
about a broad range of products—analog integrated circuits, amplifiers,
converters, and digital signal processors.
To access a complete technical library for each processor family, go to
http://www.analog.com/processors/technical_library. The manuals
selection opens a list of current manuals related to the product as well as a
link to the previous revisions of the manuals. When locating your manual
title, note a possible errata check mark next to the title that leads to the
current correction report against the manual.
Also note, myAnalog is a free feature of the Analog Devices Web site that
allows customization of a Web page to display only the latest information

ADSP-BF506F EZ-KIT Lite Evaluation System Manual xvii
Preface
about products you are interested in. You can choose to receive weekly
e-mail notifications containing updates to the Web pages that meet your
interests, including documentation errata against all manuals.
myAnalog provides access to books, application notes, data sheets, code
examples, and more.
Visit myAnalog (found on the Analog Devices home page) to sign up. If
you are a registered user, just log on. Your user name is your e-mail
address.
EngineerZone
EngineerZone is a technical support forum from Analog Devices. It allows
you direct access to ADI technical support engineers. You can search
FAQs and technical information to get quick answers to your embedded
processing and DSP design questions.
Use EngineerZone to connect with other DSP developers who face similar
design challenges. You can also use this open forum to share knowledge
and collaborate with the ADI support team and your peers. Visit
http://ez.analog.com to sign up.

Related Documents
xviii ADSP-BF506F EZ-KIT Lite Evaluation System Manual
Related Documents
For additional information about the product, refer to the following
publications.
Notation Conventions
Text conventions used in this manual are identified and described as
follows.
Table 1. Related Processor Publications
Title Description
ADSP-BF504/BF504F/BF506F Blackfin Embedded
Processor Data Sheet
General functional description, pinout, and
timing of the processor
ADSP-BF50x Blackfin Processor Hardware
Reference
Description of the internal processor archi-
tecture and all register functions
Blackfin Processor Programming Reference Description of all allowed processor assembly
instructions
Example Description
Close command
(File menu)
Titles in reference sections indicate the location of an item within the
development environment’s menu system (for example, the Close com-
mand appears on the File menu).
{this | that} Alternative required items in syntax descriptions appear within curly
brackets and separated by vertical bars; read the example as this or
that. One or the other is required.
[this | that] Optional items in syntax descriptions appear within brackets and sepa-
rated by vertical bars; read the example as an optional this or that.
[this,…] Optional item lists in syntax descriptions appear within brackets delim-
ited by commas and terminated with an ellipse; read the example as an
optional comma-separated list of this.

ADSP-BF506F EZ-KIT Lite Evaluation System Manual xix
Preface
.SECTION Commands, directives, keywords, and feature names are in text with
letter gothic font.
filename Non-keyword placeholders appear in text with italic style format.
Note: For correct operation, ...
A Note provides supplementary information on a related topic. In the
online version of this book, the word Note appears instead of this
symbol.
Caution: Incorrect device operation may result if ...
Caution: Device damage may result if ...
A Caution identifies conditions or inappropriate usage of the product
that could lead to undesirable results or product damage. In the online
version of this book, the word Caution appears instead of this symbol.
Warning: Injury to device users may result if ...
A Warning identifies conditions or inappropriate usage of the product
that could lead to conditions that are potentially hazardous for the
devices users. In the online version of this book, the word Warning
appears instead of this symbol.
Example Description




Notation Conventions
xx ADSP-BF506F EZ-KIT Lite Evaluation System Manual
