Analog devices Lite adsp-21375 ez-kit User guide

ADSP-21375 EZ-KIT Lite®

Evaluation System Manual

Revision 1.2, August 2012

Part Number

82-000940-02

Analog Devices, Inc.

One Technology Way

Norwood, Mass. 02062-9106

Downloaded from Arrow.com.

ment may not be reproduced in any form without prior, express written

consent from Analog Devices, Inc.

Printed in the USA.

Disclaimer

Analog Devices, Inc. reserves the right to change this product without

prior notice. Information furnished by Analog Devices is believed to be

accurate and reliable. However, no responsibility is assumed by Analog

Devices for its use; nor for any infringement of patents or other rights of

third parties which may result from its use. No license is granted by impli-

cation or otherwise under the patent rights of Analog Devices, Inc.

Trademark and Service Mark Notice

The Analog Devices logo, CrossCore, EngineerZone, EZ-KIT Lite,

SHARC, and VisualDSP++ are registered trademarks of Analog Devices,

Inc.

All other brand and product names are trademarks or service marks of

their respective owners.

Downloaded from Arrow.com.Downloaded from Arrow.com.

Regulatory Compliance

The ADSP-21375 EZ-KIT Lite is designed to be used solely in a labora-

tory environment. The board is not intended for use as a consumer end

product or as a portion of a consumer end product. The board is an open

system design which does not include a shielded enclosure and therefore

may cause interference to other electrical devices in close proximity. This

board should not be used in or near any medical equipment or RF devices.

The ADSP-21375 EZ-KIT Lite has been certified to comply with the

essential requirements of the European EMC directive 89/336/EEC

amended by 93/68/EEC and therefore carries the “CE” mark.

The ADSP-21375 EZ-KIT Lite has been appended to Analog Devices,

Inc. EMC Technical File (EMC TF) referenced ‘DSPTOOLS1’ dated

December 21, 1997 and was declared CE compliant by an appointed

Notified Body (No.0673) as listed below.

Notified Body Statement of Compliance: Z600ANA1.027

Issued by: Technology International (Europe) Limited

60 Shrivenham Hundred Business Park

Shrivenham, Swindon, SN6 8TY, UK

The EZ-KIT Lite evaluation system contains ESD (electrostatic discharge)

sensitive devices. Electrostatic charges readily accumulate on the human

body and equipment and can discharge without detection. Permanent

damage may occur on devices subjected to high-energy discharges. Proper

ESD precautions are recommended to avoid performance degradation or

loss of functionality. Store unused EZ-KIT Lite boards in the protective

shipping package.

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADSP-21375 EZ-KIT Lite Evaluation System Manual v

CONTENTS

PREFACE

Product Overview .......................................................................... x

Purpose of This Manual .............................................................. xiii

Intended Audience ...................................................................... xiii

Manual Contents ......................................................................... xiv

What’s New in This Manual ......................................................... xiv

Technical Support ......................................................................... xv

Supported Processors .................................................................... xvi

Product Information .................................................................... xvi

Analog Devices Web Site ........................................................ xvi

EngineerZone ........................................................................ xvii

Related Documents .................................................................... xviii

Notation Conventions ................................................................ xviii

USING THE ADSP-21375 EZ-KIT LITE

Package Contents .......................................................................... 1-2

Default Configuration ................................................................... 1-3

CCES Install and Session Startup .................................................. 1-4

Session Startup ........................................................................ 1-6

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Contents

vi ADSP-21375 EZ-KIT Lite Evaluation System Manual

VisualDSP++ Install and Session ................................................... 1-8

Session Startup ........................................................................ 1-9

CCES Evaluation License ........................................................... 1-10

VisualDSP++ Evaluation License ................................................. 1-11

External Memory ........................................................................ 1-12

ELVIS Interface .......................................................................... 1-13

Analog Audio ............................................................................. 1-14

LEDs and Push Buttons .............................................................. 1-15

Example Programs ...................................................................... 1-17

Board Design Database ............................................................... 1-17

ADSP-21375 EZ-KIT LITE HARDWARE REFERENCE

System Architecture ...................................................................... 2-2

External Port ........................................................................... 2-3

DAI Interface .......................................................................... 2-4

DPI Interface .......................................................................... 2-5

FLAG Pins .............................................................................. 2-6

External PLL ........................................................................... 2-7

Expansion Interface ................................................................. 2-7

JTAG Emulation Port ............................................................. 2-8

Switches ....................................................................................... 2-9

Boot Mode and Clock Ratio Select Switch (SW2) .................. 2-10

Codec Setup Switch (SW3) ................................................... 2-11

Electret Microphone Select Switch (SW4) .............................. 2-12

UART Enable Switch (SW5) ................................................. 2-12

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADSP-21375 EZ-KIT Lite Evaluation System Manual vii

Contents

Loopback Test Switches (SW6 and SW14) ............................. 2-12

Push Button Enable Switch (SW7) ......................................... 2-13

ELVIS Oscilloscope Configuration Switch (SW1) ................... 2-13

ELVIS Function Generator Configuration Switch (SW13) ...... 2-14

AD1835A and Flash Disconnect Switch (SW15) .................... 2-15

LEDs and Push Buttons .............................................................. 2-15

General Purpose LEDs (LED1–8) .......................................... 2-16

Power LED (LED9) ............................................................... 2-16

Reset LED (LED10) .............................................................. 2-16

USB Monitor LED (ZLED3) ................................................. 2-16

Push Buttons (SW8–11) ........................................................ 2-17

Board Reset Push Button (SW12) .......................................... 2-17

Jumpers ...................................................................................... 2-18

VCO Select Jumper (JP1) ...................................................... 2-19

ELVIS Select Jumper (JP2) .................................................... 2-19

ELVIS Voltage Selection Jumper (JP3) ................................... 2-20

ELVIS Programmable Flag Jumper (JP4) ................................ 2-20

Connectors ................................................................................. 2-21

Expansion Interface Connectors (J1–3) .................................. 2-22

Audio In RCA Connector (J10) ............................................. 2-22

Audio Out RCA Connector (J5) ............................................ 2-23

Headphone Out Jack (J9) ...................................................... 2-23

Power Jack (J4) ...................................................................... 2-23

S/PDIF Coax Connectors (J7 and J8) .................................... 2-24

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Contents

viii ADSP-21375 EZ-KIT Lite Evaluation System Manual

DPI Header (P3) ................................................................... 2-24

DAI Header (P4) .................................................................. 2-25

JTAG Header (ZP4) .............................................................. 2-25

ADSP-21375 EZ-KIT LITE BILL OF MATERIALS

ADSP-21375 EZ-KIT LITE SCHEMATIC

INDEX

ADSP-21375 EZ-KIT Lite Evaluation System Manual ix

PREFACE

Thank you for purchasing the ADSP-21375 EZ-KIT Lite®, Analog

Devices, Inc. evaluation system for SHARC®processors.

SHARC processors are based on a 32-bit super Harvard architecture that

includes a unique memory architecture comprised of two large on-chip,

dual-ported SRAM blocks coupled with a sophisticated I/O processor,

which gives a SHARC processor the bandwidth for sustained high-speed

computations. SHARC processors represents today’s de facto standard for

floating-point processing, targeted toward premium audio applications.

The evaluation system is designed to be used in conjunction with the

CrossCore®Embedded Studio (CCES) and VisualDSP++®development

environments to test capabilities of the ADSP-21375 SHARC processors.

The development environment aids advanced application code develop-

ment and debug, such as:

• Create, compile, assemble, and link application programs written

in C++, C, and ADSP-21375 assembly

• Load, run, step, halt, and set breakpoints in application program

• Read and write data and program memory

• Read and write core and peripheral registers

• Plot memory

Access to the ADSP-21375 processor from a personal computer (PC) is

achieved through a USB port or an external JTAG emulator. The USB

interface provides unrestricted access to the ADSP-21375 processor and

Product Overview

x ADSP-21375 EZ-KIT Lite Evaluation System Manual

evaluation board peripherals. Analog Devices JTAG emulators offer faster

communication between the host PC and target hardware. Analog Devices

carries a wide range of in-circuit emulation products. To learn more about

Analog Devices emulators and processor development tools, go to

http://www.analog.com/dsp/tools.

The ADSP-21375 EZ-KIT Lite provides example programs to demon-

strate the capabilities of the evaluation board.

Product Overview

The board features:

• Analog Devices ADSP-21375 processor

• 208-pin MQFP package

• 266 MHz core clock speed

• Synchronous dynamic random access memory (SDRAM)

• 2M x 16-bit x 4 banks

• Flash memory

• 1M x 8-bit

• Serial peripheral interface (SPI) flash memory

•2Mbit

ADSP-21375 EZ-KIT Lite Evaluation System Manual xi

Preface

• Analog audio interface

• Analog Devices AD1835A audio codec

• 4 x 2 RCA phono jack for four channels of stereo output

• 2 x 1 RCA phono jack for one channel of stereo input

• 3.5 mm headphone jack for one channel stereo output

• Universal asynchronous receiver/transmitter (UART)

• ADM3202 RS-232 driver/receiver

• DB9 female connector

• National Instruments Educational Laboratory Virtual Instrumen-

tation Suite (ELVIS) Interface

• LabVIEW™-based virtual instruments

• Multifunction data acquisition device

• Bench-top workstation and prototype board

•LEDs

• Eleven LEDs: one power (green), one board reset (red),

one USB monitor (amber), and eight general-purpose

(amber)

• Push buttons

• Five push buttons: one reset, two connected to DAI and

two connected to the FLAG pins of the processor

Product Overview

xii ADSP-21375 EZ-KIT Lite Evaluation System Manual

• Expansion interface (type A)

• Parallel port, FLAG pins, DPI, DAI

• Other features

• JTAG ICE 14-pin header

• Test points for processor current measurement

• DPI header

• DAI header

The EZ-KIT Lite board has a total of 1 MB of parallel flash memory and

2M bit of SPI flash memory. Flash memories can store user-specific boot

code and allow the board to run as a standalone unit. For more informa-

tion, see “External Memory” on page 1-12 and “Boot Mode and Clock

Ratio Select Switch (SW2)” on page 2-10. The board has 16 MB of

SDRAM, which can be used at runtime or from which code can be

executed.

The DAI port of the processor is connected to the AD1835A audio codec

and an external phase lock loop (PLL). The DAI interface facilitates devel-

opment of digital and analog audio signal-processing applications. See

“Analog Audio” on page 1-14 for more information.

The DPI port of the processor is connected to the UART and SPI inter-

faces. The UART interface can connect to a standard RS-232, while the

SPI connects to the 2M bit of serial flash memory.

Additionally, the EZ-KIT Lite board provides access to all of the proces-

sor’s peripheral ports. Access is provided in the form of a three-connector

expansion interface. See “Expansion Interface” on page 2-7 for details.

ADSP-21375 EZ-KIT Lite Evaluation System Manual xiii

Preface

Purpose of This Manual

The ADSP-21375 EZ-KIT Lite Evaluation System Manual provides

instructions for installing the product hardware (board). The text

describes operation and configuration of the board components and

provides guidelines for running your own code on the ADSP-21375

EZ-KIT Lite. Finally, a schematic and a bill of materials are provided for

reference.

Intended Audience

The primary audience for this manual is a programmer who is familiar

with Analog Devices processors. This manual assumes that the audience

has a working knowledge of the appropriate processor architecture and

instruction set.

Programmers who are unfamiliar with Analog Devices processors can use

this manual but should supplement it with other texts that describe your

target architecture. For the locations of these documents, see “Related

Documents”.

Programmers who are unfamiliar with CCES or VisualDSP++ should refer

to the online help and the user’s manuals.

Manual Contents

xiv ADSP-21375 EZ-KIT Lite Evaluation System Manual

Manual Contents

The manual consists of:

• Chapter 1, “Using the ADSP-21375 EZ-KIT Lite” on page 1-1

Provides information on the EZ-KIT Lite from a programmer’s

perspective and provides an easy-to-access memory map.

• Chapter 2, “ADSP-21375 EZ-KIT Lite Hardware Reference” on

page 2-1

Provides information on the hardware aspects of the evaluation

system.

• Appendix A, “ADSP-21375 EZ-KIT Lite Bill of Materials” on

page A-1

Provides a list of components used to manufacture the EZ-KIT

Lite board.

• Appendix B, “ADSP-21375 EZ-KIT Lite Schematic” on page B-1

Provides the resources to allow board-level debugging or to use as a

reference guide. Appendix B is part of the online help.

What’s New in This Manual

This is revision 1.2 of the ADSP-21375 EZ-KIT Lite Evaluation System

Manual. The manual has been updated to include CCES information.

Additional changes include the following.

• Modifications and corrections based on errata reports against the

previous manual revision have been made.

• Added note in the “System Architecture” section:

There is no S/PDIF interface on the ADSP-21375 processor.

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADSP-21375 EZ-KIT Lite Evaluation System Manual xv

Preface

For the latest version of this manual, please refer to the Analog Devices

Web site.

Technical Support

You can reach Analog Devices processors and DSP technical support in

the following ways:

• Post your questions in the processors and DSP support community

at EngineerZone®:

http://ez.analog.com/community/dsp

• Submit your questions to technical support directly at:

http://www.analog.com/support

• E-mail your questions about processors, DSPs, and tools develop-

ment software from CrossCore Embedded Studio or

VisualDSP++:

Choose Help > Email Support. This creates an e-mail to

processor.tools.support@analog.com and automatically attaches

your CrossCore Embedded Studio or VisualDSP++ version infor-

mation and license.dat file.

• E-mail your questions about processors and processor applications

to:

[email protected]m or

[email protected] (Greater China support)

•IntheUSA only, call 1-800-ANALOGD (1-800-262-5643)

• Contact your Analog Devices sales office or authorized distributor.

Locate one at:

www.analog.com/adi-sales

Supported Processors

xvi ADSP-21375 EZ-KIT Lite Evaluation System Manual

• Send questions by mail to:

Processors and DSP Technical Support

Analog Devices, Inc.

Three Technology Way

P.O. Box 9106

Norwood, MA 02062-9106

USA

Supported Processors

The ADSP-21375 EZ-KIT Lite evaluation system supports Analog

Devices ADSP-21375 SHARC processors.

Product Information

Product information can be obtained from the Analog Devices Web site

and the online help system.

Analog Devices Web Site

The Analog Devices Web site, www.analog.com, provides information

about a broad range of products—analog integrated circuits, amplifiers,

converters, and digital signal processors.

To access a complete technical library for each processor family, go to

http://www.analog.com/processors/technical_library. The manuals

selection opens a list of current manuals related to the product as well as a

link to the previous revisions of the manuals. When locating your manual

title, note a possible errata check mark next to the title that leads to the

current correction report against the manual.

ADSP-21375 EZ-KIT Lite Evaluation System Manual xvii

Preface

Also note, myAnalog is a free feature of the Analog Devices Web site that

allows customization of a Web page to display only the latest information

about products you are interested in. You can choose to receive weekly

e-mail notifications containing updates to the Web pages that meet your

interests, including documentation errata against all manuals.

myAnalog provides access to books, application notes, data sheets, code

examples, and more.

Visit myAnalog (found on the Analog Devices home page) to sign up. If

you are a registered user, just log on. Your user name is your e-mail

address.

EngineerZone

EngineerZone is a technical support forum from Analog Devices. It allows

you direct access to ADI technical support engineers. You can search

FAQs and technical information to get quick answers to your embedded

processing and DSP design questions.

Use EngineerZone to connect with other DSP developers who face similar

design challenges. You can also use this open forum to share knowledge

and collaborate with the ADI support team and your peers. Visit

http://ez.analog.com to sign up.

Popular Motherboard manuals by other brands

Asus

Asus Z9NR-D12 user guide

NXP Semiconductors

NXP Semiconductors EVB9S08DZ60 user manual

MSI

MSI K8NNeo4 Platinum Series user guide

Gigabyte

Gigabyte GA-8I915P Duo Pro-A user manual

ASROCK

ASROCK 775XFIRE-ESATA2 - 02-2006 user manual

MSI

MSI MPG B650I EDGE WIFI user guide

ASROCK

ASROCK X370M-HDV R4.0 manual

Silicon Laboratories

Silicon Laboratories CP2102N quick start guide

Ampro

Ampro LittleBoard800 Reference manual

ASROCK

ASROCK Z590M-ITX/ax user manual

CHAINTECH

CHAINTECH P4M266A user guide

TYAN

TYAN Toledo q35T user manual

MSI

MSI MS-98D2 manual

Intel

Intel D875PBZ - Desktop Board Motherboard Specification update

ASROCK

ASROCK Phantom Gaming 4/D5 Z690 manual

SOYO

SOYO SC-5EH5 User's guide & technical reference

ASROCK

ASROCK SBC-211M user manual

ON Semiconductor

ON Semiconductor NB4N11MDTEVB user manual

Analog Devices Lite ADSP-21375 EZ-KIT User guide

Popular Motherboard manuals by other brands
