1
dc2492af
DEMO MANUAL DC2492A
Description
LTC7000-1
Fast High Voltage Protected
High Side NMOS Static Switch Driver
Demonstration circuit 2492A is a 135V protected, high
side switch featuring the LT C
®
7000-1. The demo board is
designed to switch a 5.5A output load from input voltages
from 8V to 135V. The wide input range and low shutdown
current (1µA typical) make it suitable for automotive,
industrial, medical instrument and telecom applications.
This board offers a low 50ns (typical) propagation delay,
fast switching times (<10ns) and 100% duty cycleopera-
tion.
The LTC7000-1 is a fast high voltage protected high side
N-channel MOSFET driver with high voltage pin spacing
(0.657mm). An internal charge pump fully enhances an
external N-channel MOSFET switch, allowing it to remain
on indefinitely. A powerful gate driver can drive large gate
capacitance MOSFETs with very short transition times,
ideal for both high frequency switching and static switch
applications. The LTC7000-1 operates over a 3.5V to 135V
input supply range. When an external current sense resis-
tor and internal comparator sense that the switch current
has exceeded a preset level, a fault flag is asserted and
the switch is turned off after a period of time set by an
external timing capacitor. After a cooldown period, the
LTC7000-1 can be configured to automatically retry or
remain off until the input is re-cycled.
L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Analog
Devices, Inc. All other trademarks are the property of their respective owners.
performance summary
The demo board includes input capacitors and an output
diode to accommodate input and output supply induc-
tance when switching loads. The switch can be controlled
directly with external signal or using the on-board on/
off switch. A single-shot pulse generator is included for
evaluating switching times while limiting output power.
Optional auxiliary VCC input accommodates gate power
associated with high frequency switching. Positions for RC
delay network to control inrush current are alsoincluded.
The LTC7000-1 data sheet gives a complete description of
the part, operation and application information. The data
sheet must be read in conjunction with this demo manual
for demo circuit 2492A. Proper board layout is essential
for maximum thermal and electrical performance. See the
data sheet sections for details. The LTC7000-1 is available
in 16-lead MSOP package and three operating junction
temperature grades, extended and industrial from –40°C
to 125°C, high temp automotive version from –40°C to
150°C and a military grade from –55°C to 150°C.
Design files for this circuit board are available at
http://www.linear.com/demo/DC2492A
Specifications are at TA= 25°C
SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS
VIN Input Voltage 8.0 135 V
IOUT Output Current 5.5 A
Insertion Drop VIN – VOUT, 5.5A Load, Input to Output Terminals 150 mV
VIN Start-Up Voltage 100kΩ Load, VINP = 4V 7.0 8.0 V
VCCUV VCC Undervoltage Lockout VCC Rising
VCC Falling
Hysteresis
6.5
5.8
7.0
6.4
0.6
7.5
6.9
V
V
V
Overcurrent to VOUT Low Turn-On into a 10A Resistive Load 19 µs
Input to Output Propagation Delay VIN = 135V, 50Ω Load, INP = 2.2V to VOUT = 13.5V 50 ns
Output Rise Time VIN = 135V, 50Ω Load, 10% to 90% 6.5 ns

2
dc2492af
DEMO MANUAL DC2492A
DC2492 F01
+
–
+–
V
OUT
IOUT IIN
LOAD
+
–
+
–
+
–
VIN
+–
POWER
SUPPLY
Quick start proceDure
Refer to Figure 1 for proper measurement equipment
setup and follow the procedure below:
NOTE:When measuring the output voltage during switch-
ing transitions, care must be taken to avoid a long ground
lead on the oscilloscope probe. Measure the output volt-
age by touching the probe tip and ground ring directly
across the output capacitor as shown in Figure 2.
1. Place SW1 to OFF position. Move JP1 from the PULSE
(default position) to ON/OFF position (load on continu-
ously when SW1 is ON).
2. With input power supply set to zero volt and power off,
connect the input power supply to +VIN and GND.
3. With power off, connect load from +VOUT to GND.
4. Turn on the input power supply and increase the input
voltage slowly to 8V minimum. The input range is up
to 135V but hot-plugging with long leads may result
in input voltages in excess of 135V.
5. Place SW1 to ON position.
6. Check for the proper output voltage using a voltmeter.
Output voltage should be close to input voltage.
NOTE: If there is no output, temporarily disconnect the
load and cycle SW1 (the ON/OFF switch) or press reset
pushbutton SW2. If output is good, the load may be
set too high.
7. Once the proper output voltage is established, adjust
the load, if desired, to test current limit.
8. Placing SW1 to OFF position, moving JP1 to PULSE
position then placing SW1 in ON position will allow
pulse operation. Pushing SW2 will turn the high side
switch on for 300µs time.
9. Placing SW1 to OFF position, moving JP1 to INPUT
position connects INPUT terminal to LTC7000-1 INP
pin. An INPUT pin voltage of 2.2V or more will turn-on
the high side switch.
Figure 1. Proper Measurement Equipment Setup

3
dc2492af
DEMO MANUAL DC2492A
Quick start proceDure
typical performance charateristics
Figure 2. Measuring Output Voltage During Switching across C9. Note that C9 May Not Be Installed
Figure 3. Rise Time into 50Ω Load (VIN = 135V, VINP 5V/DIV, VOUT 50V/DIV, 10ns/DIV)
Figure 4. Board Photo
+ –
VOUT GND
C9
DC2492 F03
VOUT
50V/DIV
50Ω RESISTIVE LOAD
INP
5V/DIV

4
dc2492af
DEMO MANUAL DC2492A
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 5 C3, C4, C5, C7, C8 CAP., 1µF, X7T, 250V, 1812 TDK, C4532X7T2E105K250KA
2 2 C11, C14 CAP., 1000pF, X7R, 25V, 10%, 0603 MURATA, GRM188R71E102KA01D
3 1 C12 CAP., 0.1µF, X7R, 25V, 10%, 0805 AVX, 08053C104KAT2A
4 1 C13 CAP., 0.1µF, X7R, 200V, 10%, 1206 AVX, 12062C104KAT2A
5 1 C17 CAP., 1µF, X7R, 25V, 10%, 0805 AVX, 08053C105KAT2A
6 1 D1 DIODE, ES1PD, 200V, 1A, DO-220AA VISHAY, ES1PD-M3/84A
7 1 Q1 MOSFET, N-CH, 150V, POWERPAK-SO-8 FAIRCHILD, FDMS86250
8 1 R1 RES., SENSE, 0.004Ω, 1W, 2%, 2512 PANASONIC, ERJM1WTF4M0U
9 2 R7 RES., 100Ω, 1/10W, 1%, 0603 VISHAY, CRCW0603100RFKEA
10 1 R35 RES., 10Ω, 1/10W, 1%, 0603 VISHAY, CRCW060310R0FKEA
11 1 U1 IC, LTC7000EMSE-1, MSE-16L(12) LINEAR TECH., LTC7000EMSE-1#PBF
Additional Demo Board Circuit Components
1 1 C1 CAP., 10nF, X7R, 200V, 10%, 1206 AVX, 12062C103KAZ2A
2 1 C2 CAP., 22µF, ALUM, 160V, 20%, TH C-10X12.5 SUN ELECT., 160ME22HPC
3 0 C6, C9 CAP., OPTIONAL, 1812 OPTIONAL
4 0 C10 CAP., OPTIONAL, TH C-10X12 OPTIONAL
5 0 C16 CAP., OPTIONAL, 1206 OPTIONAL
6 2 C18, C19 CAP., 0.1µF, X7R, 25V, 10%, 0603 AVX, 06033C104KAT2A
7 0 C23 CAP., OPTIONAL, 0603 OPTIONAL
8 0 D2, D3, D4 DIODE, OPTIONAL, SOT23 OPTIONAL
9 1 D5 DIODE, MMSZ5V1T1, SOD-123 ON SEMICONDUCTOR, MMSZ5V1T1G
10 1 D6 DIODE, MMBD4148, SOT23 DIODES INC., MMBD4148-7-F
11 0 D7 DIODE OPTION, PDS4150, POWERDI5 OPTIONAL
12 0 D8 DIODE, OPTION, BAS21, SOT23 OPTIONAL
13 0 D9 DIODE., OPTION, CMMR1U, SOD-123F OPTIONAL
14 0 Q2 MOSFET, N-CH, 80V, PSOF08A FAIRCHILD, FDBL86361_F085
15 1 Q4 XSTR, PNP, 0.2A, MMBT3906, SOT23 FAIRCHILD, MMBT3906
16 1 Q5 MOSFET, P-CH, -200V, SOT23 DIODES INC., ZXMP2120FFTA
17 1 R2 RES., 0Ω, 1/10W, 1%, 0805 VISHAY CRCW08050000Z0EA
18 1 R4 RES., 100Ω, 1/2W, 5%, 1210 NIC, NRCP25J101TRF
19 7 R6, R12, R14, R22, R25, R45, R47 RES., 0Ω, 1/10W, 0603 VISHAY, CRCW06030000Z0EA
20 0 R9, R17 RES., OPTIONAL, 0805 OPTIONAL
21 0 R13, R18, R19, R33, R34, R36, R39 RES., OPTIONAL, 0603 OPTIONAL
22 5 R15, R21, R37, R38, R46 RES., 100k, 1/10W, 1%, 0603 VISHAY, CRCW0603100KFKEA
23 1 R23 RES., 787Ω, 1/10W, 1%, 0603 VISHAY, CRCW0603787RFKEA
parts list

5
dc2492af
DEMO MANUAL DC2492A
parts list
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
24 2 R27, R31 RES., 240k, 1/10W, 1%, 0805 VISHAY, CRCW0805240KFKEA
25 1 R28 RES., 976k, 1/10W, 1%, 0603 VISHAY, CRCW0603976KFKEA
26 1 R29 RES., 232k, 1/10W, 1%, 0603 VISHAY, CRCW0603232KFKEA
27 1 R30 RES., 182k, 1/10W, 1%, 0603 VISHAY, CRCW0603182KFKEA
28 1 R32 RES., SENSE, 0Ω, 1/2W, 1%, 1225 TEPRO, RN5326
29 1 SW1 SWITCH, SUB MINIATURE SLIDE C&K COMPONENTS, JS202011CQN
30 1 SW2 SWITCH, MICRO MINIATURE PUSHBUTTON TE CONNECTIVITY, FSM4JSMA
31 1 U2 IC, LTC6993CS6-3, TSOT23-6 LINEAR TECH., LTC6993CS6-3#PBF
Hardware: For Demo Board Only
1 8 E1-E8 TESTPOINT, TURRET 0.094" MILL MAX 2501-2-00-80-00-00-07-0
2 1 JP1 CONN., HEADER, 2X3, 2mm WURTH ELEKTRONIK, 62000621121
3 4 J1, J2, J3, J4 CONN, BANANA JACK KEYSTONE, 575-4
4 1 XJP1 SHUNT, 2mm WURTH ELEKTRONIK, 60800213421
5 4 MH1, MH2, MH3, MH4 STAND-OFF, NYLON 0.559" tall WURTH ELEKTRONIK, 702935500

6
dc2492af
DEMO MANUAL DC2492A
schematic Diagram
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
16V
2%
5%
Note: Unless otherwise specified: All resistors are in ohms, 1%, 0603. All capacitors are in microfarads 0603. All capacitors are 25V. 1/16W = 0402, 1/10W = 0603, 1/8W = 0805, 1/4W = 1206, 1/2W =1210, 1W = 2512. 1uF 250V TDK C4532X7T2E105K250KA (1812, X7T, -50% at 125V). 22uF 160V Sun Elect Ind 160ME22HPC (10X12.5,153mA at 120Hz). 5.1V Zener On Semi MMSZ5V1T1. 0 Ohm 1225 TEPRO RN5326 0.004ohms 1W Panasonic ERJM1WTF4M0U (2512). 100ohm 1210 NIC NRCP25J101TRF (0.5W, 400W for 0.1ms). Fairchild FDMS86250 (150V, 25mohmmax and 25nCtyp at 10V, 33mohmmax at 6V, Power56).
See Page 2 for SW1 (ON/OFF) and SW2 (PULSE)
Note: OPT = (OPT) = Optional = Not Used
2512
FAST HIGH VOLTAGE PROTECTED HIGH-SIDE NMOS STATIC SWITCH DRIVER
PULSE
ON/OFF INPUT
135VIN MAX
DANGER, HIGH VOLTAGE
Vccuv rising = 7.0V typ (7.5V max) Vccuv falling = 6.4V typ (5.8V min)
5.5A MAX
VCC
VCC
TD TS
TG
VIN2
VCC
BST
BST
+VOUT
VIN
TRIGOUTONOFF
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
2
Tuesday, August 15, 2017
12
KURK M.
N/A
LTC7000EMSE-1
LT
DC2492A
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
2
Tuesday, August 15, 2017
12
KURK M.
N/A
LTC7000EMSE-1
LT
DC2492A
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
2
Tuesday, August 15, 2017
12
KURK M.
N/A
LTC7000EMSE-1
LT
DC2492A
REVISION HISTORY DESCRIPTION DATEAPPROVEDECO REV
KURK M.
PRODUCTION2 08-15-17
__
REVISION HISTORY DESCRIPTION DATEAPPROVEDECO REV
KURK M.
PRODUCTION2 08-15-17
__
REVISION HISTORY DESCRIPTION DATEAPPROVEDECO REV
KURK M.
PRODUCTION2 08-15-17
__
R1
0.004
1W
R6
0
C14 1nF
J2
GND
R46
100K
R2 0 0805
J4
GND
R45
0
E4
GND
C23 OPT
R32
0
1225
C11
1nF
E2
GND
C6
250V
1812
OPT
R19
OPT
C7 1uF 1812
C9 OPT 1812
D1 ES1PD
U1
LTC7000EMSE-1
BST 12
VCC 3
SNS- 14
SNS+ 16
TGUP 10
VCCUV 5
TIMER
7
INP
8
GND
17
TS 11
TGDN 9
FAULT
6
VIN
1
R17
OPT
0805
D4
OPT
C17
1uF 0805
R35 10
R12
0
J3 +VOUT
C13
0.1uF
1206 200V
J1
+VIN
C16
OPT 1206
200V
R7
100
R18
OPT
JP1
MODE
12 34 56
R4 100 1210
E6
FAULT
E7
INPUT
+
C2
22uF
160V
C1
10nF 1206 200V
R47
0
C8 1uF 250V 1812
R14
0
R36
OPT
E3 +VOUT
C12
0.1uF
1206-0805
R39
OPT
E1
+VIN
E8
GND
Q1 FDMS86250
4
5
2 3
6 7 8
1
R15 100k

7
dc2492af
DEMO MANUAL DC2492A
Information furnished by Linear Technology Corporation is believed to be accurate and reliable.
However, no responsibility is assumed for its use. Linear Technology Corporation makes no representa-
tion that the interconnection of its circuits as described herein will not infringe on existing patent rights.
schematic Diagram
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
ON OFF
FAST HIGH VOLTAGE PROTECTED HIGH-SIDE NMOS STATIC SWITCH DRIVER
OPTIONAL ON/OFF and SINGLE SHOT
PowerDI5
SOT23 SOD-123F
PULSE or RESET
T=300us
5V
5V
5V
TRIGOUT
ONOFF
+VOUT
TS TG
VCC
TD
BST TG TS
VIN2VIN
VIN
VIN2
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
2
Tuesday, August 15, 2017
22
KURK M.
N/A
LTC7000EMSE-1
LT
DC2492A
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
2
Tuesday, August 15, 2017
22
KURK M.
N/A
LTC7000EMSE-1
LT
DC2492A
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
2
Tuesday, August 15, 2017
22
KURK M.
N/A
LTC7000EMSE-1
LT
DC2492A
SW1
JS202011CQN
4 1 5 2 6 3
E5
AUX_VCC
R34
OPT
R33 OPT
R38
100k
C5
250V
1812
1uF
D7 OPT
12
3
R25
0
R9 OPT 0805
Q4 MMBT3906
R22 0
R29
232k
SW2
FSM4JSMA
1 23
4
R23 787
R21
100K
+
C10 OPT
160V
U2
LTC6993CS6-3
TRG
1
GND
2
SET
3DIV 4
V+ 5
OUT 6
R30
182k
C4
250V
1812
1uF
Q2
OPT PSOF08
SD
G
R27 240K 0805
C19 0.1uF
D6
MMBD4148
D8
OPT
D2 OPT
D9
OPT
21
R37 100k
D5 5.1V
R13
OPT
D3
OPT (CMPZ5242B)
R28
976k
C3
250V
1812
1uF
C18 0.1uF
Q3 OPT POWERPAK-SO-8
4
5
2 3
6 7 8
1
Q5
ZXMP2120FF
R31 240K 0805

8
dc2492af
DEMO MANUAL DC2492A
 LINEAR TECHNOLOGY CORPORATION 2017
LT 0917 • PRINTED IN USA
DEMONSTRATION BOARD IMPORTANT NOTICE
Linear Technology Corporation (LTC) provides the enclosed product(s) under the following AS IS conditions:
This demonstration board (DEMO BOARD) kit being sold or provided by Linear Technology is intended for use for ENGINEERING DEVELOPMENT
OR EVALUATION PURPOSES ONLY and is not provided by LTC for commercial use. As such, the DEMO BOARD herein may not be complete
in terms of required design-, marketing-, and/or manufacturing-related protective considerations, including but not limited to product safety
measures typically found in finished commercial goods. As a prototype, this product does not fall within the scope of the European Union
directive on electromagnetic compatibility and therefore may or may not meet the technical requirements of the directive, or other regulations.
If this evaluation kit does not meet the specifications recited in the DEMO BOARD manual the kit may be returned within 30 days from the date
of delivery for a full refund. THE FOREGOING WARRANTY IS THE EXCLUSIVE WARRANTY MADE BY THE SELLER TO BUYER AND IS IN LIEU
OF ALL OTHER WARRANTIES, EXPRESSED, IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS
FOR ANY PARTICULAR PURPOSE. EXCEPT TO THE EXTENT OF THIS INDEMNITY, NEITHER PARTY SHALL BE LIABLE TO THE OTHER FOR
ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user releases LTC from all claims
arising from the handling or use of the goods. Due to the open construction of the product, it is the user’s responsibility to take any and all
appropriate precautions with regard to electrostatic discharge. Also be aware that the products herein may not be regulatory compliant or
agency certified (FCC, UL, CE, etc.).
No License is granted under any patent right or other intellectual property whatsoever. LTC assumes no liability for applications assistance,
customer product design, software performance, or infringement of patents or any other intellectual property rights of any kind.
LTC currently services a variety of customers for products around the world, and therefore this transaction is not exclusive.
Please read the DEMO BOARD manual prior to handling the product. Persons handling this product must have electronics training and
observe good laboratory practice standards. Common sense is encouraged.
This notice contains important safety information about temperatures and voltages. For further safety concerns, please contact a LTC application
engineer.
Mailing Address:
Linear Technology
1630 McCarthy Blvd.
Milpitas, CA 95035
Copyright © 2004, Linear Technology Corporation
