Analog way Rackmount Control Unit User manual

QUICK START GUIDE
Rackmount Control Unit –Ref. RCU300
Go to our website to register your
product(s) and be notified about
new firmware updates:
http://bit.ly/AW-Register
LEDs (see Section below)
Startup/Shutdown
Double Power Supplies
Connection panel
2 USB ports
USB Ports
Thank you for choosing Analog Way and the Rackmount Control Unit. By following these
simple steps, you will be able to install and use your RCU device.
RCU is a rack mountable master control unit that combine and control multiple Analog Way
LiveCoreTM image processors to create a large-scale system solution for video wall applications
that require a large amount of inputs, outputs and layers.
WHAT’S IN THE BOX
•1x Rackmount Remote Control Unit
•2x Power Supply cords
•1x RJ45 Ethernet cable
•1x Rack rail kit
•1x Screw kit
•1x Quick Start Guide*
•1x Safety instruction
*Quick Start Guide is available on www.analogway.com
PANEL DESCRIPTION
FRONT PANEL
REAR PANEL

SET UP THE RCU
Step 1 Take the inner member (smaller slide channel) apart by
sharply pulling the front activating release latch forward.
Step 2 Each slide is pre-attached with front and rear adjustable
brackets. Loosen the nuts on the both brackets, and
decide the proper setback distance to the opening, then
tighten the nuts on the front brackets.
Step 3 Extend the rear brackets to where it reaches the rear rack.
Do not fully tighten rear bracket screws until final adjustment is made.
Repeat step 2 & step 3 above for other side of outer slide member.
Step 4 For chassis width of 430mm, attach the L-shaped bracket to
the front mounting flange using screw & nylon ring from
screw kit (bar nut kit is optional for your selection).
For chassis width over 430mm, attach the L-shaped bracket
to the back of the mounting flange using screw & nylon ring
from screw kit.
Step 5 For chassis width of 430mm, attach the L-shaped bracket to
the rear mounting flange using & nylon ring from screw kit,
then tighten rear bracket mounting.
For chassis width over 430mm, attach the L-shaped bracket
to the back of the mounting flange screw & nylon ring from
screw kit.
Repeat step 4 & step 5 for the other side of the slide.
Step 6 Attach the inner slide member to your RCU using screw from
screw kit.

Step 7 Pick up the RCU and insert it with inner slide member into the
intermediate member. The RCU will be locked when it
reaches the fully open position, then pull forward on the front
activating release latch in order to push the RCU all the way
inward till the closed positon.
Step 8 Plug the mouse and the screen to your RCU.
Step 9 Plug the two Power Supply cords to the RCU and switch on the two Power Supplies.
Your RCU is now ready to be used!
LED indicator for operating system
Four LEDs are placed on the left side of the front panel to indicate system health and activity.
When the system power is on, the Power LED is GREEN.
If the Power LED is RED, it indicates a redundant power supply module failure. Examine the
redundant power supply right away and replace the failed module with a working one.
If the fan LED is RED, it indicates a failed cooling fan, and the alarm is also activated. Replace the
failed fan with a working one immediately.
If the temperature LED is RED, it means that inside of the chassis is overheated (more than 50°C).
An audible alarm will be activated. Inspect the fan filter and the rear section of the chassis
immediately. Make sure the airflow inside the chassis is smooth and not blocked by dust or other
particles.
LED
DESCRIPTION
GREEN
RED
System Power
Normal
Abnormal
Hard Drive Disk activity
Data Access
No light
Temperature in the chassis
Normal
Abnormal
Cooling fan status
Normal
Abnormal

SPECIFICATIONS
Dimensions (in Rack Units - RU)
2RU
Dimensions (without rack ears and rear rack
mount)
W 16.77’’ x H 3.46’’ x D 20.0’’
L 426 mm x H 88 mm x P 510 mm
Dimensions (with handles)
W 19’’ x H 3.46’’ x D 21.45’’
L 483 mm x H 88 mm x P 545 mm
Dimensions (without handles)
W 16.77’’ x H 3.46’’ x D 20.0’’
L 426 mm x H 88 mm x P 510 mm
Weight without accessories
11,7 kg / 24.25 lbs
Shipping weight accessories included
17,5 kg / 37.47 lbs
Operating conditions
Temperature: 0 to 40°C (32 to 104°F)
Humidity: 10% to 80%, non-condensing
Use: indoor
Warranty
3-year warranty on parts and labor back to factory
Noise (@1,6m height)
Front: 54 DBa@1m
Rear: 56 DBa@1m
Thermal dissipation
392 BTU/hr
Pollution degree
2
Electrical installation required
TT, TN or IT 230V for Norway (IEC60364-1)
Power Supply
100-240 VAC 50/60Hz 6A
Redundant power supplies, hot swappable
Max consumption: 115 W
Overvoltage category: II (IEC60664-1)
Safety Compliance
IEC/UL/EN 60950-1, CSA22.2#60950-1, ETL Listed (US
& Canada)
Supplied with
2 x Power supply cords
1 x Pair of front handles + screws
1 x Pair of rack slide rails
1 x Quick Start Guide*

TROUBLESHOOTING RCU
Should you encounter difficulty with your RCU device, please contact our technical support
department. See below for contact details.
CONTACT INFORMATION
The Americas Europe, Middle East & Africa Asia Pacific
Analog Way SAS - Headquarters
Tel.: [phone]
Fax: [phone]
2/4 rue GeorgesBesse
92160 Antony
FRANCE
Sales/General information:
[e-mail]
Technical support:
[e-mail]
Tel.: [phone]
Analog Way Inc.
Tel.: [phone]
Fax: [phone]
3047 Summer Oak Place
Buford, GA 30518
USA
Sales/General information:
[e-mail]
Technical support:
[e-mail]
Analog Way Pte Ltd
Tel.: [phone]
Fax: [phone]
152 Beach Road
#15-03 Gateway East
SINGAPORE 189721
Sales/General information:
[e-mail]
Technical support:
[e-mail]
09/01/2017
RCU - QSG
