Analog way Picturall Series User manual

1
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
Picturall Series Media Servers (V3.5)
References: MST02-R1, MSTC02-R1, MSQ04-R1, MSQC04-R1, MSP16-R1,
MST02-R2, MSTC02-R2, MSQ04-R2, MSQC04-R2, MSP16-R2,
MSTC02-MkII, MSQ04-MkII, MSQC04-MkII, MSP16-MkII
USER MANUAL

2
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
Information contained in this document, in particular data, pictures, information, trademarks and logos
are exclusive property of Analog Way and are protected by copyrights and other intellectual property
rights.
2018, Analog Way, all rights reserved –10/2022
Consequently, any representation and/or reproduction, in part or in full, is prohibited and would be
considered a violation of Analog Way’s copyright and other intellectual property rights.
Visual representations (diagrams, photos, icons, pictograms, screenshots, spare parts, etc.) are not
contractual.

3
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
Contents
1.1 Copyrights .....................................................................................................................................8
1.2 Media ............................................................................................................................................8
1.3 Warranty.......................................................................................................................................8
1.4 Liability..........................................................................................................................................8
1.5 Force Majeure...............................................................................................................................8
2.1 General safety instructions...........................................................................................................9
2.1.1 English.................................................................................................................................................... 9
2.1.2 French.................................................................................................................................................. 10
2.1.3 Italian................................................................................................................................................... 11
2.1.4 German................................................................................................................................................ 12
2.1.5 Spanish ................................................................................................................................................ 14
2.1.6 Symbols on product identification and warning labels ....................................................................... 15
2.1.7 Environmental specifications for all Picturall models.......................................................................... 17
3.1 Picturall Series Media Servers.....................................................................................................18
3.2 Package Contents........................................................................................................................18
3.3 Rack mount information.............................................................................................................18
3.4 Front panel..................................................................................................................................19
3.4.1 Display screen...................................................................................................................................... 19
3.4.2 Power off ............................................................................................................................................. 19
3.4.3 Forced shutdown................................................................................................................................. 19
3.5 Rear panels and Connections......................................................................................................20
3.5.1 Picturall Twin rear panel...................................................................................................................... 20
3.5.2 Picturall Twin Compact rear panel ...................................................................................................... 20
3.5.3 Picturall Twin Compact Mark II rear panel .......................................................................................... 21
3.5.4 Picturall Quad rear panel..................................................................................................................... 21
3.5.5 Picturall Quad Mark II rear panel ........................................................................................................ 22
3.5.6 Picturall Quad Compact rear panel ..................................................................................................... 22
3.5.7 Picturall Quad Compact Mark II rear panel ......................................................................................... 23
3.5.8 Picturall Pro rear panel........................................................................................................................ 23
3.5.9 Picturall Pro Mark II rear panel............................................................................................................ 24
3.5.10 Hardware and license options ............................................................................................................. 25
3.5.11 Audio support (optional) ..................................................................................................................... 25
4.1 Precautions when Mounting Picturall Series Media Server .......................................................26
4.2 Start the Picturall Series Media Server .......................................................................................26
5.1 Web configurator........................................................................................................................27
5.1.1 Dashboard ........................................................................................................................................... 27
5.1.2 Server configuration ............................................................................................................................ 28
5.1.3 LTC configuration................................................................................................................................. 28
5.1.4 Display configuration........................................................................................................................... 29
5.1.5 Custom display resolutions.................................................................................................................. 32
5.1.6 DMX Configuration .............................................................................................................................. 32
5.1.7 Audio configuration (optional) ............................................................................................................ 33
5.1.8 Network configuration ........................................................................................................................ 36
5.1.9 Time configuration .............................................................................................................................. 38
5.1.10 Synchronization settings...................................................................................................................... 38

4
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
5.1.11 Import and Export configuration......................................................................................................... 40
5.1.12 Format Media Drives - Storage configuration ..................................................................................... 41
5.1.13 Conflicting Settings.............................................................................................................................. 41
5.2 SPX graphics................................................................................................................................42
5.2.1 Adding new SPX templates and SPX content....................................................................................... 42
5.2.2 Adding SPX graphics to playback......................................................................................................... 44
5.2.3 Controlling SPX graphics with cues...................................................................................................... 51
5.3 User management.......................................................................................................................53
5.3.1 Create an admin user account............................................................................................................. 53
5.3.2 Log out - Close an admin user session................................................................................................. 53
5.3.3 Delete an admin user account............................................................................................................. 53
5.4 Manage firmware........................................................................................................................54
5.4.1 Firmware update ................................................................................................................................. 54
5.4.2 Remove uploaded firmware installer .................................................................................................. 54
5.4.3 Updating the Server Firmware with an USB drive............................................................................... 55
5.5 Media manager...........................................................................................................................57
5.5.1 Adding media files ............................................................................................................................... 57
5.5.2 Upload media files to specific folders.................................................................................................. 58
5.5.3 Contextual menus................................................................................................................................ 58
5.5.4 Fading settings..................................................................................................................................... 59
5.6 Configuration mode....................................................................................................................59
6.1 Installing / Updating Picturall Commander.................................................................................60
6.2 Connecting to Picturall Series Media Server...............................................................................61
6.3 User Interface .............................................................................................................................61
6.4 Control Tabs................................................................................................................................61
6.4.1 Arrange windows................................................................................................................................. 62
6.4.2 Reset windows..................................................................................................................................... 62
6.5 Preferences .................................................................................................................................62
6.6 Hotkeys .......................................................................................................................................62
7.1 Media types ................................................................................................................................63
7.2 Importing and encoding media files ...........................................................................................64
7.2.1 Import a local media file...................................................................................................................... 64
7.2.2 Import and encode a file to AWX format ............................................................................................ 65
7.2.3 Import an image sequence.................................................................................................................. 65
7.2.4 Import a media using FTP .................................................................................................................... 65
7.2.5 Reuse imported media files –Add server files to a media collection.................................................. 66
7.2.6 Encode a media file present on the server.......................................................................................... 66
7.2.7 Encoding media to AWX format without a Picturall Series Media Server........................................... 67
7.3 Edit server filenames and location..............................................................................................68
7.4 Add inputs to a media collection ................................................................................................68
7.5 Add web pages and video streams .............................................................................................68
7.5.1 Add a web page to a media collection ................................................................................................ 68
7.5.2 Import a web page using FTP .............................................................................................................. 69
7.5.3 Add FTP imported web page to a media collection............................................................................. 69
7.5.4 Add a URL video stream to the server................................................................................................. 69
7.5.5 Add an NDI video stream to the server ............................................................................................... 69

5
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
7.6 Add a custom text.......................................................................................................................70
7.7 Add SPX graphics.........................................................................................................................70
7.8 Manage Media Collections .........................................................................................................70
7.9 Default Media transition.............................................................................................................70
7.9.1 End action (Media) .............................................................................................................................. 70
7.9.2 Media Crossfade.................................................................................................................................. 71
7.9.3 Media Fade in / Fade out..................................................................................................................... 71
8.1 Display menu icons .....................................................................................................................73
8.2 Display adjustment tabs..............................................................................................................73
8.3 Test images .................................................................................................................................73
8.4 Positioning and Grouping Displays .............................................................................................74
8.4.1 Multi-display screen –Display wizard ................................................................................................. 75
8.4.2 Reset Display ....................................................................................................................................... 76
8.5 Optimize pixel space –GPUs tab ................................................................................................76
8.6 Edge Blending..............................................................................................................................76
8.6.1 Keystone and Angle Correction ........................................................................................................... 76
8.6.2 Edge Blending panel ............................................................................................................................ 77
8.6.3 Edge blending example........................................................................................................................ 77
8.7 Adjust curved surface projection –Warp correction..................................................................78
8.8 Vioso Autocalibration..................................................................................................................78
8.8.1 Autocalibration example for two projectors on a curved surface....................................................... 78
8.8.2 Vioso autocalibrated outputs in Picturall Commander ....................................................................... 90
8.9 Color correction (Display) ...........................................................................................................92
8.9.1 Adjust display color ............................................................................................................................. 92
8.9.2 Alpha display ....................................................................................................................................... 92
8.10 Crop display size..........................................................................................................................92
9.1 Layers tab....................................................................................................................................93
9.1.1 Layer List.............................................................................................................................................. 93
9.1.2 Layer Priority ....................................................................................................................................... 93
9.1.3 Layers adjustments.............................................................................................................................. 93
9.2 Select and play a media –Media selection.................................................................................94
9.2.1 Playback control .................................................................................................................................. 94
9.2.2 End action (Layer)................................................................................................................................ 94
9.2.3 Layer fading settings............................................................................................................................ 94
9.3 Composition................................................................................................................................95
9.3.1 Draw modes......................................................................................................................................... 96
9.3.2 Graph................................................................................................................................................... 97
9.3.3 Composition Advanced settings .......................................................................................................... 97
9.4 Color correction (layer)...............................................................................................................98
9.5 Advanced.....................................................................................................................................98
9.5.1 Synchronize to another layer .............................................................................................................. 98
9.5.2 Set layer Frame rate ............................................................................................................................ 98
9.6 Audio channel mixer (optional) ..................................................................................................99
9.7 Using Effects..............................................................................................................................100
9.7.1 Alpha Fill and Alpha Key –Cut & Fill..................................................................................................108
9.8 Layer macro...............................................................................................................................108

6
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
9.8.1 Create a layer macro ......................................................................................................................... 108
9.8.2 Load a layer macro ............................................................................................................................ 108
9.9Geometry ..................................................................................................................................109
9.10 Set default show on server boot –Export show.......................................................................109
10.1 Presentation..............................................................................................................................110
10.1.1 How cues work ..................................................................................................................................110
10.1.2 Timings (Wait, Fade and Hold) .......................................................................................................... 110
10.1.3 Trigger................................................................................................................................................ 112
10.2 Creating Cues ............................................................................................................................112
10.2.1 Create the first Cue............................................................................................................................ 112
10.2.2 Edit a Cue........................................................................................................................................... 113
10.3 Cue Stacks .................................................................................................................................113
10.3.1 Create a cue stack.............................................................................................................................. 113
10.3.2 Remove a cue from a cue stack......................................................................................................... 113
10.3.3 Change trigger type ........................................................................................................................... 113
10.3.4 Order cues in the stack –Index number............................................................................................ 113
10.4 Timing and Running Cues in Playback.......................................................................................114
10.5 Cue tracking ..............................................................................................................................114
10.5.1 Example without cue tracking ........................................................................................................... 115
10.5.2 Example with cue tracking enabled...................................................................................................115
10.5.3 Forward tracking................................................................................................................................ 115
10.5.4 Full tracking ....................................................................................................................................... 116
10.6 Triggering cues with Timecode .................................................................................................117
10.6.1 Cue programming with timecode...................................................................................................... 117
10.6.2 Set trigger timecoded with System Wallclock ................................................................................... 119
10.6.3 Media layer & Cue stack playback as timecode providers ................................................................ 120
10.6.4 Timecode generator .......................................................................................................................... 121
10.6.5 Midi Timecode (MTC) ........................................................................................................................ 121
10.6.6 Linear timecode (LTC)........................................................................................................................122
10.6.7 Synchronizing layer timecode over network ..................................................................................... 123
10.7 Scheduling cues and playback...................................................................................................123
10.7.1 Playback schedule view ..................................................................................................................... 126
10.7.2 Schedule export to PDF/CSV.............................................................................................................. 126
10.8 Show example...........................................................................................................................127
10.9 Live show recommendations....................................................................................................127
10.10 Cue macro.................................................................................................................................128
10.10.1 Cue macro and Cue stack macro ....................................................................................................... 128
10.10.2 Cue macro actions ............................................................................................................................. 129
10.10.3 Edit or remove a cue macro .............................................................................................................. 130
10.10.4 Create cue macros using Lua commands .......................................................................................... 130
10.11 Automatic show start on system start up.................................................................................131
11.1 Save a show...............................................................................................................................132
11.2 Sync card –Genlock (Picturall Pro only) ...................................................................................132
11.2.1 Genlock menu.................................................................................................................................... 132
11.2.2 House sync status LED .......................................................................................................................132
11.2.3 GPU sync status ................................................................................................................................. 132

7
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
11.2.4 Framelock menu on front panel display............................................................................................133
11.3 Performance .............................................................................................................................133
11.3.1 Toggle view........................................................................................................................................ 134
11.3.2 Refresh............................................................................................................................................... 134
11.3.3 Color .................................................................................................................................................. 134
11.4 Timecode out ............................................................................................................................134
11.5 Control Model...........................................................................................................................135
11.6 Commander Log........................................................................................................................135
12.1 User Maintenance –Air filter....................................................................................................136
12.1.1 Air filter cleaning - Picturall Twin, Quad and Pro............................................................................... 136
12.1.2 Air filter cleaning - Picturall Twin Compact and Quad Compact .......................................................136
12.2 System Diagnostics ...................................................................................................................136
12.3 Troubleshooting........................................................................................................................137

8
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
1 Disclaimer
The information in this document is subject to change without notice, while every effort is made to be
accurate. Analog Way cannot be held liable for any kind of loss whatsoever that may be caused by the use of
or reliance in this manual.
1.1 Copyrights
The Software installed in the Picturall Series Media Server remains the sole property of Analog Way unless
stated otherwise in a separate licensing agreement. Any attempt to copy or alter the software is prohibited
and will render any warranties void.
1.2 Media
Analog Way may have supplied video libraries pre-installed on the media server. If you have any questions
regarding them, please contact us. These videos have been licensed exclusively for use within the Picturall
Series Media Servers. Any copying or other usage without proper rights clearance is forbidden. Analog Way
will not accept any liability or claims from third parties.
1.3 Warranty
The Picturall Series Media Server has been tested in various applications and is deemed to be suitable for
uses described in this manual. This product is provided “as is”, including all or any ‘perceived’ or possible
faults. The Licensor grants no warranty regarding the utility or contents of the software. Analog Way will
warrant the hardware for three years from the date of purchase. The method of warranty is Return to Base
(transport costs from and to us are the owner’s responsibility). In case of hardware fault please contact your
local distributor or us (www.analogway.com).
While not an exhaustive list, the following are provided for guidance. Warranty claims will be invalidated in
these circumstances:
•A hardware failure is caused by inappropriate handling of hardware such as dropping the media
server, using the media server without proper ventilation, exposing the media server to water, other
liquids or dust.
•The software has been loaded or there has been an attempt to load software onto the media server
in any way other than described in the manual or recommended by Analog Way.
•The hardware has been modified by someone other than a certified Analog Way dealer.
1.4 Liability
Analog Way shall not be liable for any loss or damage, be it direct or indirect in regards to the utility or
contents of the software or hardware, except to the extent provided by law. Notwithstanding the above,
liability for indirect, special, incidental or consequential loss or damage that may arise in respect of the
software or hardware, is expressly excluded.
1.5 Force Majeure
Liability of Analog Way is excluded in all cases that constitute Force Majeure circumstances, namely,
circumstances beyond the control of Analog Way.

9
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
2 Hardware Specifications
2.1 General safety instructions
2.1.1 English
All of the safety and operating instructions should be read before the product is operated and should be
maintained for further reference. Please follow all of the warnings on this product and its operating
instructions.
• WARNING: Not suitable for children. To prevent the risk of electric shock and fire, do not expose this device
to rain, humidity or intense heat sources (such as heaters and direct sunlight). This equipment is not suitable
for use in locations where children are likely to be present.
• INSTALLATION: Slots and openings in the device are provided for ventilation and to avoid overheating.
Make sure the device is never placed near a textile surface that could block the openings. Also keep away
from excessive dust, vibrations and shocks.
• POWER: Only use the power supply indicated on the device of the power source. Devices equipped with a
grounding plug should only be used with a grounding type outlet. In no way should this grounding be
modified, avoided or suppressed. Connection of equipment to main supply must be after branch circuit
breaker of the building installation.
For equipment identified with the symbols above, grounding is mandatory before plug connection.
Use a grounding cable to connect a screw on the unit chassis to ground.
• POWER CORD: The device is equipped with one or multiple detachable power cords.
A device identified with the symbol above indicates that the equipment has multiple power cords. To remove
mains, disconnect all power cords at appliance coupler.
Caution: The power cords constitute the only mean to completely disconnect the equipment from the main power.
Use the following guidelines:
- The equipment connected to the network must have a release system easily accessible and located
outside the unit.
- Unplug the power from mains if the device will not be used for a few days or more.
- To unplug the power cords; do not pull on the power cords but always on the plug itself.
- The outlet should always be near the device and easily accessible.
- Power supply cords should be routed so that they are not likely to be walked on or pinched by items
placed upon or against them.
If one of the power supply cords is damaged, unplug the device. Using the device with a damaged power
supply cord may expose your device to electric shocks or other hazards. Verify the condition of the power
supply cords periodically. Contact your dealer or service center for replacement if damaged.
• CONNECTIONS: All inputs and outputs (except for the power input) are Electrical energy source class 1 (ES1)
as defined in IEC/UL 62368-1 edition 2.
ES1 limits: 60Vdc or 30V rms/ 42.4V peak.
• SERVICING: Disconnect all power supply cords from main before servicing.
According to IEC 62368-1 standard, an ordinary person is authorized to:
- Open the front panel cabinet and clean the air filter (depending on the model)
- Change a removable power supply (depending on the model)

10
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
The fuse(s) present in the unit have not been designed to be replaceable.
Do not attempt to service this product yourself by opening or removing covers and screws since itmay expose
your device to electric shocks or other hazards. The internal Lithium cell battery is not replaceable. In case of
problem, contact your supplier or Analog Way.
• OPENINGS: Never push objects of any kind into this product through the openings. If liquids have been
spilled or objects have fallen into the device, unplug it immediately and have it checked by a qualified
technician.
2.1.2 French
Afin de mieux comprendre le fonctionnement de cet appareil nous vous conseillons de bien lire toutes les
consignes de sécurité et de fonctionnement avant utilisation. Conservez les instructions de sécurité et de
fonctionnement afin de pouvoir les consulter ultérieurement. Respectez toutes les consignes marquées dans
la documentation, sur le produit et sur ce document.
• ATTENTION : Ne convient pas aux enfants. Afin de prévenir tout risque de choc électrique et d’incendie, ne
pas exposer cet appareil à la pluie, à l’humidité ou à des sources de chaleur intense. Cet équipement ne
convient pas pour une utilisation dans des endroits où des enfants sont susceptibles d’être présents.
• INSTALLATION : Veillez à assurer une circulation d’air suffisante pour éviter toute surchauffe à l’intérieur
de l’appareil. Ne placez pas l’appareil sur ou à proximité d’une surface textile susceptible d’obstruer les
orifices de ventilation. N’installez pas l’appareil à proximité de sources de chaleur comme un radiateur ou
une poche d’air chaud, ni dans un endroit exposé au rayonnement solaire direct, à des poussières excessives,
à des vibrations ou à des chocs mécaniques. Ceci pourrait provoquer un mauvais fonctionnement et un
accident.
• ALIMENTATION : Ne faire fonctionner l’appareil qu’avec la source d’alimentation indiquée sur l’appareil.
Les appareils doivent être obligatoirement connectés sur une source équipée d’une mise à la terre efficace.
En aucun cas cette liaison de terre ne devra être modifiée, contournée ou supprimée. Raccordement des
équipements à l’alimentation principale doit être postérieur au disjoncteur de branchement de l’installation
électrique du bâtiment.
Pour les équipements identifiés avec les symboles ci-dessus, une mise à la terre est obligatoire avant
branchement. Utiliser un câble de terre pour relier une vis du châssis de l’appareil à la terre.
• CORDON D’ALIMENTATION : L’appareil est équipé d’un ou plusieurs cordons d’alimentation détachables.
Un appareil identifié avec le symbole ci-dessus indique que l’équipement possède plusieurs cordons secteurs.
La mise hors tension se fait en débranchant tous les cordons de l’appareil.
Attention : Les cordons d’alimentation constituent le seul moyen de débrancher l’appareil totalement de l’alimentation
secteur.
Appliquer les consignes suivantes :
- Le matériel relié à demeure au réseau, doit avoir un dispositif de sectionnement facilement accessible qui
doit être incorporé à l’extérieur de l’appareil.
- Débrancher les cordons d’alimentation de la prise murale si vous prévoyez de ne pas utiliser l’appareil
pendant quelques jours ou plus.
- Pour débrancher les cordons, tirez-les par la fiche. Ne tirez jamais sur les cordons proprement dit.
- La prise d’alimentation doit se trouver à proximité de l’appareil et être aisément accessible.
- Ne laissez pas tomber le cordon d’alimentation et ne posez pas d’objets lourds dessus.

11
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
Si un des cordons d’alimentation est endommagé, débranchez-le immédiatement de la prise murale. Il est
dangereux de faire fonctionner un appareil avec un cordon endommagé ; un câble abîmé peut provoquer un
risque d’incendie ou un choc électrique. Vérifiez les câbles d’alimentation de temps en temps. Contactez
votre revendeur ou le service après-vente pour un remplacement.
• CONNEXIONS : Toutes les entrées et sorties (exceptée l’entrée d’alimentation) sont des sources d’énergie
électrique de classe 1 (ES1) tel que défini dans IEC/UL 62368-1 édition 2.
ES1: Electrical energy source class 1 (limites : 60Vdc ou 30V rms/ 42.4V peak).
• RÉPARATION ET MAINTENANCE : Débrancher les cordons d’alimentation avant toute maintenance.
Selon la norme IEC 62368-1, une personne ordinaire est autorisée à :
- Ouvrir la face avant pour nettoyer le filtre à air (dépend du modèle)
- Changer un bloc d’alimentation accessible de l’extérieur (dépend du modèle)
Le ou les fusibles présents dans l’appareil n’ont pas été conçus pour être remplaçables.
L’utilisateur ne doit en aucun cas essayer de procéder aux opérations de dépannage, car l’ouverture des
appareils par retrait des capots ou de toutes autres pièces constituant les boîtiers ainsi que le dévissage des
vis apparentes à l’extérieur, risquent d’exposer l’utilisateur à des chocs électriques ou autres dangers.
La pile bouton au Lithium présente à l’intérieur de la machine n’est pas remplaçable. En cas de problème,
contactez le service après-vente, votre revendeur ou adressez-vous à un personnel qualifié uniquement.
• OUVERTURES ET ORIFICES : Les appareils peuvent comporter des ouvertures (aération, fentes, etc.),
veuillez ne jamais y introduire d’objets et ne jamais obstruer ses ouvertures. Si un liquide ou un objet pénètre
à l’intérieur de l’appareil, débranchez immédiatement l’appareil et faites-le contrôler par un personnel
qualifié avant de le remettre en service.
2.1.3 Italian
Allo scopo di capire meglio il funzionamento di questa apparecchiatura vi consigliamo di leggere bene tutti i
consigli di sicurezza e di funzionamento prima dell’utilizzo. Conservare le istruzioni di sicurezza e di
funzionamento al fine di poterle consultare ulteriormente. Seguire tutti i consigli indicati su questo manuale
e sull’apparecchiatura.
• ATTENZIONE: Questo apparecchio non e’ adatto all’utilizzo da parte di bambini. Al fine di prevenire
qualsiasi rischio di shock elettrico e d’incendio, non esporre l’apparecchiatura a pioggia, umidità e a sorgenti
di eccessivo calore. Questo apparato non e’ adatto all’utilizzo in luoghi dove ci siano presenti bambini.
• INSTALLAZIONE: Assicuratevi che vi sia una sufficiente circolazione d’aria per evitare qualsiasi
surriscaldamento all’interno dell’apparecchiatura. Non collocare l’apparecchiatura in prossimità o su
superfici tessili suscettibili di ostruire il funzionamento della ventilazione. Non installate l’apparecchiatura in
prossimità di sorgenti di calore come un radiatore o una fuoruscita d’aria calda, né in un posto esposto
direttamente ai raggi del sole, a polvere eccessiva, a vibrazioni o a shock meccanici. Ció potrebbe provocare
un erroneo funzionamento e un incidente.
• ALIMENTAZIONE: Far funzionare l’apparecchiatura solo con la sorgente d’alimentazione indicata
sull’apparecchiatura. Le apparecchiature queste devono essere obbligatoriamente collegate su una sorgente
fornita di una efficiente messa a terra. In nessun caso questo collegamento potrà essere modificato,
sostituito o eliminato. Connessione delle apparecchiature alla rete elettrica deve essere successiva
interruttore di circuito dell’impianto dell’edificio.
Per apparecchiature identificate con i simboli sopra, collegare la terra prima di collegarla all’alimentazione.
Utilizzare un cavo di terra per mettere a terra la vite del telaio dell’unità.
• CAVO DI ALIMENTAZIONE: Il dispositivo è dotato di uno o più cavi di alimentazione removibile.

12
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
Un dispositivo identificato con il simbolo sopra indica che l’apparecchiatura dispone di più cavi di
alimentazione. Per rimuovere le alimentazioni scollegare i cavi dalla Presa.
Attenzione: i cavi di alimentazione sono l’unico di disconnettere l’apparecchio all’alimentazione.
Seguire le instruzioni seguenti:
- Il materiale collegato a residenza alla rete, deve avere un dispositivo di sezionamento facile da raggiungere
e che deve essere inserito all’esterno del apparecchio.
- Scollegare l’apparecchiatura dalla presa a muro se si prevede di non utilizzarla per qualche giorno.
- Per disconnettere i cavi, tirare facendo forza sul connettore.
- La prese d’alimentazione deve trovarsi a prossimità dell’apparecchiatura ed essere facilmente accessibile.
- Non far cadere il cavo di alimentazione né appoggiarci sopra degli oggetti pesanti.
Se uno dei cavi di alimentazione é danneggiato, spegnere immediatamente l’apparecchiatura. E’ pericoloso
far funzionare questa apparecchiatura con un cavo di alimentazione danneggiati, un cavo graffiato puó
provocare un rischio di incendio o uno shock elettrico. Verificare i cavi di alimentazione spesso. Contattare il
vostro rivenditore o il servizio assistenza per una sostituzione.
• CONNESSIONE: Tutti gli ingressi e le uscite (ad eccezione per l’ingresso di alimentazione) sono sorgenti di
energia in classe 1 (ES1) come definito nelle normative IEC/UL 62368-1 edizione 2. Limiti ES1: 60Vdc or 30V
rms/ 42.4V di picco.
• RIPARAZIONI E ASSISTENZA: Scollegare tutti i cavi di alimentazione dalle prese prima di fare manutenzione.
In accordo alle normative IEC 62368-1, no addetti alla manutenzione possono effettuare le seguenti
operazioni :
- Aprire il pannello frontale e effettuare la pulizia dei filtri (dipende dal modello)
- Sostituire un alimentatore rimuovibile (dipende dal modello)
I fusibili presenti nel dispositivo non sono stati progettati per essere sostituibili.
L’utilizzatore non deve in nessun caso cercare di riparare l’apparecchiatura, poiché con l’apertura del
coperchio metallico o di qualsiasi altro pezzo costituente la scatola metallica, nonché svitare le viti che
appaiono esteriormente, poiché ció puó provocare all’utilizzatore un rischio di shock elettrico o altri rischi.
La batteria al litio all’interno dell’apparato non e’ sostituibile. In caso di problemi contattare il fornitore o
Analog Way.
• APERTURE DI VENTILAZIONE: Le apparecchiature possono comportare delle aperture di ventilazione, si
prega di non introdurre mai oggetti o ostruire le sue fessure. Se un liquido o un oggetto penetra all’interno
dell’apparecchiatura, disconnetterla e farla controllare da personale qualificato prima di rimetterla in servizio.
2.1.4 German
Um den Betrieb dieses Geräts zu verstehen, raten wir Ihnen vor der Inbetriebnahme alle Sicherheits und
Betriebsanweisungen genau zu lesen. Diese Sicherheits- und Betriebsanweisungen für einen späteren
Gebrauch sicher aufbewahren. Alle in den Unterlagen, an dem Gerät und hier angegebenen
Sicherheitsanweisungen einhalten.
• ACHTUNG: Nicht für Kinder geeignet. Um jegliches Risiko eines Stromschlags oder Feuers zu vermeiden,
das Gerät nicht Regen, Feuchtigkeit oder intensiven Wärmequellen aussetzen. Dieses Gerät ist nicht geeignet,
um in der Nähe von Kindern betrieben zu werden. Lassen Sie Kinder in der Nähe des Geräts nicht
unbeaufsichtigt.
• EINBAU: Eine ausreichende Luftzufuhr sicherstellen, um jegliche Überhitzung im Gerät zu vermeiden. Das
Gerät nicht auf und in Nähe von Textiloberflächen, die Belüftungsöffnungen verschließen können, aufstellen.
Das Gerät nicht in Nähe von Wärmequellen, wie z.B. Heizkörper oder Warmluftkappe, aufstellen und es nicht

13
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
dem direkten Sonnenlicht, übermäßigem Staub, Vibrationen oder mechanischen Stößen aussetzen. Dies
kann zu Betriebsstörungen und Unfällen führen.
• STROMVERSORGUNG: Das Gerät nur mit der auf dem Gerät bezeichnete Stromquelle betreiben. Gerät mit
geerdeter Hauptstromversorgung muss an eine Stromquelle mit effizienter Erdung angeschlossen werden.
Diese Erdung darf auf keinen Fall geändert, umgangen oder entfernt werden. Anschluss von Geräten ans
Stromnetz muss nach Abzweigschalter des Gebäudes Installation.
Für Geräte, die mit den obigen Symbolen gekennzeichnet sind, Zuerst das Gerät erden bevor die
Spannungsversorgung hergestellt wird. Verwenden Sie Erdungskabel und eine Schraube auf der Rückseite
des Gehäuses, um das Gerät zu erden.
NETZKABEL: Das Gerät ist mit ein oder mehrere lösbaren Netzkabel ausgestattet.
Ein mit dem obigen Symbol gekennzeichnetes Gerät weist darauf hin, dass das Gerät über mehrere Netzkabel
verfügt. Um es völlig vom Netz zu trennen, ziehen Sie bitte die Netzkabel aus der Kaltgerätebuchse.
Achtung: Die Netzkabel stellt die einzige Möglichkeit dar, das Gerät vollständig vom Netzanschluss zu trennen.
Bitte beachten Sie die folgenden Hinweise:
- Wenn Geräte dauerhaft am Netz bleiben, müssen sie über eine leicht zugängliche Trennvorrichtung
verfügen, die außen am Gerät angebracht sein muss.
- Trennen Sie das Gerät vom Stromnetz, wenn es einige Tage oder länger nicht benutzt wird.
- Die Kabel mittels des Steckers herausziehen. Niemals am Stromkabel selbst ziehen.
- Die Steckdose muss sich in der Nähe des Geräts befinden und leicht zugänglich sein.
- Das Stromkabel nicht fallen lassen und keine schweren Gegenstände darauf stellen.
Wenn eines der Netzkabel beschädigt ist, das Gerät sofort abschalten. Es ist gefährlich das Gerät mit einem
beschädigten Stromkabel zu betreiben; ein abgenutztes Kabel kann zu einem Feuer oder Stromschlag führen.
Die Stromkabel regelmäßig untersuchen. Für Ersatz wenden Sie sich an Ihren Verkäufer oder eine
Kundendienststelle.
• ANSCHLÜSSE: Alle Eingänge und Ausgänge (ausgenommen der Stromversorgung) entsprechen der der ES1
Klassifizierung entsprechend der IEC/UL 62368-1 Edition 2. ES1 max. Auslegung: 60Vdc oder 20V rms / 42,4V
Spitze.
• REPARATUR UND WARTUNG: Trennen sie alle Netzkabel vom Strom, bevor Sie eine Wartung oder andere
Arbeiten am Gerät durchführen.
Gemäß der IEC 62368-1 Norm ist ein gewöhnlicher Nutzer autorisiert, gemäß der Betriebsanleitung folgendes
am Gerät durchzuführen:
- Öffnen der vorderen Gehäuseabdeckung und Reinigung des Luftfilters (hängt vom Modell ab)
- Austauschen der herausnehmbaren Netzteile (hängt vom Modell ab)
Die im Gerät vorhandene(n) Sicherung(en) ist/sind nicht dafür ausgelegt, austauschbar zu sein.
Der Benutzer darf keinesfalls versuchen das Gerät selbst zu reparieren, die Öffnung des Geräts durch
Abnahme der Abdeckhaube oder jeglichen anderen Teils des Gehäusessowie die Entfernung von außen
sichtbaren Schrauben zu Stromschlägen oder anderen Gefahren für den Benutzer führen kann. Die im Gerät
eingebaute Lithium Batterie ist nicht austauschbar. Im Falle eines Problems nehmen Sie Kontakt mit Ihrem
Lieferanten auf oden au Analog Way.
• ÖFFNUNGEN UND MUNDUNGEN: Die Geräte können über Öffnungen verfügen (Belüftung, Schlitze, usw.).
Niemals Gegenstände in die Öffnungen einführen oder die Öffnungen verschließen. Wenn eine Flüssigkeit
oder ein Gegenstand in das Gerät gelangt, den Stecker herausziehen und es vor einer neuen Inbetriebnahme
von qualifiziertem Fachpersonal überprüfen lassen.

14
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
2.1.5 Spanish
Para comprender mejor el funcionamiento de este aparato, le recomendamos que le acuidadosamente todas
las consignas de seguridad y de funcionamiento del aparato antes de usarlo. Conserve las instrucciones de
seguridad y de funcionamiento para que pueda consultarlas posteriormente. Respete todas las consignas
indicadas en la documentación, relacionadas con el producto y este documento.
• CUIDADO: No recomendado para niños. Para prevenir cualquier riesgo de choque eléctrico y de incendio,
no exponga este aparato a la lluvia, a la humedad ni a fuentes de calorintensas. Este equipo no es adecuado
para su utilización en lugares donde haya niños.
• INSTALACIÓN: Cerciórese de que haya una circulación de aire suficiente para evitar cualquier
sobrecalentamiento al interior del aparato. No coloque el aparato cerca ni sobre una superficie textil que
pudiera obstruir los orificios de ventilación. No instale el aparato cerca de fuentes de calor como radiador o
boca de aire caliente, ni en un lugar expuesto a los rayos solares directos o al polvo excesivo, a las vibraciones
o a los choques mecánicos. Esto podría provocar su mal funcionamiento o un accidente.
• ALIMENTACIÓN: Ponga a funcionar el aparato únicamente con la fuente de alimentación que se indica en
el aparato. Los aparatos deben estar conectados obligatoriamente a una fuente equipada con una puesta a
tierra eficaz. Por ningún motivo este enlace de tierra deberá ser modificado, cambiado o suprimido. Conexión
del equipo a la red eléctrica debe ser posterior del interruptor de circuitos derivados de la instalación del
edificio.
Para equipos identificados con los símbolos anteriores, conecte la toma de tierra antes de conectar el equipo
al suministro eléctrico. Utilize un cable para conecta cualquier tornillo del chasis, con la toma de tierra de la
instalación.
• CABLE DE ALIMENTACION: El equipo se suministra con uno o más cables de alimentación.
Un dispositivo identificado con el símbolo anterior indica que el equipo tiene más de un cable de alimentación.
Si desconectamos el cable dejamos al equipo sin alimentación.
Atención: Los cables de alimentación constituyen el único medio de desconectar el aparato totalmente de la red eléctrica.
Aplicar las siguientes consignas:
- El material conectado a residencia a la red informática, debe de tener un dispositivo de seccionamiento
fácilmente accesible que debe de ser incorporado al exterior del aparato.
- Desconectar el aparato del enchufe mural si no piensa utilizarlo durante varios días.
- Para desconectar los cables, tire de la clavija. No tire nunca de los cables propiamente dichos.
- El enchufes de alimentación debe estar cerca del aparato y ser de fácil acceso.
- No deje caer el cable de alimentación ni coloque objetos pesados encima de ellos.
Si uno de cables de alimentación sufriera algún daño, ponga el aparato inmediatamente fuera de tensión. Es
peligroso hacer funcionar este aparato con un cable averiado, ya que un cable dañado puede provocar un
incendio o un choque eléctrico. Verifique el estado los cables de alimentación de vez en cuando. Póngase en
contacto con su distribuidor o con el servicio de posventa si necesita cambiarlo.
• CONEXIONES: Todas las entradas y salidas (excepto la entrada de corriente) son de nivel eléctrico clase 1
(ES1) tal como se define en la norma IEC / UL 62368-1 2. Límites de ES1 60 VCC ó 30 V rms / 42,4 V de pico.
• REPARACIÓN Y MANTENIMIENTO: Desconecte todos los cables de alimentación de la red eléctrica antes
de realizar el mantenimiento.
De acuerdo con la norma IEC 62368-1, solo una persona autorizada puede realizar esta operación:

15
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
- Abra el frente del equipo y limpie el filtro del aire (depende del modelo)
- Cambie la fuente de alimentación extraíble (depende del modelo)
Los fusibles presentes en el dispositivo no han sido diseñados para ser reemplazables.
Por ningún motivo, el usuario deberá tratar de efectuar operaciones de reparación, ya que si abre los
aparatos retirando el capó o cualquier otra pieza que forma parte de las cajas o si destornilla los tornillos
aparentes exteriores, existe el riesgo de producirse una explosión,choques eléctricos o cualquier otro
incidente. La batería interna de litio no es reemplazable. En caso de problema, contacte con su proveedor o
Analog Way.
• ABERTURAS Y ORIFICIOS: Los aparatos pueden contener aberturas (aireación, ranuras, etc.). Nointroduzca
allí ningún objeto ni obstruya nunca estas aberturas. Si un líquido o un objeto penetra al interior del aparato,
desconéctelo y hágalo revisar por personal cualificado antes de ponerlo nuevamente en servicio.
2.1.6 Symbols on product identification and warning labels
Caution, risk of electric shock
All power sources shall be disconnected before
servicing to avoid shock hazard.
Connect protective earth before
connection to mains
The protective conductor (PE) should be
connected first to main protective earthing
terminal before connecting the line and neutral.
Protective earth
Connect an earth terminal to the ground.
Disconnection, all power plugs
All power sources shall be disconnected before
servicing to avoid shock hazard.
Alternating current
The equipment is suitable for alternating current
only.
Caution
The current situation needs operator awareness or
operator action in order to avoid undesirable
consequences.
Caution, moving fan blades
Keep away from moving fan blades.

16
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL

17
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
2.1.7 Environmental specifications for all Picturall models
Picturall Twin Compact Mark II and Quad Compact Mark II:
• Dimensions without rack mount and handles: W 440 x H 88 x D 640 mm
• Dimensions with rack mount and handles: W 482 x H 88 x D 680 mm
• Product Weight: 17,5kg
Picturall Quad Mark II and Pro Mark II
• Dimensions without rack mount and handles: W 440 x H 177 x D 645 mm
• Dimensions with rack mount and handles: W 482 x H 177 x D 694 mm
• Product Weight: Quad Mark II: 20,8g –Pro Mark II (fully loaded): 24,5kg
General:
• Cooling air flows from front side to rear.
• Max ambient operating temperature: < 40°C (< 104°F).
• Operating temperature: 0 to +40°C / +32°F to +104°F
• Storage temperature: -10 to +60°C / +14°F to +140°F
• Operating humidity: 10 to 80% (non condensing)
• Input voltage range: 100-240 VAC autosensing, 50/60 Hz 7A
• Max consumption: 660W
Safety standard:
• IEC/EN/UL 62368-1
• CSA C22.2#62368-1
Electromagnetic compatibility:
• EN55032
• EN55024
• EN61000-3-2
• EN61000-3-3
• CFR47 Part 15
• ICES-003
Environment:
• RoHS
• WEEE
Caution: Should the unit lose power unexpectedly; unsaved settings may be lost.

18
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
3 Introducing Picturall Series Media Servers
Thank you for choosing Picturall Series Media Servers! The one that combines cutting-edge technology with
ease-of-use and unrivalled efficiency.
Picturall Series Media Servers are powerful real time multi-output media servers. They can manage multiple
inputs (media files, live feeds or network streams) with various features and effects. Then output them to
multiple displays.
Control the server with Picturall Commander, a dedicated software designed exclusively for Picturall Series
Media Servers. Alternatively, Picturall Series Media Servers can also be controlled with External controllers
such as Lighting consoles.
Picturall Series Media Servers are 19” wide and 4 rack units (4U) high, following the industrial rack mounting
standard. The Twin and Quad are also available in Compact versions (2U) with the same number of outputs
and the same efficiency as their 4U counterparts.
3.1 Picturall Series Media Servers
The Picturall Series Media Servers product range includes 3 models: Twin, Quad, and Pro.
The following table illustrates the differences between the units.
Picturall Series Media
Servers
Outputs
Description
Twin, Twin Compact &
Twin Compact Mark II
2
Heavy-duty dual-output 4K Series Media Server. Designed for
medium-sized events and installations requiring high levels of
performance and reliability.
Quad, Quad Mark II,
Quad Compact & Quad
Compact Mark II
4
Heavy-duty quad-output 4K Series Media Server. Designed for
large scale events and installations requiring high levels of
performance and stability.
Pro & Pro Mark II
Up to 16
Mission critical 8K modular Series Media Server. Engineered to
support massive events and installations from one single server
unit.
Table 1 - Picturall Series Media Servers family
3.2 Package Contents
The Picturall Series Media Server sales package includes:
-One Picturall Series Media Server
-One or Two Power cords
-One Rackmount kit
-One Ethernet cross cable
A USB keyboard is needed for configuring the server and a remote computer for running Picturall
Commander.
3.3 Rack mount information
All units are equipped with 4 handy anti-slip rubber feet and can be used directly on a table.
For rack mount installation, see document Picturall - Rack mount.pdf attached to this manual.

19
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
3.4 Front panel
All the Media Servers have the same front panel. It is composed of one OLED display, two USB ports, a Power
button and a Next/Status button.
Fig. 1 - Front panel
3.4.1 Display screen
The front panel displays information such as device IP address, firmware version, or CPU.
-Press the Next/Status button to wake the display and show server information.
-Press again to cycle through the next pages.
The display automatically goes off after 3 minutes of inactivity.
3.4.2 Power off
Tip: The following procedure is the recommended method to safely turn off the Media Server.
To turn off the media server, press the Power button then press the Next/Status button to confirm.
3.4.3 Forced shutdown
If the Media Server crashed, turn off the power by Forced shutdown.
-Press and hold the Power button until shutdown.
Caution: Using Forced shutdown regularly is not recommended. Use Forced shutdown only if the Media Server has
crashed.

20
www.analogway.com
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
3.5 Rear panels and Connections
The Media Server chassis and the hardware are designed to produce the best possible performance in a sleek,
rack-mountable unit.
3.5.1 Picturall Twin rear panel
Fig. 2 - Picturall Twin rear panel
1. Power supply (optional redundant and hot-swappable power supplies)
2. Two-channel audio interface with balanced XLR outputs (optional)
3. RS232 plug (optional)
4. Ethernet plug
5. USB plug
6. Two DisplayPort 1.2 outputs (4K@60Hz 10-bit 4:4:4)
7. Two slots for additional input cards
3.5.2 Picturall Twin Compact rear panel
Fig. 3 - Picturall Twin Compact rear panel
1. Power supply
2. RS232 plug (optional)
3. Two-channel audio interface with balanced XLR outputs (optional)
4. USB plug
5. Ethernet plug
6. Two DisplayPort 1.2 outputs (4K@60Hz 10-bit 4:4:4)
7. One slot for additional input card
