Ancona Comfort 9S User manual

Comfort 9S Wall Plug-In
Installation and Operations Manual
If you need some support or before returning this product, please contact us at:
Email : [email protected]
Phone: [phone]

Model : Comfort 9S Wall Plug-In
Product Dimensions
ALLEN KEYS
FLAT HEAD SCREWDRIVERSSTAR HEAD SCREWDRIVERS
PENCIL
DRILL & BIT
LEVEL
MEASURING TAPE
Parts for wall-mounted installation
4pcs
4pcs
4pcs
4pcs
4pcs
4pcs
4pcs
Comfort 9S Wall Plug-In Installation
Ø8mm
h 1pc (small)
i 1pc (large)

Installation
Step 1: Verifying installation parts
-Ensure all parts for mounting installation were supplied with your towel warmer. (see fig.1)
-If any are missing, please contact us.
Step 2: Installing wall mount posts (fig. 2)
-Locate the following parts:
od: Metal wall leg
oe: Screw to set post in main body
of: Plastic insert (this insert may already be installed inside the metal post)
og: Set Screw (this set screw may already be installed inside the metal post) (see fig.5)
-Position parts correctly:
oPlastic insert f) is positioned inside metal leg d)
oSet screw g) is inserted in metal wall leg d) (see fig.5)
oIf part b) is inserted in part d) remove it
-Install wall leg d)
oPosition wall leg d) on the main body where the screws can be inserted
oInsert screw e) and screw wall leg into main body using appropriate sized Allen key
oRepeat for all 4 wall legs
Model :
Comfort 9S Wall Plug-In
1. Install in accordance with national and
local codes
2. Do not install in the shower, sauna or any
wet locations
3. Make sure towel warmer is properly
secured to the wall before use.
Fig. 1
24”
Fig. 2

Installation cont’d
Step 3: Marking holes for wall mount posts (fig. 3)
-Take towel warmer with 4 wall legs mounted, as per step 2
-Position against the wall where you will want to install the towel warmer
-Ensure that the electric plug will reach nearest outlet.
-Use light pencil to mark legs on the wall (you may want to erase the pencil mark following
installation completion, so make sure you mark lightly)
Step 4: Installing wall posts (fig. 4)
-If installing on dry wall with no rear beam support:
oDrill a hole in the center of each of the 4 circles marked on the wall as per step 3
oEnsure drilled hole is large enough to insert the plastic plug provided –part a)
oInsert/ screw the plastic plug in each of the 4 holes
oPosition wall post b) on top of plastic plug and put in screw c) to set in place
-If installing on surface with rear support, e.g. wood studs
oPre-drill small hole in the center of each circle as per step 3
oPosition wall post b) on top of pre-drilled hole and put in screw c) to set in place
Step 5: Mounting main body onto wall (fig. 5)
-Take main body and position each of the 4 legs on top of the wall posts b)
-Once inserted use Allen key to tighten each set screw g)
-The installation should be complete
Step 6: Power the towel warmer
-Remove protective white covers, they are located at the end of each of the vertical bars.
-Turn the switch on to start towel warmer; the on-off switch is located at the end of one of the
posts.
-The towel warmer should reach its pre-set temperature in approximately 15 minutes.
-This towel warmer is designed to operate continuously and can be left on all the times. To save
electricity it can be turned off when not in use.
Model :
Comfort 9S Wall Plug-In
Fig. 3
Fig. 4
Fig. 5

Properly hang towels
Operation and maintenance instruction
After installation, connect the electric power and turn on the switch. The indicator light will show red
and the towel warmer will start to work.
Turn off the switch when the towel warmer is not in use. The indicator light will turn dark and the
towel warmer will stop working.
Clean the towel warmer with a soft dry towel. Do not clean with abrasive cleaning powder.
This unit has been designed to run continuously.

A thermal cut off device has been integrated to avoid overheating.
Towel warmers are designed for heating towels and bathrobes and should not be used for other purposes.
The manufacturer or reseller assumes no liability if the device is used in combination with equipment or accessories not
sold by the manufacturer.
Never stand, sit or climb on the unit.
The unit is designed to warm up towels and may become very hot.
An adult must supervise when the device is used by or near children.
Unplug the unit and ensure that the electrical circuit breaker is off the main panel before wiring, carrying out a repair or
servicing your heated towel warmer.
Do not place your towel warmer inside a shower, sauna or plunge into the water.
To ensure continued protection against risk of electric shock, plug the unit into a properly grounded outlet.
Approved for domestic use only. Do not use outdoors.
Information : [e-mail]
Model :
Comfort 9S Wall Plug-In
Properly Hang Towels.
Do not overlap them.

This Towel Warmer is warranted by AMS, in the manner fully set forth below, to be free from defects in
material and workmanship and to operate properly in accordance with specifications, provided that it is used under
the normal operating conditions and for ordinary home use and service in Canada and the USA.
AMS provides a limited warranty for its Products for a period of 1 year from the original date of purchase
(the “Warranty Period”), against any defects in workmanship and materials (the “Warranty”).
Subject to the previous paragraph and during the Warranty Period, AMS will, at its sole discretion,
replace or repair any defective parts of the Product sent to AMS during the Warranty Period (or, if the Product is
no longer available, replace the defective Product with a comparable Product of equal or greater value).
AMS’S SOLE OBLIGATION AND THE CUSTOMER’S SOLE REMEDY FOR ANY DEFECTIVE
PRODUCT OR PART THEREOF SHALL BE LIMITED TO THE REPAIR AND REPLACEMENT THEREOF.
AMS’S ENTIRE AGGREGATE LIABILITY UNDER THE WARRANTY SHALL NOT EXCEED THE
ORIGINAL PURCHASE PRICE OF THIS PRODUCT (EXCEPT WHERE AMS, IN ITS SOLE DISCRETION,
DECIDES TO REPLACE THE PRODUCT WITH A PRODUCT OF GREATER VALUE).
THE PURCHASER IS RESPONSIBLE FOR ALL RELATED SHIPPING, INSURANCE AND
HANDLING COSTS DURING THE WARRANTY PERIOD. PRIOR TO RETURNING ANY PRODUCT TO
AMS, THE CUSTOMER MUST FIRST OBTAIN A RETURN AUTHORIZATION NUMBER AND SHIPPING
INSTRUCTIONS FROM AMS (AN “AUTHORIZATION”) BY CALLING THE FOLLOWING NUMBER:
1-800-350-4562.
After having obtained an Authorization from AMS, the customer should promptly ship the Product to the
address specified in the Authorization with the following documentation:
- A complete description of the problem;
- The Product model number;
- The date and location of Product purchase; and
- The original sales receipt to be valid.
This Warranty does not cover and AMS shall not be responsible for: (i) service calls to correct the
installation of the Product, to instruct the customer on how to use the Product or any other customer education and
(ii) labour costs associated with the removal, shipping and reinstallation cost or other contingent expenses.
Damages caused by accident, fire, lightning, brown-out, leaking, superior force, power failure, improper
power supply, improper installation, handling or operation, error, use for non-domestic purposes, shipping damage,
negligence, abuse, misuse, unauthorized repair, whether performed by the customer or a third party, or improper
care or maintenance WILL IMMEDIATELY RENDER THIS WARRANTY NULL AND VOID AND AMS
WILL BE RELIEVED FROM ITS OBLIGATION TO WARRANT THE PRODUCT.
AMS WILL NOT BE LIABLE FOR DAMAGES TO PERSONS OR PROPERTY IN CONNECTION
WITH THE INSTALLATION, REPAIR OR REPLACEMENT OF THE PRODUCT, NOR FOR ANY
INDIRECT, SPECIAL, PUNITIVE, EXEMPLARY, INCIDENTAL OR CONSEQUENTIAL DAMAGES,
LOSSES, INJURY OR COSTS OF ANY NATURE, INCLUDING, WITHOUT LIMITATION, LOSS OF USE
OR MALFUNCTION RELATING TO THIS PRODUCT. THIS WARRANTY IS NOT TRANSFERABLE OR
ASSIGNABLE TO ANY PERSON.
SAVE AS HEREIN PROVIDED, THERE ARE NO OTHER WARRANTIES, CONDITIONS,
REPRESENTATIONS OR GUARANTEES, EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION,
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, MADE OR
INTENDED BY AMS OR ITS AUTHORIZED DISTRIBUTORS.
Some provinces or states may not allow limitations on the exclusion or limitation of incidental or
consequential damages, so these limitations and exclusions may not entirely apply to certain customers. Any
provision in the Warranty which is unenforceable in any province or state shall be ineffective to the extent of such
unenforceability, without invalidating the remaining provisions or affecting the validity or enforceability of such
provisions in any other province or state.
This Warranty gives the customer specific legal rights, and the customer may also have rights which vary
based on state, province or country. For service and assistance, please call: 1-800-350-4562, or email us at:
[e-mail]
