Andon KD-7961N User manual

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
1/15
MODEL KD-7961N
Fully Automatic Wrist Cuff Blood Pressure Monitor
(ELECTRONIC SPHYGMOMANOMETER)
OPERATION GUIDE
INDEX
IMPORTANT INFORMATION .....................................................................................................................................2
CONTENTS AND DISPLAY INDICATORS...............................................................................................................2
INTENDED USE ...........................................................................................................................................................3
CONTRAINDICATION..................................................................................................................................................3
PRODUCT DESCRIPTION.........................................................................................................................................3
SPECIFICATIONS........................................................................................................................................................3
NOTICE..........................................................................................................................................................................4
SETUPAND OPERATING PROCEDURES.............................................................................................................5
1. BATTERY LOADING ........................................................................................................................................5
2. TOUCH BUTTON SWITCH ..............................................................................................................................6
3. CLOCKAND DATEADJUSTMENT................................................................................................................6
4. VOICE SETTING ...............................................................................................................................................6
5. CONNECTING THE CUFF TO THE MONITOR .............................................................................................7
6. APPLYING THE CUFF ......................................................................................................................................7
7. BODY POSTURE DURING MEASUREMENT................................................................................................7
8. TAKING YOUR BLOOD PRESSURE READING............................................................................................8
9. DISPLAYING STORED RESULTS ...................................................................................................................8
10. DELETING MEASUREMENTS FROM THE MEMORY ..............................................................................9
11.ASSESSING HIGH BLOOD PRESSURE FOR ADULTS ...............................................................................9
12. TECHNICALALARM DESCRIPTION.........................................................................................................10
13.TROUBLESHOOTING (1)..............................................................................................................................10
14. TROUBLESHOOTING (2).............................................................................................................................10
MAINTENANCE..........................................................................................................................................................11
EXPLANATION OF SYMBOLS ON UNIT...............................................................................................................11
WARRANTY INFORMATION....................................................................................................................................12
SERVICE CENTER....................................................................................................................................................12
ELECTROMAGNETIC COMPATIBILITY INFORMATION....................................................................................12

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
2/15
IMPORTANT INFORMATION
NORMAL BLOOD PRESSURE FLUCTUATION
All physical activity, excitement, stress, eating, drinking, smoking, body posture and many other activities or
factors (including taking a blood pressure measurement) will influence blood pressure value. Because of this, it is
mostly unusual to obtain identical multiple blood pressure readings.
Blood pressure fluctuates continually day and night. The highest value usually appears in the daytime and lowest
one usually at midnight. Typically, the value begins to increase at around 3:00AM, and reaches to highest level in
the daytime while most people are awake and active.
Considering the above information, it is recommended that you measure your blood pressure at approximately
the same time each day.
Too frequent measurements may cause injury due to blood flow interference, please always relax a minimum
moment of 1 to 1.5 minutes between measurements to allow the blood circulation in your arm to recover. It is rare
that you obtain identical blood pressure readings each time.
CONTENTS AND DISPLAY INDICATORS
Date/Time Display
Systolic Pressure
MEM button
START button
Diastolic Pressure
Touch switch
Pulse Rate
Speaker
Blood Pressure Level
Classification Indicator
Cuff

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
3/15
INTENDED USE
Fully Automatic Electronic Blood Pressure Monitor is for use by medical professionals or at home and is a
non-invasive blood pressure measurement system intended to measure the diastolic and systolic blood
pressures and pulse rate of an adult individual by using a non-invasive technique in which an inflatable cuff is
wrapped around the wrist.
CONTRAINDICATION
It is inappropriate for people with serious arrhythmia to use this Electronic Sphygmomanometer.
PRODUCT DESCRIPTION
Based on Oscillometric methodology and silicon integrated pressure sensor, blood pressure and pulse rate can
be measured automatically and non-invasively. The most recent 60 measurements can be stored in the memory
with date and time stamp. The voice function will ease the operation. The Electronic Sphygmomanometer
corresponds to the below standards:IEC 60601-1:2005/EN 60601-1:2006/AC:2010 (Medical electrical equipment
-- Part 1: General requirements for basic safety and essential performance), IEC60601-1-2:2007/EN
60601-1-2:2007 /AC:2010 (Medical electrical equipment -- Part 1-2: General requirements for basic safety and
essential performance - Collateral standard: Electromagnetic compatibility - Requirements and tests), IEC
80601-2-30 ：2009+Cor.2010/EN 80601-2-30:2010(Medical electrical equipment –Part 2-30: Particular
requirements for the basic safety and essential performance of automated non-invasive
sphygmomanometers)EN 1060-1: 1995 + A1: 2002 + A2: 2009 (Non-invasive sphygmomanometers - Part 1:
General requirements), EN 1060-3: 1997 + A1: 2005 + A2: 2009 (Non-invasive sphygmomanometers - Part 3:
Supplementary requirements for electro-mechanical blood pressure measuring systems), ANSI/AAMI
SP-10:2002+A1:2003+A2:2006.
SPECIFICATIONS
1. Product name: Blood Pressure Monitor
2. Model: KD-7961N
3. Classification: Internally powered, Type BF applied part,IPX0,No AP or APG, Continuous operation
4. Machine size: 85mm x 69mm x 30mm ( 3 11/32″ x 2 23/32″ x 1 3/16″)
5. Cuff circumference: 14cm ~ 19.5cm(5 1/2″~ 7 11/16″)
6. Weight: approx. 134g (4 23/32oz.) (exclude batteries and cuff)
7. Measuring method: oscillometric method, automatic air inflation and measurement

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
4/15
8. Memory volume: 60 times with time and date stamp
9. Power source: 2 ×1.5V SIZE AAA batteries
10. Measurement range:
Cuff pressure: 0-300mmHg
Systolic: 60-260mmHg
Diastolic: 40-199mmHg
Pulse rate: 40-180 beats/minute
11. Accuracy:
Pressure: ±3mmHg
Pulse rate: ±5%
12. Environmental temperature for operation: 5℃～40℃(41℉～104℉)
13. Environmental humidity for operation: ≤90% RH
14. Environmental temperature for storage and transport: -20℃～55℃(-4℉～131℉)
15. Environmental humidity for storage and transport: ≤90% RH
16. Environmental pressure: 80kPa-105kPa
17. Battery life: Approx. 180 times
18. All components belonging to the pressure measuring system, including accessories: Pump, Valve, LCD, Cuff,
Sensor
Note: These specifications are subject to change without notice.
NOTICE
1. Read all of the information in the operation guide and any other literature in the box before operating the
unit.
2. Stay still, calm and rest for 5 minutes before blood pressure measurement.
3. The cuff should be placed at the same level as your heart.
4. During measurement, neither speak nor move your body and arm.
5. Measuring on same wrist for each measurement.
6. Please always relax a minimum moment of 1 to 1.5 minutes between measurements to allow the blood
circulation in your arm to recover. Prolonged over-inflation (cuff pressure exceed 300 mmHg or maintained
above15 mmHg for longer than 3 minutes) of the bladder may cause ecchymoma of your arm.
7. Consult your physician if you have any doubt about below cases:
1) The application of the cuff over a wound or inflammation diseases;
2) The application of the cuff on any limb where intravascular access or therapy, or an arterio-venous (A-V)
shunt, is present;
3) The application of the cuff on the arm on the side of a mastectomy;
4) Simultaneously used with other monitoring medical equipments on the same limb;
5) Need to check the blood circulation of the user.
8. This Electronic Sphygmomanometer is designed for adults and should never be used on infants or
young children. Consult your physician or other health care professionals before use on older children.
9. Do not use this unit in a moving vehicle, This may result in erroneous measurement.

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
5/15
10. Blood pressure measurements determined by this monitor are equivalent to those obtained by a trained
observer using the cuff/stethoscope auscultation method, within the limits prescribed by the American
National Standard Institute, Electronic or automated sphygmomanometers.
11. Information regarding potential electromagnetic or other interference between the blood pressure monitor
and other devices together with advice regarding avoidance of such interference please see part
ELECTROMAGNETIC COMPATIBILITY INFORMATION.
12. If Irregular Heartbeat (IHB) brought by common arrhythmias is detected in the procedure of blood pressure
measurement, a signal of will be displayed. Under this condition, the Electronic Sphygmomanometer
can keep function, but the results may not be accurate, it’s suggested that you consult with your physician
for accurate assessment.
There are 2 conditions under which the signal of IHB will be displayed:
1) The coefficient of variation (CV) of pulse period >25%.
2) The difference of adjacent pulse period≥0.14s, and the number of such pulse takes more than 53
percentage of the total number of pulse.
13. Please do not use the cuff other than supplied by the manufacturer, otherwise it may bring biocompatible
hazard and might result in measurement error.
14. The monitor might not meet its performance specifications or cause safety hazard if stored or used
outside the specified temperature and humidity ranges in specifications.
15. Please do not share the cuff with other infective person to avoid cross-infection.
16. This blood pressure monitor is verified by auscultatory method. It is recommended that you check annex B
of ANSI/AAMI SP-10:2002+A1:2003+A2:2006 for details of verification method if you need.
17. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
SETUP AND OPERATING PROCEDURES
1. BATTERY LOADING
a. Open battery cover at the back of the monitor.
b. Load two ―AAA‖ size batteries. Please pay attention to polarity.
c. Close the battery cover.
When LCD shows battery symbol , replace all batteries with new ones.
Rechargeable batteries are not suitable for this monitor.

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
6/15
Remove the batteries if the monitor will not be used for a month or more to avoid relevant damage of
battery leakage.
Avoid the battery fluid to get in your eyes. If it should get in your eyes, immediately rinse with plenty of
clean water and contact a physician.
The monitor, the batteries and the cuff, must be disposed of according to local regulations at the
end of their usage.
2. TOUCH BUTTON SWITCH
Your monitor has a touch button as equipment. Be careful not to touch the button by mistake. Keep the touch
switch in ―OFF‖ position when the monitor is not in use to avoid unintentional operation. Please keep the
touch switch in ―ON‖ position to operate the monitor. The touch switch is in ―ON‖ position, press the touch
button (START button or MEM button), you can hear the beep.
3. CLOCK AND DATE ADJUSTMENT
a. Once you install the battery or turn off the monitor, it will enter Clock Mode, and LCD will display time
and date. See picture 3.
Picture 3 Picture 3-1 Picture 3-2 Picture 3-3 Picture 3-4
b. While the monitor is in Clock Mode, pressing both the ―START‖ and ―MEM‖ button simultaneously
(touch button switch in ON position), the month will blink at first. See picture 3-1. Press the button
―START‖ repeatedly, the day, hour and minute will blink in turn. See picture 3-2 & 3-3 & 3-4. While the
number is blinking, press the button ―MEM‖ to increase the number. Keep on pressing the button
"MEM", the number will increase fast.
c. You can turn off the monitor by pressing ―START‖ button when the minute is blinking, then the time and
date is confirmed.
d. The monitor will turn off automatically after 1 minute of no operation, with the time and date unchanged.
e. Once you change the batteries, you should readjust the time and date.
4. VOICE SETTING
a. Ensure the touch button switch in ON position.
b. Voice language setting: In clock mode, you can select the voice language by keeping on pressing the
button ―MEM‖. Now LCD blink ―L0‖, ―L1‖, ―L2‖ … ―Ln‖ (see picture 4 & 4-1) circularly. ―L0‖ represents
closing voice function, ―L1‖ represents language 1, ―L2‖ represents language 2,…,―Ln‖ represents

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
7/15
language n, and so on. You can select the wanted language by releasing button ―MEM‖ when display
the corresponding language code.
Picture 4 Picture 4-1 Picture 4-2 Picture 4-3
c. Voice volume setting: Once you have selected a language, a column of bar will appear on the LCD.
Keep on pressing the button ―MEM‖ again, you can adjust the volume. See picture 4-2 & 4-3. The
higher the bars, the louder the volume. Release button ―MEM‖ at your desirable volume for
confirmation.
5. CONNECTING THE CUFF TO THE MONITOR
The cuff is attached to the monitor when it is packaged. Should the
cuff become unattached, align the two plugs and four brackets of
the cuff with the plug sockets and bracket sockets of the monitor
and press the cuff to the monitor until the plugs and brackets are
securely attached.
6. APPLYING THE CUFF
a. Place the cuff around a bare wrist 1-2cm above the wrist joint on the palm side of the wrist.
b. While seated, place the arm with the cuffed wrist in front of your body on a desk or table with
the palm up. If the cuff is correctly placed, you can read the LCD display.
c. The cuff must be neither too tight nor too loose.
Note:
Please refer to the cuff circumference range in “SPECIFICATIONS” to make sure that the
appropriate cuff is used.
Measuring on same wrist each time.
Do not move your arm, body, or the monitor during measurement.
Stay still, calm for 5 minutes before blood pressure measurement.
Please keep the cuff clean. If the cuff becomes dirty, remove it from the monitor and clear it
by hand in a mild detergent, then rinse it thoroughly in cold water. Never dry the cuff in
clothes dryer or iron it. Clean the cuff after the usage of every 200 times is recommended.
7. BODY POSTURE DURING MEASUREMENT

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
8/15
Sitting Comfortably Measurement
a. Be seated with your feet flat on the floor, and don’t cross your legs.
b. Place palm upside in front of you on a flat surface such as a desk or table,
with your elbow resting on a chair or table
c. The middle of the cuff should be at the level of the right atrium of the heart.
8. TAKING YOUR BLOOD PRESSURE READING
a. Ensure the touch button switch in ON position.
b. After applying the cuff and your body is in a comfortable position, press the ―START‖ button, all display
characters are shown for self-test. See picture 8. Please contact the service center if segment is missing.
Picture 8 Picture 8-1 Picture 8-2 Picture 8-3
c. The LCD will momentarily display the last measurement stored in the memory. See picture 8-1. If the
monitor has no measurement stored in the memory, the LCD will display ―0‖ for blood pressure and pulse
rate. See picture 8-2.
d. If the voice function is switched on, the monitor will speak out measurement tips.
e. Then the monitor inflates the cuff until sufficient pressure has built up for a measurement. Then the
monitor slowly releases air from the cuff and carries out the measurement. Finally the blood pressure
and pulse rate will be calculated and displayed on the LCD. See picture 8-3. The irregular heartbeat
symbol (if any) and blood pressure classification indicator will blink on the screen. The result will be
automatically stored in the memory. If the voice function is on, it will announce the measurement result.
f. After measurement, the monitor will turn off automatically after 1 minute of no operation. Alternatively,
you can press the ―START‖ button to turn off the monitor manually.
g. During measurement, you can press the ―START‖ button to turn off the monitor manually.
Note: Please consult a health care professional for interpretation of pressure measurements.
9. DISPLAYING STORED RESULTS
a. Ensure the touch button switch in ON position.
b. Press ―MEM‖ button in Clock Mode. The amount of results will be displayed. See picture 9.
c. Then the last result will be displayed with date and time. See picture 9-1. The irregular heartbeat symbol
(if any) and blood pressure classification indicator will blink at the same time. If the monitor has no result
stored in the memory, the LCD will display ―0‖ for blood pressure and pulse rate. See picture 9-2.

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
9/15
Picture 9 Picture 9-1 Picture 9-2 Picture 9-3
d. Press ―MEM‖ button again to review the next result. See picture 9-3. In this way, repeatedly pressing the
―MEM‖ button displays the respective results measured previously.
e. If the voice function is on, the monitor will announce each result displaying on the screen.
f. When displaying the stored results, the monitor will turn off automatically after 2 minutes of no operation.
You can also press the button ―START‖ to turn off the monitor manually.
10. DELETING MEASUREMENTS FROM THE MEMORY
When any result is displaying, keep on pressing button ―MEM‖ for three seconds, all results in the memory
bank will be deleted after three ―beep‖. See picture 10 & picture 10-1. Press the button ―MEM‖ or ―START‖,
the monitor will turn off.
Picture 10 Picture 10-1
11. ASSESSING HIGH BLOOD PRESSURE FOR ADULTS
The following guideline for assessing high blood pressure (without regard to age or gender) has been
established by the World Health Organization (WHO). Please note that other factors (e.g. diabetes, obesity,
smoking, etc.) need to be taken into consideration. Consult with your physician for accurate assessment, and
never change your treatment by yourself.
Note: It is not intended to provide a basis of any
type of rush toward emergency
conditions/diagnosis based on the color scheme
and that the color scheme is meant only to
discriminate between the different levels of blood
pressure.

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
10/15
12. TECHNICAL ALARM DESCRIPTION
The monitor will show 'SYS HI','SYS Lo' ,'DIA HI' or 'DIA Lo' as technical alarm on LCD with no delay if the
determined blood pressure (systolic or diastolic) is outside the rated range specified in part SPECIFICACIONS.
In this case, you should consult a physician or check if your operation violated the instructions.
The technical alarm condition (outside the rated range) is preset in the factory and cannot be adjusted or
inactivated. This alarm condition is assigned as low priority according to IEC 60601-1-8.
The technical alarm is non-latching and need no reset. The signal displayed on LCD will disappear automatically
after about 8 seconds.
13.TROUBLESHOOTING (1)
PROBLEM
POSSIBLE CAUSE
SOLUTION
LCD Display
shows
abnormal result
The cuff position was not correct or it
was not properly tightened
Apply the cuff correctly and try again
Body posture was not correct during
testing
Review the ―BODY POSTURE DURING
MEASUREMENT‖ sections of the instructions and
re-test.
Speaking, arm or body movement,
angry, excited or nervous during testing
Re-test when calm and without speaking or moving
during the test
Irregular heartbeat (arrhythmia)
It is inappropriate for people with serious arrhythmia
to use this Electronic Sphygmomanometer.
14. TROUBLESHOOTING (2)
PROBLEM
POSSIBLE CAUSE
SOLUTION
LCD Display shows battery
symbol
Low Battery
Change the batteries
LCD Display shows
―EE‖
Arm or blood pressure monitor was
moved during testing
Re-test taking care to not move your arm or
the blood pressure monitor
The cuff does not inflate properly or
pressure falls quickly during testing
Make certain the plugs and brackets of the
cuff are securely attached to the monitor.
The cuff was not properly applied.
Apply the cuff correctly and try again
No response when you
press button or load battery.
Incorrect operation or strong
electromagnetic interference.
Take out batteries for five minutes, and then
reinstall all batteries.
In Clock Mode, no response
when you press button.
The touch switch is in OFF position.
Please keep touch switch in ON position,
and try again

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
11/15
MAINTENANCE
1. Do not drop this monitor or subject it to strong impact.
2. Avoid high temperature and solarization. Do not immerse the monitor in water as this will result in
damage to the monitor.
3. If this monitor is stored near freezing, allow it to acclimate to room temperature before use.
4. Do not attempt to disassemble this monitor.
5. If you do not use the monitor for a long time, please remove the batteries.
6. It is recommended the performance should be checked every 2 years or after repair. Please contact the
service center.
7. Clean the monitor with a dry, soft cloth or a soft cloth squeezed well after moistened with water, diluted
disinfectant alcohol, or diluted detergent.
8. No component can be maintained by user in the monitor. The circuit diagrams, component part lists,
descriptions, calibration instructions, or other information which will assist the user’s appropriately
qualified technical personnel to repair those parts of equipment which are designated repairably can be
supplied.
9. The monitor can maintain the safety and performance characteristics for a minimum of 10,000
measurements or three years, and the cuff integrity is maintained after 1,000 open–close cycles of the
closure.
10. It is recommended the cuff should be disinfected 2 times every week if needed (For example, in hospital
or in clinique). Wipe the inner side (the side contacts skin) of the cuff by a soft cloth squeezed after
moistened with Ethyl alcohol (75-90%), then dry the cuff by airing.
EXPLANATION OF SYMBOLS ON UNIT
Symbol for‖ THE OPERATION GUIDE MUST BE READ‖(The sign background colour: blue.The sign
graphical symbol: white)
Symbol for ―WARNING‖
Symbol for ―TYPE BF APPLIED PARTS‖ (The cuff is type BF applied part)
Symbol for ―ENVIRONMENT PROTECTION – Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with your local Authority or retailer for recycling
advice‖.
Symbol for ―MANUFACTURER‖
Symbol for ―COMPILES WITH MDD93/42/EEC REQUIREMENTS‖
Symbol for ―DATE OF MANUFACTURE‖

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
12/15
Symbol for ―EUROPEAN REPRESENTATION‖
SN Symbol for ―SERIAL NUMBER‖
Symbol for ―KEEP DRY‖
WARRANTY INFORMATION
Only charge the cost of components and transport.
SERVICE CENTER
ANDON HEALTH CO., LTD.
No. 3 Jinping Street, Ya An Road, Nankai District, Tianjin 300190, China.
Tel: [phone]
Lotus Global Co., Ltd.
15 Alexandra Road, London UK, NW8 0DP
Tel: [phone] Fax: [phone]
ELECTROMAGNETIC COMPATIBILITY INFORMATION
Table 1
For all ME EQUIPMENT and ME SYSTEMS
Guidance and manufacture’s declaration - electromagnetic emissions
The KD-7961N is intended for use in the electromagnetic environment specified below.
The customer or the user of the KD-7961N should assure that it is used in such an
environment.
Emissions test
Compliance
Electromagnetic environment -
guidance
RF emissions
CISPR 11
Group 1
The KD-7961N uses RF energy only for its
internal function. Therefore, its RF
emissions are very low and are not likely
to cause any interference in nearby
electronic equipment.
RF emissions
CISPR 11
Class B
The KD-7961N is suitable for use in all
establishments other than domestic and
those directly connected to the public
low-voltage power supply network that
supplies buildings used for domestic
Harmonic emissions
IEC 61000-3-2
Not applicable
Voltage fluctuations/
Not applicable

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
13/15
flicker emissions
IEC 61000-3-3
purposes.
Table 2
For all ME EQUIPMENT and ME SYSTEMS
Guidance and manufacturer’s declaration - electromagnetic immunity
The KD-7961N is intended for use in the electromagnetic environment specified below. The
customer or the user of the KD-7961N should assure that it is used in such an environment.
IMMUNITY test
IEC 60601test level
Compliance level
Electromagnetic
environment -
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floors should be
wood, concrete
or ceramic tile. If
floors are
covered with
synthetic
material, the
relative humidity
should be at least
30 %.
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m
3 A/m
Power frequency
magnetic fields
should be at
levels
characteristic of a
typical location in
a typical
commercial or
hospital
environment.
Table 3
For ME EQUIPMENT and ME SYSTEMS that are not LIFE-SUPPORTING
Guidance and manufacturer’s declaration - electromagnetic immunity
The KD-7961N is intended for use in the electromagnetic environment specified below. The
customer or the user of the KD-7961N should assure that it is used in such an environment.
IMMUNITY test
IEC 60601test level
Compliance
level
Electromagnetic environment
- guidance
Portable and mobile RF
communications equipment
should be used no closer to any
part of the KD-7961N, including
cables, than the recommended
separation distance calculated
from the equation applicable to

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
14/15
Radiated RF
IEC 61000-4-3
3 V/m 80 MHz to 2.5
GHz
3 V/m
the frequency of the transmitter.
Recommended separation
distance：
80 MHz to 800
MHz
800 MHz to 2,5
GHz
Where P is the maximum output
power rating of the transmitter
in watts (W) according to the
transmitter manufacturer and d
is the recommended separation
distance in meters (m).
Field strengths from fixed RF
transmitters, as determined by
an electromagnetic site survey,a
should be less than the
compliance level in each
frequency range.b
Interference may occur in the
vicinity of equipment
marked with the following
symbol:
NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and reflection from structures, objects and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless)
telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV
broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic
environment due to fixed RF transmitters, an electromagnetic site survey should be
considered. If the measured field strength in the location in which the KD-7961N is used
exceeds the applicable RF compliance level above, the KD-7961N should be observed to
verify normal operation. If abnormal performance is observed, additional measures may be
necessary, such as re-orienting or relocating the KD-7961N.
b Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
Table 4
For ME EQUIPMENT and ME SYSTEMS that are not LIFE-SUPPORTING
Recommended separation distances between
Pd 2.1
Pd 3.2

DN:KD-7961N-SMSY01 V3.0 Operation Guide
Template version:1
15/15
portable and mobile RF communications equipment and the KD-7961N
The KD-7961N is intended for use in an electromagnetic environment in which radiated RF
disturbances are controlled. The customer or the user of the KD-7961N can help prevent
electromagnetic interference by maintaining a minimum distance between portable and
mobile RF communications equipment (transmitters) and the KD-7961N as recommended
below, according to the maximum output power of the communications equipment.
Rated maximum
output
power of
transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz
80 MHz to 800 MHz
800 MHz to 2,5 GHz
0,01
0.12
0.12
0.23
0,1
0.38
0.38
0.73
1
1.2
1.2
2.3
10
3.8
3.8
7.3
100
12
12
23
For transmitters rated at a maximum output power not listed above, the recommended
separation distance d in meters (m) can be determined using the equation applicable to the
frequency of the transmitter, where P is the maximum output power rating of the transmitter
in watts (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range
applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and reflection from structures, objects and people.
Pd 2.1
Pd 2.1
Pd 3.2
